- Page 1 Water Flood Detector Product Manual ©2024 INTERRA PM2402290227BEN...
-
Page 2: Table Of Contents
3.1.1. Parameters List ..........................9 3.2. Water Flood ............................10 3.2.1. Parameters List .......................... 11 3.3. Lock ..............................13 3.3.1. Parameters List .......................... 14 4. ETS Objects List & Descriptions ........................15 4.1. General Objects ............................16 ©2024 INTERRA PM2402290227BEN... - Page 3 Reserved. FITNESS FOR PURPOSE. Interra disclaims all liability arising from this information and its use. Use of Interra devices in life Printed on recycled paper. support and / or safety applications is entirely at the buyer’s risk, and the buyer agrees to defend,...
-
Page 4: Content Of The Document
Product Manual 1. Content of The Document This document contains the specifications of Interra’s ITR401-0XX2 KNX Water Flood Detector product and the project context. This document applies to all products involved as a common information base and is binding on KNX system equipment involved in the project. -
Page 5: Product Description
When the water- based liquids reach to probes of detector, it will send telegrams to the KNX bus. ©2024 INTERRA PM2402290227BEN... -
Page 6: Technical Information
Water Flood Detector Product Manual 2.1. Technical Information The following table shows the technical information of the Interra Water Flood Detector. Product Code ITR401-0XX2 Power supply KNX power supply Current consumption 10 mA (Alarm condition) 1 x Alarm (Red) / Operating (Green) LED... -
Page 7: Functional Descriptions
2.3. Model and Variations I T R 4 0 1 – 0 X Relay Status Colour : Colours White Anthracite Table 1: Water Flood Detector Colours : Relay Status No Relay Relay Table 2: Water Flood Detector Relay Status ©2024 INTERRA PM2402290227BEN... -
Page 8: Ets Parameters
“In Operation” object. If this telegram is received periodically, it shows that the device is working properly. Since the period time is in minutes, it is better to keep the period time higher in order not to increase the bus line traffic. ©2024 INTERRA PM2402290227BEN... -
Page 9: Parameters List
This parameter is used to set the cyclically sending operation send 1…5… 255 time interval value of the “General - In operation” interval (min) group object. This parameter is only visible when the parameter “Enable in operation” is set to “Yes”. ©2024 INTERRA PM2402290227BEN... -
Page 10: Water Flood
The users can make many settings related to the Water Flood via ETS software. Many features such as water alarm delay, status LED, alarm LED, to reset alarm with an object and buzzer etc. can be controlled with this tab. Fig. 2: Water Flood Parameter Configuration Page ©2024 INTERRA PM2402290227BEN... -
Page 11: Parameters List
18:12:15 parameter. Alarm reset The alarm reset parameter is used to end the alarm condition of the device. No: Determined alarm conditions start when the device detects water flood. As soon as probes get ©2024 INTERRA PM2402290227BEN... - Page 12 This parameter is only visible when the parameter “Alarm LED blink” is set to “Yes”. This parameter is only visible when the parameter “Buzzer” is set to “Yes”. This parameter is only visible when the parameter “Alarm reset” is set to “Yes”. ©2024 INTERRA PM2402290227BEN...
-
Page 13: Lock
Water Flood Detector Product Manual 3.3. Lock In this section, the locking feature of the water flood detector is mentioned. Locking feature suspend to send group objects. Fig. 3: Lock Parameter Configuration Page ©2024 INTERRA PM2402290227BEN... -
Page 14: Parameters List
Lock active This parameter is only visible when the parameter “Use water flood lock” is set to “Yes”. This parameter is only visible when the parameter “Automatic unlock after delay” is set to “Yes”. ©2024 INTERRA PM2402290227BEN... -
Page 15: Ets Objects List & Descriptions
1 bit Water Flood Water Alarm 1.005 1 bit Water Flood Water Alarm Reset 1.002 1 bit Water Flood Test Sensor 1.003 1 bit Water Flood Lock 1.003 1 bit Water Flood Feedback of lock 1.003 1 bit ©2024 INTERRA PM2402290227BEN... -
Page 16: General Objects
This object is used to send feedback on the lock status for the detector. It becomes visible when the "use water flood detector lock" parameter is set to yes. If a status change occurs on the lock function, the changed statue value will be sent from this object. DPT: 1.003 (enable) ©2024 INTERRA PM2402290227BEN... -
Page 17: Contact Information
Turkey Interra provides documentation support via our Interra website www.interratechnology.com. This website Cumhuriyet Mah. Kartal Cad. Interra R&D Center is used as a means to make files and information easily available to customers. Accessible by using No:95/1 Kartal/İstanbul your favourite Internet browser, the website...
