Algam Lighting IP PAR725 HEX Manual page 17

DMX PROTOCOL
11 CHANNELS
CHANNEL FUNCTION
CH1 Master Dimmer
CH2 R dimming
G dimming
CH3
CH4 B dimming
W dimming
CH5
CH6 A dimming
CH7 UV dimming
CH8 Master strobe
CH9 CTO
CH10 Function selection
CH11 Function speed
SPECIFICATIONS
Product size
Weight
Power consumption
Input voltage
Light Source
DMX Channel
Dimmer
IP Rating
Control mode
DESCRITPTION
RGBWAUV master dimmer, from dark to bright
Red dimming, from dark to bright
Green dimming, from dark to bright
Blue dimming, from dark to bright
White dimming, from dark to bright
Amber dimming, from dark to bright
UV dimming, from dark to bright
Close the strobe
000-004
005-255 Strobe, speed from slow to fast
Color temperature: 3200-8000 warm
CH1-8 valid
0 - 50
8 common color output
51 - 100
101 - 150 Colorful jump
151 - 200 Colorful gradient
Colorful pulse change
201 - 250
Sound mode
251 - 255
Color selection / speed addition / sound control selection
260 x 160 x 285mm
2.75kg
180W
100-240V~ 50/60Hz
7 x 25W RGBWAUV 6 in 1 LED
6/11 CH
0%-100% linear dimming
IP65
DMX512, sound control, automatic, master/slave
P.17
