Summary of Contents for Mirpol MIR-H71-24
Page 1
2531-24 MIR-H71-24 2531-24 PIN:2531DP-0097 OGRZEWACZ GAZOWY Instrukcja montażu oraz wskazówki dotyczące użytkowania i bezpieczeństwa GAS HEATER Owner’s Manual Producent: Mirpol sp. z o.o. ul. Ciasna 3, 35-232 Rzeszów biuro@mirpol.rzeszow.pl www.mirpol.rzeszow.pl...
Page 2
UWAGA DANGER FIRE OR EXPLOSION HAZARD ZAGROŻENIE POŻAROWE I WYBUCHOWE If you smell gas: Jeśli poczujesz zapach gazu: Shut off gas to the appliance. • Zamknij dopływ gazu do urządzenia. • Extinguish any open flame. Zgaś otwarty płomień. • Jeśli nieprzyjemny zapach będzie się utrzymywał, If odor continues, leave the area immediately.
Page 3
RNING: Do not use any more than 1/4in depth lava rocks/pumice ane gas tank is leaking gas, you may hear, see, or smell a hiss. Do OSTRZEŻENIA DOTYCZĄCE BEZPIECZNEGO UŻYTKOWANIA e department for help. Przed rozpoczęciem użytkowania należy przeczytać obowiązkowo instrukcję obsługi. oo much propane may result in gas pooling and will not burn.
Page 4
UWAGA PRZECZYTAJ UWAŻNIE PONIŻSZE ZASADY BEZPIECZNEGO UŻYWANIA PRZED PRZYSTĄPIENIEM DO EKSPLOATACJI URZĄDZENIA! • Nie używaj urządzenia wewnątrz pomieszczeń, to może skutkować obrażeniami ciała lub uszkodzeniem mienia • Ogrzewacz zewnętrzny nie jest przeznaczony do stosowania w pojazdach rekreacyjnych lub/i na łodziach. •...
Page 5
USTAWIANIE OGRZEWACZA • Ogrzewacz przeznaczony jest tylko do użytku zewnętrznego. Zawsze upewnij się że jest CEI LI NG SUFIT odpowiedni dostęp świeżego powietrza i wentylacja. • Zawsze zachowuj odpowiedni odstęp od materiałów palnych np. 100 cm od górnej i bocznej powierzchni.
Page 6
WIDOK SZCZEGÓŁOWY I LISTA CZĘŚCI HARDWARE AA Śruba M6x10 BB Nakrętka M6 CC Śruba m5x10 DD Śruba EE Nakrętka motylkowa FF Podkładka GG Wspornik mocujący HH Śruba 3/16” Gałka JJ Duża podkładka KK Śruba m4x8 Item Description LL Wkrętak Bolt M6x10 MM Klucz M6 nut Screw M5x10...
ASSEMBLY INSTRUCTIONS MONTAŻ URZĄDZENIA 1. Przymocuj kółka (M) do dolnej półki (N) za pomocą 1.Assemble the wheel assembly (M) to the 4 śrub M6x10 (AA) i 4 nakrętek M6 (BB) bottom plate (N) using 4pcs bolt M6x10 (AA) and 4pcs M6 nut (BB). Użyte części Hardware Used Bolt M6x10...
Page 8
3. Mocowanie paska butli gazowej 3.Assemble gas tank fixing belt. Przymocuj pasek mocujący (J) do dwóch dolnych Fix the gas tank fixing belt (J) to the 2pcs wsporników (L) używając śrub M5x10 (CC) of lower support (L) using 2pcs screw Uwaga: M5x10(CC).
Page 9
5-1 Włóż górne wsporniki (D) w dolne 5-1. Insert upper support (D) to lower support wsporniki (L). Użyj śrub M5x10 (CC) (L) using 8pcs screw M5x10(CC). 5-2 Za pomocą 8 śrub 3/16” (HH) zamocuj 5-2. Assemble top plate assemble (B) to górną...
Page 10
7. Mocowanie siatek ochronnych (E). 7.Assembly the protective guard (E). Wsuń haczyki siatek ochronnych (E) w otwory Hang the hooks of the protective guard dolnych wsporników (D). Zabezpiecz siatki (E) onto the holes in upper support (D). ochronne (E) za pomocą wsporników mocujących (GG) i 4 śrub 3/16”...
Page 11
9. Zamocuj gałkę (II) to przedniego panelu (H) 9. Attach the knob (II) to front panel (H) używając śrub M4x8 (KK) i dużych podkładek using screw M4x8 (KK) and large flat (JJ) washer (JJ). Uwaga: Przełóż śrubę (KK) przez dużą Note: Put screw (KK) through płaską...
Hose / Regulator OPERATION EKSPLOATACJA Before performing a leak test, be sure that no sparks can Przed wykonaniem testu szczelności upewnij się, że nie ma iskier w pomieszczeniu, na świeżym powietrzu w którym znajdujesz. Podłącz butlę gazową do reduktora i przekręć zawór na urządzeniu na pozycję „OFF”. area.
ROZWIĄZYWANIE PROBLEMÓW PROBLEM PRZYCZYNA ROZWIĄZANIE Palnik nie zapala się Wtrysk palnika jest zatkany Przeczyść palnik NIskie ciśnienie gazu Zadzwoń do lokalnego dostawcy gazu Płomień palnika szybko NIskie ciśnienie gazu Zadzwoń do lokalnego dostawcy gaśnie po zapaleniu gazu Zapłon jest opóźniony Otwory palnika są...
Page 14
DANGER FIRE OR EXPLOSION HAZARD If you smell gas: Shut off gas to the appliance. Extinguish any open flame. If odor continues, leave the area immediately. After leaving the area, call your gas supplier or fire department. Failure to follow these instructions could result in fire or explosion, which could cause property damage, personal injury, or death.
Page 15
RNING: Do not use any more than 1/4in depth lava rocks/pumice ane gas tank is leaking gas, you may hear, see, or smell a hiss. Do WARNING SAFETY RULES e department for help. Please read the following safety rules prior to operation of the heater. oo much propane may result in gas pooling and will not burn.
Page 16
CAUTION PLEASE READ CAREFULLY TNE FOLLOWING SAFETY GUIDELINES BEFORE OPERATION! • Do not use the patio heater for indoors, as it may cause personal injury or property damage. • This outdoor heater is not Intended to be Installed on recreational vehicles and/or boats. •...
HEATER STAND AND LOCATION • The heater is for outdoor use only. Always ensure that adequate fresh air ventilation is CEI LI NG SUFIT provided. • Always maintain proper clearance to combustible materials, i.e. top 100 cm and sides 100 cm minimum.
Page 18
DETAILED VIEW AND PARTS LIST HARDWARE AA Bolt M6x10 BB M6 nut CC Screw M5x10 DD Stud EE Wing nut FF Flat washer GG Fixing Bracket HH Screw 3/16 Knob JJ Large flat washer KK Screw M4 X 8 Item Description LL Philips screwdriver Bolt M6x10...
Page 19
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS 1.Assemble the wheel assembly (M) to the bottom plate (N) using 4pcs bolt M6x10 (AA) and 4pcs M6 nut (BB). Hardware Used Bolt M6x10 M6 nut 2-1. Unscrew the ignition, load battery (NN), tighten the ignition. 2-2.
Page 20
3.Assemble gas tank fixing belt. Fix the gas tank fixing belt (J) to the 2pcs of lower support (L) using 2pcs screw M5x10(CC). ATTENTION: Ensure the gas tank fixing belt and wheel assembly are on the same side. Screw M5x10 WARNING Remove protective film before assembling.
Page 21
5-1 Włóż górne wsporniki (D) w dolne 5-1. Insert upper support (D) to lower support wsporniki (L). Użyj śrub M5x10 (CC) (L) using 8pcs screw M5x10(CC). 5-2 Za pomocą 8 śrub 3/16” (HH) zamocuj 5-2. Assemble top plate assemble (B) to górną...
Page 22
7.Assembly the protective guard (E). Hang the hooks of the protective guard (E) onto the holes in upper support (D). Secure the protective guards (E) with fixing brackets (GG) with 4pcs Screw 3/16” (HH). Hardware Used Screw 3/16” Fixing Bracket 8.
Page 23
9. Attach the knob (II) to front panel (H) using screw M4x8 (KK) and large flat washer (JJ). Note: Put screw (KK) through large flat washer (JJ) then through the end link of the Hardware Used retainer chain. Insert screw into hole on front door panel and attach the knob (II) Knob...
OPERATION OPERATION Before performing a leak test, be sure that no sparks can area. Connect the butane / propane gas tank to the regul Before performing a leak test, be sure that no sparks can occur and you are in a spacious outdoor area. Connect the butane “off”...
TROUBLESHOOTING PROBLEM CAUSE SOLUTION The burner will not The burner injector is clogged. Clean the burner injector. light. There is low gas supply pressure. Call your gas supplier. The burner flame goes There is low gas pressure. Call your gas supplier. off immediately after ignition.
