Uputstvo za upotrebu (EN)
DELL laptop Latitude 5531 (NOT20059)
Tehnoteka je online destinacija za upoređivanje cena i karakteristika bele tehnike,
potrošačke elektronike i IT uređaja kod trgovinskih lanaca i internet prodavnica u Srbiji.
Naša stranica vam omogućava da istražite najnovije informacije, detaljne karakteristike
i konkurentne cene proizvoda.
Posetite nas i uživajte u ekskluzivnom iskustvu pametne kupovine klikom na link:
https://tehnoteka.rs/p/dell-laptop-latitude-5531-not20059-akcija-cena/
Advertisement
Table of Contents
Related Manuals for Dell NOT20059
Summary of Contents for Dell NOT20059
- Page 1 Uputstvo za upotrebu (EN) DELL laptop Latitude 5531 (NOT20059) Tehnoteka je online destinacija za upoređivanje cena i karakteristika bele tehnike, potrošačke elektronike i IT uređaja kod trgovinskih lanaca i internet prodavnica u Srbiji. Naša stranica vam omogućava da istražite najnovije informacije, detaljne karakteristike i konkurentne cene proizvoda.
- Page 2 Latitude 5531 Setup and Specifications Regulatory Model: P104F Regulatory Type: P104F007/P104F008 May 2023 Rev. A01...
- Page 3 A WARNING indicates a potential for property damage, personal injury, or death. © 2022-2023 Dell Inc. or its subsidiaries. All rights reserved. Dell Technologies, Dell, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
-
Page 4: Table Of Contents
Contents Chapter 1: Set up your Latitude 5531.....................5 Chapter 2: Views of Latitude 5531....................7 Right......................................7 Left......................................7 Top......................................8 Display....................................8 Bottom....................................9 Back......................................9 Service Tag..................................10 Battery charge and status light .............................10 Chapter 3: Specifications of Latitude 5531................... 11 Dimensions and weight..............................11 Processor.................................... - Page 5 Chapter 5: Using the privacy shutter...................29 Chapter 6: Dell Optimizer......................30 Chapter 7: Keyboard shortcuts of Latitude 5531................31 Chapter 8: Getting help and contacting Dell................33 Contents...
-
Page 6: Chapter 1: Set Up Your Latitude 5531
Follow the on-screen instructions to complete the setup. For more information about installing and configuring Ubuntu, search in the Knowledge Base Resource at www.dell.com/support. For Windows: Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you: ● Connect to a network for Windows updates. NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when prompted. - Page 7 SupportAssist proactively checks the health of your system's hardware and software. When an issue is detected, the necessary system state information is sent to Dell to begin troubleshooting. SupportAssist is preinstalled on most of the Dell devices running Windows operating system.
-
Page 8: Chapter 2: Views Of Latitude 5531
Views of Latitude 5531 Right 1. microSD-card slot 2. Universal audio jack 3. USB 3.2 Gen 1 port 4. USB 3.2 Gen 1 port with PowerShare 5. HDMI 2.0 port 6. RJ45 Ethernet port (flip-down) 7. Wedge-shaped lock slot Left 1. -
Page 9: Top
1. Power button with fingerprint reader (optional) 2. Keyboard 3. Contactless smart-card reader (optional) 4. Clickpad Display 1. Ambient Light Sensor (ALS) 2. Microphone Views of Latitude 5531... -
Page 10: Bottom
3. IR emitter 4. IR camera 5. Camera shutter 6. RGB camera 7. Camera indicator LED 8. Microphone 9. LCD panel 10. Battery indicator/diagnostic LED Bottom 1. Speakers 2. Service tag label 3. Air vents Back 1. microSIM-card slot (optional) Views of Latitude 5531... -
Page 11: Service Tag
Service Tag The service tag is a unique alphanumeric identifier that allows Dell service technicians to identify the hardware components in your computer and access warranty information. Battery charge and status light The following table lists the battery charge and status light behavior of your Latitude 5531. -
Page 12: Chapter 3: Specifications Of Latitude 5531
Specifications of Latitude 5531 Dimensions and weight The following table lists the height, width, depth, and weight of your Latitude 5531. Table 3. Dimensions and weight Description Values Height: Front height 22.67 mm (0.89 in.) Rear height 24.05 mm (0.95 in.) Width 357.80 mm (14.09 in.) Depth... -
Page 13: Chipset
Chipset The following table lists the details of the chipset supported by your Latitude 5531. Table 5. Chipset Description Values Chipset Intel H45 Processor Generation Intel Core i5/i7 DRAM bus width 64-bit (for dual-channel) Flash EPROM ● 32 MB for non-vPro ●... -
Page 14: External Ports
To learn more about the features of different types of M.2 cards, see the knowledge base article 000144170 at www.dell.com/support. Ethernet The following table lists the wired Ethernet Local Area Network (LAN) specifications of your Latitude 5531. Table 9. Ethernet specifications... -
Page 15: Wireless Module
Wireless module The following table lists the Wireless Local Area Network (WLAN) module specifications of your Latitude 5531. Table 10. Wireless module specifications Description Option one Option two Option three Model number Realtek RTL8822CE Intel AX211 Intel AX211 Transfer rate Up to 867 Mbps Up to 2400 Mbps Up to 2400 Mbps... -
Page 16: Audio
NOTE: For instructions on how to find your computer's IMEI (International Mobile Station Equipment Identity) number, see the knowledge base article 000143678 at www.dell.com/support. Audio The following table lists the audio specifications of your Latitude 5531. Table 12. Audio specifications... -
Page 17: Media-Card Reader
Table 13. Storage matrix (continued) Storage SSD-slot 1 SSD-slot 2 2.5-inch hard drive (with 4- cell battery configuration) M.2 SSD Boot Not applicable M.2 SSD Boot RAID0 or RAID1 RAID0 or RAID1 M.2 SSD Boot RAID0 or RAID1 RAID0 or RAID1 Not applicable M.2 SSD Boot 2.5-inch hard drive... -
Page 18: Camera
Table 16. Keyboard specifications (continued) Description Values Number of keys ● United States and Canada: 99 keys ● United Kingdom: 100 keys ● Japan: 103 keys Keyboard size X=18.05 mm key pitch Y=18.05 mm key pitch Keyboard shortcuts Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. -
Page 19: Clickpad
Table 18. FHD RGB + IR camera specifications (continued) Description Values Still image 2.07 megapixel Video 1920 x 1080 (VGA/FHD) at 30 fps Infrared camera resolution: Still image 0.23 megapixel Video 640 x 360 (VGA/FHD) at 15 fps Diagonal viewing angle: Camera 87.6 degrees Infrared camera... -
Page 20: Power Adapter
The following table lists the battery specifications of your Latitude 5531. NOTE: Dell recommends that you charge the battery regularly for optimal power consumption. If your battery charge is completely depleted, connect the power adapter, turn on your computer and then restart your computer to reduce the power consumption. - Page 21 CAUTION: Dell recommends that you charge the battery regularly for optimal power consumption. If your battery charge is completely depleted, connect the power adapter, turn on your computer, and then restart your computer to reduce the power consumption.
-
Page 22: Display
Display The following table lists the display specifications of your Latitude 5531. Table 23. Display specifications Description Option one Option two Option three Option four Option five Display type Ultra High High Definition (HD) Full High Definition Full High Definition Full High Definition Definition (UHD), (FHD) -
Page 23: Fingerprint Reader (Optional)
Table 23. Display specifications (continued) Description Option one Option two Option three Option four Option five Touch options Fingerprint reader (optional) The following table lists the specifications of the optional fingerprint-reader of your Latitude 5531. Table 24. Fingerprint reader specifications Description Values Fingerprint-reader sensor technology... -
Page 24: Gpu-Discrete
RPMC SPI Flash SPI Flash Tamper Detection/Prevention Shunt Circuit Dell Client Command Suite : On-Prem & Cloud Dell Optimizer Dell Power Manager Support assist : PCs & OS Recovery (Excalibur) Dell SafeBIOS - Off-Host Verification Dell SafeBIOS - Indicator of Attack... -
Page 25: Smart-Card Reader
Table 29. Hardware security (continued) Dell SafeID Vmware Carbon Black Endpoint: Standard, Advanced, Enterprise Absolute Visibility Absolute Control Absolute Resilience Netskope Cloud Access Security Broker (CASB) Netskope Secure Web Gateway Netskope Private Access Optional Dell Data Security and Management Software... - Page 26 Circuit Card Interface Device for OS level drivers Windows Certified Device certified by Microsoft WHCK Dell ControlVault support Device connects to Dell ControlVault for usage and processing FIDO2 compliance Dell ControlVault 3 Smart-card reader is compliant with the FIDO SPEC NOTE: 125 Khz proximity cards are not supported.
-
Page 27: Contacted Smart-Card Reader
Circuit Card Interface Device for OS level drivers. Windows Certified Device certified by WHCK FIPS 201 (PIV/HSPD-12) Compliant via Device compliant with FIPS 201/PIV/ HSPD-12 requirements FIDO2 compliance Dell ControlVault 3 Smart-card reader is compliant with the FIDO SPEC Specifications of Latitude 5531... -
Page 28: Operating And Storage Environment
Operating and storage environment This table lists the operating and storage specifications of your Latitude 5531. Airborne contaminant level: G1 as defined by ISA-S71.04-1985 Table 33. Computer environment Description Operating Storage Temperature range 0°C to 35°C (32°F to 95°F) -40°C to 65°C (-40°F to 149°F) Relative humidity (maximum) 10% to 90% (non-condensing) 0% to 95% (non-condensing) -
Page 29: Chapter 4: Comfortview Plus
ComfortView Plus WARNING: Prolonged exposure to blue light from the display may lead to long-term effects such as eye strain, eye fatigue, or damage to the eyes. Blue light is a color in the light spectrum which has a short wavelength and high energy. Chronic exposure to blue light, particularly from digital sources, may disrupt sleep patterns and cause long-term effects such as eye strain, eye fatigue, or damage to the eyes. -
Page 30: Chapter 5: Using The Privacy Shutter
Using the privacy shutter 1. Slide the privacy shutter to the left to access the camera lens. 2. Slide the privacy shutter to the right to cover the camera lens. Using the privacy shutter... -
Page 31: Chapter 6: Dell Optimizer
Dell Optimizer This section details the Dell Optimizer specifications of your Latitude 5531. On Latitude 5531 with Dell Optimizer, the following features are supported: ● ExpressConnect—Automatically joins the access point with the strongest signal, and directs bandwidth to conferencing applications when in use. -
Page 32: Chapter 7: Keyboard Shortcuts Of Latitude 5531
Keyboard shortcuts of Latitude 5531 NOTE: Keyboard characters may differ depending on the keyboard language configuration. Keys used for shortcuts remain the same across all language configurations. Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. - Page 33 Table 35. Secondary behavior (continued) Function key Secondary behavior Fn + F4 Operating system and application specific F4 behavior Fn + F5 Operating system and application specific F5 behavior Fn + F6 Operating system and application specific F6 behavior Fn + F8 Operating system and application specific F8 behavior Fn + F9 Operating system and application specific F9 behavior...
-
Page 34: Chapter 8: Getting Help And Contacting Dell
Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 36. Self-help resources Self-help resources Resource location Information about Dell products and services www.dell.com My Dell app... - Page 35 Ovaj dokument je originalno proizveden i objavljen od strane proizvođača, brenda Dell, i preuzet je sa njihove zvanične stranice. S obzirom na ovu činjenicu, Tehnoteka ističe da ne preuzima odgovornost za tačnost, celovitost ili pouzdanost informacija, podataka, mišljenja, saveta ili izjava sadržanih u ovom dokumentu.
