- Page 1 INSTRUCTION MANUAL UnRoll 500 Submerged slatted cover Walter Pool 2 rue de l'industrie - 67490 DETTWILLER Tel. +33 3 90 29 51 00 info@walter-pool.com...
-
Page 2: Table Of Contents
Table of contents Standards Foreword Required tools UnRoll 500 variants Acceptance of the automatic safety cover Package content Pit width STEP 1 – Flanges and shaft installation Case 1 – Flange with wall mounting Case 2 - Flange with under-coping mounting... - Page 3 4.13 Automatic mode usage 4.14 Speed ramp programming 4.15 Anti-tear STEP 5 – Setting up the safety loops Generalities Locking 5.2.1 Traditional locking 5.2.2 Stainless steel lock under coping (optional) Number and position of safety hooks STEP 6 – Grating Installation Wooden Grating Aluminium grating STEP 7 –...
-
Page 4: Standards
Duration of the assembly : 4hours Required tools Spirit level Allen key set Percussion Flat spanner Mallet Pencil Tape drill ⌀ Socket set Ratchet Cutter Strap Masonry drill 8/10 Electric Screwdriver wrench screwdriver UnRoll 500 variants Masonry partition wall Partition wall... -
Page 5: Acceptance Of The Automatic Safety Cover
Acceptance of the automatic safety cover The WALTER company cannot be held responsible for any loss or damage to equipment transported by the carrier. It is specified that the goods travel at the recipient's risk. In the case of missing or defective parts, it is important: Note any reservations and observations on the transport note. -
Page 6: Step 1 - Flanges And Shaft Installation
STEP 1 – Flanges and shaft installation Depending on the motorization, you will have in the package: Case 1 : Case 2 : Motor side, wide flange Opposite side of the motor, Motor side and opposite side, identical narrow flange flange, only the cable protection trough indicates the motor side On the flange on the side opposite the motor, secure the shaft with the screw and the locknut, and insert... -
Page 7: Case 1 - Flange With Wall Mounting
Case 1 – Flange with wall mounting Center the flanges in the pit. Both flanges must be level with each other while respecting the minimum distances described in the diagram below. The drill holes must be made above the water level. The flanges must be installed so that the winding shaft is perfectly perpendicular to the pool wall and level. -
Page 8: Case 2 - Flange With Under-Coping Mounting
For the motor side, place the two small washers for the central screws. Case 2 - Flange with under-coping mounting Center the flanges in the pit while respecting the minimum distances described in the diagram below. Both flanges must be level with each other. Also, ensure that the flange is flush against the pool edge without leaving any gaps. -
Page 9: Installation Of The Winding Shaft
Spacer washer (if necessary) ✓ Soft protection Installation of the winding shaft Check the presence of the shaft/slat connection straps on the winding shaft. Use a strap to lower the shaft into the pit by inserting the shaft already on the flange opposite the motor side into the winding shaft. - Page 10 Opposite side of the motor...
-
Page 11: Step 2 - Installation Of The Beam And/Or Partition Wall
STEP 2 - Installation of the beam and/or partition wall Case 1 - Fixing the beam support to the wall Place the two supports under the coping, ensuring they are level with the resting area at the end of the pool. -
Page 12: Case 3 - Fixing The Partition Wall And Beam Support Under The Coping
Pool side Pit side Case 3 - Fixing the partition wall and beam support under the coping Measure the depth of your pit to adjust, if necessary, the length of the bracket and the rail. 150mm 150mm Be careful, the brackets have a specific orientation (right and left). The screw that is not aligned with the others is on the pit side. - Page 13 Adjust the length of the rails by cutting them to the correct size. Screw the bottom rail end cap into the rail, then secure the rails on both sides using washers and locknuts. Insert the panels of the wall into the rails by sliding them in. Clip the top rail cover and the top cover for the partition wall.
-
Page 14: Step 3 - Installation Of The Slatted Cover
STEP 3 - Installation of the slatted cover Slats orientation The top of the slat is slightly curved, while the bottom is flat. The open side of the slat is oriented towards the end of the pool, and the male part is oriented towards the axis. Finishing trim With the movement of the water, in some cases, the first slat may damage the wall on the opposite side of the mechanism. -
Page 15: Slats Number
Assembly method by clipping: Insert the locking trim along the length of the first slat. Condensation may appear inside the transparent and solar PVC slats, such as Polycarbonate; this is a normal phenomenon. Slats number Depending on the length of your pool, a certain number of slats is determined. We systematically deliver additional slats to account for potential damage during transport or installation. -
Page 17: Special Cases
Special cases Stairs If there is a presence of a staircase, you must lock the slats with the locking profile. Cut a piece of the locking profile to the desired length and then insert it into the groove of the previous slat. -
Page 18: Cover Diagram
Next, pull the right slat upwards to release the lower part of the tab. Finally, with an up-and-down motion of the slats, you will be able to release the slat. Be cautious, as using a flat object to lift the tab may seem tempting, but the risk of damaging the slats is very high. -
Page 19: Interchangeables Wings
Interchangeables wings If necessary, the wings can be removed or added to adapt to the pool. A space between the edge of the pool and the slats of 30mm minimum and 70mm maximum (combined from both widths) must be maintained. If this is not the case, it is possible to remove the standard fin to reduce by 7.5 or 0.2mm per side, or add accessory wings to gain 7.5 or 5mm per side. -
Page 20: Step - Motorisation
STEP – Motorisation Installation of th electrical box Refer to standard NF C15-100 section 702 for the placement of the electrical box. CAUTION! Always disconnect the power supply when wiring the electrical box or the motor to avoid the risk of irreversible damage. The electrical box must be installed in a frost-free technical room, sheltered from rain, sunlight, any heat sources, and any risk of splashing or immersion. - Page 21 • Motor on the Right Technical room Pool Watertight box Refer to the section table (Not provided) • Motor on the Left Technical room Pool Watertight box Refer to the section table (Not provided) Cable section table (not provided): Motor/control box 2m<L<=20m 20m<L<= 30m 30m<L<= 50m...
-
Page 22: Electrolyzer Or Pump (Optional)
Electrolyzer or pump (Optional) - If the water treatment device has an input to indicate the state of the pool (closed or open), it is possible to connect a contact from the electrolyzer terminal block. This connection will be made using two wires: one will be the common wire for the treatment device, and the other will be the signal wire. -
Page 23: Pairing Of The Remote Switch
4.4.1 Pairing of the remote switch Hold for 2 seconds Press the switch button once. Press the "PROG/RES" button for at least 2 seconds, until you hear a beep. A double beep confirms the success A beep confirms the press, wait for of the operation. -
Page 24: End-Of-Travel Programming
LANGUAGE End-of-travel programming ENGLISH During the first use, select the language and then confirm. In the settings menu, then in basic settings, select the motor type "120/200/300" and the sensor type "COVEO 4 wires," then confirm. BASIC SETTINGS BASIC SETTINGS MENU SETTINGS TYPE OF CAPTOR... -
Page 25: Connection Of Motor Type 2
Connection of motor type 2 Connect the cables to the quick connectors as shown in the diagram below: If you are using a dry contact, for example, for an electrolyzer, please refer to point 4.8. The motor connects to a waterproof box at the pool outlet. It is essential to install the key switch in a location that allows continuous visibility of the pool during operations. -
Page 26: Remote Control Module Connection (Optional)
Remote control module connection (Optional) In case of using the remote switch, you must wire the remote switch box as indicated in the following diagram: Use a 5-wire cable between the remote control terminals of the electrical box and the terminals of the remote switch box. -
Page 27: 4.10 Bluetooth Control
4.10 Bluetooth control (See the user manual for Bluetooth usage) The Bluetooth box connects to the remote control terminal block of the box. It should be mounted near the emission location (smartphone) with a view of the pool. Bluetooth 4.11 Forced mode To be used only by qualified personnel Direction verification: 1. -
Page 28: 4.13 Automatic Mode Usage
4.13 Automatic mode usage This mode allows for the normal operation of opening and closing the cover, with automatic stopping at the end-of-travel positions. Switch 1 (“OP H/P”) must be set to ON (to the right) to activate the impulsive opening of the cover Ensure that switch 2 (“CL H/P”) is set to OFF (to the left) to activate the manual closing of the cover... -
Page 29: Step 5 - Setting Up The Safety Loops
STEP 5 – Setting up the safety loops To enhance the safety of your cover, place safety hooks at the end of the apron. These hooks are mandatory in France to comply with the NF P 90-308 standard. When the cover closes the pool, the apron is locked. LOCKED COVER = SAFETY The number and position of the fixings are determined by the standards. -
Page 30: Stainless Steel Lock Under Coping (Optional)
5.2.2 Stainless steel lock under coping (optional) Determine the position of the safety anchors according to the table below (5.3) ● If you do not wish to use an under coping bracket Mark the position of the holes to drill the fixing points for the safety clamp. Drill and inject silicone before inserting the plugs. -
Page 31: Step 6 - Grating Installation
Régler la longueur des sangles de sécurité une fois l’installation effectuée. STEP 6 – Grating Installation If the grating is not supplied by Walter, we disclaim any responsibility for the compliance of the system. Wooden Grating The grating is delivered in sections, with the last sections adjusted to fit the width. These cut sections should be placed at the ends. -
Page 32: Aluminium Grating
Aluminium grating The aluminum gratings are pre-adjusted in depth; however, the final sections will need to be adjusted in width by you to fit your pool. STEP 7 – Service and Troubleshooting Troubleshooting assistance is available on the website www.waluroll.com under the "Technical Space"... - Page 33 If this is the case, the internal sensor of the motor is broken and needs to be repaired by WALTER. Until the replacement intervention, the cover can be used with caution in forçage mode. The motor does not start, One of the fuses has blown;...
-
Page 34: Complete Reset Of The Electronic Board
When activating a function To fully activate advanced optional functions such as the safety with the appropriate dip loop or the pulse mode at opening, the board must always be switch, nothing happens. reset by turning it off and then turning it back on. The motor stops suddenly. -
Page 35: User Manual
User manual The person performing the operation must ensure there are no swimmers in the pool and always keep the pool in view during the opening or closing procedures. It is essential to fully open or close the cover, never leaving it in an intermediate position. Always verify that the water level in the pool remains constant and in accordance with the manufacturer's recommendations. -
Page 36: Use The Remote Switch (Option)
Use the remote switch (Option) Child safety Please place the remote switch out of the reach of children. Hold for 5 sec Press both buttons simultaneously for at least 5 Press once on the central button. The board will seconds. The electronic board will then emit an then emit a double audible signal. -
Page 37: Use The Bluetooth (Option)
Attach the safety straps (ensure that the water level allows the cover to be securely locked). Use the Bluetooth (Option) Pairing a new phone Download the Roll'Connect app directly from the Play Store or the App Store. To use the Roll'Connect app, Bluetooth must be enabled on the phone. Enter the password. -
Page 38: Using The Bluetooth App
STOP button. Maintenance of the cover Maintenance is the responsibility of the customer. Walter covers require very little maintenance. In fact, simply cleaning the slats twice a year (in spring and autumn) will ensure their longevity. You can use a regular sponge (non-abrasive side) with soapy water and clean the slats as they unroll from the grid. -
Page 39: Influence Of Water Quality On Plastic Parts, Especially The Slats
Influence of water quality on plastic parts, especially the slats: • The PVC and PC used by Walter are of superior quality. However, excessive chlorine or other pool chemicals will shorten the lifespan of the slats. • All slats, except white, sand, and light gray PVC, should be protected from direct sun exposure when not in contact with water. -
Page 40: Winterization
Winterization Active Winterization: ● In case of freezing, never attempt to operate your cover. ● For winterizing your pool, there is a winter cover screen for the cover: SLAT PROTECT PREMIUM. SLAT PROTECT PREMIUM is the perfect complement for an above-ground or submerged roller cover. The protective cover is made to the interior dimensions of the pool and is secured directly to the cover with small Sandow clips. -
Page 41: Warranty Conditions
The warranty is granted when the normal conditions of installation, use, winterizing, and maintenance are respected. WALTER ensures the replacement of defective parts during the warranty period, starting from the commissioning date. The installation and repairs of the automatic cover must be carried out by a... -
Page 42: Warranty Duration
> Deformation of polycarbonate blades due to lack of contact with the water surface > Damage caused by hail, storms, or lightning > Modifications made to a WALTER cover without our consent > Labor costs for disassembly and reassembly > Compensation fees and any penalty claims >... -
Page 43: Troubleshooting
Troubleshooting In case of any issues while using your cover, please contact your installer. Installed by: Customer reference : Date :... - Page 44 E-Mail mit Bildern des Problems an service@walter-pool.com schicken. Any problems? If you encounter problems when you are installing the mobile deck, you can always send an e-mail with photos about the problem to service@walter-pool.com Walter Pool 2 rue de l’industrie 67490 DETTWILLER Tel.
