Durite 0-856-10 Manual

Modified wave 1000 watt voltage inverter
12 volt dc to 230 volt 50Hz ac
Read all instructions before attempting to install or use the inverter.
High voltage, 230 volts ac, is generated by this unit.
Do not use with wet hands or near water.
This unit is only suitable for 12 volt electrical systems with negative earth.
To supply 230 volt 50 Hz loads of <1000 watts.
Do not connect to any other ac power source.
Installation Instructions
1. Disconnect all battery leads, -ve leads first, before installing the inverter.
2. Locate a suitable position for the inverter and fit securely. The site chosen should be:
(a) Well ventilated.
(b) Not exposed to direct sunlight or heat source.
(c) Away from water or moisture.
(d) Out of reach of children.
(e) Away from any flammable or heat sensitive substance.
3. Connect the black 12 volt -ve terminal to the negative side of the supply source and the red 12 volt
+ve terminal to a fused positive supply source. Use a minimum of 16.0mm
runs as short as possible.
4. Connect the inverter case ground terminal to the chassis ground when installing in a vehicle, the
vessel's grounding system in a boat or to earth in a fixed location. The case ground terminal is
connected to the ground terminal in the ac outlet socket.
5. If using the optional remote control (part 0-856-98), fix the remote control in a suitable position and
insert the connector into the remote control socket on the inverter control panel.
Operating Instructions
1. Ensure that the inverter is supplied by a 12-14 volt dc negative earth system and that the load
requires <1000 watts at 230 volt 50Hz ac.
2. Plug the appliance into the inverter and then turn on the inverter's power switch. The LED will
illuminate to indicate ac power is present, then switch on the appliance. Always turn on the inverter
before turning on loads individually. If using the optional remote control, ensure the control panel
power switch is set to 'Remote' then use the remote 'On/Off' switch as the inverter power switch.
3. Switch off the inverter when not in use or when heavy current is drawn from the dc supply, e.g. when
starting an engine from the same supply source.
4. Battery voltage and current bar graphs indicate supply voltage and current. In normal operation the
inverter will operate in the green region. The inverter can operate for short periods in the current
yellow zone and protective shutdown will occur if used in the red zone.
Gordon Equipments Limited
Part 0-856-10
Warnings
2 cable and keep all cable
Read all instructions before attempting to install or use the inverter.
This unit is only suitable for 12 volt electrical systems with negative earth.
1. Disconnect all battery leads, -ve leads first, before installing the inverter.
2. Locate a suitable position for the inverter and fit securely. The site chosen should be:
(a) Well ventilated.
(b) Not exposed to direct sunlight or heat source.
(c) Away from water or moisture.
(d) Out of reach of children.
(e) Away from any flammable or heat sensitive substance.
3. Connect the black 12 volt -ve terminal to the negative side of the supply source and the red 12 volt
+ve terminal to a fused positive supply source. Use a minimum of 16.0mm
runs as short as possible.
4. Connect the inverter case ground terminal to the chassis ground when installing in a vehicle, the
vessel's grounding system in a boat or to earth in a fixed location. The case ground terminal is
connected to the ground terminal in the ac outlet socket.
5. If using the optional remote control (part 0-856-98), fix the remote control in a suitable position and
insert the connector into the remote control socket on the inverter control panel.
1. Ensure that the inverter is supplied by a 12-14 volt dc negative earth system and that the load
requires <1000 watts at 230 volt 50Hz ac.
2. Plug the appliance into the inverter and then turn on the inverter's power switch. The LED will
illuminate to indicate ac power is present, then switch on the appliance. Always turn on the inverter
before turning on loads individually. If using the optional remote control, ensure the control panel
power switch is set to 'Remote' then use the remote 'On/Off' switch as the inverter power switch.
3. Switch off the inverter when not in use or when heavy current is drawn from the dc supply, e.g. when
starting an engine from the same supply source.
4. Battery voltage and current bar graphs indicate supply voltage and current. In normal operation the
inverter will operate in the green region. The inverter can operate for short periods in the current
yellow zone and protective shutdown will occur if used in the red zone.
0-856-10LEAF1
Modified wave 1000 watt voltage inverter
12 volt dc to 230 volt 50Hz ac
Part 0-856-10
Warnings
High voltage, 230 volts ac, is generated by this unit.
Do not use with wet hands or near water.
To supply 230 volt 50 Hz loads of <1000 watts.
Do not connect to any other ac power source.
Installation Instructions
Operating Instructions
Gordon Equipments Limited
2 cable and keep all cable
0-856-10LEAF1
