INTRODUCTION
The PD108-420 programming remote provides IR control and setup of PDI's smart television models. It
will operate any PDI TV regardless of the TV's Bed A/B/C/D setting. Because this remote has the SETUP
button to gain full access to the TV's menus, it should not be given to patients. PDI offers other remotes
designed for patient use.
ARROW KEYS
Newer model TVs (after 2018) may not
respond to the arrow keys. If that happens,
use the following key mapping.
UPDATE to move right
MODE to move left
INDEX to move up
MIX to move down
PDI offers an overlay for the PD108-420
remote that indicates the key mapping used
by newer model TVs. The overlay part number
is PD227-298.
For newer TVs PDI recommends using the
PD108-520 remote which contains separate
arrow, volume and channel keys.
Troubleshooting
•
Install two high-quality 1.5V "AAA"
alkaline batteries. Don't mix old batteries
with new batteries.
•
Remove batteries when you won't use
the remote for a long time. Liquid
leakage from old batteries may cause
remote failure.
•
Make sure there are no objects between
the remote control and the TV's sensor
that might block the signal.
•
Don't place the remote control near a
heater or in a damp place. Strong impact
to the remote control may cause
operational failure.
•
Signal from the remote control may be
disturbed by sun light or other bright
lights. In this case, darken the room or
move the TV.
PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH 1-800-628-9870 FX 937-743-5664
MODEL NUMBER:
PD108-420
TV Programming Remote Control
®
Document Number:
PD196-265R2
Page 1 of 2
PD227-298
overlay
