- Page 1 OPERATOR INSTRUCTION COMPACT Hydraulic broom From serial No: 5013 Box 924 S-591 29 Motala Sweden • Tel + 46 141-22 41 00 • Fax + 46 141-22 41 90 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 5/4/06...
-
Page 2: Table Of Contents
• Check that the carrier is appropriate to the Mounting of sweeper roll attachment (hydraulic flow, stability etc.) When ordering spare parts or by other contacts with Holms or your local dealer, always inform about the attachment type and series No. This number you will find on the machine plate. -
Page 3: Product Facts
Weight incl. std brushes without 120 kg + 55 kg/m bracket ca Weight incl. rubber brushes, 280 kg without bracket Max oil flow 130 l/min 130 l/min Max return pressure 140 Bar 140 Bar © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 5/4/06... -
Page 4: Generally About The Sweeper
The brush is made for sweeping related to digging, cleaning containers/railway trucks, uncover of mountains related to bursting, etc. The COMPACT can be delivered in optional size from 0,6 to 2,0 meters working width, the diameter of the brush is 915 mm. -
Page 5: Change Of Brushes
5. Check the core free from damage. 6. Fasten one end ring with screws on the core. 7. Lift the sweeper core up with the end ring downwards. 3. End ring screws 4. End ring mounting © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 5/4/06... -
Page 6: Mounting Of Sweeper Roll
See picture 9. Attention! Avoid clamping. 8. Location of the brush element pins 3. Mount the four gable side bolts. 9. Mounting of gable side 10. Gable side bolts © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 5/4/06...
