A
B
C
Adjusting image focus
Open the front door by pressing the top left front corner. The image focus adjustment lever is located behind the hatch on
the side of the projector. Push the locking mechanism forward (1) to open the hatch (2). Adjust the image resolution from
the adjustment lever (3).
support@artome.fi | www.artome.fi
Artome support: +358 40 455 4455
quick user guide
1
Connect the power cable to the POWER connector on the back wall of the
•
device (see picture A).
2
Connect the HDMI cable to the HDMI connector on the back wall (see
•
picture B).
3
Connect the other end of the HDMI cable to the computer. Use an adapter if
•
necessary (see picture C).
4
Artome will start automatically when the HDMI cable is connected between
•
the computer and Artome.
If needed, start Artome from the POWER button on the control panel.
•
1.
1.1
2.
3.
