Dolphin Velocity ECO BC2002W User Manual

BC2002W
DOLPHIN ECO HAND DRYER
› Quality stainless steel body with all metal back plate for excellent vandal
resistance
› Very low operating power saving 80% or more of user's energy costs
› Infra red self adjusting sensor
› Heater on/off switch and adjustable airflow giving the potential for even
greater energy savings
› Dries hands in only 12-15 seconds with heater and full speed – reducing
CO emissions drastically
2
› Outlet temperature 55ºC (131ºF) at 25ºC (77ºF) ambient temperature
with heater on and dryer at full speed
› Three year limited warranty
› IPX1 rated
› Class 1 rated isolation
› Average Reuse Rate under WEEE Directive: 78%
› Average Recovery Rate under WEEE Directive: 96%
› Complies with Ska rating criteria
› Unit should be mounted to give no less than 300mm clearance from the
bottom of the unit to the nearest surface below
All manuals and user guides at all-guides.com
246
145
HEIGHT 230
MM
WIDTH 246
MM
PROJECTION 145
MM
PRODUCT CODES
› Stainless steel version of this product
PLEASE NOTE: We strongly recommend that the surfaces
beneath and to either side of this dryer allow regular cleaning
(such as smooth cleanable paint, tile, Perspex, stainless steel
etc) to prevent staining from the water blown from users
hands. New generation high speed dryers such as this are
designed to blow the water off the hands so consideration
like this needs to be given to deal with the water deposits.
TECHNIC AL HELPLINE 01424 202224
DOLPHINSOLUTIONS.CO.UK
BC2002
