- Page 1 WMS1 / WMS2 MEDIA SYS User Manual...
-
Page 2: Document Version
©2025 ADJ Products, LLC all rights reserved. Information, specifications, diagrams, images, and instructions herein are subject to change without notice. ADJ Products, LLC logo and identifying prod- uct names and numbers herein are trademarks of ADJ Products, LLC. Copyright protection claimed includes all forms and matters of copyrightable materials and information now allowed by statutory or judicial law or hereinafter granted. -
Page 3: Table Of Contents
C O N T E N T S General Information Limited Warranty (USA Only) Safety Guidelines Maintenance Guidelines Overview Handling and Transportation Vacuum Removal Tool Installation Display Stand Setup Uploading Content Technical Specifications Dimensional Drawings | Optional Components and Accessories... -
Page 4: General Information
Please read and understand the instructions in this manual carefully and thoroughly before attempting to operate this device. These instructions contain important safety and use information. Discover the cutting-edge ADJ WMS1/WMS2 LED Video Panel – a pinnacle in high-resolution display technology designed for seamless integration into diverse projects. Expanding ADJ’s professional LED video panel portfolio, the WMS1/WMS2 stands out as the company’s highest resolution offering to date. - Page 5 G E N E R A L I N F O R M AT I O N Customer Support: Contact ADJ Service for any product related service and support needs. Also visit with questions, comments or suggestions. forums.adj.com Parts: To purchase parts online visit: http://parts.adj.com...
-
Page 6: Limited Warranty (Usa Only)
All shipping charges must be pre-paid. If the requested repairs or service (including parts replacement) are within the terms of this warranty, ADJ Products, LLC will pay return shipping charges only to a designated point within the United States. If the entire instrument is sent, it must be shipped in its original package. No accessories should be shipped with the product. -
Page 7: Safety Guidelines
This device is a sophisticated piece of electronic equipment. To guarantee smooth operation, it is important to follow all instructions and guidelines in this manual. ADJ is not responsible for injury and/ or damages resulting from the misuse of this panel due to the disregard of the information printed in this manual. - Page 8 S A F E T Y G U I D E L I N E S DO NOT touch panel housing during operation. Turn OFF power and allow approximately 15 minutes • for panel to cool down before servicing. DO NOT operate devices with covers open and/or removed. •...
-
Page 9: Maintenance Guidelines
M A I N T E N A N C E G U I D E L I N E S • Careful and regular maintenance is necessary to optimize the potential functional lifespan of the video panels. • Read the installation and operation instructions for correct operation of the video panels. •... -
Page 10: Overview
O V E R V I E W VIDEO PANEL Please note: Video panel is shown rotated 90 degrees in order to fit this page. During actual installation, the video panel should always be oriented so that the directional arrows are pointed upwards. Mounting Mounting Bolt... - Page 11 O V E R V I E W LED PANEL Directional Arrows Module Connector Module Magnets Safety Cable Module Connector Directional Arrows...
-
Page 12: Handling And Transportation
H A N D L I N G A N D T R A N S P O R TAT I O N ELECTROSTATIC DISCHARGE (ESD) PRECAUTIONS Because these are ESD sensitive units, ESD precautions must be observed when removing the video panels from their flight case (ESD gloves, protective clothing, wrist straps, etc.). -
Page 13: Vacuum Removal Tool
VA C U U M M O D U L E R E M O VA L T O O L A technician can use the optional Vacuum Module Removal Tool (ADJ part number EVSVAC, sold separately) to safely remove and reinstall any of the eight LED Modules in the video panel, and minimize potential damage from mishandling, ESD exposure, or other issues. -
Page 14: Installation
I N S TA L L AT I O N DO NOT INSTALL THE PANEL IF YOU ARE NOT QUALIFIED TO DO SO! INSTALLATION BY QUALIFIED TECHNICIANS ONLY! INSTALLATIONS SHOULD BE CHECKED BY A QUALIFIED PERSON AT LEAST ONCE A YEAR! FLAMMABLE MATERIAL WARNING Keep panel(s) a minimum of 5.0 feet (1.5m) away from flammable materials and/or pyrotechnics. -
Page 15: Display Stand Setup
D I S P L AY S TA N D S E T U P The ADJ Lighting WMS1/WMS2 Media Sys is a powerful LED display solution equipped with two WMS1 or WMS2 LED panels, an integrated Novastar processor, and a rugged flight case. - Page 16 D I S P L AY S TA N D S E T U P 3. Align the lower end of the brace bar with the 4. Install each LED module. Orient each module bracket on the frame base, then secure in so that the arrows on the module are pointing place with a bolt and nut.
- Page 17 D I S P L AY S TA N D S E T U P 5. Connect the display stand to power via the power port on the integrated Novastar processor, then switch the power on. POWER PORT 6. Assembly is now complete. Please note, when returning the display stand to the flight case for storage, always remove the LED panels first using the vacuum removal tool.
-
Page 18: Uploading Content
U P L O A D I N G C O N T E N T Uploading content into the NovaStar TB50 involves a few key steps, typically done through ViPlex Express or ViPlex Handy software. Please follow the steps below: 1. -
Page 19: Technical Specifications
T E C H N I C A L S P E C I F I C AT I O N S MEDIA SYS DISPLAY STAND Specifications: • Pixel Pitch (mm): WMS1: 1.95; WMS2: 2.6 • Pixel Density (dot/m2): WMS1: 262,144; WMS2: 147,456 •... -
Page 20: Dimensional Drawings | Optional Components And Accessories
D I M E N S I O N A L D R AW I N G S 20.3 in (515mm) 19.7 in (500mm) O P T I O N A L C O M P O N E N T S A N D A C C E S S O R I E S SKU (US) SKU (EU) DESCRIPTION...
