Teknim TPU-9245P Installation & User Manual

TPU-9245P
External Power Supply, 24VDC 5A, Plastic Case
Installation & User Manual
Important Warnings
General
• Read this manual carefully before operating the appliance and save it for later use.
• Follow all warnings and precautions specified in the manual. Follow all operating and operating instructions,
respectively.
• Keep devices away from water and moisture.
Service and Maintenance
Do not try to fix the device on your own. Removal of cover may end up with electricity shock. In case of any
defect or malfunction, contact with your dealer or with authorized service. All the technical interventions have
to be done by technicians of company. Device must be cleaned up with a dry fabric. No-chemicals are allowed
for cleaning.
Warning: Do not attempt to remove the electronic board from its plastic case. The electronic board is
closed for your safety. Users should avoid from interference.
Failure Situations Requiring Service
If a fault occurs or the cases mentioned below, please contact your authorized dealer or reseller.
• When the power cord or plug is damaged,
• When any liquid flows or the object falls into the device,
• When exposed to water or rain,
• If the device has been dropped or the case has been damaged,
• If the device has a noticeable level of performance change,
• If the device does not operate normally according to the operating instructions,
Incorrect operations may cause other malfunctions, so call for service.
Transportation and Shipping
The device must be carefully handled so that it is not exposed to any external impact and does not allow any
liquid to enter. Malfunctions resulting from improper transport are not covered by the warranty.
Human Health and Environmental
This device does not contain any chemical or biological substances that may harm human health.
* 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return this
product to your local supplier upon the purchase of equivalent new equipment, or
dispose of it at designated collection points. For more information see:
www.recyclethis.info.
Release Date: 06/05/2023
Rev. Date: 11/01/2024 - Rev. No:02
Doc. Ref.: HM.Z.KLV.7921
General Information
TPU-9245P are 24Vdc 5A uninterruptible power supplies with an intelligent battery charger unit designed for
use in systems requiring external power supply. The device allows use 7Ah or 7.2Ah charger, depending on the
needs of the user.
General Features
•
Selectable single or double output
•
7Ah or 7.2Ah battery support
• Dry contact relay output in case of error
•
Status indicator LEDs for easy fault identification
•
Temperature compensated, intelligent battery charging circuit
•
Protection against short circuit and overload conditions
•
Totally enclosed and robust construction
Technical Specifications
Models
Standart
Supply
Input Voltage
Output Voltage
Mains Input Fuse
Number of Outputs
Output Current
(S1 off, S2 on)
Output Current
(S1 on, S2 off)
Output Fuse (F1-F2)
Battery
Battery Cut Off Voltage
Battery Internal Resistance Fault
Greatest Current to be drawn from
the Battery
Charging Voltage
Charging Current
Battery Fuse (F3)
Imin
ImaxA
ImaxB
Outputs
General Error Relay
Environmental Conditions
Temperature
Humidity
IP Class
Mechanical
Housing Material
Weight (Without Battery)
TPU-9245P
EN 54-4
230~115Vac (+%10 / -%15) 50/60Hz
20~24Vdc ±%2
6A
2
Output -1: 5,0A
Output -2: 0,0A
Output -1: 2,5A
Output -2: 2,5A
2x3A (not resettable)
2x12V, 7Ah - 2x12V, 7.2Ah (Yuasa NP7-12)
20,5Vdc
>1,5Ω
5A
27,6Vdc @20C (Temperature Compensated)
1A
1,85A
20mA
4A
5A
1 pcs NC/N0 30V 2A
-10C ~ +55C (14F ~ 131F)
95% RH (max)
IP30
Plastic, ABS
1,767kg
