Summary of Contents for LIT ATS-AEBH-24
- Page 1 Infrared Strip Heaters USER MANUAL Toggle Controls single OPERATION AND SAFETY INSTRUCTION MANUAL This unit must be serviced by qualified personnel only. Service by unqualified personnel may lead to electric shock or burn.
- Page 2 Characteristic ★ Attached toggle controls for simple operation ★ Durable metal sheathed elements produce intense heat to keep foods at peak serving temperatures without overcooking. ★ Heavy-duty stainless steel construction; mounting brackets included for easy installation ★ Perfect for use in cafeteria, restaurant, or buffet line Toggle Controls Toggle controls are simple to operate and provide one level of heat, so you can be sure your staff does not...
-
Page 3: Safety Instructions
Introduction, Requirements and Safety Introduction 1.Please read instructions before using this appliance.This appliance is for commercial use only. 2. When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock and injury. 3. Clean machine thoroughly before and after each use following the cleaning instructions provided below. Safety Instructions WARNING! All power must be disconnected at power source before any service procedure is performed. - Page 4 ITEM# Item# Type Voltage Power ATS-AEBH-24 24",Toggle switch 120V 500W ATS-AEBH-30 30",Toggle switch 120V 650W ATS-AEBH-36 36",Toggle switch 120V 850W ATS-AEBH-42 42",Toggle switch 120V 1050W ATS-AEBH-48 48",Toggle switch 120V 1200W ATS-AEBH-54 54",Toggle switch 120V 1425W ATS-AEBH-60 60",Toggle switch 120V 1550W ATS-AEBH-72 72",Toggle switch...
-
Page 5: Installation
Installation Installing Chain Suspended Units Chain suspension mounting attaches a strip heater to an overhead surface with the use of “S” hooks. NOTE: Units ordered with the “S” hook option come with two“S” hooks and two 6″ (152 mm) pieces of connecting chain. - Page 6 Adjustable Angle Bracket Mounting on Aluminum Models Use the following procedure to install adjustable brackets on each end of aluminum housing models 1.Position the unit on a flat surface with the heating element facing down. 2. Remove the two hanger tab screws and hanger tabs.These items will not be needed. 3.
-
Page 7: Maintenance
Maintenance The Infrared Strip Heaters are designed for maximum durability and performance with minimum maintenance. WARNING ELECTRIC SHOCK HAzARD: • Turn OFF power switch, unplug power cord/turn off power at circuit breaker, and allow unit to cool before performing any cleaning, adjustments, or maintenance. •... -
Page 8: Troubleshooting Guide
Troubleshooting Guide Symptom Probable Cause Corrective Action Check circuit breaker and reset as No power to unit. necessary. Unit is turned “On” but there is no Switch is defective. Contact authorized Service agent heat. Wiring is open. Contact authorized Service agent Heating element defective Contact authorized Service agent Unit mounted too high above target...
