Summary of Contents for PrintSir Plus PS-3100+
- Page 1 PrintSir Plus PS-3100+ 3-Port 10/100Mbps Desktop Print Server User’s Manual n Hardware Installation n Features and Specifications...
- Page 2 FCC COMPLIANCE STATEMENT This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the instructions provided with the equipment, may cause interference to radio and TV reception. The equipment has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference in a...
- Page 3 Hardware Installation Thanks for purchasing this Fast Ethernet Print Server - PS-3100+. This guide explains its external features, explains how to unpack your Print Server hardware, and tells how you can connect it to your printer and to your network. Requirements To use your PS-3100+, you will need : Ÿ...
- Page 4 LED Indicators The PS-3100+ is equipped with five LED indicators that show its current status, and can be used for diagnosing problems on the network and the PS-3100+ itself : DIMAX 10/100Mbps 3-port Print Server 100Mbps/LNK/ACT 10Mbps/LNK/ACT Parallel Port Ÿ Status LEDs (green) The Status LED is lit : 1.
- Page 5 Ÿ 10M Link/ACT LED (yellow) The 10M Link/ACT LED shows the status of the Print Server’s 10Mbps network connection : 1. If you are using a 10BaseT connection to the Print Server, the 10M Link/ACT LED will normally be on to indicate a good link. 2.
- Page 6 Features & Specifications Features Ÿ One 10BaseT/100BaseTX, auto-sensing port. Ÿ Three parallel ports. Ÿ Windows 95/98 only network printer share support. Ÿ Quick and easy installation, support DHCP server and client. Ÿ Web-based management enables administrator using web browser to view and configure the print server.
