Wilder Technologies SFP-DD User Manual

Test adapter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SFP-DD Test Adapter User Manual
SFP-DD
Test Adapter
User Manual
P a g e
| 1
©2022-2025 Wilder Technologies, LLC
Document No. 910-0072-000 Rev. D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SFP-DD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wilder Technologies SFP-DD

Summary of Contents for Wilder Technologies SFP-DD

  • Page 1 SFP-DD Test Adapter User Manual SFP-DD Test Adapter User Manual P a g e ©2022-2025 Wilder Technologies, LLC Document No. 910-0072-000 Rev. D...

  • Page 2: Table Of Contents

    Cooling Module (Optional Accessory) ..................... 7 Thermal Data for SFPDD-TPAxxx-MCB-R ..................7 Product Inspection ........................10 The SFP-DD Test Adapter Care and Handling Precautions ............11 General Test Adapter, Cable, and Connector ................13 Handling and Storage ........................ 13 Visual Inspection ........................13 Cleaning .............................

  • Page 3: Introduction

    HCB-P and SFPDD-TPA-MCB-R), and Low Speed HCB Plug Switch Module assembly. The two test adapter types, shown in Figures 1 and 2, test SFP-DD interface cables, hosts, and modules to the requirements of the SFP-DD MSA, SFP-DD MIS and EEE 802.3ck standards.

  • Page 4: Sfpdd-Tpaxxx-Hcb-P

    SFP-DD Test Adapter User Manual SFPDD-TPAxxx-HCB-P The SFP-DD Host Compliance Test Adapter can be used for testing the compliance of SFP-DD Host Devices to SFP-DD MSA and SFP-DD MIS specifications. 8x 2.92mm, 2.4mm or 1.85mm Connectors for High-Speed Testing SFP-DD Switch...

  • Page 5: Sfpdd-Tpaxxx-Mcb-R

    60W, 12Vdc, 5A, 2.5 x 5.5 x 11mm Output Connector Figure 2. The SFP-DD MCB Test Adapter and its Included cabling (Note: The coaxial cables are configuration dependent and may be terminated with different connectors than what is shown). P a g e ©2022-2025 Wilder Technologies, LLC...
  • Page 6 2.92mm 0 - 40GHz 1.2:1 Pasternack Part Number PE6TR1106 NOTE: The metal shell of both the plug (SFP-DD HCB) and receptacle (SFP-DD MCB) connector housing or cage tie high-speed ground to chassis ground. P a g e ©2022-2025 Wilder Technologies, LLC...

  • Page 7: Cooling Module (Optional Accessory)

    (DUT) connector’s heat sink and subsequently keep the device module case temperature within recommended ranges (per SFP-DD MSA). The Cooling Module may be required when testing SFP-DD and there is a need to reduce case temperatures lower. The recommended maximum case temperature is 70°C.

  • Page 8: Thermal Data For Sfpdd-Tpaxxx-Mcb-R

    Figure 4. SFP-DD MCB with DUT Temperature locations, Cooling Module not shown The SFP-DD is designed using the standard high-level finned cage. Table 1 lists the SFP-DD module power classes and their effects on case temperatures and MCB heatsink temperatures.
  • Page 9 Based on measurements conducted by Wilder Technologies, the Cooling Module is an optional recommendation for use on the SFP-DD MCB (Receptacle) when testing modules of Power Class 6 or greater (not yet defined by specification). At these power classes, the case temperatures and heatsink temperatures of the SFP-DD MCB may exceed recommended limits (Per MSA and ASTM standards).

  • Page 10: Product Inspection

    SFP-DD Test Adapter User Manual Product Inspection Upon receiving the SFP-DD test adapters from Wilder Technologies, perform the following product inspection: • Inspect the outer shipping container, foam-lined instrument case, and product for damage. Retain the outer cardboard shipping container until the contents of the shipment have been inspected for completeness and the product has been checked mechanically and electrically.

  • Page 11: The Sfp-Dd Test Adapter Care And Handling Precautions

    If the SFP-DD TPA must be turned or twisted to make connection to the DUT, avoid using the SFP-DD TPA housing alone to make this occur. Try to distribute the torque forces along the length of the test setup and cabling.
  • Page 12 2. Insert the mating High-Speed connector barrel and hand-tighten the free-spinning nut onto the connector while avoiding pulling, bending, or twisting the SFP-DD TPA coaxial cable. The SFP-DD TPA High-Speed connectors have flats that accept an open-end 1/4-inch or 5/16-inch wrench, depending on configuration.

  • Page 13: General Test Adapter, Cable, And Connector

    Observing simple precautions can ensure accurate and reliable measurements. Handling and Storage Before each use of the SFP-DD TPA, ensure that all connectors are clean. Handle all cables carefully and store the SFP-DD TPA in the foam-lined instrument case when not in use, if possible.

  • Page 14: Electrostatic Discharge Information

    Electrostatic Discharge Information Protection against electrostatic discharge (ESD) is essential while connecting, inspecting, or cleaning the SFP-DD test adapter and connectors attached to a static-sensitive circuit (such as those found in test sets). Electrostatic discharge can damage or destroy electronic components. Be sure to perform all work on electronic assemblies at a static-safe workstation, using two types of ESD protection: •...

  • Page 15: User Model

    An RX signal, inputted from a connected Signal Generator, is transferred through the HCB’s RX lines into the SFP-DD host under test. The Host responds by outputting TX signals which are transferred through the HCB, out through its TX lines into a connected Oscilloscope for measurement.

  • Page 16: Sfpdd-Tpaxxx-Mcb-R Is Used To Test An Sfp-Dd Module

    *DC blocks are accessories and are not supplied with the product Figure 6. SFP-DD MCB User Model In this configuration, the SFP-DD MCB is used to test an SFP-DD Module. The MCB must be powered by provided 12VDC source. The MCB receives input signals from a signal generator connected to its TX lines (indicated by TX IN).

  • Page 17: Power Indicator

    Figure 7. Closeup of SFP-DD I/O’s and External Functions Banana plugs delivered to the Module Source Switch allows a user to select which power input supplies the 3.3V SFP-DD EXT PWR module VCC pins. With the switch in the position the module will take power from the External 3.3V Power...
  • Page 18 Two Wire Interface. To access this information, use the Wilder Technologies CMIS GUI software. Installation and instructions are in the CMIS GUI user manual (970-0070-000). This manual is supplied with USB Flash Drive supplied with the SFP-DD MCB product.

  • Page 19: Calibration Through De-Embedding

    Calibration Through De-Embedding The SFP-DD Test Adapters are fully passive components. Therefore, calibration compensating for the losses must occur within the test instrumentation that drives the SFP-DD Receivers or looks at the response of the SFP-DD Transmitters. The SFP-DD TPA’s have Touchstone S4P files for de-embedding the electrical length and losses within the TPA up to the SFP-DD connector interface pads.

  • Page 20: Mechanical And Environmental Specifications

    -40°C to +70°C (-40°F to +158°F) (Characteristic) SFPDD-TPAxxx-HCB-P Cable Pin-out The SFP-DD HCB TPA cables provide eight high-speed connectors (one lane of primary differential TX and RX). Labels clearly mark each cable or connector. The following figure refers to the pin-description table for the plug connector.

  • Page 21: Sfpdd Switch Module

    SFP-DD Test Adapter User Manual SFPDD Switch Module: The following figure shows the SFPDD-TPA-HCB-P switch module assembly. (Note: The default setting for the DIP switches S1 and S2 is the Off position). Output LED’s are green, Input LED’s are blue and Power LED’s are red.

  • Page 22: Sfpdd Switch Module Schematic

    SFP-DD Test Adapter User Manual SFPDD Switch Module Schematic: Figure 10. TPAxxx-HCB-P Switch Module Schematic P a g e | 22 ©2022-2025 Wilder Technologies, LLC Document No. 910-0072-000 Rev. D...
  • Page 23 SFP-DD Test Adapter User Manual Table 3. SFPDD-TPAxxx-HCB-P (Plug) 20-Position Cable Connector (P2) (Low-Speed) and Switch Module 20- Position Connector J1. LABEL Pin No. Color ID for HCB Description TXFLT Pin 1 Black Tx_Fault, Transmit fault TXDIS Pin 2 Black...
  • Page 24 SFP-DD Test Adapter User Manual Table 4. SFPDD-TPAxxx-HCB-P (Plug) Pin Assignments Per MSA Connector Pin Destination Color ID for Data Color Identification Description Number Number HCB Line Polarity (HCB/MCB) Ground P2 Pin 4,10 Black Insulation/NA Tx Fault P2 Pin 1...
  • Page 25 SFP-DD Test Adapter User Manual SFPDD-TPAxxx-MCB-R Cable Pin-out The SFP-DD MCB TPA cables provide eight high-speed connectors (one lane of primary differential TX and RX). Labels clearly mark each cable or connector. The following figure refers to the pin-description table for the SFPDD-TPA-MCB-R (Receptacle) test adapter.
  • Page 26 SFP-DD Test Adapter User Manual Table 5. SFPDD-TPAxxx-MCB-R 20-Position Male Connector (Conn6) (Low-Speed) LABEL Pin No. Color ID for MCB Description Pin 1 No Connection TXFLT Pin 2 Black Tx_Fault, Transmit fault SP1DD Pin 3 Black Rx Rate Select for DD channel...
  • Page 27 SFP-DD Test Adapter User Manual Table 6. SFPDD-TPAxxx-MCB-R (Receptacle) Pin Assignments Per MSA Connector Pin Destination Color ID for Data Color Identification Description Number Number MCB Line Polarity (HCB/MCB) Ground Conn6 Pin 17,19 Black Insulation/NA Tx Fault Conn6 Pin 2...

  • Page 28: Electrical Responses

    SFP-DD Test Adapter User Manual Electrical Responses Documented in the following pages are the electrical responses of the Wilder 112G SFP-DD TPAs. HCB loss, MCB loss, MTF response and ICN data is shown. Wilder 112G SFP-DD HCB Response Figure 12. Plot of SFP-DD HCB Insertion Loss The loss of the HCB up to but excluding the connector and its PCB pads is plotted in Figure 10.

  • Page 29: Wilder 112G Sfp-Dd Mcb Response

    SFP-DD Test Adapter User Manual Wilder 112G SFP-DD MCB Response Figure 13. Plot of SFP-DD MCB Insertion Loss The loss of the MCB up to but excluding the connector and its associated PCB pads is plotted in Figure 11. The loss at 28GHz is in table below. Note that the IEEE 802.3ck specification states that the difference between reference and MCB response should be accounted for in the measurement.

  • Page 30: Wilder 112G Sfp-Dd Typical Mtf Response

    SFP-DD Test Adapter User Manual Wilder 112G SFP-DD Typical MTF Response Figure 14. Plot of SFP-DD Mated Test Fixture Response (CK Limits) MTF ILoss is plotted with 802.3ck limits and ILoss at 28GHz is in the table below. Table 9. MTF Insertion Loss @ 28GHz...
  • Page 31 SFP-DD Test Adapter User Manual Figure 15. Plot of SFP-DD Mated Test Fixture Response (CEI Limits) MTF ILoss is plotted with OIF CEI VSR limits. P a g e | 31 ©2022-2025 Wilder Technologies, LLC Document No. 910-0072-000 Rev. D...
  • Page 32 SFP-DD Test Adapter User Manual Figure 16. Plot of SFP-DD Mated Test Fixture Worst Case Response Worst case FOM_ild is plotted in Figure 14 and typical results for all 4 channels are shown in the table below. FOM_ild below is calculated using IEEE 802.3ck and CEI VSR parameters.
  • Page 33 SFP-DD Test Adapter User Manual Figure 17. Plot of SFP-DD Mated Test Fixture Return Loss with Original 802.3ck Limit (Informative) MTF RLoss is shown for information only. P a g e | 33 ©2022-2025 Wilder Technologies, LLC Document No. 910-0072-000 Rev. D...
  • Page 34 SFP-DD Test Adapter User Manual Figure 18. Plot of SFP-DD Mated Test Fixture Return Loss with Original CEI VSR Limit (Informative) MTF RLoss is shown for information only. The ERL numbers below are for all 4 measured channels and are calculated with no gating.
  • Page 35 SFP-DD Test Adapter User Manual Figure 19. Plot of SFP-DD MTF Common Mode Return Loss with 802.3ck Limit Figure 20. Plot of SFP-DD MTF Common Mode Return Loss with CEI VSR Limit P a g e | 35 ©2022-2025 Wilder Technologies, LLC...
  • Page 36 SFP-DD Test Adapter User Manual Figure 21. Plot of SFP-DD MTF Conversion Return Loss with 802.3ck Limit Figure 22. Plot of SFP-DD MTF Conversion Return Loss with CEI VSR Limit P a g e | 36 ©2022-2025 Wilder Technologies, LLC...
  • Page 37 SFP-DD Test Adapter User Manual Figure 23. Plot of SFP-DD MTF Conversion Insertion Loss with 802.3ck and CEI VSR Limit P a g e | 37 ©2022-2025 Wilder Technologies, LLC Document No. 910-0072-000 Rev. D...

  • Page 38: Wilder 112G Sfp-Dd Icn

    CK and OIF specification. Both single valued integrated noise levels are then added RSS to give the total ICN value. Figure 24. Diagram showing TX and RX Victim and Aggressors on SFP-DD P a g e | 38 ©2022-2025 Wilder Technologies, LLC...
  • Page 39 SFP-DD Test Adapter User Manual Table 12. TX ICN Data (802.3ck) Figure 25. Plot of TX Victim Response to NEXT and FEXT The table above is ICN data calculated as outlined in 802.3CK for the TX victim responses. Note that each row represents an ICN value as each aggressor is added to the power sum.
  • Page 40 SFP-DD Test Adapter User Manual Table 13. RX ICN Data (802.3ck) Figure 26. Plot of RX Victim Response to NEXT and FEXT The table above is ICN data calculated as outlined in 802.3CK for the RX victim responses. Note that each row represents an ICN value as each aggressor is added to the power sum.
  • Page 41 SFP-DD Test Adapter User Manual Table 14. TX ICN Data (CEI VSR) The table above is ICN data calculated as outlined in CEI VSR for the TX victim responses. Note that each row represents an ICN value as each aggressor is added to the power sum.

  • Page 42: Compliance With Environmental Legislation

    European Union Directive 2002/96/EC on waste electrical and electronic equipment ("WEEE Directive"). As a service to our customers, Wilder Technologies is also available for managing the proper recycling and/or disposal of all Wilder Technologies products that have reached the end of their useful life.
  • Page 43 SFP-DD Test Adapter User Manual P a g e | 43 ©2022-2025 Wilder Technologies, LLC Document No. 910-0072-000 Rev. D...

  • Page 44: Glossary Of Terms

    Enhanced Small Form Factor Pluggable connection. (SFP+ 1X 28 Gb/s) SFP-DD Host The SFP-DD Host is the fixed end of the connection supporting IEEE 802.3 (clauses 38, 49, 52, 59, or 68), 8 GFC, 10 GFC, and 10GSFP+Cu serial protocols.

  • Page 45: Index

    AC coupled, 6 SFP-DD MTF Worst Case Response, 32 Cable Bend Limits, 11 SFP-DD Rx Victim Response to NEXT and FEXT, 40 Cable Tension (Pull Forces), 11 SFP-DD Tx Victim Response to NEXT and FEXT, 39 Cable Twisting (Torque), 11...
  • Page 46 Visit our website at www.wilder-tech.com Wilder Technologies, LLC 11201 NE 9 Street Vancouver, WA 98684 Phone: 360-859-3041 Fax: 360-859-3105 www.wilder-tech.com ©2022-2025 Wilder Technologies, LLC Document No. 910-0072-000 Rev. D Created: 8/4/2022 Revised: 1/23/2025 inprotected.com...
