PCB Piezotronics IMI SENSORS EXM641B01 Installation And Operating Manual page 20

Model Number
641B01
Performance
Measurement Range
Output
Frequency Range(± 10 %)
Broadband Resolution
Non-Linearity
Environmental
Temperature Range
Enclosure Rating
Electrical
Excitation Voltage
Settling Time(within 2% of value)
Electrical Isolation(Case)
Physical
Size (Hex x Height)
Weight
Mounting Thread
Mounting Torque
Sensing Element
Sensing Geometry
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
Electrical Connections(Pin A)
Electrical Connections(Pin B)
[5]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change
specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
4-20 MA OUTPUT VELOCITY SENSOR
ENGLISH SI
0.0 to 1 in/sec rms 0.0 to 25.4 mm/s rms
4-20 mA 4-20 mA
600 to 60,000 cpm 10 to 1 kHz
0.005 in/sec rms 0.13 mm/s rms
± 1 % ± 1 %
-40 to 185 °F -40 to 85 °C
IP68 IP68
12 to 30 VDC 12 to 30 VDC
<15 sec <15 sec
8 8
>10 Ohm >10 Ohm
1.0 in x 2.6 in 25.4 mm x 66 mm
4.7 oz 131 gm
1/4-28 UNF No Metric Equivalent
3 to 5 ft-lb 4 to 7 Nm
Ceramic Ceramic
Shear Shear
Stainless Steel Stainless Steel
Welded Hermetic Welded Hermetic
2-Pin MIL-C-5015 2-Pin MIL-C-5015
Top Top
4-20 mA Pos (+) 4-20 mA Pos (+)
4-20 mA Neg (-) 4-20 mA Neg (-)
[1]
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
[2][3]
[4] - Hazardous Area Approval- contact factory for specific approvals
EX
DIV II, CL I, GRPS A-D, ExnL,
Hazardous Area Approval
EEx ia IIC T4, -40°C≤Ta≤80°
Hazardous Area Approval
EEx nL IIC T4, -40°C≤Ta≤80°
Hazardous Area Approval
DIV I, CL I, II, III, GRPS A-G,
Hazardous Area Approval
- Metric Mount
M
Supplied Accessory : Model M081A61 Mounting Stud 1/4-28 to M6 X 1 (1) replaces Model
081A40
- Buffered Analog Signal Output - 100 mV/g (±20%)
RV
Electrical Connector
Electrical Connections(Pin A)
4-20 mA Neg/Signal Output
Electrical Connections(Pin B)
Electrical Connections(Pin C)
NOTES:
[1] Conversion Factor 1 in/sec = 0.0254 m/sec.
[2] Current will fluctuate at frequencies below 5 Hz.
[3] 1Hz = 60 cpm (cycles per minute).
[4] Typical.
[5] See PCB Declaration of Conformance PS039 or PS053 for details.
SUPPLIED ACCESSORIES:
Model 081A40 Mounting Stud (1)
Model ICS-4 NIST-traceable single-axis amplitude response calibration from 0 cpm (0 Hz) to
upper 10% frequency for 4 - 20 mA output vibration sensor (1)
Entered: LK Engineer: NJF
Date: 6/12/2017 Date: 6/12/2017
3425 Walden Avenue, Depew, NY 14043
Revision: D
ECN #: 46922
OPTIONAL VERSIONS
DIV II, CL I, GRPS A-D, ExnL,
AExnA, IIC T4 AExnA, IIC T4
EEx ia IIC T4, -40°C≤Ta≤80°
C, II 1 G C, II 1 G
EEx nL IIC T4, -40°C≤Ta≤80°
C, II 3 G C, II 3 G
DIV I, CL I, II, III, GRPS A-G,
Exia, AExia, IIC T4 Exia, AExia, IIC T4
3-Pin MIL-C-5015 3-Pin MIL-C-5015
4-20 mA Pos (+) 4-20 mA Pos (+)
4-20 mA Neg/Signal Output
Neg Neg
Signal Output Pos Signal Output Pos
Sales: MC Approved: NJF
Date: 6/12/2017 Date: 6/12/2017
Phone: 800-959-4464
Fax: 716-684-3823
E-Mail: imi@pcb.com
Spec Number:
27319
