Summary of Contents for CSE AIO1-PCS-3K-G1
- Page 1 User Manual V4.6 AIO1-5K-G1/-L Residential Low-voltage All-In-One Device (Single Phase) User Manual Inverter: AIO1-PCS-3K-G1 AIO1-PCS-5K-G1 AIO1-PCS-5K-G1-L Battery: AIO1-P-5.12K-G2 Release Date: 17/12/2024 Version: 4.6...
-
Page 2: Inverter Model
This manual describes the introduction, installation, operation and emergency situations of the AIO1-5K-G1 series. Please read this manual carefully before installations and operations. Keep this manual for future reference. 2. ALL IN ONE Model Description 2.1 Inverter Model Model AIO1-PCS-3K-G1 AIO1-PCS-5K-G1 AIO1-PCS-5K-G1-L... -
Page 3: Limitation Of Liability
4 Copyright This manual is under the copyright of CSE Energy & Technologies Co.,Ltd. with all rights reserved. Please keep it properly and flow the operational instructions strictly. No modification, reproduced should be down without permit. - Page 4 User Manual V4.6 • Read through this document before any operation and follow instructions strictly. 6. Statement and Declaration An All-in-One (AIO) device is mainly composed of 2 parts: a hybrid inverter and variable amount of battery modules. Available amount of battery modules ranges from 1 to 4, while the hybrid inverter can worked seperately without battery modules either.
-
Page 5: Table Of Contents
User Manual V4.6 Content 1 Introduction ..................................1 1.1 Safety Symbols &Warnings ..........................1 1.1.1 Symbols Explanation ..........................1 1.1.2 Safety Warning ............................2 1.1.3 Battery Handing Guide ..........................2 1.2 Response to Emergency Situations ........................3 1.2.1 Leaking Batteries ............................3 1.2.2 Fire ................................ - Page 6 User Manual V4.6 7.9 Install Protective Cover ............................29 8 Startup Procedure ................................30 9 Shutdown Procedure ..............................31 10. Monitoring System ............................... 32 10.1 Software Download ............................32 10.2 Register Account ............................... 33 10.3 For Distributor/Installer ............................. 35 10.3.1 WIFI Dongle Local Connection ......................35 10.3.2 Create Site ..............................
-
Page 7: Introduction
User Manual V4.6 1 Introduction 1.1 Safety Symbols &Warnings The AIO1-5K-G1 series is designed, manufactured, and tested as per international safety standards. However, as an electrical and electric product, it must be installed, operated, and maintained strictly according to related safety notices. -
Page 8: Safety Warning
1.1.3 Battery Handing Guide Use the battery pack only as directed. If the battery is defective, appears cracked, broken, or otherwise damaged, or fails to operate, contact the CSE ESS hotline immediately. Do not attempt to open, disassemble, repair, tamper, or modify the battery. -
Page 9: Response To Emergency Situations
If the battery catches fire, it will produce poisonous gases. Do not approach. 1.2.3 Wet Battery If the battery is wet or submerged in water, do not try to access it. Contact CSE ESS hotline or your distributor for technical assistance. -
Page 10: Damaged Battery
Damaged batteries are not suitable for use and may pose a danger to people or property. If the battery seems to be damaged, return it to CSE ESS or your distributor. -
Page 11: Contact Information
To wholeheartedly deliver quality products and excellent service, we have established a 7×24 hours customer service hotline at 021-50809880. Furthermore, our after-sales service headquarters is located in Shanghai: After-sales Service Headquarters: CSE Energy & Technology Co., Ltd. After-sales service hotline: 021-50809880 After-sales headquarters address: No. - Page 12 User Manual V4.6 Battery Voltage Range (V) 42-58.5 50/50 100/100 Max. Charge/Discharge Current (A) Module Number Energy (kWh) 5.12 10.24 96.90% Max. Efficiency European Efficiency Max. Battery Discharge Efficiency General 730*205*932 730*205*1302 Dimensions (W mm * D mm * H mm) Weight (kg) 85.3 133.8...
-
Page 13: Aio1-5K-G1 Series Diagram
User Manual V4.6 4.2 AIO1-5K-G1 series Diagram AIO1-5K-G1 series is designed with BACK-UP versions for customer to choose based on the local rules. NOTE Please control the home loads and make sure it’s within the “BACK-UP output rating” under BACK-UP mode, ... - Page 14 User Manual V4.6 Charge Power setting. power, the grid is used to continue working. The inverter preferentially uses the PV’s electricity to power the load, and charge the battery with excess No grid, but have PV power, if there is no enough PV, and battery the battery will be used for any shortfall until the battery SOC is...
-
Page 15: Battery (Aio1-P-5.12K-G2)
User Manual V4.6 NOTE If the anti-reverse function is set to enable, when the system is in Self-consume, Peak load shift, or Backup mode, it will not feed power to the grid. 4.4 Indicators and Ports 4.4.1 Battery (AIO1-P-5.12K-G2) Object Description Object Description... -
Page 16: Inverter
User Manual V4.6 4.4.2 Inverter Model AIO1-PCS-3K-G1/AIO1-PCS-5K-G1/AIO1-PCS-5K-G1-L Object Description DC switch PV1~PV2 Input Backup Load Output Grid Output Wi-Fi Module DRM (Demand Response Enabling Device) Meter Communication Port BMS Communication Port with Battery Battery Negative - Battery Positive + Battery SOC... -
Page 17: Indicators
User Manual V4.6 4.4.3 Indicators SOC indicator shows the valid capacity of battery modules. Color: Green Color Status: Solid and Flash 5 Installation Prerequisite 5.1 Packing List Make sure the products are intact during transportation. If there is any visible damage, such as cracks, please contact your dealer immediately. - Page 18 User Manual V4.6 Back-up Connector*1 PE Cable*1 Inverter Mounting Bracket*1 PV Connector (+)*2 PV Connector (-)*2 Hex Flange Screw*5 Basement*1 Self-tapping Screw*5 Expansion Anchor Bolt*5 Wifi Dongle*1 Meter (Single Phase)*1 Current Transformer (CT)*1 L-shaped Mounting Bracket*1 UT Terminal*2 Communication Connector*2 Rubber Cover*2 The battery packing list shown as below.
-
Page 19: Installation Position
User Manual V4.6 DC Power Cable*2 PE Cable*1 PACK Protective Cover*1 5.2 Installation Position AIO1-5K-G1 is designed for outdoor installation (IP65). Make sure the installation site meets the following conditions: Not in direct sunlight. Not in areas where highly Flammable materials are stored. ... - Page 20 User Manual V4.6 The wall hanging the inverter should meet conditions below: 1.Solid brick/concrete, or strength equivalent mounting surface; 2.Inverter must be supported or strengthened if the wall’s strength isn’t enough (such as wooden wall, the wall covered by thick layer of decoration) Please AVOID direct sunlight, rain exposure, snow laying up during installation and operation.
-
Page 21: Tools
User Manual V4.6 5.3 Tools To install the system, the following tools are required: Diagonal Pliers Torque Wrench Cable Crimper Wire Stripper Voltmeter Heat Gun Drill Ruler Heat Shrink Tubing Rubber Mallet Rolling Strip Marking Pen DC Wrench In order to protect the operator and the installer’s safety, please select and use suitable tools and measuring instruments that are certified for precision and accuracy. -
Page 22: Safety Instruments
User Manual V4.6 5.4 Safety Instruments When dealing with the battery, the following safety gears should be equipped. Installers must meet the relevant requirements of UL or the domestic legislation and other relevant international standards. Insulated glove Safety goggles Safety shoes 5.5 Unacceptable Installations Please avoid the following installations, which will damage the system. -
Page 23: Installation
User Manual V4.6 Do not expose the system to water. The products box should be upright and not stacked upside down when storing the battery box. If the battery needs to be stored for over 3 months, the main breaker of the battery is suggested to be ... -
Page 24: Install The Battery
User Manual V4.6 6.2 Install the Battery STEP 1: Put the battery module (a module) on the basement by aligning the positioning pillars (on the Basement) and holes (on the Battery Module); STEP 2: Fix the module and the basement with a L-shaped mounting bracket;... -
Page 25: Install The Inverter
User Manual V4.6 STEP 3: Lock the module and the basement together with a locking plate; STEP 4: Get other modules stacked by align the positioning pillars and holes; STEP 5: Lock between modules on both sides; 6.3 Install the Inverter STEP 1: Get the inverter wall mounting bracket and the inverter;... -
Page 26: Electrical Connection
User Manual V4.6 6.4 Electrical Connection WARNING Before electrical connection, turn off the DC switch and AC output switch of the inverter to ensure that the device is powered off. Live operation is strictly prohibited,otherwise, electric shock and other hazards may occur. 1. - Page 27 User Manual V4.6 General wiring diagram of system. Australia and New Zealand wiring diagram of system. Breakers Recommended: 1. Rated Current (back-up):32A 2. Rated Current (Grid On): 63A 3. Breaking Capacity:> 3kA 4. Earth-leakage Sensitivity: 30mA 5. Earth-leakage Protection Class: Type A 6.
-
Page 28: Cable Connection
User Manual V4.6 CAUTION All switches and RCD devices in the figure are for reference only and the specific installation shall be subject to local regulations! NOTE The arrow on the CT points to the power grid, showing as above. If the CT connector is improperly connected, the inverter cannot read the data correctly, so that the relevant working conditions cannot be realized normally. -
Page 29: Pv Connection
User Manual V4.6 NOTE Place cover lids over the terminals that do not have any connections. WARNING Positive and negative wires are not allowed to reverse. 7.2 PV Connection Hybrid can be connected in series with 2-strings PV modules for inverter.Select PV modules with excellent function and reliable quality. -
Page 30: Grid Connection
User Manual V4.6 NOTE PV negative(PV-) on the system side are not grounded as default design. Connect PV- to the ground are strictly forbidden. 7.3 Grid Connection Step1: Check the grid voltage. 1. Check the grid voltage and compare with the permissive voltage range (Please refer to technical data). -
Page 31: Back-Up: Load Connection
User Manual V4.6 7.4 Back-up: Load Connection Inverter has On and Off grid function, the inverter will deliver output power through AC port when the grid is on, and it will deliver output power through back-up port when the grid is off. Load port: important load. - Page 32 User Manual V4.6 Step3: Pass the backup cables through anti-pull cover, the backup terminal in sequence Step4: plug back-up terminal into the port and secure the anti-pull plate to the cover using screw M4 WARNING Make sure the BACK-UP load power rating is within BACK-UP output rating, otherwise the inverter will shut ...
-
Page 33: Wi-Fi Connection
User Manual V4.6 7.5 Wi-Fi Connection Inverter provides a Wi-Fi port which can collect data from inverter and transmit it to monitoring-website by Wi-Fi. 1. Wi-Fi Connection: Step1: Plug Wi-Fi into “Wi-Fi” port at the bottom of the inverter. Step2: Build the connection between the inverter and router. Step3: Create a user account online. -
Page 34: Ct&Meter Installation
User Manual V4.6 7.7 CT&Meter Installation CT is short for“current transform”,it's used to detect Grid current. Step1: Get the connector together with RJ45 header in a parts bag then unscrew it； Step2: Thread the cable through the connector； Step3: Strip a distance of 12~15mm； Step4: Rearrange the sequence of color-coated copper wires in the standards of TIA568B；... -
Page 35: Drm Connection
DRM on the right side of PCS. Wire crimping steps are the same as a normal comm. cable with a connector. To enable or disable a DRM function, please go to your CSE APP>>Parameter>>Factory Data>>DRM The hybrid inverter will detect and initiate a response to all supported demand response commands within 2s, and will continue to respond while the mode remains asserted. -
Page 36: Startup Procedure
User Manual V4.6 8 Startup Procedure Step 1: Turn on the battery breaker. -
Page 37: Shutdown Procedure
User Manual V4.6 Step 2: Turn on the PV switch. Step 3: Turn on the grid breaker. Step 4: If the back-up load is applied, turn on the backup breaker. Step 5: Configure the WIFI stick. CAUTION Make sure the WIFI connected is 2.4GHz, if not, that is not work. NOTE If the indicator is green, the system is successfully started. -
Page 38: Monitoring System
User Manual V4.6 10. Monitoring System 10.1 Software Download CSE monitoring platform supports both APP and web monitoring. Users can monitor detailed running information like generating capacity, system data, and send command, set parameters. 1. Scan the QR Code APP Download 2. -
Page 39: Register Account
User Manual V4.6 10.2 Register Account If you are distributor 1. Select Register Now 2. Select I am the Admin 3. Enter your information If you are installer 1. Select Register Now 2. Select I am an installer 3. Enter your information... - Page 40 User Manual V4.6 4. Select the 科大数能 5. Select the CSE(Select the corresponding distributor or factory according to the situation.) If you are home user 1. Select Register Now 2. Select I am a home user 3. Enter your information...
-
Page 41: For Distributor/Installer
User Manual V4.6 10.3 For Distributor/Installer 10.3.1 WIFI Dongle Local Connection 1. Login your account 2. Tap Service at the bottom of 3. Select the right WiFi device to page and select local connection connect 4. Select the Network Setting 5. -
Page 42: Create Site
User Manual V4.6 10.3.2 Create Site 1. After local connection setting, 3. Enter Create Site for Me/Home 4. Select the Allow While Using select Manage user 2. Click + 5. Enter your information 6. Enter the Config Net 7. Select the right device to connect PCS code: Scan the SN barcode on the side of the PCS with your phone. -
Page 43: Increasing Pcs In Your Site
User Manual V4.6 location. NMI: Enter the identification number of your electricity meter. (optional input items) 8. Select the Network Setting 9. Enter your local WIFI info CAUTION Make sure the WIFI connected is 2.4GHz, if not, that is not work. 10.3.3 Increasing PCS in Your Site 1. -
Page 44: Mode Setting
User Manual V4.6 4. Select the + 5. Enter your information 10.3.4 Mode Setting 1. Select the PCS 2. Select the the one of Site 3. Select the Parameter... - Page 45 User Manual V4.6 4. Select the Mode Setting 5. Select the mode as your needs Power Limited: AC output power, This function takes precedence over VPP function, except Exp Power Limit En VPP Grid Power: For VPP energy You can set the system to charge or You can set the charge and scheduling, charge and discharge discharge, and then the inverter will...
- Page 46 User Manual V4.6 Parameter-Network Setting: Exp Power Limit En: Batt SOC Set High ： Battery cutoff Set the local standard grid Enable/Disable charge SOC requirements Exp Power Limit ctrl: Set the power Batt SOC Set Low ： Battery cutoff feeds to grid discharge SOC This function takes precedence over Backup Mode SOC Reserve...
-
Page 47: Grid Setting Of Inverter
User Manual V4.6 10.3.5 Grid Setting of Inverter 1. Select the PCS 2. Select the the one of Site 3. Select the Parameter 4. Select the Network Setting 5. Tap the Inverter Safety Code 6. Select the region_A or B or C Select the country: Australia... - Page 48 User Manual V4.6 7. You can adjust the grid protection 8. You can adjust the grid protection 9. You can set the power quality setting: setting: response modes: select multiple OPV: Over-voltage protection OFP: Over-frequency protection options under the Safety Mode Ctrl UPV: Under-voltage protection UFP: Under-frequency protection and then click apply setting.
- Page 49 User Manual V4.6 allowed volt_varMod_EN: enable the adjustment of inverter’s reactive output power in response to grid voltage FeedCtrl_Hardlimit_EN: enable of imposing strict limits on the inverter’s output power to prevent exceeding the predefined output power range 10. You can set the Reactive Mode 11.
-
Page 50: Inverter Settings Overview
User Manual V4.6 10.3.6 Inverter settings Overview 1. Select the one of Site 2. Select the Device and tap one of 3. You can see the PCS Detail; Safety Regulation Code: you can see the Country.Grid.Code/Region settings. DSP version & ARM version: you can see the inverter firmware version 10.4 For Home User 10.4.1 Create Site... -
Page 51: Increasing Pcs In Your Site
User Manual V4.6 4. Select the right device to connect 5. Select the Network Setting 6. Enter your local WIFI info 10.4.2 Increasing PCS in Your Site 1. Select Device, then click + 2. Enter your info... -
Page 52: Wifi Dongle Local Connection
User Manual V4.6 10.4.3 WIFI Dongle Local Connection 1. Home-Local connection 2. Select the right WiFi device to 3. Select the Network Setting connect 4. Enter your local WIFI info and the network is configured successfully... -
Page 53: Inverter Settings Overview
User Manual V4.6 10.4.4 Inverter settings Overview 1. Select device, then choose the You can see the PCS Detail; one of your pcs Safety Regulation Code: you can see the Country.Grid.Code/Region settings. DSP version & ARM version: you can see the inverter firmware version 11 Fault Diagnosis and Solutions Error Cause... - Page 54 User Manual V4.6 Communication internal Please contact your dealer Lost Com.M<->S Err Inverter is abnormal. or after-sale service. 1. Check whether the PV input cables are broken. 2. Check whether the The grounding impedance module frames and the ISO Err of PV system is below the metal bracket are securely allowable range.
