CONTENTS Important Safety Instructions Contents: Warnings and safety instructions appearing in this Important Safety Instructions ..........2 guide are not meant to cover all possible conditions and Unpacking Your Appliance ..........3 situations that may occur. Common sense, caution, and Installing Your Appliance .............4 care must be exercised when installing, maintaining, or Product Dimensions ............6 operating this appliance.
If there is damage, the packaging will be needed as proof of damage in transit. Afterwards please dispose of all items responsibly. VIKING RANGE, LLC GREENWOOD, MS 38930 WARNING XXXXXXXXXXXX...
Viking Range, LLC does not recom- Raise or lower the legs to the required dimension by turning mend the use of a custom made grille as air fl ow may be the legs.
INSTALLING YOUR APPLIANCE WARNING Electrical Shock Hazard Do not remove • Do not use an extension cord with this appliance. ground prong They can be hazardous and can degrade product performance. • This appliance should not, under any circumstanc- es, be installed to an un-grounded electrical supply. •...
PRODUCT DIMENSIONS ROUGH-IN OPENING DIMENSIONS CABINET DIMENSIONS “A” “B” “C” “D” “E” “F” “G” “H” “J” 24” 34” to 35” 24” 23 7/8” 33 3/4” to 34 3/4” 23 5/8” 39 3/16” (61 cm) (86.4 cm to 88.9 cm) (61 cm) (60.7 cm) (85.7 cm to 88.3 cm) (60 cm)
Page 7
PRODUCT DIMENSIONS PRODUCT DATA ELECTRICAL PRODUCT REQUITEMENTS # WEIGHT 140 lbs 115V/60Hz/15A (63.6 kg) “F” “D” “E” 21 1/2” (54.6 cm) “H” Figure 9 Minimum rough-in opening is required to be larger than the adjusted height of the cabinet. A grounded 15-amp dedication circuit us required. Follow all local building codes when installing electrical and appliance.
INSTALLING THE ANTI-TIP DEVICE Anti-Tip WARNING Bracket Leveling Leg • ALL APPLIANCES CAN TIP RESULTING IN INJURY. • INSTALL THE ANTI-TIP Bottom View of ⁄ " BRACKET PACKED WITH Appliance (54.6 cm) THE APPLIANCE. • FOLLOW THE INSTRUC- TIONS BELOW Front of cabinet Anti-Tip Device Figure 10...
Page 9
INSTALLING THE ANTI-TIP DEVICE NOTE When the floor mounted anti-tip bracket is used the mini- mum adjusted height of the cabinet is increased by ⁄ " (9 mm). "V" notches Rear Leveling leg in bracket Figure 11a Screw ⁄ " (54.6 cm) Figure 11 "V"...
DRAWER DIVIDER Drawer Divider The top and bottom drawer have an adjustable drawer divider. To adjust the divider, making the 4 areas larger or smaller, move the center post along the length of the rods in either direction. See Figure 12 and 12a. The divider can also be removed from the drawer.
INTEGRATED PANEL INSTALLATION CAUTION It is important to use the factory provided grille that came with the product to assure proper air flow is maintained through the condenser. The use of a custom grille is not recommended and will void the warranty. Full Integrated Panel Installation Instructions Determine Wood Screw Requirements 1.
Page 13
INTEGRATED PANEL INSTALLATION Step 1: Remove Drawers from unit. Begin by pulling out the top drawer. (See Figure 14). .35/.31 Remove screws securing drawer to slides (See Figure (9 mm/7.5 mm) 15). Pull drawer forward, lift up and out to clear clips in rear of drawer.
Page 14
INTEGRATED PANEL INSTALLATION Step 3: Attach the Integrated Panel to the Drawer 1. Set the integrated panel on drawer front face and align edges. (See Figure 18). The custom integrated panel should be flush with the top of the drawer and centered on the width of the drawer.
• Close door to silence alert and reset etc. Viking recommends allowing the unit to reach set points before loading. High/Low Temp. Notifications When the compartment temperature exceeds the control setting for an extended amount of time: •...
CARE AND CLEANING AND ENERGY SAVING TIPS The following suggestions will minimize the Front Grille cost of operating your refrigeration appliance. Be sure that nothing obstructs the required air fl ow open- ings in front of the cabinet. At least once or twice a year, brush or vacuum lint and dirt from the front grille area (see 1.
Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking Range, LLC at (888) 845-4641 or write to: VIKING RANGE, LLC...
TROUBLESHOOTING Before You Call for Service CAUTION If the appliance appears to be malfunctioning, read through this manual fi rst. If the problem persists, check the troubleshooting guide below. Locate the problem in the In the unlikely event you lose cooling in your unit, do not guide and refer to the cause and its remedy before calling unplug the product from the electric supply, but do call for service.
Any sealed refrigeration system component, as listed below, is warranted to be free from defective materials or workmanship in normal household use during the third through the sixth year from the date of original retail purchase. Viking Range, LLC, warranter, agrees to repair or replace, at its option, any part which fails or is found to be defective during the warranty period.
Page 20
Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-(845-4641) or visit our web site at vikingrange.com 30737 (102824)
