- Page 1 User's Manual BW-1500S BANNER WELDER Please read and retain these instructions. To register your product, please go to www.sign-in-global.us USA. Click the Customer Support Tab then Registration Tab. California Global-Signs Information Technology...
-
Page 2: Table Of Contents
BW-1500S CONTENTS 1. INTRODUCTION∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 2. SAFETY PRECAUTIONS ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 3. PRODUCT IDENTIFICATION ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5 4. INSTALLATION∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 6 4.1 Electrical requirements ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 6 4.2 Box contents ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 6 4.3 Assembly∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5. Control Panel∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 9 6. OPERATION ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 10 7. MAINTENANCE ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 11 8. -
Page 3: Introduction
BW-1500S 1. INTRODUCTION Thank you for choosing a Qomolangma BW-1500S. It has been designed and manufactured to provide years of continuous service. For complete operating and maintenance information please read this manual thoroughly. Upon receipt of your Banner Welder, please inspect the box, the machine and all other contents for shipping damage. Damage should be brought to the immediate attention of the delivering carrier (See page 6 for list of shipment elements). - Page 4 BW-1500S Dangerous areas and residual risks To avoid the risk of injury or health problems avoid all moving parts. Pay attention to hands when operating the Banner Welder. During certain intervention procedures on the machine, which are pointed out each time in this manual, residual risks for the operator may arise.
-
Page 5: Product Identification
BW-1500S 3. PRODUCT IDENTIFICATION PART NAME PART NAME Guide Plate Main Switch Feed Table Adjustable Stand Top Cover Support Bar Speed Knob Base Body Caster Emergency Switch Leveling Legs Rear Cover... -
Page 6: Installation
• Proper illumination. • Normal ambient operating conditions. 4.1 Electrical requirements Qomolangma recommends that licensed electrician ensures proper power installation to your Banner Welder in accordance with electrical codes in your area. 4.2 Box contents Thoroughly inspect the parts and the unit. It is imperative that any missing parts are reported and a claim is filed with the reseller immediately upon receipt of shipment. - Page 7 RBW-1500 Part name Quantity Picture Support Bar Base Caster Foot Tube stopper inside 5/16 Hexa Head Bolt Screw (M8*80) Star Washer (Ø8.2) Knob-Bolt Guide 5/16 Hexa Head Bolt Screw (M8*30) Spring Washer (Ø8.2) Welding Belt Tool box Wood Screw Washer Plain Fuse (AC250V 10A Lanbao) (100- 120V)
-
Page 8: Assembly
BW-1500S 4.3 Assembly 1. Open the box carton and remove all parts. 2. Open the tool-box. Fig. 4-1 3. Attach the caster to the base.(Fig. 4-1) 4. Attach the support bar to the base using the supplied screws (M8x80).(Fig. 4-2) Fig. -
Page 9: Control Panel
RBW-1500 8. The machine is now ready for Operation(Fig. 4-6). Note the recommended component spacing. 2" to 4" gap 6" to 8" gap Fig. 4-6 5. CONTROL PANEL 1. Speed: To adjust the speed of the welding belt, turn the speed knob clockwise to increase speed or counter-clockwise to decrease the speed. -
Page 10: Operation
BW-1500S 6. OPERATION The Banner Welder must only be used by trained and qualified personnel. The Banner Welder must be used only for welding material for which it has been designed. For recommended maximum welding thickness see page 15. Welding: NOTE: When you feed the banner into the machine, you should guide the banner by the hand or by Banner Guide to keep it move in a straight line. -
Page 11: Maintenance
RBW-1500 9. Turn the speed back up and rotate the banner again and fold the longer side of the Sample Pocket Configurations banner and guide the banner into the machine with the 4 layer fold entering last. (Note: Turn the speed back down 1 to 2 positions to compensate for the extra layers of material). - Page 12 BW-1500S 1. Run a piece of scrap material 2-3 times through the unit. This should clean belts sufficiently. If you need a more in depth cleaning go to step 2. 2. Power the unit off and unplug the unit from the outlet. Once the unit has sufficiently cooled remove the top and bottom cover (as needed) and use a rubber sand belt cleaner to remove residual adhesive from the belts.
- Page 13 RBW-1500 3. To increase or decrease tension on the heating blocks use the adjustment screw, one for the heating block and one for the cooling block.(Fig. 7-3) Adjustable screw Fig. 7-3 4. Replace the worn out belts with new belts. 5.
-
Page 14: Troubleshooting
BW-1500S 7. Adjust the upper and lower screws to ensure the belts run in the proper position.(Fig. 7-5) Upper screw Lower screw Close to the machine Fig. 7-5 To move the belts closer to the machine loosen the upper screw and tighten the lower screw. -
Page 15: Specification
RBW-1500 9. SPECIFICATION Model Name RBW-1500 Input Voltage 220V(60Hz),220~240V(50Hz),100V(50/60Hz),110~120V(60Hz) Power Consumption 800W Welding Width 0.6" (13~15mm) Stock Thickness 0.03" (0.2mm-0.8mm) Max. Pocket Width 6" (150mm) Welding Speed 16 ft./min. ( 0-5m/min) Max. Heating Temperature 662° F(350° C) Adjustable stand 29"-42" (735 ~ 1055mm) Cooling Method Digital Display Unit Dimensions... -
Page 16: Warranty
11. WARRANTY Qomolangma International warrants the equipment sold is free from defects in material and workmanship for a period of One (1) year for Parts and Labor from the date of installation. This warranty is valid only to the original purchaser. This warranty is the only warranty made by Qomolangma International and cannot be modified or amended.
