SERVICE MANUAL
2004
1
YF018
GR-D32US,GR-D71US,
GR-D72US,GR-D74US
For disassembling and assembling of MECHANISM ASSEMBLY, refer to the SERVICE MANUAL No.86700 (MECHANISM ASSEMBLY).
Regarding service information other than these sections, refer to the service manual No. YF005 (GR-D73US).
Also, be sure to note important safety precautions provided in the service manual.
NOTE :
There are two types of VF(COLOR) ASSEMBLY used for this model: S type and K type.
Prior to repair operation related to VIEW FINDER, be sure to see the VF(COLOR)
ASSEMBLY and Parts List.
Methods to distinguish the two types are as follows:
1. Distinction based on EEPROM DATA (EEPROM utility). ( * 1)
2. Distinction based on a part number of the MONI-C BOARD ASSEMBLY.
3. Distinction based on a sticker attached to the VF(COLOR) ASSEMBLY.
EEPROM DATA ( * 1)
MONI-C PWB
VF(COLOR) ASSY
( * 1) It is necessary to confirm the original data (before repair work) of EEPROM.
COPYRIGHT © 2004 VICTOR COMPANY OF JAPAN, LIMITED
DIGITAL VIDEO CAMERA
GR-D32US[M4D1S3], GR-D71US,GR-D72US,GR-D74US[M4D1S7]
S TYPE
ADRS 3CCH:01H
YB10447 SERIES
NO STICKER
K TYPE
ADRS 3CCH:05H
YB10453 SERIES
STICKER ON TOP FACE
VF(COLOR) ASSEMBLY
STICKER
No.YF018
2004/1
