  • Page 1 CS 2245 II CS 2245S II CS 2250S II Operator′ ′ ′ ′ s manual English Please read the operator’s manual carefully and make sure you understand the instructions before using the machine.
  • Page 7: Key To Symbols

    KEY TO SYMBOLS Symbols on the machine: Refuelling. WARNING! Chain saws can be dangerous! Careless or incorrect use can result in serious or fatal injury to the Adjustment of the oil pump. operator or others. Please read the operator’s manual carefully and make sure you understand the instructions before using the Other symbols/decals on the machine refer to special...
  • Page 8: Table Of Contents

    CONTENTS Contents KEY TO SYMBOLS Symbols on the machine: ........7 Symbols in the operator’s manual: ......7 CONTENTS Contents ............... 8 INTRODUCTION Dear Customer, ............. 9 WHAT IS WHAT? What is what on the chain saw? ......9 GENERAL SAFETY PRECAUTIONS Before using a new chain saw ......
  • Page 9: Introduction

    17 Bar tip sprocket appearance of products without prior notice. 18 Guide bar 19 Spike bumper 20 Chain catcher 21 Chain tensioning screw (CS 2245 II) 22 Clutch cover (CS 2245 II) 23 Right hand guard 24 Throttle trigger 25 Throttle lockout...
  • Page 10: General Safety Precautions

    GENERAL SAFETY PRECAUTIONS Before using a new chain saw WARNING! Never allow children to use or be in the vicinity of the machine. As the • Please read this manual carefully. machine is equipped with a spring- • (1) - (112) refer to figures on p. 2-6. loaded stop switch and can be started by low speed and force on the starter •...
  • Page 11: Always Use Common Sense

    GENERAL SAFETY PRECAUTIONS Always use common sense (2) carried out correctly and if service and/or repairs are not carried out professionally. If you need further information It is not possible to cover every conceivable situation you please contact your nearest service workshop. can face when using a chain saw.
  • Page 12 GENERAL SAFETY PRECAUTIONS designed to be activated by the inertia in the kickback control (B). When you release the handle the throttle direction. (7) control and the throttle lockout both move back to their original positions. This arrangement means that the If the kickback is less violent or the kickback zone of throttle control is automatically locked at the idle setting.
  • Page 13: Cutting Equipment

    • Avoid increasing vibration levels. a bar and chain combinations recommended by Husqvarna. See instructions under the heading Technical General rules Data for a list of replacement bar and chain combinations we recommend.
  • Page 14: Sharpening Your Chain And Adjusting Depth Gauge Setting

    (26) one side first, then turn the chain saw over and file the teeth on the other side. CS 2245 II • File all the teeth to the same length. When the length of the cutting teeth is reduced to 4 mm (5/32") the...
  • Page 15: Lubricating Cutting Equipment

    GENERAL SAFETY PRECAUTIONS • Raise the tip of the bar and stretch the chain by Filling with chain oil tightening the chain tensioning screw using the • All our chain saws have an automatic chain lubrication combination spanner. Tighten the chain until it does system.
  • Page 16 GENERAL SAFETY PRECAUTIONS Checking wear on cutting equipment WARNING! Most chain saw accidents happen when the chain touches the operator. Wear personal protective equipment. See Check the chain daily for: instructions under the ”Personal • Visible cracks in rivets and links. protective equipment”...
  • Page 17: Fitting The Bar And Chain

    Hold up the bar tip and tighten the bar knob by turning the knob clockwise. (33) CS 2245 II When fitting a new chain, the chain tension has to be •...
  • Page 18: Fuel

    FUEL HANDLING Fuel Mixing ratio 1:50 (2%) with JONSERED two-stroke oil. Note! The machine is equipped with a two-stroke engine 1:33 (3%) with oils class JASO FB or ISO EGB formulated and must always be run using a mixture of petrol and two- for air-cooled, two-stroke engines.
  • Page 19: Fueling

    FUEL HANDLING Fueling Transport and storage • Always store the chain saw and fuel so that there is no risk of leakages or fumes coming into contact with sparks or naked flames from electrical equipment, electric motors, relays/switches, boilers and the like. •...
  • Page 20: Starting And Stopping

    STARTING AND STOPPING Starting and stopping Pull the starter handle, 5: Grip the front handle with your left hand. Hold the chain saw on the ground by placing your right foot through the rear handle. (51) WARNING! Note the following before starting: Pull the starter handle with your right hand and pull out the starter cord slowly until you feel a resistance (as the...
  • Page 21: Working Techniques

    WORKING TECHNIQUES Before use: (55) Take great care when removing small branches and avoid cutting bushes (i.e. cutting many small branches Check that the chain brake works correctly and is not at the same time). Small branches can be grabbed by damaged.
  • Page 22: Basic Cutting Technique

    WORKING TECHNIQUES saw chain and be thrown towards you. Even if this Terms does not need to be a danger, you may be surprised Cutting = General term for cutting through wood. and lose control of the saw. Never saw stacked logs or Limbing = Cutting branches off a felled tree.
  • Page 23: Tree Felling Technique

    WORKING TECHNIQUES risk that the chain will touch the ground when you finish the tree has no damaged or dead branches that might the cut. (68) break off and hit you during felling. Cut all the way through the log from above. Avoid letting The main point to avoid is letting the tree fall onto another the chain touch the ground as you finish the cut.
  • Page 24: Freeing A Tree That Has Fallen Badly

    WORKING TECHNIQUES Set the spike bumper (if one is fitted) just behind the felling Never cut straight through a tree or branch that is in hinge. Use full throttle and advance the chain/bar slowly tension! into the tree. Make sure the tree does not start to move in If you must cut across tree/limb, make two to three cuts, the opposite direction to your intended felling direction.
  • Page 25: Maintenance

    MAINTENANCE General Checking, maintaining and servicing chain saw safety The user must only carry out the maintenance and service work described in this Operator's Manual. More equipment extensive work must be carried out by an authorized service workshop. Note! All service and repair work on the machine Carburettor adjustment demands special training.
  • Page 26: Muffler

    MAINTENANCE Throttle lockout Muffler Never use a machine that has a faulty muffler. • Make sure the throttle control is locked at the idle setting when the throttle lockout is released. (95) Regularly check that the muffler is securely attached to the machine.
  • Page 27: Air Filter

    MAINTENANCE Tensioning the recoil spring An air filter that has been in use for a long time cannot be cleaned completely. The filter must therefore be replaced • Hook the starter cord in the notch in the pulley and with a new one at regular intervals. A damaged air filter turn the starter pulley about 2 turns clockwise.
  • Page 28: Turbo Air Cleaning" Centrifugal Cleaning

    MAINTENANCE Cylinder cover (directs cold air over the cylinder). (110) Clean the cooling system with a brush once a week, more often in demanding conditions. A dirty or blocked cooling system results in the machine overheating which causes damage to the piston and cylinder. ”Turbo Air Cleaning”...
  • Page 29: Maintenance Schedule

    MAINTENANCE Maintenance schedule The following is a list of the maintenance steps that must be performed on the machine. Most of the items are described in the Maintenance section. Daily maintenance Weekly maintenance Monthly maintenance Check the brake band on the chain brake for wear.
  • Page 30: Technical Data

    TECHNICAL DATA Technical data CS 2245 II CS 2245S II CS 2250S II Engine Cylinder displacement, cm 45,7 45,7 50,2 Cylinder bore, mm Stroke, mm Idle speed, rpm 2500-2700 2500-2700 2500-2700 Power, kW/ rpm 2,1/9000 2,1/9000 2,4/9000 Ignition system NGK BPMR 7A/...
  • Page 31: Guide Bar And Saw Chain Combinations

    TECHNICAL DATA Guide bar and saw chain combinations The following cutting attachments are approved for the models Jonsered CS2245 II, CS2245e II and CS 2250S II. Guide bar Saw chain Length, drive links Length, inch Pitch, inch Gauge, mm Max. nose radius Type (no.) 0,325...
  • Page 32: Ec Declaration Of Conformity

    Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: +46-36-146500, declares under sole responsibility that the chain saws for forest service Jonsered CS 2245 II, CS 2245S II and CS 2250S II from 2016’s serial numbers and onwards (the year is clearly stated in plain text on the type plate with subsequent serial number), are in conformity with the requirements of the COUNCIL’S DIRECTIVES:...
