Related Manuals for Discount Equipment PANTHER 5280
Summary of Contents for Discount Equipment PANTHER 5280
- Page 1 5280 PANTHER WALK-BEHIND SCRAPER ® OPERATING & SERVICE MANUAL Read Manual Before Operating or Servicing Machine 401871 Rev J...
- Page 2 TO PURCHASE THIS PRODUCT PLEASE CONTACT US Equipment Financing and Extended Warranties Available Discount-Equipment.com is your online resource for commercial and industrial quality parts and equipment sales. 561-964-4949 visit us on line @ www.discount-equipment.com Select an option below to find your Equipment We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,...
-
Page 3: Table Of Contents
Table of Contents Table of Contents ........................................3 Features & Specifications ...................................... 4 Safety ............................................5 General Rules for Safe Operation ................................5 Walk-Behind Scraper Safety Guidelines ............................... 6 Hydraulic Safety......................................7 Electrical Practices ....................................... 8 Components and Assembly ....................................10 Transport ........................................ -
Page 4: Features & Specifications
Features and Specifications Forward Hydraulic Control Speed Control Knob Lifting Bail Eyebolts Saddle Weight Debris-Deflecting Front Weight FEATURES Forward Hydraulic Control- Safely propels the scraper forward. Saddle Weight- Provides additional down pressure and traction for tough jobs. Lifting Bail Eyebolts- Eases loading/unloading. Speed Control Knob - Controls the rate the machine travels forward. -
Page 5: Safety
Safety GENERAL RULES FOR SAFE OPERATION Before use, anyone operating or performing maintenance on this equipment must read and understand this manual, as well as any labels pack- aged with or attached to the machine and its components. Read the manual carefully to learn equipment applications and limitations, as well as potential hazards associated with this type of equipment. -
Page 6: Walk-Behind Scraper Safety Guidelines
Safety Safety WALK-BEHIND SCRAPER SAFETY GUIDELINES Before use, anyone operating this equipment must read and understand these safety instructions. Scraping Beware of hidden obtrusions. Watch out for hidden dangers and protrusions in flooring. Do not use on largely uneven surfaces. Observe location of electrical supplies and extension cords. -
Page 7: Hydraulic Safety
Safety HYDRAULIC SAFETY Maintaining a Safe Work Environment Establishing a safe work environment in and around your hydraulic equipment is extremely important. The easiest and most effective way to avoid problems is to make sure associates understand their equipment, know how to operate the machines safely, and recognize the dangers if handled carelessly. -
Page 8: Electrical Practices
Safety ELECTRICAL PRACTICES WARNING: ELECTRICAL CORDS CAN BE HAZARDOUS. MISUSE CAN RESULT IN FIRE OR DEATH BY ELECTRICAL SHOCK. READ CAREFULLY AND FOLLOW ALL DIRECTIONS. CAUTION: ALWAYS FOLLOW APPLICABLE ELECTRICAL CODES, STANDARDS AND/OR REGULATIONS. CONSULT YOUR LOCAL ELECTRICAL AUTHORITY OR A LICENSED ELECTRICIAN BEFORE ATTEMPTING TO MODIFY AN ELECTRICAL INSTALLATION. ENSURE THAT CIRCUIT AND GROUND FAULT PROTECTION DEVICES AND ALL OTHER ELECTRICAL SAFETY EQUIPMENT ARE FUNCTIONING PROPERLY. - Page 9 Safety ELECTRICAL PRACTICES (CONT’D) How to Use This Table Determine your supply voltage. Determine the total length of your cord including all extension cords. Determine the maximum amp draw for your machine. Trace your voltage across the top of the table to the first length that is greater than or equal to your cord length. Follow the column down to the first row that contains a maximum amp draw greater than or equal to yours.
-
Page 10: Components And Assembly
Components and Assembly TRANSPORT Lifting Bail The lifting bails make loading/unloading easier when unable to use a ramp. Place rope, hook system, or chain through eyelets located on top of machine. Raise machine with a fork lift or winch. Slowly lower to desired location. Ramp Loading FIG. -
Page 11: Preparing Machine For Job
Components and Assembly PREPARING MACHINE FOR JOB WARNING: BLADES ARE SHARP, USE EXTREME CAUTION WHEN HAN- DLING. ALWAYS WEAR GLOVES AND EYE PROTECTION. NEVER CHANGE CUTTING HEAD OR SERVICE BLADES WHILE MACHINE IS RUNNING. Blade Setting Note: This machine is designed to remove soft good materials. •... -
Page 12: Operation
Operation OPERATING CONTROLS (FIGURE 7) ON/OFF Speed Control Switch Forward • Turning speed control knob clockwise (towards turtle) decreases forward speed. Hydraulic • Turning speed control knob counterclockwise (towards rabbit) increases forward Control speed. • Speed control knob can be adjusted while machine is running. Forward Hydraulic Control •... -
Page 13: Application Setup
Operation APPLICATION SETUP VCT Tile Never use a blade wider than the size of the tile being removed. If goods being removed still do not come up clean or machine jumps on top of goods, reduce blade size until proper blade size is found or use a smaller portion of the blade. Pure Vinyl Rubber Tile Goods will need to be scored down to 10-12”... -
Page 14: Troubleshooting Guide
Troubleshooting Guide Problem Cause Solution No forward movement. Damaged belt. Remove front cover plate and inspect belt. Damaged speed control valve. Inspect speed control valve. Turn counter-clockwise to open valve. Motor shuts off or won’t start. Inspect ON/OFF switch and capacitor. 401871_5280_RevJ... -
Page 15: Maintenance
Maintenance WARNING: ALWAYS UNPLUG MACHINE BEFORE PERFORMING MAINTE- NANCE. WHEEL REMOVAL Examine back of wheels to see if debris is built up. Use a flashlight if needed. Unplug machine; place block under machine between wheels. Securing Screw Use 5/16” hex wrench to remove wheel securing screw (Figure 10). Remove wheel securing cap;... -
Page 16: Control Valve Replacement
Maintenance CONTROL VALVE REPLACEMENT Follow procedure to change fluid in order to drain the tank. Re-place drain plug and filler port cap. Disconnect valve plunger from control linkage. Mark the placement of the four hoses so they can be returned to their original positions. Disconnect and remove the four hoses from valve body. -
Page 17: Parts List And Diagrams
Parts List and Diagrams OVERALL MACHINE 11, 12 5, 13 PART# DESCRIPTION PART# DESCRIPTION 1 400330 WHEEL, DRIVE, LIGHT DUTY, COMPLETE 2 10 72837 CLAMP, CABLE, VINYL COATED, 5/16 2 5280-136 COVER, BLADE 11 6280-161B PLUG, VENT, FILLER CAP 3 5280-137W WRENCH, BLADE 12 6280-161D PLUG, FILLER PORT... -
Page 18: Drive Components
Parts List and Diagrams DRIVE COMPONENTS PART# DESCRIPTION PART# DESCRIPTION 1 5280-1 CHAIN, DRIVE, 40 STRAND 13 5280-129 ECCENTRIC 2 5280-2 SPROCKET, 40BS13 3/4 14 5280-132C PULLEY, PUMP 3 5280-3 SPROCKET, MOTOR, 40BS12X1 15 73903 KEY, 3/16X3/16X2-1/4 4 5280-4 BELT, PUMP DRIVE 16 5280-139 BRACKET, HANDLE ADJUSTMENT 5 74104... -
Page 19: Motor Parts
Parts List and Diagrams MOTOR PARTS PART# DESCRIPTION 1 72353 MOTOR, 1 HP, 116265 2 5280-151 CAPACITOR, MOTOR 3 62182 COVER, CAPACITOR, LEESON 4 401698 BOX, JUNCTION, MOTOR, 3” X 3.3” 5 401869 GASKET, FRAME, JUNCTION BOX, 3X3.33” 6 401699 COVER, JUNCTION BOX, MOTOR, 3”... -
Page 20: Hydraulic Tank
Parts List and Diagrams HYDRAULIC TANK PART# DESCRIPTION 1 5280-120 HOSE, HYDRAULIC, 3/8 X 9.25, 90F/90F 2 5280-162-SV HYDRAULIC TANK BODY, SILVER VEIN 3 6280-214 PLUG, TANK 4 6280-161D HYDRAULIC TANK FILLER CAP 5 6280-162G MAGNET, TANK (NOT SHOWN) 6 70601 STRAINER, TANK MOUNTED 7 72816 FITTING, ELBOW, 90 DEGREE, 3/8”... -
Page 21: Back Of Machine
Parts List and Diagrams BACK OF MACHINE (DOMESTIC SHOWN) PART# DESCRIPTION 1 5280-139C ISOLATOR, HANDLE VIBRATION 2 6280-168 CORD, POWER, SJTOW, 12/3, NEMA 5-15, YELLOW, 27IN 3 72612* ASSEMBLY, CORD, HANDLE, 14/3, NEMA L5-15R, 28” 4 5280-172A LEVER, HANDLE 5 74650 BOLT, HEX FLANGE M10-25 6 73502* STRAIN RELIEF, STRAIGHT 1/2 INCH, .3376-.5686... -
Page 22: Handle
Parts List and Diagrams HANDLE (DOMESTIC SHOWN) PART# DESCRIPTION PART# DESCRIPTION 1 6280-117 FITTING, PUMP 16 5700-76 HOSE, HYDRAULIC, 3/8 X 26, F/F 2 5280-167 HANDLE BODY 17 6280-207 SWITCH, ON-OFF 3 5280-167B COVER, HANDLE BODY 18 6280-215 VALVE BLOCK ASSEMBLY 4 5280-167C PLATE, HANDLE SWITCH 19 73002... -
Page 23: Handle (International Only)
ITEM PART NUMBER DESCRIPTION QTY. NOTES Parts List and Diagrams 404583-028 Assembly, Cord, Handle, 2.5mm/3, NEMA L6-15R, 28in 404313 Cover, Handle, Safety Switch 404172 Assembly, Cord, Power, 1.5mm/3, EU1-16P, 15in HANDLE (INTERNATIONAL ONLY) 404180 Switch, Rocker Breaker, 10A, 220-240V, UVR 403281 Nut, Keps, M4-0.7, Clear Zinc ITEM... -
Page 24: Labels
Parts List and Diagrams LABELS PART# DESCRIPTION 1 403357-XX* KIT, LABELS, 5280, [LANGUAGE] 2 402627 LABEL, PRIVATE, 1.5 X 2 (5280-23XXXX ONLY) 3 402628 LABEL, PRIVATE, 3.5 X 5.5 (5280-23XXXX ONLY) *Suffix (-XX) denotes language: None=English; -FR=French; -NL=Dutch; -DE=German. 401871_5280_RevJ... -
Page 25: Wiring Diagrams
Parts List and Diagrams WIRING DIAGRAM (120V DOMESTIC) 5280 WIRING DIAGRAM PG 1 120V VERSION T-F11 T-F12 2.5mm-BRN 120V T-F21 T-F22 2.5mm-BLU SUPPLY ON/OFF SWITCH 2.5mm-GRN/YEL T-M1 T-F1 GROUND 401871_5280_RevJ... - Page 26 Parts List and Diagrams WIRING DIAGRAM (230V INTERNATIONAL) 5280 WIRING DIAGRAM 230V VERSION PG 2 T-F11 T-F12 2.5mm-BRN 230V T-F21 T-F22 2.5mm-BLU SUPPLY ON/OFF SWITCH 2.5mm-GRN/YEL UNDERVOLTAGE PROTECTED T-R1 T-R2 GROUND GROUND TITLE: REVISIONS NAME DATE DESCRIPTION DATE 5280 WIRING DIAGRAMS DRAWN BY 2/25/2021 INITIAL RELEASE...
- Page 27 Parts List and Diagrams WIRING DIAGRAM (100V-110V INTERNATIONAL) 5280 WIRING DIAGRAM 100-110V VERSION PG 3 T-F11 T-F12 2.5mm-BRN 100V - 110V T-F21 T-F22 2.5mm-BLU SUPPLY ON/OFF SWITCH 2.5mm-GRN/YEL UNDERVOLTAGE PROTECTED T-R1 T-R2 GROUND GROUND 401871_5280_RevJ...
-
Page 28: Hydraulics
Parts List and Diagrams HYDRAULICS BLEED HYDRAULIC VALVE FWD. PRESS. FLOW TO TOP OF TANK. FWD. PRESS. FLUID FLOW TANK HYDRAULIC MOTOR SUCTION (NEGATIVE PRESS.) POSITIVE HYD. PRESSURE PUMP 401871_5280_RevJ... - Page 29 TO PURCHASE THIS PRODUCT PLEASE CONTACT US Equipment Financing and Extended Warranties Available Discount-Equipment.com is your online resource for commercial and industrial quality parts and equipment sales. 561-964-4949 visit us on line @ www.discount-equipment.com Select an option below to find your Equipment We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,...
