INSTALLATION MANUAL
INSTALLATION PARTS
1
Installation kit box 1 pc.
C-130043
6
Latch STL S-5 R/L 1 pair.
C-110060
11
Shock STABILUS GAS 2 pcs.
C-160204
16
Box switch 1 pcs.
C-100530
INSTALLATION TOOLS
1
Screw Driver
1
Clean the edge of truck bed.
.
2
3
Sponge rubber edge 1 roll.
C-020494-04
7
8
Double bolt M8x33 SUS 2 pcs.
C-120108S
12
13
Weather strip 1 roll.
C-020132
17
18
Cable tie 5.5" 15 pcs.
C-130046
2
Torque Wrench No.13
1/7
4
Tape page 2 1 roll.
C-070050-01
9
PVC Double bolt washer 2 pcs.
C-020221V
14
Screw 2 pcs.
CARRYBOY SR5 LOGO 2 pcs.
C-030059
19
Electric klamp lock 4 pcs.
C-160259
3
Wrench No.13
2
Clean of under the hardtop.
FORD RANGER T6 D/CAB
5
Kwick klamp S6 1 set.
C-120490-02
10
Nut M8 SUS 4 pcs.
AL. adjustable shim for latch 2 pcs.
C-030645
15
CARRYBOY
CARRYBOY
C-160416-01
C-090432-02(Front) or C-090437-06(Rear)
Installation manual 1 set.
C-132701-01
4
5
Cutter
SR5
CFTD-SR5
CARRYBOY
Kwick klamp cover 6 pcs.
C-100597-01BL
C-110160
Wiring harness 1 set.
Check list 1 pc.
CL-280045-02
Measuring tape
C-132701-01
19/11/61
REV : 00
