  • Page 1 Lenovo C24d-20 User Guide...

  • Page 2: Product Numbers

    © Copyright Lenovo 2024 LENOVO products, data, computer software, and services have been developed exclusively at private expense and are sold to governmental entities as commercial items as defined by 48 C.F.R. 2.101 with limited and restricted rights to use, reproduction and disclosure.

  • Page 3: Table Of Contents

    Contents Safety information .......................... iii General Safety guidelines ..............................iii TCO Certified ..................................iv Chapter 1. Getting started ......................1-1 Shipping contents ................................1-1 Notice for use ..................................1-1 Product overview ................................1-2 Types of adjustments ..............................1-2 Tilt ....................................1-2 Swivel ..................................1-2 Height Adjustment ................................

  • Page 4: Safety Information

    Safety information General Safety guidelines For tips to help you use your computer safely, go to: http://www.lenovo.com/safety Before installing this product, read the Safety Information. DANGER To avoid shock hazard: • Do not remove the covers. • Do not operate this product unless the stand is attached.

  • Page 5: Tco Certified

    TCO Certified A third-party certification according to ISO 14024 Toward sustainable IT products Say hello to a more sustainable product IT products are associated with a wide range of sustainability risks throughout their life cycle. Human rights violations are common in the factories.
  • Page 6 Chapter .

  • Page 7: Chapter 1. Getting Started

    Chapter 1. Getting started This User’s Guide contains detailed information on the your Flat Panel Monitor. For a quick overview, please see the Setup Poster that was shipped with your monitor. Shipping contents The product package should include the following items: Flat Panel Monitor Information Flyer Stand...

  • Page 8: Product Overview

    Product overview This section will provide information on adjusting monitor positions, setting user controls, and using the cable lock slot. Types of adjustments Tilt Please see the illustration below for an example of the tilt range. Swivel With the built-in pedestal, you can tilt and swivel the monitor for the most comfortable viewing angle.

  • Page 9: Height Adjustment

    Height Adjustment For height adjustment, user needs to press down or lift up the monitor. 150mm 130mm 1. Head monitor tilt backforward ≥12⁰: Height lift 150mm 2. Head monitor vertical(90⁰): Height lift 130mm Monitor Pivot - Adjust the screen position before rotating the monitor screen. (Make sure that the monitor screen ascent to its highest point, and it inclines backward at 35°.) - then rotate clockwise /counterclockwise until the monitor stops at 90°.

  • Page 10: Monitor Controls

    Monitor controls Your monitor has controls on the front which are used to adjust the display. MENU INPUT MODE For information on how to use these controls, please see “Adjusting your monitor image”on page 2-3. Cable lock slot Your monitor is equipped with a cable lock slot located on the rear of your monitor. Chapter 1.

  • Page 11: Setting Up Your Monitor

    Note: The type of plug & Socket shown here are for illustration only. 2. Connect the cables according to below icon indication. 3. For computer in HDMI connecting. Note: Lenovo recommends that customers who require to use the HDMI input on their monitor purchase the “Lenovo HDMI to HDMI cable OB47070” www.lenovo.com/support/monitoraccessories.
  • Page 12 4. For computer in DP connecting. 5. For computer in DVI Cable connecting. 6. For computer in Analog Signal Cable connecting. Chapter 1.
  • Page 13 7. For computer in USB-A connecting. Note: USB-A Power delivery: 4.5W, 0.9A 8. For computer in USB-B connecting. 9. For computer in USB-C connecting. Note: Type C Power delivery: 15W, 3.0A If there are any *,you can consult the comments on page 1-1. Chapter 1.
  • Page 14 10. Connect the speaker’s audio cable and audio jack of monitor to transfer audio source from HDMI or DP. Note: The audio output in HDMI or DP modes. Warning note: Excessive sound pressure from earphones and headphones can cause hearing loss. Adjustment of the equalizer to maximum increases the earphones and headphones output voltageand therefore the sound pressure level.
  • Page 15 12. Insert the power cord into the monitor, then plug the monitor power cord and the computer cord into grounded electrical outlets. Note: A certified power supply cord has to be used with this equipment. The relevant national installation and or equipment regulations shall be considered. A certified power supply cord not lighter than ordinary polyvinyl chloride flexible cord according to IEC 60227 (designation H05VV-F 3G 0.75mm or H05VVH2-F2...

  • Page 16: Registering Your Option

    Thank you for purchasing this Lenovo product. Please take a few moments to register your Product and provide us with information that will help Lenovo to better serve you in the future. Your feedback is valuable to us in developing product and services that are important to you, as well as in developing better ways to communicate with you.

  • Page 17: Chapter 2. Adjusting And Using Your Monitor

    For more detailed information on any of these topics, visit the Healthy Computing Web site at: http://www.lenovo.com/healthycomputing/. Arranging your work area Use a work surface of appropriate height and available working area to allow you to work in comfort.

  • Page 18: Quick Tips For Healthy Work Habits

    Use adequate lighting for the type of work you are performing. Use the monitor brightness, contrast controls, if equipped to optimize the image on your screen to meet your visual preferences. Keep your monitor screen clean so you can focus on the screen’s contents. Any concentrated and sustained visual activity can be tiring for your eyes.

  • Page 19: Adjusting Your Monitor Image

    Adjusting your monitor image This section describes the control features to adjust your monitor image. Using the direct access controls The direct access controls can be used when the On Screen Display (OSD) is not displayed. Table 2-1. Direct access controls Function Make image and OSD settings / Advanced configuration / MENU...

  • Page 20: Using The On-Screen Display (Osd) Controls

    Using the On-Screen Display (OSD) controls To adjust the settings, the user controls can be viewed through the OSD. MENU MENU Image INPUT Image Sharpness MODE Saturation AUDIO Presence Sensor BRIGHTNESS/CONTRAST Advanced Information To use the controls: 1. Press [menu] key to open the main OSD menu. 2.
  • Page 21 Table 2-2. OSD functions OSD Icon on Controls and Sub menu Description Main Menu Adjustments Phase Adjust bar (0-100) Clock Adjust bar (0-100) H-position Adjust bar (0-100) Only for VGA V-position Adjust bar (0-100) Image Auto adjust Sharpness Adjust bar (0-100) All input Full screen signals...
  • Page 22 OSD Icon on Controls and Sub menu Description Main Menu Adjustments Brightness Adjust bar (0-100) Contrast Adjust bar (0-100) Black Level Adjust bar (0-100) All input BRIGHTNESS/ signals CONTRAST Auto Brightness Lighting Guide Chapter 2.

  • Page 23: Selecting A Supported Display Mode

    Selecting a supported display mode The display mode the monitor uses is controlled by the computer. Therefore, refer to your computer documentation for details on how to change display modes. The image size, position and shape might change when the display mode changes. This is normal and the image can be readjusted using automatic image setup and the image controls.

  • Page 24: Understanding Power Management

    Understanding power management Power management is invoked when the computer recognizes that you have not used your mouse or keyboard for a user-definable period. There are several states as described in the table below. For optimal performance, switch off your monitor at the end of each working day, or whenever you expect to leave it unused for long periods during the day.

  • Page 25: Caring For Your Monitor

    Caring for your monitor Be sure to turn off the power before you perform any maintenance on the monitor. Do not: Apply water or liquid directly to your monitor. Use solvents or abrasives. Use flammable cleaning materials to clean your monitor or any other electrical equipment.
  • Page 26 Step 3: Remove the base from the monitor, refer to “Detaching the monitor base and stand”. Step 4: Attach the mounting bracket from the VESA compatible wall mounting kit (100mm x100mm distance), VESA Mounting Screw M4 x 10 mm. VESA hole Step 5: Attach the LCD display to the wall, following the instructions in the wallmounting kit.

  • Page 27: Chapter 3. Reference Information

    Chapter 3. Reference information This section contains monitor specifications, instructions to manually install the monitor driver, troubleshooting information, and service information. Monitor specifications Table 3-1. Monitor specifications for type-model 63FE-NAR2-WW Dimensions Depth 212.7 mm (8.37 inch) Height 365.7 mm (14.40 inch) Width 532.2 mm (20.95 inch) Panel...
  • Page 28 Table 3-1. Monitor specifications for type-model 63FE-NAR2-WW Video input (DP) Interface Input signal VESA TMDS (Panel Link™) Horizontal addressability 1920 pixels (max) Vertical addressability 1200 lines (max) Clock frequency 180 MHz Communications VESA DDC Supported Display Horizontal frequency 30 kHz - 82 kHz Modes Vertical frequency 48 Hz - 76 Hz...

  • Page 29: Troubleshooting

    Troubleshooting If you have a problem setting up or using your monitor, you might be able to solve it yourself. Before calling your dealer or Lenovo, try the suggested actions that are appropriate to your problem. Table 3-2. Troubleshooting Problem...
  • Page 30 Table 3-2. Troubleshooting Problem Possible cause Suggested action Reference The power The video signal Be sure the video cable is “Connecting and indicator is cable is loose or connected with the system turning on your orange, but disconnected from properly. monitor”on page 1-5 there is no the system or...

  • Page 31: Manually Installing The Monitor Driver

    Note: On LCD monitors, unlike CRTs, a faster refresh rate does not improve display quality. Lenovo recommends using either 1920 x 1200 at a refresh rate of 60 Hz, or 640 x 480 at a refresh rate of 60 Hz.

  • Page 32: Appendix A. Service And Support

    Product replacement assistance or exchange of defective components also is available during the warranty period. In addition, if your option is installed in a Lenovo computer, you might be entitled to service at your location. A Lenovo technical support representative can help you determine the best alternative.

  • Page 33: Appendix B. Notices

    The result obtained in other operating environments may vary. Lenovo may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you. Any references in this publication to non-Lenovo Web sites are provided for convenience only and do not in any manner serve as an endorsement of those Web sites.
  • Page 34 systems. Furthermore, some measurements may have been estimated through extrapolation. Actual results may vary. Users of this document should verify the applicable data for their specific environment. Appendix B.

  • Page 35: Recycling Information

    Collecting and recycling a disused Lenovo computer or monitor If you are a company employee and need to dispose of a Lenovo computer or monitor that is the property of the company, you must do so in accordance with the Law for Promotion of Effective Utilization of Resources.

  • Page 36: Power Cords And Power Adapters

    Power cords and power adapters Use only the power cords and power adapters supplied by the product manufacture Do not use the ac power cord for other devices. Appendix B.
