HCD-Lite
INSTRUCTOIN MANUAL
APPEARANCE & FUNCTION BUTTONS
OLED display
READING AREA
CONFIRM
UP
CANCEL / SWITCH
DOWN
HORN
CHARGE / PROGRAM / TRANSMISSION
RESTART
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the HCD-Lite and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Remocon HCD-Lite

Summary of Contents for Remocon HCD-Lite

  • Page 1 HCD-Lite INSTRUCTOIN MANUAL APPEARANCE & FUNCTION BUTTONS OLED display READING AREA CONFIRM CANCEL / SWITCH DOWN HORN CHARGE / PROGRAM / TRANSMISSION RESTART...

  • Page 2: Power On/Off

    L 1 . 0 . 0 Will show the version number here Main Menu  ⚡ HCD-Lite  Duplicate Code Frequency Meter Setting Function mode：Duplicate Code / Frequency Meter / Setting Press「」or「」to select the mode you want to use and press「」button to enter.
  • Page 3 Press「」and it will show【Are You Sure To Quit?】 ，and press「」to go back to main menu. Duplication Steps   Input the code from the same button 2 times it(HCD-Lite) will automatically recognize whether it is a hopping code or fixed code， and show【Receiving Seed Code】if you need to input the seed code.
  • Page 4  Decryption Failure If HCD-Lite can not recognize the remote(no bulild-in data found) or the code received is problematic, will show【Corrupted Code or Unknown Format】.  Decryption Success Fixed code：will show B4、B10 or C. Hopping code：will show H and the brand name of the remote，and then need to set up the serial number of the new remote.
  • Page 5  After inputting all buttons，connect corresponding REMOCON remote by cable and press「」to program. Duplicate Programming . . . Will show the type of the RMEOCON remote you connect at this time. If you forget to connect the remote, will show【Please Connect Remote】.
  • Page 6 Press「」to set the new serial number same as the original remote. Press「」to confirm the new serial number.  Input the rest buttons(if they are from the same remote, just need to input 1 time). Duplicate REMOCON 433.9MHz 02 013579B  Press「」to program. Duplicate Programming .
  • Page 7 REMOCON remote. Duplicate Please Enter 1st Code Will show【Remocon Read Back】 when reading the data，and show the type of the remote it reads. If you forget to connect the remote, will show【Please Connect Remote】.
  • Page 8 Remocon Read Back Hopping code Read Back   After you read back a hopping code REMOCON remote, it will show the brand name of the remote, and then need set up the serial number of the new remote. Duplicate H4 REMOCON 013579B →...
  • Page 9 Hold「」or「」to adjust the frequency，or press「」to switch to the common frequencies.  Connect new RMEOCON remote and press「」to program. Duplicate Programming . . . After the programming is completed, press「」to continue program to another remote，and the new serial number will " +1" automatically. Frequency Meter Normal Mode(200-900MHz) ...
  • Page 10 Are You Sure To Quit ? Press「」and will show【Are You Sure To Quit?】 ，and press「」to go back to main menu. Setting Setting Menu  Setting  Language English Set Freq. Auto Idle Time 3 min Setting menu (1/2) Setting  About HCD-Lite Setting menu (2/2)
  • Page 11 Press「」and it will save current setting automatically and go back to main menu. Language : English / Español Set Freq.： Auto / Manual Idle Time： 3min / 5min / 10min About HCD-Lite  About Version 1 . 0 . 0 000001 Enter to show the version number and serial number of this machine，press「」to go...
  • Page 12 HCD-Lite API Operating interface description  CONNECTION LANGUAGE HCD-Lite UPDATE REPRODUCE READ EEPROM STATUS EEPROM FIELD DATABASE API version update  Will automatically judge whether itself is latest version or not；if not，a message window will pop up.

  • Page 13: Api Mode

    ；if not, please close this window by clicking the " x " on the upper right corner. Connection   Connect HCD-Lite to the computer by updating cable，HCD-Lite must be at main menu at this time.  Click red part of this button to connect.
  • Page 14 HCD-Lite Update   Will automatically judge whether your HCD-Lite is the latest version or not after the connection is build，and a message will show on the status field to inform you. You can press to update your HCD-Lite，or you can just ignore it.
  • Page 15 Do not remove the cable or disconnect the internect during the updating，the update failure will result in the deadlock of machine. After the update is completed，HCD-Lite will restart automatically.
