POP UP PUPS04 Installation Manual

PUPS 04 + 05
INSTALLATION
MANUAL
UNIT INFORMATION
• The PUPS04 unit weighs 100kg, including the weight of the concrete box
• The PUPS05 unit weighs 130kg, including the weight of the concrete box
DIGGING AND INSTALLATION
Follow these instructions:
1. If the soil is well-drained, dig a trench to host the unit: depth 1340 mm – diameter 850mm.
2. On the bottom put a 400mm layer of gravel;
3. Place on it a 100mm concrete screed plinth with a 30mm hole at the center.
In case of non-draining soil, follow these instructions:
1. Dig a trench to host the unit: depth 1340 mm – diameter 850mm.
2. Place on it a 100mm concrete screed plinth, leaving an opening at the center for the pipe
of the white water system.
Preparing the ground is indispensable in order to avoid flooding inside the product.
Placing the unit into the ground:
1. Remove the plastic from the unit and lift it with the help of the eyebolts (Fig.1). It is
recommended not to make sudden shakes that could tear the threaded rods apart;
2. Lay down the supply unit into the trench by keeping it as square as possible to the ground
in order to ensure that the mechanical equipment are not subjected to major stress (Figure 2).
In order to make sure that the electrical / water groups are in the desired position, follow
the symbols on the product, which indicate the equipped sides of the unit.
ELECTRICAL CONNECTIONS
Once the unit is in place and if it is supplied by a power cord, these instructions must be
meticulously followed:
1. Use the handle to lift the tower until the end of stroke;
2. Verify that the cable inside the concrete is enough to allow the complete extraction in
case of maintenance.
If there's no power cord to supply energy, you must follow these instructions:
1. Remove all the electromechanical part;
2. Insert the power cable into the hole at the bottom of the concrete, twisting it half-around
the central screw of the mechanical part carrier;
3. Open the lid of the box and plug the power cord;
4. Re-place the tower inside the cockpit and close it, making sure that the cable is not in the
way of the tower's stroke.
On request it is possible to obtain the tower with the external junction box; in this case:
1. Remove the cover and connect the cable to the terminal;
2. Within the enclosure mix the 3M's scotchcast resin (TI type format C, 3415) or equivalent.
It's preferable that each tower is connected to its own independent line in a radial way
and protected by a single 30 mA differential thermal breaker.
It is suggested to use a good flexible cable (H07RN-F) or equivalent.
Futhermore it's necessary that the power cord is equipped with an earth conductor.
The New VMR products are manifactured with high-quality materials.
