ISOTHERMAL CONTAINERS
INDEX
1. INTRODUCTION
1.1 Field of application
1.2 Consultation of the manual
1.3 Warranty
2. WARNINGS
2.1 General recommendations
3. USE OF THE PRODUCT
3.1 First use
3.2 Instructions for using the opening handle with release button
3.3 Instructions for using the opening lever handle
3.4 Instructions for preparing the container before loading
3.5 Loading instruction
3.6 Instructions for carriage
4. MAINTENANCE
4.1 Washing instructions
4.2 Maintenance instructions
4.3 Routine maintenance
4.4 Extraordinary maintenance
4.4.1 Replacement of the gasket
4.4.2 Replacement of wheels
4.4.3 Replacement of the closing handle with release button
4.4.4 Replacement of the closing lever handle
4.4.5 Replacement of the handle stop
4.4.6 Replacing the thermometer
4.5 Welding instructions
5. DISPOSAL
5.1 Packaging
5.2 Product
6. CERTIFICATIONS
USE AND MAINTENANCE MANUAL
REV0 7/30/2023
CARGO
PBCA0106GB
1
Advertisement
Summary of Contents for Milford CARGO
- Page 1 USE AND MAINTENANCE MANUAL PBCA0106GB REV0 7/30/2023 CARGO ISOTHERMAL CONTAINERS INDEX 1. INTRODUCTION 1.1 Field of application 1.2 Consultation of the manual 1.3 Warranty 2. WARNINGS 2.1 General recommendations 3. USE OF THE PRODUCT 3.1 First use 3.2 Instructions for using the opening handle with release button 3.3 Instructions for using the opening lever handle...
- Page 2 Please note that CARGO is an exclusive product of MELFORM. The manufacturer reserves the right to make changes to the characteristics of the models at any time without prior notice. In addition, it is possible that there are variations in the shades of the colors of the product.
- Page 3 The product is guaranteed to be used in a temperature range between -30°C and +85°C. • Please note that the CARGO container is intended for use by adults and trained persons and must be kept out of reach of children.
- Page 4 With the thumb of your right hand, push the handle release button forward. Release the unlock button and open the handle by pulling it towards you. Return the handle to the closed position, pushing it forward. 3.3 Instructions for using the opening lever handle Move the movable handle plate upwards, then turn it anticlockwise until it stops.
- Page 5 To close the container: Place the left hand on the grip on the left side of the Cargo and, with the right hand on the handle, push the door as far as possible against the body. Repeat the sequence described for the opening in reverse order.
-
Page 6: Maintenance
It is possible to separate the load inside the container using intermediate grids. We recommend the use of one grid for Cargo 500, three grids for Cargo 370, 780, 1300TW and four grids for Cargo 1000EU. For Cargo 1300 there are no intermediate grids. - Page 7 • For hygiene, after washing, always dry the container with warm air or disposable paper (never reusable cloths). 4.2 Maintenance instructions MELFORM places great emphasis on the importance of regular maintenance of the container in order to prevent breakage, extend its service life and ensure its proper functioning. In this regard, the following is recommended: - Carry out the maintenance of the container at least once a year, using only qualified technicians.
- Page 8 PRODUCT PERIODICITY TYPE OF CONTROL Bolts, screws, plugs, rivets 6 months Check the presence of all the screws supplied. - Check the absence of breakages on the body and door. Any breakage Body and door: must be restored as soon as possible by welding, to avoid degradation aesthetic check 6 months of the internal insulation (section 4.5 "Welding instructions").
- Page 9 3 - Cut the gasket to the correct length, so that the two flaps fit together 4.4.2 Replacement of wheels Replace the wheels by following these steps: 1 - Place the container on the back 2 - Unscrew the M8 screws with the relative washers 3 –...
- Page 10 4.4.3 Replacement of the closing handle with release button Replace the closing handle by following these steps: 1 – Remove the rivets for steel 3.2x10 using a drill and a 2.5-3mm iron bit 2 – Remove the metal cover using a flat tool (e.g. cutting screwdriver) 3 –...
- Page 11 5 - Unscrew the 2 stainless steel screws cylindrical head with recessed hexagon M8x16 with the relative groover stainless steel washers (last two screws located on the right) 6 – Remove the two upper and lower rods of the door and remove the stainless steel closure. 7 –...
- Page 12 9 - Insert on the rod the two stainless steel screws with flat countersunk head and M6x25 recessed hexagon and screw the two stainless steel nuts hexagonal self-locking M6 10 – Screw the 2 stainless steel screws cylindrical head with recessed hexagon M8x16 with the relative groover stainless steel washers (screws positioned on the left, next to the rod) 11 –...
- Page 13 4.4.4 Replacement of the closing lever handle Replace the closing handle proceeding in the following manner: 1 – Unhook the closing handle from the handle 2 – Unscrew the nut and the M8 unscrewing screw with its Ø10mm washer. 3 - Replace the handle. 4 - Reassemble the nut and the unscrewing screw with the relative washer, proceeding in the opposite direction.
- Page 14 3 - Unscrew the nuts and the unscrewing screws M8, with the relative washers; Replace the complete handle stopper; Refit the nuts and anti-loosening screws with their washers, proceeding in reverse order; reposition the polyethylene caps. 4.4.6 Replacing the thermometer Replace the thermometer by following these steps: 1 –...
- Page 15 4.5 Welding instructions To weld the polyethylene walls, we recommend the use of a WEGENER continuous wire welding machine (available on request), proceeding as follows: 1 - Connect the welding machine mains plug into the 230V power outlet. 2 - Turn on the welding machine by placing the gray switch (A) on ON. 3 - Operate the resistors by placing the black switch (B) on ON.
- Page 16 8 - To turn off the welding machine, place the red knob (C) of the thermostat on the value 0, deactivate the resistors by placing the black switch (B) on OFF, turn off the welding machine by placing the switch gray (A) to OFF and remove the mains plug from the 230V power outlet. 9 - Allow the layer of polyethylene deposited on the area to be welded to cool for a few minutes.
- Page 17 These certifications confirm that the CARGO container is designed and manufactured in such a way as to guarantee the highest quality and safety in the transport and storage of perishable food products.
