EN
Installation Manual
Flexa 25
AZC25CB1MOT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Flexa 25 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Airzone Flexa 25

Summary of Contents for Airzone Flexa 25

  • Page 1 Installation Manual Flexa 25 AZC25CB1MOT...

  • Page 3: Table Of Contents

    ENVIRONMENTAL POLICY _______________________________________________________________________________5 BEFORE STARTING________________________________________________________________________________________6 ELEMENTS AND INSTALLATION________________________________________________________________________8 > Basic system elements _______________________________________________________________________8 > Airzone Flexa 25 main control board (AZC25CB1MOT) ___________________________8 > Airzone AirQ Box horizontal ducted ionizer (12V) (AZAIQBOXDCHM) __________13 > AirQ indoor air quality Sensor (AZX6AIQSNSB) ____________________________________15 >...
  • Page 4 CHECKING THE INSTALLATION _________________________________________________________________________53 INITIAL CONFIGURATION ________________________________________________________________________________55 > Airzone Blueface Zero _________________________________________________________________________55 > Airzone Think ___________________________________________________________________________________56 > Airzone Lite ______________________________________________________________________________________58 > Checking the initial configuration ___________________________________________________________59 > System reset ____________________________________________________________________________________59 > Zone reset _______________________________________________________________________________________59 SYSTEM ADVANCED SETTINGS ________________________________________________________________________60 > Airzone Blueface Zero _________________________________________________________________________60 >...

  • Page 5: Environmental Policy

    Environmental policy • Never dispose of this equipment with household waste. Electrical and electronic products contain substances that can be harmful to the environment if not properly handled. The crossed-out waste bin symbol indicates separate collection of electrical devices, which must be separated from other urban waste. For correct environmental management, at the end of its useful life the equipment should be taken to the collection centers provided for this purpose.

  • Page 6: Before Starting

    Connect all wiring securely. Loose wiring may cause overheating at the connection points and is a possible fire hazard. • Do not locate the Airzone communication bus close to power lines, fluorescent lights, actuators, etc. as this may cause interference in communications. •...
  • Page 7 • A Blueface Zero thermostat must be used to enable all the Airzone system functionalities. • Recommendations for the placing of the thermostats: • For equipment using R32 refrigerant, verify the compliance with the local refrigerant regulation. • The room size installation requirements mentioned in the manual of the ducted indoor unit, to which the Easyzone is connected, remain applicable to each and every separate room served by the Airzone unit.

  • Page 8: Elements And Installation

    Elements and installation BASIC SYSTEM ELEMENTS Airzone Flexa 25 main control board (AZC25CB1MOT) For further information, see the technical datasheet. Assembly The system’s main control board is delivered in a screwed box for surface mounting. The location and installation of this element must comply with the current electronic regulations.
  • Page 9 Airzone connection bus (AZ1 - AZ2 - AZ3) The Airzone connection bus is used to connect all the internal elements independent of the main control board and can control up to 8 zones. The devices that can be connected to this bus are: •...
  • Page 10 The automation bus allows several systems to be interconnected in order to manage all of them, using the control peripherals offered by Airzone or their integration into a higher-level control network. The devices that can be connected to this bus are: •...
  • Page 11 Manual configuration (requires Webserver version equal to or later than 4.0.1): ON/OFF control through Airzone Cloud (requires version equal to or later than 4.11). The technical characteristics of the O2 relays are: Imax 1 A at 24-48 V voltage free. To control...
  • Page 12 Manual configuration (requires Webserver version equal to or later than 4.0.1): ON/OFF control through Airzone Cloud (requires version equal to or later than 4.11). The technical characteristics of the O1 relays are: Imax 1 A at 24-48 V voltage free. To control higher power elements, the use of contactors of the power to be controlled is recommended.

  • Page 13: Airzone Airq Box Horizontal Ducted Ionizer (12V) (Azaiqboxdchm)

    Airzone AirQ Box horizontal ducted ionizer (12V) (AZAIQBOXDCHM) For further information, see the technical datasheet. Elements Nº Description Fixing frame AZAIQBOXDCHM Spindles Screws Assembly It is recommended to install the device in the initial section of the ventilation duct, near the HVAC unit, following the restrictions in the image.
  • Page 14 Connect the AirQ Box to the CAN bus of the main control board. For this purpose, there is one 5-pin terminal. Use 2x0.5 + 2x0.22 mm Airzone cable. Fix the cables with the screws on the terminal, following the color code.

  • Page 15: Airq Indoor Air Quality Sensor (Azx6Aiqsnsb)

    You can secure the device by a small anti-theft screw located at the bottom (optional). 65 X 65 mm / ∅ 65 mm T8 Allen Connection Nº Description Integration bus 0-10 V output (CMV) Airzone damper control CAN bus Relay output (CMV remote On/Off)
  • Page 16 Connect the AirQ Sensor to the CAN bus of the main control board. To do this, there is one 5-pin terminal. Use 2x0.5 + 2x0.22 mm Airzone cable. Fix the cables with the screws on the terminal, following the color code.

  • Page 17: Wired Thermostats

    Important: Use the tool provided to press on the fastening tabs. Fix the back of the thermostat to the wall. Connect the Airzone connection bus to any of the three terminals (AZ1, AZ2 or AZ3). For increased safety, fix the cables to the main control board using the turrets.

  • Page 18: Wireless Thermostats

    Assembly Airzone wireless thermostats are surface mounted on a support. Remember that the maximum recommended distance for this device is 40 meters. For wall mounting, follow these steps: Remove the back of the thermostat and insert the CR2450 button battery.

  • Page 19: Optional System Elements

    OPTIONAL SYSTEM ELEMENTS AirQ Box in-duct IAQ monitoring and controlling device (AZX6AIQBOXM) For further information, see the technical datasheet. Elements Nº Description Fixing frame AZX6AIQBOXM Spindles Screws Assembly It is recommended to install the device in the initial section of the ventilation duct, near the HVAC unit, following the restrictions in the image.
  • Page 20 Connection Nº Description Ionizers Airzone connection bus CAN bus Power supply CAN bus Connect the AirQ Box to the CAN bus (together with the AZAIQBOXDCHM ionizer) of the main control board. For this purpose, there is one 5-pin terminal. Use 2x0.5 + 2x0.22 mm Airzone cable.
  • Page 21 Power supply (N L The AirQ Box is externally powered at 110/230 VAC. The power connection to the module is via a 3-pin terminal. Fix the cables with the screws on the terminal, following the color code. The connection to the external power supply must include a main switch or other method of disconnection that includes a constant separation for all polarities, in accordance with appropriate local and national regulations.

  • Page 22: Airq Box In-Duct Iaq Controlling Expansion Module (Azx6Aiqboxs)

    Connection Connect the expansion modules to outputs IO3 - IO6 of the AirQ Box. For this purpose, there are two 4-pin terminals. Use 2x0.5 mm2 Airzone cable. Fix the cables with the screws on the terminal, following the color code.

  • Page 23: Airzone Dehumidifier Control Module (Azce8Cm1Dry)

    Connect the AZCE8CM1DRY module to the CAN bus of the main control board. For this purpose, there is one 5-pin terminal. Use 2x0.5 + 2x0.22 mm Airzone cable. Fix the cables with the screws on the terminal, following the color code.
  • Page 24 Relay outputs Relay specs: Pump Imax: 12 A at 250 VAC / 12 A at 24 VDC. Fan Imax: 5 A at 250 VAC / 3 A at 30 VDC. Note that to control elements with a greater power, it is recommended to use contactors in accordance with the power required.

  • Page 25: Airzone Control Module For Wireless Valves Valr (Azce8Cm1Valr)

    Airzone control module for wireless valves VALR (AZCE8CM1VALR) For further information, see the technical datasheet. Assembly This module is mounted on DIN rail. It should be placed and mounted in accordance with the current electrotechnical regulations. Note: To remove the module on DIN rail, pull the tab downwards to release it.

  • Page 26: Airzone Wireless Thermostatic Valve Actuator Valr For Radiators

    Assembly Airzone wireless thermostatic valve actuators are mounted on each of the valves of a heater. Check that the thermostatic valve actuator is compatible with the valve body that you are going to equip (M30 x 1.5). See compatibility table.

  • Page 27: Airzone Control Module For Wired Valves 110/230V Valc (Azce8Cm1Valc)

    Airzone control module for wired valves 110/230V VALC (AZCE8CM1VALC) For further information, see the technical datasheet. Assembly This module is DIN rail or surface mounted. It is externally powered at 110/230 Vac. It should be placed and mounted in accordance with the current electrotechnical regulations.
  • Page 28 Connect the AZCE8CM1VALC module to the CAN bus of the main control board. For this purpose, there is one 5-pin terminal. Use 2x0.5 + 2x0.22 mm Airzone cable. Fix the cables with the screws on the terminal, following the color code.
  • Page 29 Power supply (N L The module for wired valves is externally powered at 110/230 VAC. The power connection to the module is via a 3-pin terminal. Fix the cables with the screws on the terminal, following the color code. The connection to the external power supply must include a main switch or other method of disconnection that includes a constant separation for all polarities, in accordance with appropriate local and national regulations.

  • Page 30: Airzone Wired Thermostatic Valve Actuator 110/230V Valc For Radiant Elements (Azx6Ac1Valc)

    Assembly Airzone wired thermostatic valve actuators are mounted on each of the valves of a manifold / heater. Check that the thermostatic valve actuator is compatible with the valve body that you are going to equip (M30 x 1.5). See compatibility table.
  • Page 31 Connection Airzone wired thermostatic heads are elements that are connected to the Z1 - Z8 outputs on the AZCE8CM1VALC. Connect throught 2 wires without polarity. Maximum number of valves permitted: 2 for each output (20 valves in total). Important: Use a suitable screwdriver to press in the locking tabs.

  • Page 32: Webserver Airzone Cloud Wi-Fi Dual 2.4-5G (Azx6Wsc5Ger)

    Assembly The Webserver Airzone Cloud Wi-Fi Dual 2.4-5G (AZX6WSC5GER) is integrated in the main control board automation bus or in the outdoor automation bus of the production control board. It has a 5-pin terminal; disconnect the terminal to which you want to connect the Webserver and fit the connector.
  • Page 33 AZX6WSC5GR from a system main control board to other system main control boards If the Webserver Airzone Cloud se encuentre conectado a la CCP, is connected to the CCP, use the CCP's indoor automation bus to connect to the system main control board.

  • Page 34: Webserver Hub Airzone Cloud Dual 2.4-5G/Ethernet (Azx6Wsphub)

    Note: To remove the module on DIN rail, pull the tab downwards to release it. Connection Nº Description Ethernet Wi-Fi Automation bus Integración output Ethernet Wi-Fi Important: All Airzone systems must be connected to the internet to provide technical support.
  • Page 35 Automation bus (DM1 - DM2) The Webserver HUB is an element that connects to the automation bus on the system's main control board. For connection to the bus there is one 5-pin terminal (DM1). Fix the cables with the screws on the terminal, following the color code.

  • Page 36: Airzone Hydronic Production Control Board (Azx6Ccpgawi)

    Airzone hydronic production control board (AZX6CCPGAWI) For further information, see the technical datasheet. Assembly The production control board is delivered in a screwed box for surface mounting. The location and installation of this element must comply with the current electronic regulations.
  • Page 37 System search (SW1) A short press on SW1 forces the production control board to search for the systems connected to it and to set the addressing configuration. To reset the CCP, press SW1 for 10 seconds. Configuration (SW2) The SW2 microswitch configures the type of installation to be controlled by the production control board.
  • Page 38 Control relays This device has 6 relays for controlling the installation. The characteristics of the control relays are Imax 10 A at 110/230 VAC voltage free. To control higher power elements, the use of contactors of the power to be controlled is recommended. Important: Remember to connect the neutral directly from the circuit to the element to be controlled.
  • Page 39 Important: In order to optimize the production temperature of the air to water units, the following combinations will not generate air demand in the production control board: • Airzone 3.0 control gateway (AZX8GTCxxx) in the system main control boards. • Airzone control gateway - Electromechanical unit (AZX6ELECTROMEC) in system main •...
  • Page 40 Automation bus (DM1) The outdoor domotic bus allows several systems to be interconnected in order to manage all of them, using the control peripherals offered by Airzone or their integration into a higher-level control network. To connect to the bus, there is one 5-pin terminal. This system only uses bus connections. Fix the cables with the screws on the terminal, following the color code.
  • Page 41 Digital inputs The production control board is equipped with 4 digital inputs for external control of Airzone systems. These inputs are configured as normally open. For connection, the use of shielded cable is recommended. • DHW: This input activates the DHW mode, whereby all systems that are working in air heating will stop and display the DHW message on the zone thermostats.

  • Page 42: Airzone Knx Integration Gateway (Azx6Knxgtway)

    KNX bus Programming Automation bus The Airzone-KNX integration gateway is connected to the automation bus on the main control board. To do this, there is one 5-pin terminal. Fix the cables with the screws on the terminal, following the color code.

  • Page 43: Airzone Control Gateway 3 Speed Fancoil (Azx6Fancoilz)

    Airzone control gateway 3 speed Fancoil (AZX6FANCOILZ) For further information, see the technical datasheet. Assembly This device is DIN rail or wall mounted. This module is externally powered at 110/230 VAC. The location and assembly of this module must comply with current electronic regulations.
  • Page 44 Control relays The characteristics of the control relays are: Imax 10 A at 110/230 VAC voltage free. To control higher power elements, the use of contactors of the power to be controlled is recommended. 2-pipe installation 4-pipe installation AC unit bus For connection to the main control board AC unit bus there is one 4-pin terminal.

  • Page 45: Airzone Control Gateway 0-10 V Fancoil (Azx6010Voltsz)

    Airzone control gateway 0-10 V Fancoil (AZX6010VOLTSZ) For further information, see the technical datasheet. Assembly This device is DIN rail or wall mounted. This module is externally powered at 110/230 VAC. The location and assembly of this module must comply with current electronic regulations.
  • Page 46 Control relays The characteristics of the control relays are: Imax 10 A at 110/230 VAC voltage free. To control higher power elements, the use of contactors of the power to be controlled is recommended. 2-pipe installation 4-pipe installation AC unit bus For connection to the main control board AC unit bus there is one 4-pin terminal.

  • Page 47: Airzone Control Gateway Electromechanical Unit (Azx6Electromec)

    Airzone control gateway electromechanical unit (AZX6ELECTROMEC) For further information, see the technical datasheet. Assembly This device is DIN rail or wall mounted. This module is externally powered at 110/230 VAC. The location and assembly of this module must comply with current electronic regulations.
  • Page 48 Control relays The characteristics of the control relays are: 24/48 VAC voltage free. To control higher power elements, the use of contactors of the power to be controlled is recommended. The operation logic of the relays is as follows: Control relays Mode Demand 0 - W...
  • Page 49 Microswitch The operation logic of the microswitch is as follows: Meaning ON: 4 min Compressor start up time OFF: 10 s ON: permanently On except when in Stop mode Steady ventilation OFF: only if there is demand ON: 2 stages 1 or 2 stage unit OFF: 1 stage AC unit bus...

  • Page 50: Clamp-On Temperature Probe (Azx6Acctpa)

    Clamp-on temperature probe (AZX6ACCTPA) For further information, see the technical datasheet. Connects to the temperature probe (AI1) connector. Protects the AC unit from the water returning to the boiler. Temperature probe in sheath (AZX6SONDPROTEC) For further information, see the technical datasheet.

  • Page 51: Airzone Consumption Meter (Azx6Acccon)

    Ammeter clamp connection Association / Reset Antenna Power supply Ammeter clamp Ammeter clamp connection The Airzone consumption meter is an element that is connected by means of an ammeter clamp to the wiring of the outdoor unit to measure the installation's consumption.
  • Page 52 The power connection to the module is via a 2-pin terminal. Fix the cables with the screws on the terminal, following the polarity. Association To associate to the Airzone system main control board, carry out the following steps: Open the system's wireless channel. Press to associate the consumption meter.

  • Page 53: Checking The Installation

    Checking the installation Check the following items: LED status of the control elements connected. Consult the “Self-diagnostics” section on each element's technical datasheet. The main control board LED indicating the opening of motorized elements light up in sequence. Power supply to wired and wireless thermostats. Blinking Steady Switches...
  • Page 54 Meaning Status Color Reception of data from the automation bus Blinking Green Transmission of data to the automation bus Blinking Main control board activity Blinking Green Transmission of data to the connection bus Blinking Reception of data from the connection bus Blinking Green AC unit On/Off...

  • Page 55: Initial Configuration

    Initial configuration AIRZONE BLUEFACE ZERO Master: Allows the control of Languages: Select the zone associated to • • Spanish Italian this thermostat. all installation parameters. • • English Portuguese Zone: Only allows the control • • French German of the zone parameters.

  • Page 56: Airzone Think

    AIRZONE THINK Languages: Wireless Think • • Spanish Italian Open the wireless association channel. To do so, click SW1. • • English Portuguese Once opened, you have 15 minutes to perform the association. • • French German You can also open the wireless association channel through the Blueface Zero thermostats.
  • Page 57 Finish the process. Access • setup Wizard • Radiant advanced settings from • Combined Airzone Cloud and/or activate the basic function (the latter stages allows on/off, speed setting, deactivated, operation mode setting and corresponding previously temperature setting). selected control output will be disabled.

  • Page 58: Airzone Lite

    This association must be carried advanced settings menu from an Airzone out from the configuration wizard Blueface Zero thermostat. (through Airzone Cloud). The icon will blink 5 times in green to indicate that the association is correct.

  • Page 59: Checking The Initial Configuration

    AC unit-system communication: Set the Airzone system to Stop mode and verify that the AC unit turns off and dampers open.

  • Page 60: System Advanced Settings

    Press and hold AIRZONE THINK Press and Press and hold hold AIRZONE CLOUD Advanced system configuration can be performed from the Airzone Cloud application (see Airtools section of the Digital Support). The following parameters can be configured: • System parameters •...

  • Page 61: System Parameters

    By default, it displays the value 1. The system will show the free address values with a maximum value of 99. If you have address 1 and have an Airzone production control board (AZX6CCPGAWI) in the installation, you can use the Supermaster function, which imposes the operation mode of...
  • Page 62 Semi-forced cooling mode: can be changed to Ventilation / Dry / Stop mode. ◊ Semi-forced heating mode: can be changed to Ventilation / Stop mode. In installations with AZX6CCPGAWI, forced mode inputs will have priority over this function. Parameters not available in Airzone Blueface Zero thermostats...
  • Page 63 This parameter is disabled by default. • Filter maintenance warning . (Only for Airzone Cloud) It is used to enable or disable the warning, edit hours of operation or reset the filter maintenance count. • Centralized controller .

  • Page 64: Basic Mode

    By default, it is set to All/Nothing. *Note: Changing this parameter affects all motorized dampers in the installation. It is not recommended for RINT and RIC smart grilles. Parameters not available in Airzone Blueface Zero thermostats...
  • Page 65 Manual control (On/Off control visible from Airzone Cloud) • Input DI1 . (Only for Airzone Cloud) Allows you to modify the operation logic of the digital input. The configurations available are: ◊ Disabled: keeps the alarm input disabled, so that no action is taken when opening/ closing the contact.
  • Page 66 Cooling mode phases • Cooling mode phases. (Only for Airzone Cloud and if there is an air stage in any of the zones) This allows you to define the phases that act in the Cooling Mode stages in order to carry out different combinations according to the needs of the system.
  • Page 67 • IAQ ranges. (Only for Airzone Cloud and installations with AirQ Box) Allows you to define the IAQ measurement ranges (upper and lower). • AirQ Box S installed. (Only for Airzone Cloud and installations with AZX6AIQBOXS expansion modules) For the correct operation of the system, the number of expansion modules installed must be indicated.

  • Page 68: Zone Parameters

    *Note: It cannot be configured as Master if there is already another thermostat configured as such. • Output configuration. (Only for Airzone Cloud) This displays and allows you to select the control outputs associated to the thermostat. • Thermostat offset.
  • Page 69 Only for Airzone Cloud and installations with AZX6AIQSNSB. • Controlled mechanical ventilation. Allows you to control a ventilation unit through the relay or the 0-10 V output. It is enabled by default. ◊ Steady ventilation*. Allows you to act on the ventilation in the zone, regardless of whether it is in demand or not.

  • Page 70: Production Parameters

    PRODUCTION PARAMETERS Parameters available in installations with AZX6CCPGAWI. Control from Airzone Cloud. • Installation type. This allows you to configure the operation logic of the control relays of the CCP: ◊ Air-to-Water Heat Pump (by default) ◊ 2 pipes ◊...

  • Page 71: Incidences

    Incidences In the case of Airzone Blueface Zero and Think thermostats, a warning will appear on the display screen. WARNINGS Anti-freezing. This is displayed if the function is enabled. Active window. Indicates that the air conditioning has been suspended in the zone due to an open window.

  • Page 72: Errors

    IAQ7. Loss of communication between the AZX6AIQSNSB and the main control board IAQ8. AirQ Box (AZAIQBOXDCHM / AZX6AIQBOXM) not detected Lite errors In the case of Airzone Lite thermostats, if the On/Off icon blinks rapidly in red, it means communication with the main control board has been lost.
  • Page 73 Main control board status: Check that the power supply is correct. Main control board status: Correct operation of the Airzone connection bus LED. Connections: Check that the polarity of the connections to the main control board and the thermostat is correct.
  • Page 74 Error 1. Thermostat (Wireless) - Main control board This issue does not allow the zone to be controlled. Check whether the error appears on all thermostats; if it does, check that the main control board is operating properly. To resolve this issue, make the following checks: Thermostat status: Check the thermostat's signal range from the main control board by checking the Information parameter (see the section System advanced settings, System...
  • Page 75 Error 5. Open circuit in temperature probe The zone loses the room temperature measurement, leaving the zone unable to generate demand. In the event of such an incident, the device must be replaced or sent for repair. Error 6. Short circuit in temperature probe The zone loses the room temperature measurement, leaving the zone unable to generate demand.
  • Page 76 Error 8. Lite thermostat (Wireless) - Main control board The zone loses the room temperature measurement of an associated wireless Lite thermostat, leaving the zone disabled and unable to generate demand. From your Blueface Zero thermostat, check whether the Lite thermostat has lost communications. To resolve this issue, make the following checks: Power supply: Check the battery's status and, if in doubt, replace it with a new battery.
  • Page 77 Error 9. Gateway - Airzone system The system loses communication with the gateway and therefore with the AC unit. The system will open all its zones and disable control from the system's thermostats, thus allowing the AC unit to operate from the manufacturer's thermostat. To resolve this issue, make the following checks: That the gateway is properly connected to the main control board's IU port.
  • Page 78 That the AC unit is powered. To do this, check that the AC unit's thermostat is switched on. Check whether the AC unit operates properly independently of the system. To do so, disconnect the AC unit from the Airzone system and activate the unit from the AC unit's thermostat.
  • Page 79 Error 12. Webserver - Airzone system The system loses communication with the Webserver. To resolve this issue, make the following checks: Check that the Webserver is properly connected to the main control board's automation port. Check that the polarity of the connectors of the Webserver and the main control board's automation port is correct.
  • Page 80 Error 13. Control module of radiant elements - Main control board This issue does not allow the system to control the device. To resolve this issue, make the following checks: Control module of radiant elements status: Check that the power supply is correct. Control module of radiant elements and main control board status: Correct operation of the CAN bus LED.
  • Page 81 Error 15. Consumption meter - Main control board This incident doesn't allow you to measure the AC unit’s consumption. To resolve this issue, make the following checks: Signal range of the device: Check the signal range of the meter with the main control board; to do so, check the LED on the meter.
  • Page 82 Error 17. Lutron gateway - Airzone system Webserver configured as Lutron The system loses communication with the Webserver. Check that the Webserver is properly connected to the main control board's automation port (DM1). Blinking...
  • Page 83 Error 18. Dehumidifier module - Main control board This issue does not allow the system to control the device. To resolve this issue, make the following checks: Dehumidifier module status: Check that the power supply is correct. Dehumidifier module and main control board status: Correct operation of the CAN bus LED. Connection: Check that the polarity of the connections to the main control board and the dehumidifier module is correct.
  • Page 84 Error 19. Alarm jumper error The system detects that the alarm jumper is not connected and forces it into Stop mode. Check to be sure that the alarm jumper is properly connected. Error C-02. Production control board - Main control board This issue does not allow the zone to be controlled.
  • Page 85 Error C-09. Air to water gateway - Production control board The gateway loses communication with the air to water unit. Control of the system will be disabled, thus allowing the air to water unit to operate from the manufacturer’s thermostat. To resolve this issue, make the following checks: Check that the gateway is properly connected to the production control board's AC unit port.
  • Page 86 Error V01. AZCE8CM1VALR module - Main control board This issue does not allow the system to control the device. To resolve this issue, make the following checks: AZCE8CM1VALR module and main control board status: Correct operation of the CAN bus LED.
  • Page 87 Error IAQ0. AirQ Sensor (AZX6AIQSNSB) not detected This warning indicates that the AirQ Sensor (AZX6AIQSNSB) has not been detected and, therefore, Indoor Air Quality cannot be measured. Once an AirQ Sensor is connected, the error disappears. Error IAQ1. Loss of communication between the AZAIQBOXDCHM / AZX6AIQBOXM and the main control board This issue does not allow the system to control the device.
  • Page 88 (in the case of a VRF system, the warning will also be given). The Airzone system will give control to the indoor unit, so control of the air stage will be lost momentarily. Neither the radiant stage nor CCP production will be affected by the blocking.

  • Page 89: Navigation Trees

    Navigation trees AIRZONE BLUEFACE ZERO Screensaver Time and date* Zone name Room temperature Relative humidity Indoor air quality Zone status, On/Off warnings or errors *Note: If the system has Webserver, weather information will also appear. Main screen Operation mode Fan speed...
  • Page 90 Screensaver • • Time and date* Relative humidity* • • Current zone Zone status • • Room temp.* Weather information *Configurable values Touch any place on the screen Main screen Relative Operation mode ECO-Adapt Fan speed Current zone humidity Cooling Automatic Indoor air Room temp.

  • Page 91: Airzone Think

    AIRZONE THINK Screensaver Date* Control bar Zone status On/Off Main screen / Confirm *Note: If the system has Webserver, weather information will also appear. Main screen Access the main screen by pressing from the screensaver: Eco-Adapt function Operation mode Fan speed...
  • Page 92 Screensaver • • Date* Weather information* • • Current zone* Airzone • Zone status *Depending on the devices Press on connected Main screen Informative icons Capacitive buttons Operation mode ECO-Adapt Fan speed Settings menu Cooling Automatic Mode** Heating High Speed...
  • Page 93 airzonecontrol.com Marie Curie, 21 29590 Málaga Spain v 100...
