Thank you for purchasing this highly advanced fishing aid. Before you use it, please take a few
moments to read these instructions..
Charging Socket
Red LED
Drain Hole
Guard
Neck Strap
Mounting
Joystick
(Lights & Hopper
Release)
Sliding Trims
Power LEDs
Operation Instructions:
1. There is no external boat aerial as it is fitted internally
2. The aerial on the transmitter has it's optimum operating position when the aerial tip is vertical. The transmitter is
supplied with, and will operate for 24 hours, using 4 off Heavy Duty AA batteries ie. Duracell.
The batteries supplied are NOT rechargeable.
When the battery level falls to an unacceptable level an alarm will sound and the LED's will flash.
3. The transmitter features sliding trims.
result in the boat possibly losing some operations or not working correctly.
4. Turn the Transmitter "ON".
5. Now turn "ON" the boat using the "ON/OFF" button. The navigation LED's will flash for 5-10 seconds while the boat
registers itself to the transmitter and then the LED's will remain "ON" or will go "OFF" depending where the left hand
joystick is vertically positioned.
6. When opening the door using the transmitter (not manually) then you
the door catch to return to it's natural position, if you force it's return manually, then you will stretch the door release
mechanism.
7. To position your rig in the boat, pass the rig under the back of the boat and up through the open space behind the hopper
compartment. Place the rig inside the hopper ensuring that the line passes through the space in the line guards.
Load the rest of you free offering bait into the hopper.
8. Place the boat in the water and using the right-hand joystick steer the boat to it's destination. At the desired position
release the bait and your rig by moving the left-hand joystick left or right.
Angling Technics Limited
Technicat MkII -"L"
On/Off Button
Green LED
Drain Hole
Blue
LEDs
Guard
Propellers
Aerial
Joystick
(Directional steering)
Sliding Trims
Power On/Off
Be very careful to ensure the sliding trims are not moved as this will
Line Guides
Note: When operating the boat the digital trims
MUST
MUST
Battery Boxes
Hopper Door
always be set centrally.
wait approximately 15-20 seconds for
White LEDs
Spotlight
Advertisement
Related Manuals for Angling Technics Technicat Mk II L
Summary of Contents for Angling Technics Technicat Mk II L
- Page 1 Angling Technics Limited Technicat MkII -”L” Thank you for purchasing this highly advanced fishing aid. Before you use it, please take a few moments to read these instructions.. Battery Boxes Line Guides Charging Socket On/Off Button White LEDs Red LED...
- Page 2 9. When the hopper is released the boat LED’s will go “off” (provided you are using the boat with the navigation lights “ON”) until the joystick is back in the central position and the hopper has opened. The hopper can be operate independently of the other controls so you can have the option to release the bait while the boat is moving.
- Page 3 Batteries & Charging: There is a mains powered charger supplied with the boat. The Boat charger is capable of charging the boats batteries from fully discharged to fully charged in 7-8 hours. Please refer to the ALTechnologies “charging, storage & handling Lithium batteries” included with the batteries.
- Page 4 Angling Technics Ltd Resetting the steering on the following boats. Microcat “HD”, Technicat MkII & Procat MkIV If the boat is not travelling straight when the doors are closed and the boat is empty please follow the instructions below to reset the steering.
