Summary of Contents for CAEL FL104
- Page 2 Catalogue Catalogue ....................1 Safety precautions ..................2 Parts List ....................3-4 Installation step ..................5-12 Maintaining ....................13...
-
Page 3: Safety Precautions
Safety Measure Safety precautions To ensure your safety, please read the following precautions before using this product. 1. Please read, study and understand the instruction manual and all warning labels before use. (It is recommended to be familiar with the normal operation and usage of the instrument before using this product. -
Page 4: Parts List
Parts List 2 underframe right 4 barrel seat 1 underframe left 3 rear base 5 pedal 6-pole frame 7 Zhulizhu left 8 right column 9 rear column 10 rear cross member 13 front roof beam 11 brace left 14 rear roof beam 12 brace right 15 left roof beam 18 crossbeam right... - Page 5 Parts List 44 Pulley 70 45 Pulley 90 41 Ball joint pin 42 Wire rope fixing frame 43 Hook left 49 Protection rack right 48 left protection frame 50 hook left 46 parallel bars left 47 parallel bars right 53 Attachment Parallel 54 foot covers 51 hook right 52 Attachment Parallel Bar...
-
Page 6: Installation Step
Installation step figure 1 1. Install 4 foot covers (#54) on the left and right bases (#1) (#2); 2. Use (#G)(#A) (#D) to install the barrel base (#4) on the rear base (#3); 3. Use (#G)(#A)(#D) to install the foot pedal (#5) on the right base (#2); 4. - Page 7 Installation step Figure 2 1. Install the front column left and right (#7) (#8) and the rear column (#9) on the base with (#6) (#A) (#D); 2. Use (#H)(#A)(#D) brace to connect the left and right (#11)( #12) to the upright post; 3.
- Page 8 Installation step Figure 3 1. Use (#G) (#A) (#D) to install the left and right top beams (#15) (#16) on the upright posts; 2. Use (#H) (#A) (#D) to connect the front roof beam (#13) to the left and right of the front pillar; 3.
- Page 9 Installation step Figure 4 1. Use (#I) (#A) (#D) to install (# 26) and (# 27) to the barrel seat; 2. Use (#H)(#A)(#D) to connect the right brace (#12) with the rear roof beam, and install it on the rear column together with the right beam (#18); (#18) The front end is connected with the right top beam with (#I) (#A) (#D);...
- Page 10 Installation step Figure 5 1. Put (#35), (#24) and (#35) (#22) on (#19) in turn, and insert the front column with (#M) (#B) Install the other side of the same installation; 2. Put both ends of (#20) into (#21) and connect (#21)(#22) with (#L)(#B)(#E). 3.
- Page 11 Installation step Figure 6 1. Tilt the guide rod (#29), put it in (#35), (#32)(#33) (#31)(#30) in turn, and sleeve it in (#36); Insert (# 55); Finally, fix that guide rod and the beam; 2. Install the other side in the same way.
- Page 12 Installation step Figure 7 As before, install the wire rope in the direction of arrow;...
- Page 13 Installation step Figure 8 1. Install the above components according to the use requirements.
- Page 14 Use and maintenance Use: 1、 Your instrument is now fully assembled. Please use a wrench to tighten all bolts and nuts. 2、 Before using it correctly, please check that all pulleys and wire ropes have been fixed. 3、 In the first stage, adjust the wire rope according to the actual situation. Maintenance method: In order to prolong the service life of the instrument, it is necessary to moisten the parts and components on time.
