- Page 1 EN User Manual | Dishwasher EEA23200L...
-
Page 2: Table Of Contents
Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. INSTALLATION....................5 4. PRODUCT DESCRIPTION................7 5. -
Page 3: General Safety
• Children of less than 3 years of age should be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep detergents away from children. •... -
Page 4: Safety Instructions
• If the appliance has ventilation openings in the base, they must not be covered e.g. by a carpet. • The appliance is to be connected to the water mains using the new supplied hose-sets. Old hose sets must not be reused. -
Page 5: Installation
3. INSTALLATION 3.1 Building in WARNING! Refer to Safety chapters before www.youtube.com/electrolux installation. www.youtube.com/aeg For detailed installation information, see the How to install your AEG/Electrolux installation instruction supplied with the 45 cm dishwasher appliance. ENGLISH... - Page 6 820-900 818-898 3.2 Safety caps If the furniture panel is not installed, open the 5 mm appliance door carefully to avoid the risk of injury. After installation, make sure the plastic covers are locked in position. Damage or removal of the plastic covers on the sides of the door may impact the functionality of the appliance and may cause an injury.
-
Page 7: Product Description
4. PRODUCT DESCRIPTION Upper spray arms Lower basket Lower spray arm Upper basket Filters Cutlery drawer Rating plate Salt container The graphic is a general overview. For Air vent more details, refer to other chapters or documents provided with the appliance. Rinse aid dispenser Detergent dispenser 4.1 Beam-on-Floor... -
Page 8: Control Panel
5. CONTROL PANEL On/Off button / Reset button ExtraPower option button Delay start button AUTO Sense program button Indicators MY TIME program selection bar 5.1 Indicators Indicator Description ECO programme indicator. It indicates the most environmentally friendly programme selec‐ tion for a normally soiled load. Refer to "Programme selection". Rinse aid indicator. - Page 9 6.3 Options normal soil. This is the standard programme for test institutes. You can adjust the programme selection to your needs by activating options. 6.2 AUTO Sense The AUTO Sense programme automatically ExtraPower adjusts the dishwashing cycle to the type of load.
-
Page 10: Consumption Values
Consumption values Water (l) Energy (kWh) Duration (min) Programme 1)2) 30min 10.3 0.623 Pre-rinse 0.014 90min 10.4 0.858 0.754 AUTO Sense 10.5 0.942 Machine Care 0.659 The pressure and the temperature of the water, the variations of the mains supply, the options, the quantity of dishes and the degree of soil can change the values. -
Page 11: Setting Mode
How to change a setting Make sure the appliance is in setting mode. 1. Press Previous or Next until the indicator dedicated to the desired setting flashes. The light related to indicates the current setting value: • For the settings with two values (on and off), the light is either on (= the setting is on) or off (= the setting is 7.1 Setting mode... - Page 12 Water hardness German de‐ French de‐ mmol/l mg/l (ppm) Clarke de‐ Water softener grees (°dH) grees (°fH) grees level 47 - 50 84 - 90 8.4 - 9.0 835 - 904 58 - 63 43 - 46 76 - 83 7.6 - 8.3 755 - 834 53 - 57...
-
Page 13: The Rinse Aid Level
Each performed softener rinse (possible more than one in the same cycle) may prolong the programme duration by another 5 minutes when it occurs at any point at the beginning or in the middle of a programme. All the consumption values mentioned in this section are determined in line with the currently applicable standard in laboratory conditions with water hardness... -
Page 14: Before First Use
8. BEFORE FIRST USE 1. Make sure that the current level of the 5. Remove the salt around the opening of water softener agrees with the the salt container. hardness of the water supply. If not, adjust the level of the water softener. 2. -
Page 15: Daily Use
2. Pour the rinse aid in the dispenser (C) 4. Close the lid. Make sure that the lid locks until the liquid reaches the marking into position. "FILL". 3. Remove the spilled rinse aid with an absorbent cloth to prevent excessive foam formation. -
Page 16: How To Delay The Start Of A Programme
ExtraPower is not a permanent option If you cancel the delay start, you have to and must be activated every time before select the programme again. you start a programme. 9.8 How to cancel a running programme It is not possible to activate or deactivate Press and hold for about 3 seconds. -
Page 17: Hints And Tips
10. HINTS AND TIPS 10.1 General 10.2 Using salt, rinse aid and detergent Follow the hints below to ensure optimal cleaning and drying results in daily use and to • Only use salt, rinse aid and detergent protect the environment. designed for dishwasher. -
Page 18: Care And Cleaning
4. When the programme is completed, and unprotected carbon steel. This can adjust the water softener according to the cause them to crack, warp, discolour, pit water hardness in your area. or rust. 5. Adjust the released quantity of rinse aid. •... -
Page 19: Internal Cleaning
11.5 Cleaning the filters 2. Press and hold simultaneously The filter system is made of 3 parts. for about 3 seconds. The indicators flash. 3. Close the appliance door to start the programme. When the programme is complete, the indicator is off. -
Page 20: Cleaning The Lower Spray Arm
CAUTION! An incorrect position of the filters can cause bad washing results and damage to the appliance. 11.6 Cleaning the lower spray arm We recommend to clean the lower spray arm regularly to prevent soil from clogging the holes. Clogged holes can cause unsatisfactory washing results. -
Page 21: Troubleshooting
the holes. Clogged holes can cause 3. Wash the spray arm under running water. unsatisfactory washing results. Use a thin pointed tool, e.g. a toothpick, to remove particles of soil from the holes. The upper spray arms are placed under the upper basket. - Page 22 Problem and alarm code Possible cause and solution You cannot activate the appliance. • Make sure that the mains plug is connected to the mains socket. • Make sure that there is no damaged fuse in the fuse box. The programme does not start. •...
- Page 23 Problem and alarm code Possible cause and solution The temperature of the water inside • Make sure that the temperature of the inlet water does not exceed the appliance is too high or malfunc‐ 60°C. tion of the temperature sensor oc‐ •...
- Page 24 Once you have checked the appliance, WARNING! deactivate and activate the appliance. If the problem occurs again, contact an Authorised We do not recommend using the Service Centre. appliance until the problem has been completely fixed. Unplug the appliance For alarm codes not described in the table, and do not plug it in again until you are contact an Authorised Service Centre.
-
Page 25: Technical Information
Problem Possible cause and solution There are residues of detergent in the • The detergent tablet was stuck in the dispenser and was not washed dispenser at the end of the pro‐ away by water. gramme. • Water cannot wash away the detergent from the dispenser. Make sure that the spray arms are not blocked or clogged. -
Page 26: Environmental Concerns
13.1 Link to the EU EPREL database database using the link https:// eprel.ec.europa.eu and the model name and The QR code on the energy label supplied product number that you can find on the with the appliance provides a web link to the rating plate of the appliance. - Page 28 156825950-A-462023...
