Summary of Contents for MasterKraft MCTMSP01
- Page 1 Curved Treadmill Pro Assembly Instructions MCTMSP01...
- Page 2 MCTMSP01 A-x1 C-x1 B-x1 F-x1 G-x1 H-x1 D-x1 E-x1...
- Page 3 MCTMSP01 6-M10x90lL AA 6-M8x12L 6-M5x16L 6-018x010.5X1.5t 2-M5x16L 6-M5x12L 2-M5x25L 2-M5x30L...
- Page 4 MCTMSP01 Unpack the treadmill base and parts and ensure that all listed parts are included in the packaging. Place the treadmill base facing forward (logo will be at the rear of the base).
- Page 5 MCTMSP01 With the treadmill base facing forward, attach the FRONT left upright handle (A) to the left side of the base with 3 screws (AA) and 3 washers (BB), using the included 8mm allen wrench (II) 8MM II AA x3...
- Page 6 MCTMSP01 On the right side of the base, connect wire FW to wire BW and repeat the previous step to attach the right upright handle (B) to the right side of the base. FRONT...
- Page 7 MCTMSP01 FRONT 5MM JJ GG x6 At the top of the right upright handle, connect wire BW to wire CW. Attach the rail (C) to parts A and B with 6 screws (GG), using the included 5mm allen wrench (JJ).
- Page 8 MCTMSP01 Attach the cup holder (D) to the left upright handle with 2 screws (CC) using the included 3mm allen wrench (LL). At the centre of the rail, connect wire CW to wire EW. Attach the console (E) to the centre of the rail (C) with 4 screws (DD) using the 3mm allen wrench.
- Page 9 MCTMSP01 Attach the left upright handle cover (G) to the left upright handle with 1 screw (HH) at the top right corner of the cover, 1 screw (EE) at the left corner, and 1 screw (FF) at the bottom of the cover, using the included 4mm allen wrench (KK).
