Page 1 STATUS 2.0 Web-based SNMP Card for UPS User’s Manual...
Page 2: Table Of Contents
Contents Chapter 1 Introduction ________________________________________________ 4 Introduction _______________________________________________________ 4 Features __________________________________________________________ 4 Function __________________________________________________________ 5 Chapter 2 Installation Requirement _____________________________________ 5 Chapter 3 Appearance and Installation __________________________________ 6 3.1 Appearance __________________________________________________________ 6 3.2 Components ___________________________________________________________ Chapter 5 Web Configuration _________________________________________ 10 5.1 Login Web browser ___________________________________________________ 10 5.2 Web Operation Introduction _____________________________________________ 5.2.1.3 Device Basic Information ______________________________________________ 12...
Page 3 6.4 Forget the login password, how to do? ___________________________________ 38 6.5 Cannot connect with the device, how to do? ______________________________ 38 Chapter 7 Notice Items _______________________________________________ 38...
Page 4: Chapter 1 Introduction
Chapter 1 Introduction Introduction STATUS 2.0 UPS network monitor adapter card is a new standard UPS network centralized monitoring products with delicate design. The function includes Email and SMS warning, task schedule, history event and history data record, etc. Its graphical...
Page 5: Function
Function  Remote monitoring for UPS through network;  User interface based on Web;  Compatible with multi-brand and multi-type of UPS;  Support SMS alarm;  Support Email alarm;  Multi-user authority management;  Support DHCP;  Support remote self-test, shutdown and restart UPS function (Required UPS support);...
Page 6: Chapter 3 Appearance And Installation
Chapter 3 Appearance and Installation 3.1 Appearance External Internal...
Page 7: Installation
 LAN: Interface of UTP 10/100M RJ45 Ethernet. 3.2 Installation Internal: insert the STATUS 2.0 internal card to the slot of UPS, and connect the STATUS 2.0 to running network environment via Ethernet port. External: connect the STATUS 2.0 adapter to running network environment via Ethernet port;...
Page 8: Web Operation Introduction
Setting] menu item to set all the configuration items (the setting operation will be introduced in chapter 6). Then the UPS status could be correctly displayed by other pages. Enter STATUS 2.0 UPS Web Page，there are 5 main function items in the first Web page：  Status Inquiry ...
Page 9: Status Inquiry
This part is to display STATUS 2.0 basic information. Values in system name/system administrator/system installation position/hardware version/software version product serial number are provided by STATUS 2.0 itself, other values come from user’s settings in [Parameter Settings] page A， System Name This part will display the information automatically when users have finished the settings in [SNMP Settings] page.
Page 10 F， Other information is provided by STATUS 2.0 system itself. 2. Network Information This part is to display STATUS 2.0 network information. The MAC address is provided by Netmate II. All other values in this section come from your settings in [Parameter Settings] page.
Page 11 This part will display the information automatically when users have finished the settings in [Warning Settings] page. I, MAC Address The information is provided by STATUS 2.0 system automatically. 5.2.1.2 Bus Device Information This page is to display the signal collects card analog data status and environment status, which can be realized via connecting with relevant modules such as signal collects module, temperature and humidity module, etc.
Page 12: Device Basic Information
parameters in [System Settings] page. 5.2.1.3 Device Basic Information This part is to display basic information of each part of the device (UPS basic information, Battery Information, Rating Information and Warning Definition Information. The contents will change according to users’ settings and UPS real situation. 1.
Page 13 Display battery used time, the information will be provided by STATUS 2.0 automatically. 3. Rating Information Values here are all provided by the UPS automatically. 4. Warning Definition Information This part will display the information automatically when users have finished the settings in [System Settings] page.
Page 14: Current Run Status
Display the temperature upper limit values. This part will display the information automatically when users have finished the settings in [System Settings] page. G, Battery Low Electric Level Display the battery low electric level values. This part will display the information automatically when users have finished the settings in [System Settings] page.
Page 15: Parameter Setting
Three- phase UPS Running Page Basic information The current values about Input Voltage/Input frequency/Battery Voltage/Battery Content/UPS Temperature/Environment Temperature/ Environment Humidity/Output Voltage/Output Max Voltage/Output Min Voltage/ Current Load are displayed here. Current Running Status current running status about connection/AC/Switch/UPS/Working /Battery/Testing/Beep is displayed here. 5.2.2 Parameter Settings Sub-Menu: ...
Page 16 2. Warning Definition Settings A, Inquiry Time Set the inquiry time interval whether UPS is offline. B, Offline Times Set the inquiry times whether UPS is offline. If UPS status is offline all the time during the set inquiry times, the system will judge the UPS is offline and send UPS offline warning. C, Input Voltage Upper limit Set current voltage upper limit, if the UPS input voltage exceeds the upper limit value, the system will send the input voltage abnormal warning.
Page 17 This part is to set up the Upper and Lower limit of temperature and humidity, it can also set up the tolerance numerical value of temperature and humidity. STATUS 2.0 will send warning messages when the temperature and humidity of UPS exceeds the limit. (This part needs to connect the...
Page 18 temperature and humidity module) A, Alarm description Set alarm description, it is convenient for users to distinguish the alarm position. B, Temperature Alarm Upper Limit Set current temperature alarm upper limit, if the UPS temperature exceeds the upper limit value, the system will send UPS high temperature warning.
Page 19 6. Load Device List This part can list the server’s name and IP; it is convenient for user to manage. 5.2.2.2 485 Bus Device Settings This page is to set up the signal collect card relevant parameters. It needs to connect signal collect module and enable the bus collect card in [system settings] page, which support 4 channels dry contact signal input and 2 channels output control.
Page 20: Network Settings
When we choose Manual Setting, we can revise it. B, Other Items The MAC address is provided by STATUS 2.0, we can not reset it. Users can set the IP address, Subnet Mark, gateway freely according to our real situation, but the IP address should not be conflicted with other IP.
Page 21 Choose whether enable TELNET, that is to say, users can choose whether allow users to remote login Netmate II Web Server via TELNET. After choosing Enable TELNET, users still need to set the needed port number via TELNET remote login STATUS 2.0 Web Server. D, Enable HTTP Choose whether enable HTTP, that is to say, users can choose whether allow users to login Netmate II Web Server via Web browser.
Page 22 A, System Name Name the STATUS 2.0. B, System Administrator Set the administrator of the STATUS 2.0. C, System Installation Position Set STATUS 2.0 installation location. [The basic settings is convenient for centralized monitoring and management, when we use many devices.
Page 23: Warning Settings
3. Trap Settings Receiver IP Address is used to receive traps sent by STATUS 2.0. Users can set 4 Trap receivers IP address at most. Users can also choose whether receive the traps. 5.2.2.5 Warning Settings This page is to set the relevant configuration by Email and Mobile SMS alarm. It includes Email setting, Receiver Setting, Mobile Information Configuration and Mobile Receiver Setting.
Page 24 Email need to receive. Users can also choose whether send warning and log. 3. Mobile Information Configuration This part is to show the interface of another product ——MobileMate， with the following function which STATUS 2.0 does not include.
Page 25 STATUS 2.0 does not include. Send warning or log via Local GSM Modem This part is to set Mobile number to receive warning short message sent by STATUS 2.0 when an event occurs. Users can set 6 mobile numbers at most.
Page 26 5.2.2.6 User Settings This page is to set the user information which is used to login STATUS 2.0 via using Web or Telnet and manage STATUS 2.0 user information via using IP Power software. 1. Web/Telnet User Settings This part is to set Web/Telnet user authorization, the users which have the authorization can access,...
Page 27: System Time Setting
IP Power software. Authorization item includes Manage and Access. 5.2.2.7 System Time Settings This page is to update the current system time of STATUS 2.0，we provide two kinds of update ways, Manual Reset and Auto Reset. 1. System Current Time Display current system time of STATUS 2.0, it is provided by STATUS 2.0 automatically, and will...
Page 28: Remote Control
Set current primary time server IP address of STATUS 2.0. Secondary Time server Set current secondary time server IP address of STATUS 2.0, when the primary time server cannot work normally, the system will choose secondary time server to proofreading time automatically. C, Auto Refresh Time Interval Set auto refresh time interval of current STATUS 2.0 system time.
Page 29 5.2.3.2 Task Scheduler This part is to display our task scheduler, including the carry out time, dictate item, and carry out frequency, task parameter and operation. Click the “Add” button, the system will pop out the following box. Users can set the target project, which includes UPS self-test, switch off and dormancy item.
Page 30: History Record
Set UPS timing switch off automatically, after fixed time the UPS will be restarted automatically. 2. Task Attribute Execute Frequency Used for setting order execute frequency of timing control task. Execute Time Used for setting order execute starting time of timing control task. 5.2.3.3 Extend Output Control This part needs to connect signal collecting module to show.
Page 31: System Help
5.2.4.1 History Event Record This page is to display record of all events. Record includes the Date/Time of the event and the event description. 5.2.4.2 History Data Maintenance This part is to set Everyday Time for Sending Log Mail and record history data time interval.
Page 32: Chapter 6 Common Problem Solutions
6.1 Forget the IP address, how to do? If forgot the IP address of STATUS 2.0, user can connect the one end of configuration cable to the serial port of the computer and connect the other end to the RS232 connecting cable, and then connect to the RS232 port of the STATUS 2.0.
Page 33 1. Restart the device; 2. Check whether the IP is conflicted with other IP; If user still cannot open the webpage, please cut off the STATUS 2.0, click Open Menu→ Running→ Input “cmd” →click the “Enter” key，enter the doc order interface, then input ***.***.
Page 34 “Enter” key, then the Hyper Terminal will display the “Password:” input the relevant password, the default password is admin. At last click the “Enter” key, the Hyper Terminal will display the main configuration menu of STATUS 2.0, the page is as follows:...
Page 35 8) Input 7 after the “please enter your choice:” user will enter the system function configuration menu of STATUS 2.0; user can check and modify the function configuration. The page is as follows: Http Enable status Http port number（default is 80）...
Page 36 10) If the HTTP default port has been modified, user can modify it via inputting 6 after “Please enter your choice:” operation is as follows: 11) Input 0 after “Please enter your choice:” after finishing the modification, exit Net configuration, and enter the main configuration menu. The operation is as follows:...
Page 37 12) Inputting 0 after “Please enter your choice:”, and the Hyper Terminal will display 3 ways to save and reboot for STATUS 2.0, user can choose one way according to own real situation, the operation is as follows:...
Page 38: What Is The Login User Name And Password
6.3 What is the login user name and password? When login the STATUS 2.0 at first time via IE browser, user name is admin and password is also admin. But if login the webpage, user can set other user name, so other setting users can also login the webpage.
