Summary of Contents for Bigger Boyz Toyz BULL-601U
- Page 1 OWNER’S MANUAL Assembly & Operating Instructions Bull BBQ Stainless Steel Long Outdoor Kitchen Large MODEL N0. BULL-601U...
-
Page 2: Customer Support
Warehouse: Unit 2/3 Delta Place, Albion Park Rail NSW 2527 We are here to ensure that your Bull BBQ experience is exceptional. Feel free to contact us anytime with any questions or concerns. Happy grilling! Bigger Boyz Toyz Australia BIGGER BOYZ TOYZ • BBTA.COM.AU... -
Page 3: Table Of Contents
CLEANING AND CARE ................15 ASSEMBLING ..................17 EXPANDED VIEW AND PART LIST ................17 NATURAL GAS CONVERSION ..................20 INSTRUCTION FOR CONVERTING THE MAIN BURNERS ........21 BARBEQUE LIGHT ......................23 SPECIFICATION ..................24 WARRANTY ................... 25 BBTA.COM.AU • BIGGER BOYZ TOYZ... -
Page 4: Safety & Alert Symbols
The descriptions and sections contained in this manual were in effect at the time of printing. Equipment described within this manual may be optional. Some illustrations may not be applicable to your equipment. BIGGER BOYZ TOYZ • BBTA.COM.AU... -
Page 5: Important Safety Information
WARNING Your Responsibility—Restrict the use of this equipment to persons who have read, understood, and will follow the warnings and instructions in this manual and on the machine SAVE THESE INSTRUCTIONS! BBTA.COM.AU • BIGGER BOYZ TOYZ... -
Page 6: Safety Warnings
» Avoid placing any items on or against the BBQ. » Keep chemicals, flammable materials, and aerosols away from the BBQ. » Only operate the appliance after leak-checking hoses and gas cylinder connection. » Avoid moving the appliance during use. BIGGER BOYZ TOYZ • BBTA.COM.AU... - Page 7 » Avoid positioning the BBQ under surfaces that can burn. » Ensure proper ventilation around the BBQ housing and avoid obstructing the airflow. Remember these safety measures to enjoy safe and satisfying grilling experiences with your Bull BBQ Stainless Steel Outdoor Kitchen. BBTA.COM.AU • BIGGER BOYZ TOYZ...
-
Page 8: Maintenance Manual
6. You can use a mixture of baking soda and water to create a paste for stubborn stains or rust. Apply the paste to the affected area and scrub gently. Rinse and dry afterwards. BIGGER BOYZ TOYZ • BBTA.COM.AU... -
Page 9: Regular Inspections
If you have any questions or need further assistance, please contact our customer service team. We are here to support you throughout your BBQ ownership journey. BBTA.COM.AU • BIGGER BOYZ TOYZ... -
Page 10: General Safety Rules
- the same principles apply to any other shaped area [Figure 1] Enclosure with walls on all [Figure Partial Enclosure with sides but no overhead cover and no overhead cover more than two walls BIGGER BOYZ TOYZ • BBTA.COM.AU... -
Page 11: Gas Cylinder Information
LPG cylinder not attached to the BBQ for use should be stored outdoors and well away from this appliance. IMPORTANT When disconnecting and removing the gas cylinder for the purpose of refilling, always observe the following procedure. BBTA.COM.AU • BIGGER BOYZ TOYZ... -
Page 12: Regulator Connection
5. Bubbling of the solution will indicate that there is a leak present. 6. Re-tighten or re-seal any joints that are leaking. 7. If a leak persists then contact your distributor or the manufacturer for assistance. BIGGER BOYZ TOYZ • BBTA.COM.AU... -
Page 13: Operations
5. To turn the barbeque OFF, turn the cylinder valve or regulator switch to the “OFF” position and then turn all of the control knobs on the barbeque clockwise to the “OFF” position. BBTA.COM.AU • BIGGER BOYZ TOYZ... -
Page 14: Abnormal Operation
» Yellow tipping of the yellow flame » Burners failing to remain alight » Sooting up of grills plates » Burner extinguished by trolley doors » Burners not igniting properly » Gas valves, which are difficult to turn BIGGER BOYZ TOYZ • BBTA.COM.AU... -
Page 15: Cleaning And Care
7. Check burner for damage, due to normal wear and corrosion some holes may become enlarged. If any large cracks or holes are found replace burner. 8. Care fully refit burners. 9. Replace screw at the end of burner. 10. Replace grease tray and cooking grates. BBTA.COM.AU • BIGGER BOYZ TOYZ... -
Page 16: Natural Hazard Spiders
An obstruction can result in a “flashback” (a fire in the burner tubes). The grill may still light, but the obstruction does not allow full gas flow to the burners. BIGGER BOYZ TOYZ • BBTA.COM.AU... -
Page 17: Assembling
ASSEMBLING EXPANDED VIEW AND PART LIST Tools required 1. Philips Screwdriver 2. Gloves (if necessary) BBTA.COM.AU • BIGGER BOYZ TOYZ... - Page 18 1. Left and right brackets assembly 2. Flame Diffuse Assebly 3. Cooking Grid/Plate Assembly BIGGER BOYZ TOYZ • BBTA.COM.AU...
- Page 19 4. Warming Rack Assembly 5. Grease Tray Assemby 6. Rotisserie and Battery Assembly BBTA.COM.AU • BIGGER BOYZ TOYZ...
-
Page 20: Natural Gas Conversion
3. All gas pipe connections must be sealed with a gas pipe compound resistant to natural gas. NOTE TO INSTALLERS The U-LPG jet is 0.98mm, the NGjet is 1.50mm. Both U-LPG injector and NG injector are installed together like right photo shows. The BBQ is set for U-LPG by manufacturer. BIGGER BOYZ TOYZ • BBTA.COM.AU... -
Page 21: Instruction For Converting The Main Burners
3. With the burner removed, you will see the brass gas jet (LPG) which is screwed into the end of the valve. Using the 6mm nut driver supplied, unscrew the end LPG jet while retaining the inner (NG) jet. BBTA.COM.AU • BIGGER BOYZ TOYZ... - Page 22 1. Remove the back burner cover 2. Remove the back burner gas pipe and remove the LPG jet from the elbow shaped brass injector assembly 3. Re-assemble the burner BIGGER BOYZ TOYZ • BBTA.COM.AU...
-
Page 23: Barbeque Light
3. The output for the Blue LED is 12V Way to replacing the barbeque light (if necessary) 1. Unscrew the lights 2. Take out the light sets 3. Unscrew the cable 4. Replacing a new BBQ lights. BBTA.COM.AU • BIGGER BOYZ TOYZ... -
Page 24: Specification
» The thread type of this appliance is G1/4B-19 » Technical Data subject to change without notice. For Electrical components AC Adapter Input 230-240VAC, 50Hz Output 12VAC 5000mA Cord 250V,10A Caution: Always keep the cord and electrical components in a dry location BIGGER BOYZ TOYZ • BBTA.COM.AU... -
Page 25: Warranty
Customer Support For further assistance, kindly reach out to our dedicated Customer Support Department at Bigger Boyz Toyz. We are here to assist you. Phone: 02 4257 4787 Email: bbt@bbta.com.au Warehouse: Unit 2/3 Delta Place, Albion Park Rail NSW 2527 BBTA.COM.AU... - Page 26 BBTA.COM.AU Copyright © Bigger Boyz Toyz Australia Unit 2/3 Delta Place Albion Park Rail NSW 2527 • 02 4257 4787...
