Summary of Contents for Clarus LYNK
- Page 1 Lynk Install Video LYNK™ 55-Inch Installation Instructions PLEASE READ ALL INSTRUCTIONS BEFORE INSTALLATION...
-
Page 2: Tools Needed
TABLE OF CONTENTS LYNK™ Page 3 | Overview of Lynk Components Page 4-6 | Lynk Positioning Page 7-13 | Installation Page 14 | Maintenance IMPORTANT We recommend a minimum of 3 people to install. However, this product can be installed with 2 people. - Page 3 OVERVIEW OF LYNK • Fig. A for a general layout of the Lynk hardware components COMPONENTS • 1: Supports the screen • 2: Extends the connection ports from the screen to the front of the Lynk system • 3: This attaches to the screen and secures it to the wall •...
- Page 4 LYNK POSITIONING • Dimensions: Lynk is 96” W x 53.5” tall. • The screen measures 50.75” W x 29.5” tall. 96” Lynk glass 50.75” Screen...
- Page 5 LYNK POSITIONING • There are 22.5” of glass on the left and right of the screen and 12” of glass above and below. (CONTINUED) • Determine the location for the screen on the wall. Then, using the measurements below (Fig.
- Page 6 (CONTINUED) where mounting hardware is located (Fig. • To route power to Lynk, you may use outlets that are above or below Lynk, but not within the red areas. • Confirm that the wall flatness across the installation area is within ¼”...
- Page 7 1. Mark the desired location of the bottom of the screen using (Fig. painters tape or laser level (Fig. 2. Mark the vertical center of Lynk using painter’s tape or a laser line (Fig. 3. Ensure all markings are level.
- Page 8 STEP 2 1. Take (2) and install over the two leftmost holes on (1). Mark the (Fig. two remaining holes of (2) on the wall. (You can hold (2) in place instead of installing if that’s easier). 2. Remove the two leftmost screws of (1), remove (2), and drill wall anchor locations (Fig.
- Page 9 STEP 3 (CONTINUED) 5. Using two people, lift screen and place on (1), ensuring that the standoffs on (1) insert into the bottom of the screen. 6. Continuing to hold the screen in place, mark the hole locations on (3) on either side of the screen. Do not leave the screen unsupervised–the standoffs are meant to guide installation, not secure the screen.
- Page 10 3. Install camera on top of screen. 4. Plug in power cable to power outlet. Ensure the power outlet is not located in a red zone as referenced in “Lynk Positioning” section of this installation guide. 5. Take (4) and insert into studs on (3).
- Page 11 STEP 6 1. Take (5) and line up the notches with the bottom of (4). Use a (Fig. level to confirm (5) and (4) are level. Ensure that (5) has the “face up” side facing up. 2. Holding (5) in place, mark the location of the holes. 3.
- Page 12 STEP 7 1. The glass is now ready to be installed. Ensure you have the ¼-20 (Fig. Socket Head Cap Screw ready. 2. Using three people, lift the glass up so that the glass brackets slide into (5). Be careful not to hit the camera or screen during this install.
- Page 13 STEP 8 1. Take (6) and slide over (5). (Fig. 2. Screw the 1/4-20 screw, (6) onto bracket making sure the screw goes through (5) slot (Fig. N). Tighten using provided Allen key. Fig. N...
-
Page 14: Maintenance
4. Loosen the nuts securing (4) and remove by sliding them out. 5. Unscrew (3) from the wall. 6. Using two people, lift the screen and place on sawhorses or flat surface for maintenance. clarus.com | +1.888.813.7414 © 2025 Clarus. All rights reserved.
