THANK YOU FOR CHOOSING IDS TO PROTECT YOU
Thank you for purchasing an IDS SmartCharger. The IDS SmartCharger is designed
to fast charge Sealed Lead Acid(SLA), Gel and LiFePo batteries on any retro fit or
new system. (Product codes: 862-20-065; 862-20-GEL8; 862-20-069)
This Installer manual covers all installation topics.
Note: Please read the entire installer manual before attempting the installation!
Features
1.
Easy retro fit installation
2.
Low battery cut-out to protect battery from over discharge
3.
Fast charging of various battery chemistries
4.
Intelligent battery monitoring
Diagram
Battery Leads
Battery Connectors
Battery Type LEDs
IDS SmartCharger
!
The correct battery type must be selected.
700-704-01A IDS SmartCharger
Programming Button
24VDC Input
DC Output
Advertisement
Summary of Contents for IDS SmartCharger
- Page 1 IDS SmartCharger THANK YOU FOR CHOOSING IDS TO PROTECT YOU Thank you for purchasing an IDS SmartCharger. The IDS SmartCharger is designed to fast charge Sealed Lead Acid(SLA), Gel and LiFePo batteries on any retro fit or new system. (Product codes: 862-20-065; 862-20-GEL8; 862-20-069) This Installer manual covers all installation topics.
- Page 2 Installation Programming Battery Type The default mode of the SmartCharger is set for an SLA battery. To select a different battery type: 1. Press and hold the PROGRAM button until all three LEDs light up 2. Press the PROGRAM button until the battery type you require lights up. Wait for 10 seconds with the button released for the charger to accept the selection.
