Counterflow Gas or Oil Heating Appliance
OWNER'S MANUAL & INSTALLATION INSTRUCTIONS
CMF80-PG Convertible (65, 75, and 90 KBTU/H Inputs),
CMF 100-PG (90 KBTU/H Input)
CMF80-PO Convertible (65, 75, and 90 KBTU/H Inputs),
CMF 100-PO (90 KBTU/H Input)
Read all instructions carefully before beginning the installation. Read all labels and tags on the furnace
carefully and follow all precautions outlined on those labels and tags.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
WARNING:
Improper installation, alteration, service or
maintenance can cause injury or property
damage. Refer to this manual for assistance or
consult a qualified installer, service agency, or
the gas supplier for additional information.
FOR YOUR SAFETY
WHAT TO DO IF YOU
SMELL GAS
• Do not try to light any appliance.
• Do not touch any electric switch; do not use any
phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire
department.
Rated
CFM-PG
BTUH
80 CONV.
Input
75,000
Output
56,000
GENERAL
CMF furnaces are high quality, direct vent furnaces used
for manufactured housing, recreational vehicle, and
residential† applications. These furnaces are offered
in either power gas (designated by PG) or power oil
(designated by PO) models. The power gas models are
de- signed for operation with either natural or pro- pane
(LP) gas.
CFM-PO
CFM-PG
80 CONV.
100
75,000
90,000
60,000
68,000
The CMF series is convertible from power oil to power
gas, and vice versa. Furthermore, the firing rate of the
CMF80 Convertible Series can be changed using a certified
NORDYNE conversion kit field-installed by a qualified
service technician. Refer to the "Firing Rate Conversion"
section later in these instructions for more information on
the firing rate change.
These furnaces are certified to the UL307 standards (UL
307A for oil models; UL 307B for gas models), and can
be installed in a variety of applications, as shown in Table
1. This furnace is not to be used for temporary heating of
buildings or structures under construction.
This furnace must be installed by a qualified
installing agency and in accordance with
applicable local codes and ordinances that
govern this type of equipment. Failure to properly
install the furnace, base assembly, and venting
system as described herein may damage the
equipment and/or the home, can create a fire
or asphyxiation hazard, violates U.S. listing
requirements, and will void the warranty. This
furnace is NOT approved for installation with
split system air conditioning. Use a NORDYNE
packaged air conditioning system.
CFM-PO
100
90,000
72,000
WARNING:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMF80-PG and is the answer not in the manual?

Questions and answers

Summary of Contents for Nordyne CMF80-PG

  • Page 1 Counterflow Gas or Oil Heating Appliance OWNER’S MANUAL & INSTALLATION INSTRUCTIONS CMF80-PG Convertible (65, 75, and 90 KBTU/H Inputs), CMF 100-PG (90 KBTU/H Input) CMF80-PO Convertible (65, 75, and 90 KBTU/H Inputs), CMF 100-PO (90 KBTU/H Input) Read all instructions carefully before beginning the installation. Read all labels and tags on the furnace carefully and follow all precautions outlined on those labels and tags.
  • Page 2: Installation Requirements

    System Required Used Exhausted By Manufactured Housing MA-100 or MA-200 NORDYNE SRJ or Recreational Vehicle Universal Base Roofjack Only MA-100 or MA-200 NORDYNE SRJ Roofjack † Residential Universal Base or an Existing Chimney* CB-200A Cottage NORDYNE SRJ Roofjack Residential † Base...
  • Page 3 When unsure about combustion air supply availability, of Oil-Burning Equipment), and NFPA 211 (Chimneys, a direct vent system should be used. For small rooms, Fireplaces, Vents, and Solid Fuel-Burning Appliances). confined spaces, tight construction or similar situations in which the combustion air requirements of the furnace WARNING: might not be met, a direct vent system must be used.
  • Page 4 Improperly sized venting systems can result in the formation of condensate, leakage, spillage, et cetera. Refer to the ANSI Z223.1/NFPA 54, (National Fuel Gas Code), and ANSI/NFPA 31( Installation of Oil Burning Equipment) for correcting any improperly operating venting system. The following steps shall be followed with each appliance connected to the venting system placed in operation, while any other appliances connected to the venting system are...
  • Page 5: Installer Information

    INSTALLER INFORMATION IMPORTANT SAFETY INFORMATION ALL MODELS CLOSET ALCOVE INSTALLER: Please read all instructions before servicing 6" 18" ront this equipment. Pay attention to all safety warnings and 0" 0" any other special notes highlighted in the manual. Safety 0" 0"...
  • Page 6 (NFPA 90A), Standard for Installation of Residence Type provides an access door for future installation of Warm Air Heating and Air Conditioning Systems (NFPA NORDYNE air conditioning or heat pump coils on top 90B), and all applicable local codes. NFPA publications of the furnace.
  • Page 7: Unconditioned Spaces

    Unconditioned Spaces All duct work passing through unconditioned space must be properly insulated to minimize duct losses and prevent condensation. Use insulation with an outer vapor barrier. Refer to local codes for insulation material requirements Closed-Off Spaces Living space not served by, and closed off from the return air ducts to the furnace (by doors, sliding partitions, and other means) must be provided with permanent, uncloseable openings in the doors or partitions to allow air to return to...
  • Page 8: Optional Equipment

    FURNACE INSTALLATION NOTE: Since all installations are different, the sequence of these steps may differ from the actual installation. These installation procedures are suggested for typical furnace installations. Only qualified HVAC technicians should install this furnace. General Information The E3 electric furnace is designed only for indoor installations and can be readily connected to the high static duct system of a home.
  • Page 9 Figure 5. Cut-Out Dimensions for Downflow Figure 4. Cut-Out Dimensions for Upflow Furnaces Furnaces Locating & Cutting Floor Openings 4. Measure from the top of the floor down to the top of the supply air duct to obtain the depth of the floor cavity. Floor cut-outs must be carefully located to avoid misalignment of the furnace and air duct.
  • Page 10: Standard Duct Connector Installation

    NOTE: Requirements for sealing ductwork vary DUCT CONNECTOR from region to region. Consult with local codes for IF FLOOR CAVITY TYPE & PART NUMBER “X” IS: requirements specific to your area. STANDARD DUCT SCREW DOWN 7/8” / (22) 901987A 904008 2”...
  • Page 11: Round Duct Connector Installation

    Figure 10. Narrow Ducts Figure 12. Alcove Installation Closet Installation For proper air circulation, closet installations require a return air grill installed in the door or a partially louvered door across the opening. For clearances 6” or greater, the Figure 11. Round Duct Connector Installed closet must have an open free area of 235 in minimum.
  • Page 12 Upflow Furnaces equivalent method of securing the rear of the unit may be used as long as it prevents displacement during The following steps describe installation instructions for transport if used in a manufactured home. an overhead supply duct system with a return air system that can be either over the floor (unducted) or through NOTE: The furnace does not need to be positoned the floor (ducted).
  • Page 13 ELECTRICAL WIRING WARNING: ELECTRICAL SHOCK, FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury or property damage. Improper servicing could result in dangerous operation, serious injury, death or property damage. • Before servicing, disconnect all electrical power to furnace.
  • Page 14: Connecting Supply Service Wires

    • Circuit breakers installed in this unit provide short- circuit protection of the internal wiring and serve as a disconnect. The circuit breakers DO NOT provide over-current protection of the supply wiring and may be sized larger than the branch circuit protection. Overcurrent protection of the supply wiring is provided by the breaker in the distribution panel and must be sized as shown in...
  • Page 15: Changing Blower Speed

    Blower Installation PLUG / RECEPTACLE 1. Turn off all electrical supply circuits to the furnace at POSITION the main service panel. Low Med-LO Med-Hi High peed lower 2. Remove furnace front door and switch furnace circuit Yellow Blue Black ontrol lower breaker(s) to OFF.
  • Page 16 FIGURES & TABLES Figure 18. E3 Furnace Components...
  • Page 17 Figure 19. E3 Furnace Physical Dimensions Figure 20. E3 Furnace Upflow Stand Dimensions...
  • Page 18: Electrical Data

    Electrical Data Figure 21. E3EB Thermostat Connection FURNACE MODELS E3EB- 010H 012H 015H 017H 020H 023H 023H 5-TON 35,000 41,000 53,000 57,000 70,000 75,000 75,000 ated eating utput See note & B 10.4 12.0 15.4 16.6 20.4 22.0 22.0 attS otal kw eating lementS...
  • Page 19 MAXIMUM MODEL MINIMUM LOW VOLTAGE SUPPLY TOTAL OVER- NUMBER CIRCUIT THERMOSTAT CIRCUIT AMPERES CURRENT E3EB- AMPACITY WIRE SIZE RATING 010H Single 44.6 Single 51.2 2-Wire system 012H Dual "A" 27.1 maximum wire lengths: Dual "B" 24.2 24 Ga. = 55' 22 Ga.
  • Page 20: Wiring Diagrams

    Wiring Diagrams Figure 22. E3EB-010H Models...
  • Page 21 Figure 23. E3EB-012H Models...
  • Page 22 Figure 24. E3EB-015H & E3EB-017H Models...
  • Page 23 Figure 25. E3EB-020H, E3EB-023H, & E2EB-015HBR Models...
  • Page 24: Proposition 65 Warning

    Return these instructions to the customer’s package for future reference. Complies with H.U.D. Manufactured Home Construction & Safety Standards. Specifications & illustrations subject to change without notice or incurring obligations (02/25). 10500840 O’Fallon, MO, © Nordyne LLC 2025. All Rights Reserved. (NEW)
