PLT005 User Manual
Specifications, device installation, compliance and safety information
Updated: 2024-10-02
CONFIDENTIAL
All rights reserved. No part of this document may be re produced by any means whatsoever without the prior permission
of Core Transport Technologies Limited. Although Core Transport Technologies has taken reasonable care in the
preparation of this document; Core Transport Technologies accepts no liability whatsoever of whatsoever nature for any
loss or expense incurred due to reliance on or use of this document.
This document contains confidential information that is the property of Core Transport Technologies Limited. All use,
disclosure and/or reproduction not specifically authorised by Core Transport Technologies is prohibited. All names are
trademarks of their respective holders.
Advertisement
Table of Contents
Summary of Contents for Descartes PLT005
- Page 1 PLT005 User Manual Specifications, device installation, compliance and safety information Updated: 2024-10-02 CONFIDENTIAL All rights reserved. No part of this document may be re produced by any means whatsoever without the prior permission of Core Transport Technologies Limited. Although Core Transport Technologies has taken reasonable care in the preparation of this document;...
-
Page 2: Table Of Contents
Table Of Contents Revision History ..........................3 Introduction ............................ 4 Specifications ..........................5 Safety............................7 PLT005 ............................7 Operating Instructions ......................7 Usage ............................8... -
Page 3: Revision History
Revision History Name Date Description Version MARIA 2024/08/26 Create document MARIA 2024/10/02 Compliance... -
Page 4: Introduction
Introduction The PLT005 Descartes IoT ® BLE Beacon Tag is an active Bluetooth Low Energy (BLE) beacon that uses the Nordic nRF5833 module. This user manual provides detailed instructions for using the PLT005 in a production environment. The tag broadcasts an advertisement every 6 seconds on BLE channels 37... -
Page 5: Specifications
Specifications FCC ID 2A4F8-PLT005 RF specification operating frequency 2402 MHz (low), 2426 MHz (medium), 2480 MHz (high) Type of modulation GFSK RF transmit power 1.8 dBm EIRP Number of channels 3 channels Antenna type Ceramic Patch Antenna gain 1.3dBi Specialty... -
Page 6: Fcc Compliance Statement
Compliance FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: The grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. -
Page 7: Safety
20 cm from all persons. Please maintain at least a 20 cm spacing from the antenna and device. PLT005 Production versions of the tag come in a sealed case with the batteries installed. They are already powered on and ready for installation. -
Page 8: Installation
3. Once installed, assign the tag to the Descartes IoT system for tracking. Usage The PLT005 COREInsight BLE Beacon tag is an active BLE beacon. The PLT005 tag advertises every 6 seconds. COREInsight® Readers listen for special (custom) adverts from the Beacon Tag and when it is...
