Summary of Contents for Metria HT-2
- Page 1 Data Logger for High Temperatures, HT-2 Please read the User Manual carefully before use, and follow all operating and safety instructions! user manual english...
-
Page 2: Warranty
User Manual HT-2 Data Logger for High Temperatures Preface Users should read this Manual carefully, follow the instructions and procedures, and beware of all the cautions when using this instrument. Service In order to guarantee this equipment works safely and efficiently, it must receive regular maintenance. In case of any faults, do not try to repair it yourself. - Page 3 At 121°C, the operation time should not exceed 48 hours. At 134°C, the operation time should not exceed 30 minutes (0.5 hours). Caution: The logger will be HOT when removed from the sterilizer. Handle with care. Quick Guide Step 1: Connect the logger to a USB port on a Windows computer to configure it. Step 2: The logger will automatically start according to the chosen start delay time.
-
Page 4: Product Description
Product Description ① USB 2.0 plug-and-play connector. No USB driver or PC software is required. A Type-C cable is included in the package. ② LED Indicator: Status LED Indication Power OFF All LEDs are OFF. Standby The green LED blinks dimly every 5 seconds when the logger is programmed to stand by and has not yet started logging. -
Page 5: Battery Installation
To close, rotate the cover clockwise until it aligns with the marking. Battery Installation The battery is pre-installed and is replaceable but not rechargeable. It provides enough power for up to 1 million records or 18 months of use, whichever comes first. When the red LED blinks, contact the retailer where you purchased the datalogger to obtain a new battery. -
Page 6: Operation
4. Rotate the cover clockwise until it aligns with the marking. Operation NOTE: 1. Adobe Reader software is required. 2. Program the logger and generate the PDF and Excel reports at room temperature. For example, if the logger is removed from an autoclave, it should be allowed to return to ambient room temperature before generating the PDF report. - Page 7 First, use a coin to open the USB cover. Then, connect the data logger to a PC using the USB Type-C cable. The green LED will remain on while the connection with the computer is established. Connect the data logger to a PC via the USB port. The green LED will turn ON while establishing the connection with the computer.
-
Page 8: Technical Data
However, when opening the file in Microsoft Excel, a warning message may be displayed because the file is named with a “.csv” extension but the contents are similar to a “.txt” file. It can be safely opened. Technical Data Model HT-2 Temperature Sensor By a PT1000 sensor Temperature Range -40.0 ºC to 140.0 ºC (-40.0 ºF to 284.0 ºF) - Page 9 Weight Approximately 175 g Battery 1 x 3.6V Lithium battery; installed before shipment; replaceable Sampling Interval 1, 5, 10, 30 seconds, 5, 10, 30, 60, 90, 120 minutes Start Delay 0, 5, 30, 45, 60, 90, 120 minutes, 24 hours Operation Keys No keys LED Indicator...
- Page 10 Nota importante para los aparatos electrónicos vendidos en España Important note for electronic devices sold in Spain Remarque importante pour les appareils électroniques vendus en Espagne Instrucciones sobre la protección del medio ambiente y la eliminación de aparatos electrónicos: Los aparatos eléctricos y electrónicos marcados con este símbolo no pueden desecharse en vertederos.
- Page 11 www.labbox.com...
