Summary of Contents for Hubbell BECKWITH ELECTRIC M-3311A

Page 1 Instruction Book M‑3311A Transformer Protection Relay A proud member of the Hubbell family.
Page 2 TRADEMARKS All brand or product names referenced in this document may be trademarks or registered trademarks of their respective holders. The content of this Instruction Book is provided for informational use only and is subject to change without notice. Beckwith Electric has approved only the English version of this document.
Page 3: Transformer Protection
Transformer Protection M‑3311A Integrated Protection System ® • For Transformers of All Sizes: Two-, Three- or Four-winding Transformers for ‹ Transmission and Distribution applications Generator-Transformer Unit Overall Differential ‹ Unit Protection of Other Electrical Apparatus and ‹ certain Bus Arrangements (including those with a transformer in the zone) •...
Page 4: Standard Features
M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification Standard Protective Functions Optional Features • Negative-sequence inverse time overcurrent (46) • Redundant Power Supply • Winding thermal protection (49) • Ethernet Port RJ-45 10/100 Base-T (MODBUS over TCP/IP) •...
Page 5 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification STANDARD PROTECTIVE FUNCTIONS Device Setpoint Number Function Ranges Increment Accuracy † Negative Sequence Overcurrent 46W2/46W3/46W4 Definite Time Pickup 0.10 to 20.00 A 0.01 A ±0.1 A or ±3% (0.02 to 4.00 A) (±0.02 A or ±3%) Time Delay...
Page 6 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification STANDARD PROTECTIVE FUNCTIONS (cont.) Device Setpoint Number Function Ranges Increment Accuracy † Instantaneous Residual Overcurrent Pickup 1.0 to 100.0 A 0.1 A ±0.1 A or ±3% (0.2 to 20.0 A) (±0.02 A or ±3%) Time Delay 1 to 8160 Cycles...
Page 7 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification STANDARD PROTECTIVE FUNCTIONS (cont.) Device Setpoint Number Function Ranges Increment Accuracy † Instantaneous Residual Overcurrent Pickup 5.0 to 20.0 PU 0.1 PU ±0.1 PU or ±3% Time Delay 1 to 8160 Cycles 1 Cycle -1 to +3 Cycles or ±1%...
Page 8 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification STANDARD PROTECTIVE FUNCTIONS (cont.) Device Setpoint Number Function Ranges Increment Accuracy † IPSlogic IPSlogic uses element pickups, element trip commands, control/status input state changes, output contact close signals with programmable logic array to develop schemes. Reset/Dropout Delay #1–#6 0 to 65500 Cycles 1 Cycle...
Page 9 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification STANDARD PROTECTIVE FUNCTIONS (cont.) Device Setpoint Number Function Ranges Increment Accuracy † Through Fault Through Fault 1.0 to 100.0 A 0.1 A ±0.1 A or ±5% Current Threshold (0.2 to 20.0 A) (±0.02 A or ±5%) Through Fault Count Limit...
Page 10 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification OPTIONAL VOLTAGE PROTECTION PACKAGE Device Setpoint Number Function Ranges Increment Accuracy † Volts/Hz Overexcitation Definite Time Pickup #1, #2 100 to 200% ±1% Time Delay #1, #2 30 to 8160 Cycles 1 Cycle ±25 Cycles Inverse Time...
Page 11 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification OPTIONAL VOLTAGE PROTECTION PACKAGE (cont.) Device Setpoint Number Function Ranges Increment Accuracy † Overfrequency/Underfrequency Pickup #1, #2, #3, #4 55.00 to 65.00 Hz 0.01 Hz ±0.1 Hz 45.00 to 55.00 Hz* Time Delay #1, #2, #3, #4 2 to 65,500** Cycles 1 Cycle...
Page 12: Configuration Options
M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification Configuration Options The M-3311A Transformer Protection Relay may be purchased as a fully configured two, three or four winding Transformer Protection System. The M-3311A can also be purchased with the Optional Voltage Protection Package to expand the system to satisfy specific application needs.
Page 13: Sensing Inputs
M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification Sequence of Events Log The Sequence Events Log records predefined relay events. The Sequence of Events Log includes 512 of the most recently recorded relay events. The events and the associated data is available for viewing utilizing the S-3300 IPScom Communications Software.
Page 14: Output Contacts
M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification Output Contacts Any of the functions can be individually programmed to activate any one or more of the eight programmable output contacts OUTPUT1 through OUTPUT8. Any output contact can also be selected as pulsed or latched. IPSlogic can also be used to activate an output contact.
Page 15: Hmi Module
M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification Optional Ethernet Port The RJ-45 Ethernet port supports 10/100 Base-T fast Ethernet standard with auto negotiable speed. Additionally, MDI-X capability is provided to eliminate the need of a crossover cable when two similar devices are connected.
Page 16: Electrical Environment
M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification Tests and Standards The relay complies with the following type tests and standards: Voltage Withstand Dielectric Withstand Dielectric Withstand IEC 60255-27 2,000 Vac/3,500 Vdc for 1 minute applied to each independent circuit to earth 2,000 Vac/3,500 Vdc for 1 minute applied between each independent circuit 1,500 Vdc for 1 minute applied to IRIG-B circuit to earth 1,500 Vdc for 1 minute applied between IRIG-B to each independent circuit...
Page 17: Atmospheric Environment
M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification Radiated Susceptibility Radiated Susceptibility IEEE C37.90.2 80-1000 MHz 35 V/m IEC 61000-4-3 1000-6000 MHz 10 V/m Output Contacts Output Contacts IEEE C37.90 30 A make for 0.2 seconds at 250 Vdc Resistive cULus 508 8 A carry at 120 Vac, 50/60 Hz 6 A break at 120 Vac, 50/60 Hz...
Page 18: Disposal And Recycling
M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification Physical Without Optional I/O Expansion Module Size Size: 19.00" wide x 5.21" high x 10.20" deep (48.3 cm x 13.2 cm x 25.9 cm) Mounting Mounting: The unit is a standard 19", semiflush, three-unit high, rack-mount panel design, conforming to ANSI/EIA RS-310C and DIN 41494 Part 5 specifications.
Page 19 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification –17– –17–...
Page 20 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification –18– –18–...
Page 21 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification M-3311A Typical Connection Diagram Two Winding Model This function is available as a standard protective function. This function is available in the Optional Voltage Protection Package M-3311A Winding 1 (W1) Targets Integral HMI...
Page 22 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification This function is available as a M-3311A Typical standard protective function. Connection Diagram Three Winding Model This function is available in the Optional Voltage Protection Packages. 3-CT M-3311A Targets NOTE †...
Page 23 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification M-3311A Typical This function is available as a standard protective function. Winding 1 Winding 4 Connection Diagram (W4) (W1) Four Winding Model This function is available in 3-CT 3-CT the Optional Voltage Protection Packages.
Page 24: Connection Diagram
M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification M-3311A Typical This function is available as a standard protective function. Connection Diagram Four Winding Model Winding 4 Winding 1 This function is available in the (W4) (W1) Optional Voltage Protection 3-CT 3-CT...
Page 25 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification M-3311A System M-3311A M-3311A Figure 7 Dual Generator Power Plant Differential Zone of Protection System M-3311A Figure 8 Generator Plant Overall Differential Zone of Protection –23– –23–...
Page 26 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification M-3311A System Figure 9 Three Winding Transformer with High Impedance Ground System System M-3311A M-3311A Figure 10 Dual Bank Distribution Substation –24– –24–...
Page 27 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification 87GD W2 M-3311A NOTES: ꄿ NOTES: Winding 1 & 2 current summed and Winding 3 & 4 current summed for overcurrent function 87GDW2 function 3I current is the sum of W1, W2, W3 and W4 currents. Figure 11 Auto Transformer with two Circuit Breakers on High and Low Side 52-1 52-2...
Page 28 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification 17.50 [44.45] ACTUAL 5.21 [13.23] ACTUAL 17.50 [44.45] 10.20 [25.91] 19.00 [48.26] 19.00 [48.26] 18.31 0.35 [46.51] [0.89] 0.40 [1.02] X 0.27 [0.68] Slot (4X) 2.25 [5.72] 1.48 [3.8] Standard 19"...
Page 29 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification M-3311A TRANSFORMER PROTECTION ® 0.35 18.31 [0.89] [46.51] n NOTES: NOTES: Dimensions in brackets are in centimeters. See Instruction Book Chapter 5 for Mounting and Cutout information. Figure 14 Horizontal Unit Dimensions With Expanded I/O –27–...
Page 30 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification 5.65 [14.40] 5.59 6.19 0.03 [14.20] [15.7] [0.076] Actual 2.25 1.97 2.25 1.67 0.35 [5.72] [5.0] [5.72] [4.24] [0.89] 0.28 [0.71] Dia. (4X) TARGETS 19.00 [48.26] OUTPUTS OUT 3 OUT 5 OUT 7 OUT 1...
Page 31 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification R A T E D C U R R E N T IRIG-B ø 1A , N O M TARGETS 5 A , N O M C O M 2 ETHERNET R T N Ø...
Page 32 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification This Page Left Intentionally Blank –30– –30–...
Page 33 M‑3311A Transformer Protection Relay – Specification M‑3311A Transformer Protection Relay – Specification This Page Left Intentionally Blank –31– –31–...
Page 34 PHONE (727) 544-2326 PHONE (727) 544-2326 beckwithelectricsupport beckwithelectricsupport hubbell.com hubbell.com www.beckwithelectric.com www.beckwithelectric.com ISO 9001:2015 ISO 9001:2015 A proud member of the Hubbell family. © 2005 Beckwith Electric. All Rights Reserved. © 2005 Beckwith Electric. All Rights Reserved. M-3311A-SP-12 01/24 M-3311A-SP-12 01/24...
Page 35 WARNING DANGEROUS VOLTAGES, capable of causing death or serious injury, are present on the external terminals and inside the equipment. Use extreme caution and follow all safety rules when handling, testing or adjusting the equipment. However, these internal voltage levels are no greater than the voltages applied to the external terminals.
Page 36 PRODUCT CAUTIONS Before attempting any test, calibration, or maintenance procedure, personnel must be completely familiar with the particular circuitry of this unit, and have an adequate understanding of field effect devices. If a component is found to be defective, always follow replacement procedures carefully to that assure safety features are maintained.
Page 37: Table Of Contents
M‑3311A Instruction Book Table of Contents M‑3311A Transformer Protection Instruction Book Chapter 1 Introduction Instruction Book Contents ..................... 1–1 M-3311A Transformer Protection Relay ................. 1–2 Communication Ports ..................... 1–3 S-3300 IPScom Communications Software..............1–4 Accessories ........................1–4 M-3933/M-0423 Serial Communication Cables .............. 1–4 M-3801D IPSplot Plus Oscillograph Analysis Software ..........
Page 38 M‑3311A Instruction Book Chapter 2 Operation (Cont.) View Target History from IPScom ................. 2–18 Oscillograph Recorder Data ..................2–19 Oscillograph Recorder from IPScom ................2–23 OSC to ComTrade ......................2–25 Software Version (Relay Front Panel only) ..............2–25 Serial Number (Relay Front Panel only) ............... 2–26 Alter Access Codes (from Relay Front Panel) ..............
Page 39 M‑3311A Instruction Book Chapter 3 IPScom (Cont.) Relay/Setup ........................3–18 Relay/Setup/Setup System ................... 3–18 Relay/Setup/Relay Setpoints ..................3–21 Relay/Setup/Set Date & Time ..................3–23 Relay/Setup/Display/I/O Map ..................3–24 Relay/Setup/Display All Setpoints ................3–25 Relay/Demand Status ....................3–27 Relay/Targets ........................ 3–28 Relay/Through Fault .....................
Page 40 M‑3311A Instruction Book Chapter 4 System Setup and Setpoints (Cont.) IPScom Set Date/Time ....................4–11 Communication Setup ....................4–13 Serial Ports (RS-232) ....................4–13 Serial Port (RS-485) ..................... 4–13 Direct Connection ......................4–13 Device Address......................4–13 IPScom COM Port Definitions and System's Communication Address ......4–14 Ethernet Communication Settings ................
Page 41 M‑3311A Instruction Book Chapter 4 System Setup and Setpoints (Cont.) 87 Phase Differential ....................4–82 87T Phase Differential Restrained Overcurrent ............4–82 Cross Phase Averaging ....................4–84 87T CT Tap Settings ..................... 4–84 87T CT Tap Settings For W1, W2, W3 and W4 ............. 4–84 CT Tap Setting Calculation Example ................
Page 42 M‑3311A Instruction Book Chapter 5 Installation (Cont.) IPScom Communications and Analysis Software Installation ........5–42 IPScom Installation and Setup ..................5–42 Hardware Requirements ....................5–42 Installing IPScom ......................5–42 Activating Initial Local Communications ..............5–43 Initial Setup Procedure ....................5–44 Setup Procedure ......................
Page 43 M‑3311A Instruction Book Appendix C Error Codes Appendix D Inverse Time Curves Appendix E Layup and Storage Storage Requirements (Environment) ................E–1 Storage Requirements (Periodic Surveillance During Storage) ........E–1 Layup Configuration ......................E–1 Appendix F HMI Menu Flow HMI Menu Overview ......................F–2 Key to Input Data ......................F–2 HMI Menu Flow ........................F–4 Appendix H Declaration of Conformity...
Page 44 M‑3311A Instruction Book List of Figures List of Figures Chapter 2 Operation Figure 2-1 M-3311A Front Panel .................. 2–2 Figure 2-2 Typical Two-/Three-Winding Target Module ..........2–3 Figure 2-3 Typical Four-Winding Target Module ............2–3 Figure 2-4 Screen Message Menu Flow ..............2–4 Figure 2-5 Main HMI Menu Flow ..................
Page 45 List of Figures Chapter 3 IPScom (Cont.) Figure 3-7 IPScom TCP/IP Ethernet Communication Dialog Screen ......3–6 Figure 3-8 IPScom Modem Communication Dialog Screen ........3–6 Figure 3-9 Terminal Window ..................3–7 Figure 3-10 Primary Metering Status Screen (Two-/Three-Winding) ......3–9 Figure 3-11 Primary Metering Status Screen (Four-Winding) ........
Page 46 M‑3311A Instruction Book Chapter 3 IPScom (Cont.) Figure 3-52 Setup Relay Ethernet Port Dialog Screen ..........3–37 Figure 3-53 Output Test Warning Dialog Screen ............3–38 Figure 3-54 Output Test Dialog Screen ..............3–38 Figure 3-55 Counters and Error Codes Dialog Screen ..........3–38 Figure 3-56 Firmware Update Warning Dialog Screen ..........
Page 47 List of Figures Chapter 4 System Setup and Setpoints (Cont.) Figure 4-29 IPScom (24) Volts/Hertz Setpoint Ranges ..........4–59 Figure 4-30 IPScom (27) Undervoltage Setpoint Ranges (Two-/Three-Winding) ..4–61 Figure 4-31 IPScom (27) Undervoltage Setpoint Ranges (Four-Winding) ....4–61 Figure 4-32 IPScom (46) Negative Sequence Overcurrent Setpoint Ranges .... 4–63 Figure 4-33 49 Function Overload Curves ..............
Page 48 M‑3311A Instruction Book Chapter 4 System Setup and Setpoints (Cont.) Figure 4-73 Delta-ac/Wye/Wye CT Connection Diagram ......... 4–114 Figure 4-74 Custom Settings for Delta-ac/Wye/Wye ..........4–115 Figure 4-75 Wye/Delta-ac/Delta-ac CT Connection Diagram ........4–116 Figure 4-76 Custom Settings for Wye/Delta-ac/Delta-ac ......... 4–117 Chapter 5 Installation Figure 5-1 M-3311A Horizontal Chassis Mounting Dimensions (H1) ......
Page 49 List of Figures Chapter 5 Installation (Cont.) Figure 5-28 Four-Winding – Three Ground Inputs – Zero or Two Voltage Inputs Vertical Chassis External Connections ........... 5–29 Figure 5-29 Typical (Two Winding – Two Voltage Inputs) Three-Line Connection Diagram ....................5–30 Figure 5-30 Typical (Two Winding –...
Page 50 M‑3311A Instruction Book Appendix A Configuration Record Forms Figure A-1 System Communication Setup ..............A–4 Figure A-2 Setup System (Two or Three Windings) .............A–5 Figure A-3 Setup System (Four Windings) ..............A–8 Figure A-4 System Setpoints and Settings ..............A–11 Appendix B Communications Figure B-1 Null Modem Cable for M-3311A ..............B–3 Figure B-2 RS-232 Fiber Optic Network ..............B–4 Figure B-3 RS-485 Network ..................B–5...
Page 51 List of Tables List of Tables List of Tables Chapter 1 Introduction Table 1-1 M-3311A Device Functions ................1–3 Chapter 2 Operation Table 2-1 Four-Winding Recorder Partitions .............. 2–20 Table 2-2 Two-/Three-Winding Recorder Partitions ........... 2–21 Chapter 3 IPScom Chapter 4 System Setup and Setpoints Table 4-1 Dead-Sync Time ..................
Page 52 M‑3311A Instruction Book Appendix A Configuration Record Forms Table A-1 Relay Configuration (1 of 2) .................A–2 Appendix B Communications Table B-1 Communication Port Signals ................B–3 Appendix C Selt-Test Error Codes Table C-1 Selt-Test Error Codes ................. C–1 800-3311A-IB-12 12/23 ©2007 Beckwith Electric. All Rights Reserved.
Page 53: Chapter 1 Introduction
Introduction – 1 Introduction Instruction Book Contents ..............1–1 M-3311A Transformer Protection Relay ..........1–2 Accessories ..................1–4 Instruction Book Contents This instruction book includes six Chapters and seven Appendices. Chapter 1: Introduction Chapter One summarizes the devices' capabilities, introduces the instruction book contents and describes the application of an M-3311A.
Page 54: M-3311A Transformer Protection Relay
M‑3311A Instruction Book Appendix B: Communications This Appendix describes communication port signals and various topologies and equipment required for remote communication. Appendix C: Self-Test Error Codes This Appendix lists all the error codes and their definitions. Appendix D: Inverse Time Curves This appendix contains a graph of the four families of Inverse Time Curves for V/Hz applications, the four standard and the four IEC overcurrent curves.
Page 55: Communication Ports
Introduction – 1 STANDARD FUNCTIONS DESCRIPTION 46W2, 3, 4 Negative Sequence Overcurrent Winding Thermal Protection (W1 or W2 or W3) 50 1-8 Instantaneous Phase Overcurrent 50BFW1, 2, 3, 4 Breaker Failure 50GW2, 3, 4 Instantaneous Ground Overcurrent 50N 1-8 Instantaneous Residual Overcurrent 51 1-8 Inverse Time Phase Overcurrent 51GW2, 3, 4...
Page 56: S-3300 Ipscom Communications Software
M‑3311A Instruction Book The relay may be remotely set and interrogated utilizing either a hard-wired RS-232 serial connection or modem (COM2 when activated as RS-232, or COM3), or when purchased, the ethernet connection (RJ45 activated). Detailed information regarding the use of the relay communications ports is provided in Appendix B, Communications, as well as Chapter 3, IPScom.
Page 57: Chapter 2 Operation
Operation – 2 Operation Front Panel Controls and Indicators .............2–2 Operation (HMI/PC)................2–4 This chapter contains information that describes the operation of the M-3311A Transformer Protection Relay. See Chapter 4 for System Setup, Configuration and Setpoint information. M-3311A operation from either IPScom or HMI includes the following: •...
Page 58: Front Panel Controls And Indicators
M‑3311A Instruction Book Front Panel Controls and Indicators The M-3311A can be interrogated locally with the HMI panel. An integral part of the design is the layout and function of the front panel indicators and controls, illustrated in Figure 2-1. Figure 2-1 M-3311A Front Panel Alphanumeric Display The HMI module consists of a 2 x 24-character alphanumeric display.
Page 59: Time Sync Led
Operation – 2 Time Sync LED The green TIME SYNC TIME SYNC LED illuminates to indicate that the IRIG‑B time signal is being received and validated. Breaker Closed (BRKR CLOSED) LED The red BRKR CLOSED BRKR CLOSED LED illuminates when the breaker status input (52b) is open. Diagnostic LED (DIAG) The diagnostic LED flashes upon the occurrence of a detectable self-test error.
Page 60: Operation (Hmi/Pc)
M‑3311A Instruction Book Operation (HMI/PC) The purpose of this section is to describe the steps that are necessary to interrogate the M-3311A utilizing either the HMI or a PC running S-3300 IPScom Communications software through COM1 the front RS-232 serial port. These instructions assume that the following conditions exist: •...
Page 61: Figure 2-5 Main Hmi Menu Flow
Operation – 2 NOTE: NOTE: See Appendix F Appendix F, HMI Menu Flow HMI Menu Flow for menu item details.   Figure 2-5 Main HMI Menu Flow 2–5...
Page 62: Hmi Security
M‑3311A Instruction Book HMI Security To prevent unauthorized access to the relay functions, the relay includes the provision for assigning access codes. If access codes have been assigned, the access code entry screen will be displayed after ENTER ENTER is pressed from the default message screen. The relay is shipped with the access code feature disabled. The relay includes three levels of access codes.
Page 63: Voltage Relay
Operation – 2 b. If the proper Access Code has been entered, the HMI will return: LEVEL #(1,2 or 3) Access Granted! VOLTAGE RELAY VOLT curr freq v/hz c. Go to Step 4. 3. If Level Access is not Active, then the following will be displayed: VOLTAGE RELAY VOLT curr freq v/hz...
Page 64: Figure 2-6 Primary Metering & Status Screen (Two-/Three-Winding)
M‑3311A Instruction Book Path Path: Monitor / Primary Metering & Status Figure 2-6 Primary Metering & Status Screen (Two- / Three-Winding) Path Path: Monitor / Primary Metering & Status Figure 2-7 Primary Metering & Status Screen (Four-Winding) 2–8...
Page 65: Monitor/Secondary Metering And Status
Operation – 2 SECONDARY METERING AND STATUS To access the SECONDARY METERING AND STATUS SECONDARY METERING AND STATUS parameters utilizing IPScom, select Monitor/ Monitor/ Secondary Metering and Status Secondary Metering and Status from the IPScom Main Screen drop down menu. Monitor/Secondary Metering and Status The Secondary Metering &...
Page 66: Figure 2-9 Secondary Metering & Status Screen (Four-Winding)
M‑3311A Instruction Book Path Path: Monitor / Secondary Metering & Status Figure 2-9 Secondary Metering & Status Screen (Four-Winding) METERING II To access the ME MET T E E R R I I N N G G I I I I parameters utilizing IPScom, select M M o o n n it ito o r r /M /Me e te ter r i i n n g g I I I I from the IPScom Main Screen drop down menu.
Page 67: Monitor/Metering Ii
Operation – 2 Monitor/Metering II The Metering II screen (Figure 2-10 Figure 2-11) includes the following parameters: • 2 and 5 Harmonic Differential Currents (PU), (Phase A/B/C) • Thermal Currents (Phase A/B/C) for W1 or W2 or W3 or W4 Also included on the Metering II screen are: NOTE: NOTE:...
Page 68: Demand Status
M‑3311A Instruction Book Path Path: Monitor / Metering ll Figure 2-11 Metering II Screen (Four-Winding) Demand Status Monitored Primary Demand values include: • Winding 1, 2, 3, & 4 Phase Currents • Winding 2, 3, and 4 Ground Current Maximum Demand Current Maximum values include time-tagged values for all the above quantities.
Page 69: Demand Interval
Operation – 2 Demand Interval Time integrated primary metering values, based on the chosen demand integration interval (15 min, 30 min, or 60 min), as well as the time-tagged peak readings are available for viewing. Demand (from Relay Front Panel) The HMI menu items for Demand are: •...
Page 70 M‑3311A Instruction Book To access the MAXIMUM DEMAND MAXIMUM DEMAND CURRENT CURRENT, proceed as follows: 1. Press the ENTER ENTER pushbutton. 2. If Level Access is active, the following is displayed: ENTER ACCESS CODE a. Input the required Access Code, then press ENTER ENTER.
Page 71 Operation – 2 To access the CLEAR MAXIMUM DEMAND CLEAR MAXIMUM DEMAND CURRENT CURRENT, proceed as follows: 1. Press the ENTER ENTER pushbutton. 2. If Level Access is active, the following is displayed: ENTER ACCESS CODE a. Input the required Access Code, then press ENTER ENTER.
Page 72: Demand Status From Ipscom
M‑3311A Instruction Book Demand Status from IPScom Demand Currents To display Demand Currents select Monitor/Metering II Monitor/Metering II. IPScom will display the Metering II screen (Figure 2-10 Figure 2-11). The Metering II screen includes the following Demand Currents Demand Currents: •...
Page 73: View Target History
Operation – 2 b. If the proper Access Code has been entered, the HMI will return: LEVEL #(1,2 or 3) Access Granted! VOLTAGE RELAY VOLT curr freq v/hz c. Go to Step 4. 3. If Level Access is not Active, the HMI will advance directly to: VOLTAGE RELAY VOLT curr freq v/hz...
Page 74: View Target History From Ipscom
M‑3311A Instruction Book 4. Press the Right arrow pushbutton until the following is displayed: VIEW TARGET HISTORY TARGETS osc_rec comm 5. Press the ENTER ENTER pushbutton, the following will be displayed: VIEW TARGET HISTORY TRGT clear 6. Press the Right arrow pushbutton until the following is displayed: VIEW TARGET HISTORY TRGT clear...
Page 75: Oscillograph Recorder Data
Operation – 2 Clear Targets To Clear Targets perform the following: 1. Select Relay/Targets/Clear Relay/Targets/Clear. IPScom will display the Clear Targets confirmation dialog screen (Figure 2-14). Figure 2-14 Clear Targets Confirmation Dialog Screen 2. Select Yes Yes. IPScom will display the Clear Targets dialog screen (Figure 2-15).
Page 76: Table 2-1 Four-Winding Recorder Partitions
M‑3311A Instruction Book Number of Partitions Windings 1, 2, 3, 4 Windings 1, 2, 3 Windings 1, 2 Table 2-1 Four-Winding Recorder Partitions 2–20...
Page 77: Table 2-2 Two-/Three-Winding Recorder Partitions
Operation – 2 Number of 3 Windings 2 Windings 3 Windings 2 Windings 3 Windings 2 Windings Partitions 4 Windings 4 Voltages 2 Voltages 2 Voltages Zero Voltages Zero Voltages Table 2-2 Two- / Three-Winding Recorder Partitions To access the Oscillograph Recorder VIEW RECORDER STATUS VIEW RECORDER STATUS feature, proceed as follows: 1.
Page 78 M‑3311A Instruction Book 3. If Level Access is not Active, then the following will be displayed: VOLTAGE RELAY VOLT curr freq v/hz 4. Press the Right arrow pushbutton until the following is displayed: OSCILLOGRAPH RECORDER targets OSC_REC comm 5. Press the ENTER pushbutton, the following will be displayed: VIEW RECORDER STATUS STAT clear...
Page 79: Oscillograph Recorder From Ipscom
Operation – 2 6. Press the right arrow pushbutton until the following is displayed: VIEW RECORDER STATUS stat CLEAR setup Press the ENTER pushbutton, the following will be displayed: CLEAR RECORDS — TARGETS CLEARED — 8. To exit press the EXIT pushbutton. The display will return to the following: VIEW RECORDER STATUS stat CLEAR...
Page 80: Figure 2-17 Oscillograph Record Download Dialog Screen
M‑3311A Instruction Book 4. Input the desired File Name and location, then select Save. IPScom will display the Download Status screen (Figure 2-17). Figure 2-17 Oscillograph Record Download Dialog Screen 5. Upon completion of the oscillograph file download, IPScom will display the Download Successful confirmation screen (Figure 2-18).
Page 81: Figure 2-21 Clear Oscillograph Records Confirmation Screen
Operation – 2 Clear Oscillograph Records To Clear Oscillograph Records perform the following: 1. Select Relay/Oscillograph/Clear. IPScom will display the Clear Oscillograph Records confirmation screen (Figure 2-21). Figure 2-21 Clear Oscillograph Records Confirmation Screen 2. Select Yes, IPScom will display the Clear Oscillograph Records Successful Dialog Screen. (Figure 2-22) Figure 2-22 Oscillograph Records Successfully Cleared Dialog Screen...
Page 82: Setup Unit Setup
M‑3311A Instruction Book 3. If Level Access is not Active, then the following will be displayed: VOLTAGE RELAY VOLT curr freq v/hz 4. Press the Right arrow pushbutton until the following is displayed: SETUP UNIT SETUP 5. Press the ENTER pushbutton, the following will be displayed: SOFTWARE VERSION VERS eth sn access 6.
Page 83: Alter Access Codes (From Relay Front Panel)
Operation – 2 6. Press the Right arrow pushbutton until the following is displayed: SERIAL NUMBER vers eth SN access 7. Press the ENTER pushbutton, the following will be displayed: SERIAL NUMBER XXXXXXXXXX 8. To exit press the EXIT pushbutton. Alter Access Codes (from Relay Front Panel) 1.
Page 84: Alter User Access Codes From Ipscom
M‑3311A Instruction Book 8. Input the desired User Access Code as follows (1 to 9999- Classic, up to 20 ASCII characters- Extended Mode): a. Utilizing the Up and Down arrow pushbuttons select the desired first digit. b. Press the Left arrow pushbutton once, then repeat the previous step as necessary to input the desired Access Code.
Page 85: Figure 2-24 Access Code Change Confirmation Screen
Operation – 2 Figure 2-24 Access Code Change Confirmation Screen 4. Select Yes, IPScom will display an Access Code Was Changed Successfully Confirmation Screen (Figure 2-25). Figure 2-25 Access Code Changed Confirmation Screen 5. Select OK, IPScom will return to the Main Screen. The new Comm Access Code will not be in effect until communications have been closed with the relay for approximately 2.5 minutes.
Page 86: System Error Codes, Output And Alarm Counters
M‑3311A Instruction Book 2. Enter a valid Level 3 User Access Code, then select OK. IPScom will display the Change User Access Code dialog screen (Figure 2-27). Figure 2-27 Change User Access Code Dialog Screen 3. Enter the desired New User Access Code (1 to 9999- Classic, up to 20 ASCII characters- Extended Mode), then re-enter (confirmation) the New User Access Code.
Page 87: Clear Output Counters (Relay Front Panel)
Operation – 2 3. If Level Access is not active, then the following is displayed: VOLTAGE RELAY VOLT curr freq v/hz 4. Press the Right arrow pushbutton until the following is displayed: SETUP UNIT SETUP 5. Press ENTER, the following will be displayed: SOFTWARE VERSION VERS eth sn access 6.
Page 88: Clear Alarm Counters (Relay Front Panel)
M‑3311A Instruction Book 5. Press ENTER, the following will be displayed: SOFTWARE VERSION VERS sn access number 6. Press the Right arrow pushbutton until the following is displayed: CLEAR OUTPUT COUNTER logo1 logo2 out ALRM 7. Press ENTER, the following will be displayed: CLEAR ALARM COUNTERS PRESS ENTER KEY TO CLEAR 8.
Page 89: Tools/Counters And Error Codes
Operation – 2 7. Press ENTER, the following will be displayed: CLEAR ERROR CODES PRESS ENTER KEY TO CLEAR 8. Press ENTER, the following will be displayed: CLEAR ERROR CODES -ERROR CODES CLEARED- 9. Press EXIT as necessary to return to the main menu. RESETTING COUNTERS AND ERROR CODES FROM IPSCOM Tools/Counters and Error Codes To view and/or Reset System Error Codes and Output Counters utilizing IPScom perform the following:...
Page 90: Through Fault Recorder From Ipscom
M‑3311A Instruction Book THROUGH FAULT RECORDER FROM IPSCOM Relay/Through Fault/Retrieve To download available Through Fault records perform the following: 1. From the IPScom Main Screen menu select Relay/Through Fault/Retrieve. The Through Fault Download screen will display a bar indicating the status of the download. When the download is complete the Save As screen will be displayed with a default ".tfe"...
Page 91: Relay/Sequence Of Events/Retrieve
Operation – 2 Figure 2-31 Through Fault Record Cleared Successfully Screen 3. Select OK, IPScom will return to the IPScom Main Screen. Relay/Sequence of Events/Retrieve The Retrieve selection downloads the events from the currently connected relay (events must be retrieved from the relay and stored in a file in order to view them).
Page 92: Relay/Sequence Of Events/Clear
M‑3311A Instruction Book Figure 2-33 View Sequence of Events Record Screen Relay/Sequence of Events/Clear The Clear feature clears all Sequence of Events Records stored on the relay. To Clear all Sequence of Events Records perform the following: 1. From the IPScom Main Screen menu select Relay/Sequence of Events/Clear. IPScom will display the Clear Sequence of Events Records confirmation screen (Figure 2-34).
Page 93: Chapter 3 Ipscom
IPScom – 3 IPScom IPScom Functional Description ............3–1 This chapter is designed for the person or group responsible for the operation and setup of the M-3311A. The S-3300 IPScom Communications Software can be used to successfully communicate system settings and operational commands to the M-3311A as well as access the extensive monitoring and status reporting features.
Page 94: Figure 3-2 Ipscom Main Screen
M‑3311A Instruction Book Figure 3-2 IPScom Main Screen File Windows Cascade Unconnected Tile Vertical Monitor Help Connected Tile Horizontal Contents Primary Metering & Status Ctrl + F1 Open About... Secondary Metering & Status Save Open Metering II Save as Phasor Diagram Compare Phasor Diagram (87T) Close...
Page 95: File Menu
IPScom – 3 FILE MENU Initial File Menu File Menu in File Mode File Menu Dropdown When Connected The File menu enables the user to create a New data file, Open a previously created data file, Close, Save, Save as and Exit the IPScom program. The user can also perform Print and Print Preview of the open file and Compare two files.
Page 96: File/Close Command
M‑3311A Instruction Book File/Close Command Closes the open file without saving. File/Exit Command The Exit command quits the IPScom program. Comparing Setpoint Files Comparing Setpoint Files does not require IPScom to be connected to a relay as long as the files to be compared are present on the PC.
Page 97: Connect/Communication Menu
IPScom – 3 CONNECT/COMMUNICATION MENU The Connect dialog screens allow selection of the IPScom communication parameters to coordinate with the relay. Selecting "Serial Port" displays the PC Comm Port and device Settings (Figure 3-6). Figure 3-6 IPScom Serial Communication Dialog Screen Selecting "TCP/IP"...
Page 98: Figure 3-7 Ipscom Tcp/Ip Ethernet Communication Dialog Screen
M‑3311A Instruction Book Figure 3-7 IPScom TCP/IP Ethernet Communication Dialog Screen Figure 3-8 IPScom Modem Communication Dialog Screen 3–6...
Page 99: Communication/Open Terminal Window
IPScom – 3 Communication/Open Terminal Window Opens the IPScom Terminal Window (Figure 3-9). Figure 3-9 Terminal Window 3–7...
Page 100: Monitor Menu
M‑3311A Instruction Book MONITOR MENU The Monitor Menu provides access to the screens used to monitor relay parameters. Seven submenus are provided: Primary Metering and Status, Secondary Metering and Status, Metering II, Phasor Diagram, Phasor Diagram (87T), Pickup/Timeout Status, and 87T Dual Scope. Monitor/Primary Metering &...
Page 101: Figure 3-10 Primary Metering Status Screen (Two-/Three-Winding)
IPScom – 3 Path: Monitor / Primary Metering and Status Figure 3-10 Primary Metering Status Screen (Two-/Three-Winding) Path: Monitor / Primary Metering and Status Figure 3-11 Primary Metering Status Screen (Four-Winding) 3–9...
Page 102: Monitor/Secondary Metering & Status
M‑3311A Instruction Book Monitor/Secondary Metering & Status The Secondary Metering and Status screen (Figure 3-12 Figure 3-13) allow the user to review the following SECONDARY parameters: • Voltage (V and V or V phase voltages) Ø • Frequency (Hz) • Volts Per Hertz (%) •...
Page 103: Monitor/Metering Ii
IPScom – 3 Path: Monitor / Secondary Metering and Status Figure 3-13 Secondary Metering Status Screen (Four-Winding) Monitor/Metering II The Metering II screen (Figure 3-14 Figure 3-15) include the following parameters: • 2 and 5 Harmonic Differential Currents (PU), (Phase A/B/C) •...
Page 104: Figure 3-14 Metering Ii Screen (Two-/Three-Winding)
M‑3311A Instruction Book Path: Monitor / Metering ll Figure 3-14 Metering II Screen (Two-/Three-Winding) Path: Monitor / Metering ll Figure 3-15 Metering II Screen (Four-Winding) 3–12...
Page 105: Monitor/Phasor Diagram
IPScom – 3 Monitor/Phasor Diagram The Phasor Diagram (Figure 3-16 Figure 3-17) provide the user with the ability to evaluate a reference Phase Angle to Phase Angle data from other windings. The Phasor Diagram also includes a menu that allows the user to select/deselect sources to be displayed and Freeze capability to freeze the data displayed on the Phasor Diagram.
Page 106: Figure 3-17 Phasor Diagram (Four-Winding)
M‑3311A Instruction Book Path: Monitor / Phasor Diagram When connections specifying delta-connected CTs are used, Functions 87T and 87H use NOTE: the Phasor Diagram values (currents actually entering the relay) and not the calculated values displayed on the Secondary Metering and status screen. Figure 3-17 Phasor Diagram (Four-Winding) 3–14...
Page 107: Monitor/Phasor Diagram (F87T)
IPScom – 3 Monitor/Phasor Diagram (F87T) The Phasor Diagram (F87T) (Figure 3-18 Figure 3-19) provide the user with the ability to evaluate compensated and uncompensated 87 Function parameters. Path: Monitor / Phasor Diagram (F87T) Figure 3-18 Phasor Diagram (F87T) (Two-/Three-Winding) Path: Monitor / Phasor Diagram (F87T) Figure 3-19 Phasor Diagram (F87T) (Four-Winding) 3–15...
Page 108: Monitor/Pickup/Timeout Status
M‑3311A Instruction Book Monitor/Pickup/Timeout Status The Pickup/Timeout Status screen (Figure 3-20 Figure 3-21) display the extended status information of relay functions and Input/Output contact information. Path: Monitor / Pickup / Timeout Status Figure 3-20 Pickup/Timeout Status (Two-/Three-Winding) Path: Monitor / Pickup / Timeout Status Figure 3-21 Pickup/Timeout Status (Four-Winding) 3–16...
Page 109: Monitor/87T Dual Slope
IPScom – 3 Monitor/87T Dual Slope The 87T Dual Slope display allows the user to display a graphical representation of the 87T programmable Dual Slope Percentage Restraint Characteristic. See 4.4, System Setpoints for detailed information. Section Path: Monitor / 87T Dual Slope Figure 3-22 87T Function Dual Slope Display 3–17...
Page 110: Relay Menu
M‑3311A Instruction Book RELAY MENU The Relay menu provides access to the screens used to set, monitor, or interrogate the relay. Six submenus are provided: Setup, Demand Status, Targets, Through Fault, Sequence of Events, Oscillograph and Profile as well as two commands, Write File to Relay, and Read Data From Relay. Relay/Setup The Setup submenu includes the Setup System, Relay Setpoints, Set Date &Time, Display I/O Map and Display All Setpoints selections.
Page 111: Figure 3-23 Setup System Dialog Screen (Two-/Three-Winding)
IPScom – 3 Figure 3-23 Setup System Dialog Screen (Two-/Three-Winding) 3–19...
Page 112: Figure 3-24 Setup System Dialog Screen (Four-Winding)
M‑3311A Instruction Book Figure 3-24 Setup System Dialog Screen (Four-Winding) 3–20...
Page 113: Relay/Setup/Relay Setpoints
IPScom – 3 Relay/Setup/Relay Setpoints The Relay Setpoints menu selection displays the Relay Setpoints dialog screen (Figure 3-25 Figure 3-26) from which the individual Function Setting dialog screens can be accessed. Selecting a Function Setting button will display the corresponding function dialog screen (See Figure 3-27 as an example).
Page 114: Figure 3-27 Example Function Dialog Screen
M‑3311A Instruction Book Figure 3-27 Example Function Dialog Screen Command Buttons When connected to a relay, sends the currently displayed information to the unit. Save Otherwise, saves the currently displayed information and returns to the System Setpoints screen or All Setpoints Table. Returns to the System Setpoints screen or All Setpoints Table;...
Page 115: Relay/Setup/Set Date & Time
IPScom – 3 Relay/Setup/Set Date & Time The Setup Date & Time command (Figure 3-28) allows the system date and time to be set, or system clock to be stopped. This dialog screen also displays an LED mimic to identify when the Time Sync is in use (preventing date/time from being changed by user).
Page 116: Relay/Setup/Display/I/O Map
M‑3311A Instruction Book Relay/Setup/Display/I/O Map Selecting the I/O Map button displays the I/O Map dialog screen (Figure 3-29 Figure 3-30), which contain a chart of programmed input and output contacts, in order to allow scrolling through all relay output and blocking input configurations. Both the Relay Setpoints dialog screen and the I/O Map screen include the Display All Setpoints feature and Jump Command Buttons which allow the user to jump from a scrolling dialog screen to an individual relay function dialog screen and return to the scrolling dialog screen.
Page 117: Relay/Setup/Display All Setpoints
IPScom – 3 Relay/Setup/Display All Setpoints Selecting the Display All Setpoints button displays the All Setpoints dialog screen (Figure 3-31 Figure 3-32). This dialog screen contains the settings for each relay function within a single window to allow scrolling through all relay setpoint and configuration values. The individual Feature and Function selection buttons are described in the applicable sections.
Page 118: Figure 3-32 Display All Setpoints Screen (Four-Winding)
M‑3311A Instruction Book Figure 3-32 Display All Setpoints Screen (Four-Winding) 3–26...
Page 119: Relay/Demand Status
IPScom – 3 Relay/Demand Status The Demand Status feature allows the user to access Primary Demand Values. See Chapter 2, Operation for detailed information. Figure 3-33 Demand Status Dialog Screen (Two-/Three-Winding) Figure 3-34 Demand Status Dialog Screen (Four-Winding) 3–27...
Page 120: Relay/Targets
M‑3311A Instruction Book Relay/Targets The Targets submenu provides three command options: View, Clear and Reset LED. The View command displays the View Targets Dialog Screen (see Figure 3-35). This dialog screen provides detailed data on target events including time, date, function status, phase current values, and IN/OUT contact status at the time of trip.
Page 121: Relay/Through Fault
IPScom – 3 Relay/Through Fault The Through Fault submenu provides three command options: Retrieve, View and Clear. The Retrieve command initiates the retrieval of any Through Faults present in the relay. The View command displays the View Through Fault Record dialog screen (Figure 3-36).
Page 122: Relay/Sequence Of Events
M‑3311A Instruction Book Relay/Sequence of Events The Sequence of Events submenu allows the user to Setup, Retrieve, View and Clear Sequence of Events records. The Setup command displays the Setup Sequence of Events Recorder dialog screen (Figure 3-37). Function Pickup, Trip and Dropout can be selected to initiate the recorder as well as Input Pickup, Output Pickup, Inputs Drop and Outputs Drop.
Page 123: Figure 3-39 View Sequence Of Events Recorder Screen
IPScom – 3 Figure 3-39 View Sequence of Events Recorder Screen Sequence of Events records are not retained if power to the relay is interrupted. CAUTION: ▲ 3–31...
Page 124: Relay/Oscillograph
M‑3311A Instruction Book Relay/Oscillograph The Oscillograph submenu allows setting and control over the relay's oscillograph recorder. The Setup command allows the user to set the number of partitions and triggering designations to be made (Figure 3-40 Figure 3-41), Retrieve downloads and save data to a file (Figure 3-42).
Page 125: Relay/Profile
IPScom – 3 Relay/Profile If relay is online, be sure to switch the active profile. If the wrong profile is selected, CAUTION: ▲ it may cause unexpected operation. The Profile submenu provides three command options: Switching Method, Select Profile, and Copy Active Profile.
Page 126: Relay/Write File To Relay
M‑3311A Instruction Book Relay/Write File to Relay The Write File to Relay command sends a predefined setpoint data file to the Relay. Relay/Read Data From Relay The Read Data from Relay command updates the PC data image with the relay's latest data. TOOLS MENU The Tools menu provides the user with access to IPScom relay support features and functions.
Page 127: Tools/Security/Change User Access Code
IPScom – 3 Tools/Security/Change User Access Code The Change User Access Code selection displays the Access Level Code dialog screen (Figure 3-47). After entering a valid Level 3 Access Code IPScom will display Figure 3-48 which allows the user to change the relay User Access Code.
Page 128: Tools/User Information
M‑3311A Instruction Book Tools/User Information The User Information menu selection displays the User Information screen (Figure 3-49) which provides the user with the ability to edit/input the User Logo lines of the HMI display, enter/edit the User Control Number and set the operating mode of the System OK LED. See 4.1, Unit Setup for detailed setup Section instructions.
Page 129: Tools/Output Test
IPScom – 3 Figure 3-51 Setup Relay Comm Port Dialog Screen Figure 3-52 Setup Relay Ethernet Port Dialog Screen Tools/Output Test The Output Test menu selection displays the Output Test screen (Figure 3-54) which provides the user with the ability to test each output relay. See Section 6, Testing for detailed testing instructions. Tools/Counters and Error Codes The Counters and Error Codes menu selection displays the Counters and Error Codes screen (Figure...
Page 130: Figure 3-53 Output Test Warning Dialog Screen
M‑3311A Instruction Book Figure 3-53 Output Test Warning Dialog Screen Figure 3-54 Output Test Dialog Screen Figure 3-55 Counters and Error Codes Dialog Screen 3–38...
Page 131: Tools/Firmware Update
IPScom – 3 Tools/Firmware Update The Firmware Update feature allows the user to perform M-3311A Firmware updates. Firmware update files and instructions are provided by Beckwith Electric. Figure 3-56 Firmware Update Warning Dialog Screen Tools/Calibration Data The Calibration Data feature allows the user to retrieve calibration data from M-3311A relays. It also allows relay calibration data to be restored to the relay.
Page 132: Window Menu
M‑3311A Instruction Book WINDOW MENU The Window menu enables positioning and arrangement of IPScom windows so that there is better access to available functions. This feature allows the display of several windows at the same time. Clicking on an inactive yet displayed window activates that window. HELP MENU The Help menu provides two commands.
Page 133: Unit Setup
System Setup and Setpoints – 4 System Setup and Setpoints Unit Setup ....................4–1 Setup System ..................4–32 Two- / Three-Winding Setup ..............4–32 Four-Winding Setup ................4–37 System Diagrams ................4–46 System Setpoints ................4–55 System Applications and Logic Schemes .........4–100 Transformer Connections ..............4–106 Chapter 4 is designed for the person or group responsible for the Unit Setup, Configuration and System Setpoints of the M-3311A Transformer Protection Relay.
Page 134: Comm Access Code
M‑3311A Instruction Book COMM ACCESS CODE If additional link security is desired, a communication access code can be programmed. Like the user access codes, if the communication access code is set to 9999 (default), communication security is disabled. IPScom Comm Access Code Setup To set the relay Comm Access Code perform the following: NOTE: NOTE:...
Page 135: Hmi Comm Access Code Setup
System Setup and Setpoints – 4 HMI Comm Access Code Setup 1. Press the ENTER ENTER pushbutton. 2. If Level Access is active, the following is displayed: ENTER ACCESS CODE a. Input the required Access Code, then press ENTER ENTER. b.
Page 136: Ipscom User Access Code Setup
M‑3311A Instruction Book IPScom User Access Code Setup The relay includes three levels of access codes. Depending on their assigned code, users have varying levels of access to the relay features and functions. 1. Level 1 Access Level 1 Access = Read setpoints, monitor status, view status history. 2.
Page 137: Hmi User Access Codes Setup
System Setup and Setpoints – 4 HMI User Access Codes Setup 1. Press the ENTER ENTER pushbutton. 2. If Level Access is active, the following is displayed: ENTER ACCESS CODE a. Input the required Access Code, then press ENTER ENTER. b.
Page 138: User Logo Line
M‑3311A Instruction Book 11. To set User Access Code Level #3 press the RIGHT arrow pushbutton to select LEVEL #3, then press ENTER ENTER the following will be displayed: LEVEL #3 9999 12. Repeat Step 8 to enter the desired Level #3 User Access Code. 13.
Page 139: Hmi User Logo Line Setup
System Setup and Setpoints – 4 HMI User Logo Line Setup 1. Press the ENTER ENTER pushbutton. 2. If Level Access is active, the following is displayed: ENTER ACCESS CODE a. Input the required Access Code, then press ENTER ENTER. b.
Page 140: Hmi User Control Number Setup
M‑3311A Instruction Book 9. To enter a User Logo Line 2 press the RIGHT arrow pushbutton once, the following will be displayed: USER LOGO LINE 2 LOGO 1 logo 2 alrm 10. Press ENTER ENTER, the following will be displayed: USER LOGO LINE 2 M-3311A 11.
Page 141: Hmi System Ok Led Setup
System Setup and Setpoints – 4 6. Press the Right arrow pushbutton until the following is displayed: USER CONTROL NUMBER UNUM logo1 logo2 out 7. Press ENTER ENTER, the following will be displayed: USER CONTROL NUMBER 8. Input the desired User Control Number as follows: a.
Page 142: System Clock
M‑3311A Instruction Book 6. Press the right arrow pushbutton until the following is displayed: DIAGNOSTIC MODE  alrm time error DIAG 7. Press ENTER ENTER, the following warning will be displayed: PROCESSOR WILL RESET! ENTER KEY TO CONTINUE CAUTION: CAUTION: Do not enter DIAGNOSTIC MODE when protected equipment is in service.
Page 143: Ipscom Set Date/Time
System Setup and Setpoints – 4 IPScom Set Date/Time To set the relay Date/Time perform the following: NOTE: NOTE: Communication must be established with the target relay for this procedure.   1. From the IPScom Main Screen menu select Relay/Setup/Setup Date & Time Relay/Setup/Setup Date &...
Page 144 M‑3311A Instruction Book 7. Press ENTER ENTER, the following will be displayed: DATE & TIME 01 Year 8. Input the desired Year as follows: a. Utilizing the Up and Down arrow pushbuttons select the desired first digit. b. Press the Left arrow pushbutton once, then repeat the previous step as necessary to input the desired Year.
Page 145: Date And Time
System Setup and Setpoints – 4 14. Input the desired Seconds as follows: a. Utilizing the Up and Down arrow pushbuttons select the desired first digit. b. Press the Left arrow pushbutton once, then repeat the previous step as necessary to input the desired Seconds.
Page 146: Ipscom Com Port Definitions And System's Communication Address
M‑3311A Instruction Book IPScom COM Port Definitions and System's Communication Address To setup the COM Ports and Communication Addresses perform the following: NOTE: NOTE: Communication must be established with the target relay for this procedure. The IPSCom   installation and establishing initial Local communications are covered in Section 5.6, IPScom Communications and Analysis Software Installation...
Page 147: Figure 4-8 Setup Comm Port Dialog Screen
System Setup and Setpoints – 4 9. When the COM Port settings have been entered, then select Save Save. IPScom will display the COM Port Settings Warning Screen (Figure 4-2). 10. Select OK OK, IPScom will return to the Main Screen. Communications-Line Splitter Null Modem Cable for Modem...
Page 148 M‑3311A Instruction Book 8. Press ENTER ENTER. If setting up COM1, the screen will return to the beginning of the Comm menu. If setting up COM2 or 3, the following will be displayed: COM2 DEAD SYNC TIME 50 ms 9. Input the desired Dead Sync Time as follows: a.
Page 149: Ethernet Communication Settings
System Setup and Setpoints – 4 ETHERNET COMMUNICATION SETTINGS The optional RJ45 Ethernet port can be enabled utilizing either IPScom from the Ethernet Settings menu or from the HMI Communication menu. When the ethernet port is enabled the COM2 Serial Port is not available for communications.
Page 150: Ipscom Ethernet Port Setup With Dhcp
M‑3311A Instruction Book IPScom Ethernet Port Setup with DHCP NOTE: NOTE: Communication must be established with the target relay for this procedure.   1. From the IPScom Main Screen menu select Tools/Ethernet Setup Tools/Ethernet Setup. IPScom will display the Setup Ethernet screen (Figure 4-9).
Page 151: Tcp/Ip Settings
System Setup and Setpoints – 4 3. Use the Right arrow pushbutton to select ETH (Upper Case). ETHERNET SETUP  access eth_ip 4. Press ENTER ENTER, the following will be displayed: ETHERNET DISABLE enable 5. Use the Right arrow pushbutton to select ENABLE (Upper Case), then press ENTER ENTER, the following will be displayed: TCP/IP SETTINGS...
Page 152: Manual Configuration Of Ethernet Board
M‑3311A Instruction Book Then the display will return to the following: ETHERNET SETUP  access eth_ip If the ethernet board fails to obtain an IP Address within 15 seconds the following will be displayed (for approximately 2 seconds): CONFIGURING ETH... ETH BOARD ERROR Contact the Network Administrator to determine the cause of the configuration failure.
Page 153: Installing The Modems
System Setup and Setpoints – 4 If the ethernet board is successfully configured, then the entered IP Address will be displayed for approximately 2 seconds: ETHERNET IP ADDRESS XX.XX.XX.XX The ethernet board is now configured for use and may be accessed through a network. INSTALLING THE MODEMS Using IPScom to interrogate, set or monitor the relay using a modem requires both a remote modem connected at the relays location and a local modem connected to the computer with IPScom installed.
Page 154: Initializing The Pc Modem
M‑3311A Instruction Book Initializing the PC Modem 1. Verify that the modem is connected as described in "Connecting the PC Modem". 2. Open IPScom, then select the Connect/Modem Connect/Modem menu item. 3. IPScom will display the Modem Dialog screen (Figure 4-10).
Page 155: Connecting The Local Modem To The Relay
System Setup and Setpoints – 4 Connecting the Local Modem to the Relay Setup of the modem attached to the relay may be slightly complicated. It involves programming parameters (using the AT command set), and storing this profile in the modem's nonvolatile memory. After programming, the modem will power up in the proper state for communicating with the relay.
Page 156: Oscillograph Setup
M‑3311A Instruction Book OSCILLOGRAPH SETUP The Oscillograph Recorder provides comprehensive data recording (voltage, current, and status input/ output signals) for all monitored waveforms (at 16 samples per cycle). Oscillograph data can be downloaded using the communications ports to any IBM compatible personal computer running the S-3300 IPScom Communications Software.
Page 157: Table 4-2 Four-Winding Recorder Partitions
System Setup and Setpoints – 4 Windings 1, 2, Number of Partition Windings 1, 2, 3 Windings 1, 2 3, 4 Table 4-2 Four-Winding Recorder Partitions 4–25...
Page 158: Table 4-3 Two- / Three-Winding Recorder Partitions
M‑3311A Instruction Book Number of 3 Windings 2 Windings 3 Windings 2 Windings 3 Windings 2 Windings Partitions 4 Windings 4 Voltages 2 Voltages 2 Voltages Zero Voltages Zero Voltages Table 4-3 Two- / Three-Winding Recorder Partitions 4–26...
Page 159: Ipscom Setup Oscillograph Recorder
System Setup and Setpoints – 4 IPScom Setup Oscillograph Recorder NOTE: NOTE: Communication must be established with the target relay for this procedure. When not   connected to the relay the Save selection does not save the Oscillograph Recorder settings to an open file.
Page 160 M‑3311A Instruction Book b. If the proper Access Code has been entered, the HMI will return: LEVEL #(1,2 or 3) Access Granted! VOLTAGE RELAY VOLT curr freq v/hz c. Go to step 4. 3. If Level Access is not active, then the following is displayed: VOLTAGE RELAY VOLT curr freq v/hz...
Page 161: Ipscom Setup Sequence Of Events Recorder
System Setup and Setpoints – 4 IPScom Setup Sequence of Events Recorder Protective function Pickup, Trip, Dropout and/or Output/Input Pickup or Dropout are selected to trigger the Sequence of Events Recorder. NOTE: NOTE: Communication must be established with the target relay for this procedure. When not ...
Page 162 M‑3311A Instruction Book b. If the proper Access Code has been entered, the HMI will return: LEVEL #(1,2 or 3) Access Granted! VOLTAGE RELAY VOLT curr freq v/hz c. Go to step 4. 3. If Level Access is not active, then the following is displayed: VOLTAGE RELAY VOLT curr freq v/hz...
Page 163: Hmi Demand Interval Setup
System Setup and Setpoints – 4 HMI Demand Interval Setup The Demand Interval setting determines the demand integration interval (15 min, 30 min or 60 min). Demand time-tagged peak values are stored for display and printing. See Chapter 2 Chapter 2, Operation Operation for detailed information.
Page 164: Setup System
M‑3311A Instruction Book Setup System The Setup System consists of defining common information like CT and VT ratios, nominal voltage rating, transformer connections, and which profile is the Active Profile, etc. Values are entered similar to other setpoints. Configuration information is common to all profiles, and should be entered before setpoint and time settings.
Page 165 System Setup and Setpoints – 4 Two- / Three-Winding Setup (Cont.) 籍 CAUTION CAUTION: : Changing from a standard Transformer/CT XFM/CT CONNECTION connection to the equivalent custom setting may cause standard custom the relay to momentarily trip when current is present. If Custom XFM/CT Connection is Disabled (standard transformer and CT configurations are used), the relay automatically...
Page 166: Phase Rotation
M‑3311A Instruction Book Two- / Three-Winding Setup (Cont.) The Standard configuration requires the CT connection to CT CONNECTION W2 be defined as Wye, Delta-ab, Delta-ac, Inverse Wye, Inverse xfm_w1 con_w2 xfm_w2 Section 4.6, Transformer Transformer Delta-ab, or Inverse Delta-ac. See Connections Connections, for additional information.
Page 167 System Setup and Setpoints – 4 Two- / Three-Winding Setup (Cont.) RELAY SEAL-IN TIME OUT02 Cycles RELAY SEAL-IN TIME OUT03 Cycles RELAY SEAL-IN TIME OUT04 Cycles RELAY SEAL-IN TIME OUT05 Cycles RELAY SEAL-IN TIME OUT06 Cycles RELAY SEAL-IN TIME OUT07 Cycles RELAY SEAL-IN TIME OUT08 Cycles...
Page 168 M‑3311A Instruction Book Two- / Three-Winding Setup (Cont.) The secondary VT voltage when primary voltage is equal to NOMINAL VOLTAGE the rated transformer voltage (V trans rated/VT ratio). Range 120 Volts = 60–140 V; Increment 1 V. NOMINAL CURRENT 5.00 Amps Indicate VT Configuration is either Line-to-Line, Line-to- V.T.
Page 169: Four-Winding Setup
System Setup and Setpoints – 4 Four-Winding Setup If INPUT ACTIVATED PROFILES is disabled this screen INPUT ACTIVATED PROFILES allows manual selection of the Active Profile using the front disable ENABLE panel or through communications. Allows the user to manually select the Active Profile. ACTIVE SETPOINT PROFILE This screen initiates a copy of the Active Profile to any one of COPY ACTIVE PROFILE...
Page 170 M‑3311A Instruction Book Four-Winding Setup 籍 CAUTION: CAUTION: Changing from a standard Transformer/ CUSTOM XFM/CT CONNECTION CT connection to the equivalent custom setting may cause disable enable the relay to momentarily trip when current is present. If Custom XFM/CT Connection is DISABLED (standard transformer and CT configurations used), the relay automatically computes...
Page 171 System Setup and Setpoints – 4 Four-Winding Setup (Cont.) 籍 CAUTION: CAUTION: Changing from a standard Transformer/ CT CONNECTION W1 CT connection to the equivalent custom setting may cause   CON_W1 xfm_w1 con_w2 xfm_w2 the relay to momentarily trip when current is present. ...
Page 172 M‑3311A Instruction Book Four-Winding Setup (Cont.) XFM CONNECTION W3 XFM CONNECTION W4 xfm_w2 con_w3 XFM_W3 con_w2 XFM_W4 XFM CONNECTION W3 XFM CONNECTION W4 Y dab dac inv_y  Y dab dac inv_y   inv_dab inv_dac  inv_dab inv_dac Indicates the phase rotation. PHASE ROTATION ...
Page 173 System Setup and Setpoints – 4 Four-Winding Setup (Cont.) If any of the outputs are selected as latched, then after LATCHED OUTPUTS tripping, this output will stay activated, even when the tripping o8 o7 o6 o5 o4 o3 o2 o1 condition is removed.
Page 174: Figure 4-15 Ipscom Relay Setup System Dialog Screen (Two-/Three-Winding)
M‑3311A Instruction Book Four-Winding Setup (Cont.) CT Ground Ratios W3 C.T. GROUND RATIO ct_w2g ct_3 CT_W3G The relay will calculate the W2, W3 and W4 line currents when a delta CT configuration is selected, as follows: W3 C.T. GROUND RATIO For Delta ab CTs: Line Current I = (I...
Page 175: Figure 4-16 Ipscom Relay Setup System Dialog Screen (Four-Winding)
System Setup and Setpoints – 4 Figure 4-16 IPScom Relay Setup System Dialog Screen (Four-Winding) 4–43...
Page 176: Figure 4-17 Ipscom Selection Screen For Output Settings
M‑3311A Instruction Book If neither Pulsed or Latched Output is enabled, the output contact will default to the normal mode. In this mode, the output contact will stay energized as long as the abnormal condition which caused it to operate persists.
Page 177: Figure 4-18 Ipscom Selection Screen For Input Settings
System Setup and Setpoints – 4 Figure 4-18 IPScom Selection Screen for Input Settings 4–45...
Page 178: System Diagrams
M‑3311A Instruction Book System Diagrams M-3311A Typical Connection Diagram Two Winding Model This function is available as a standard protective function. This function is available in the Optional Voltage Protection Package M-3311A Winding 1 (W1) Targets Integral HMI Metering Winding 2 Sequence Of Events (W2) Waveform Capture...
Page 179 System Setup and Setpoints – 4 This function is available as a M-3311A Typical standard protective function. Connection Diagram Three Winding Model This function is available in the Optional Voltage Protection Packages. 3-CT M-3311A Targets NOTE † 50BF Integral HMI Winding 1 (W1) Metering...
Page 180: Figure 4-21 M-3311A (Four-Winding-Two Voltage Inputs) Typical One-Line Function Diagram
M‑3311A Instruction Book M-3311A Typical This function is available as a standard protective function. Winding 4 Winding 1 Connection Diagram (W4) (W1) Four-Winding Model This function is available in 3-CT 3-CT the Optional Voltage Protection Packages. M-3311A 50BF Targets Integral HMI Metering Sequence of Events 1-VT...
Page 181: Figure 4-22 M-3311A (Four-Winding-Two Voltage Inputs) Summing Currents One-Line Function Diagram
System Setup and Setpoints – 4 M-3311A Typical This function is available as a standard protective function. Connection Diagram Four-Winding Model Winding 4 Winding 1 This function is available in the (W4) (W1) Optional Voltage Protection 3-CT 3-CT Package. M-3311A Targets Integral HMI Metering...
Page 182: Figure 4-23 Typical (Two Winding-Two Voltage Inputs) Three-Line Connection Diagram
M‑3311A Instruction Book M-3311A Output Contacts M-3311A (W-1) Self- OUT 2 OUT 1 Test Typical Typical Self- Power Trip Test Alarm Alarm Status Trip Alarm M-3311A Input Contacts IN 1 IN 2 IN 3 Winding 1 (52b) Typical Typical Return (W-1) Other Other...
Page 183: Figure 4-24 Typical (Two Winding-Four Voltage Inputs) Three-Line Connection Diagram
System Setup and Setpoints – 4 M-3311A Output Contacts Self- OUT 2 OUT 1 Typical Typical Test M-3311A (W-1) Self- Power Trip Test Alarm Alarm Status Alarm Trip M-3311A Input Contacts IN 1 IN 2 IN 3 (52b) Typical Typical Return Other Other...
Page 184: Figure 4-25 Typical (Three Winding-Two Voltage Inputs) Three-Line Connection Diagram
M‑3311A Instruction Book M-3311A Output Contacts Self- OUT 2 OUT 1 Typical Typical Test M-3311A (W-1) Self- Power Trip Test Alarm Alarm Status Alarm Trip M-3311A Input Contacts IN 1 IN 2 IN 3 (52b) Typical Typical Return Other Other Inputs Inputs Power...
Page 185: Figure 4-26 Typical (Three Winding-Four Voltage Inputs) Three-Line Connection Diagram
System Setup and Setpoints – 4 M-3311A Output Contacts M-3311A (W-1) Self- OUT 2 OUT 1 Typical Typical Test Self- Power Trip Test Alarm Alarm Status Alarm Trip M-3311A NOTES: Broken Delta VTs Delta-Wye power transformer shown with Wye-Wye connedted CTs (Connected #4 DABY yy).
Page 186: Figure 4-27 Typical (Four-Winding-Two Voltage Inputs) Three-Line Connection Diagram
M‑3311A Instruction Book M-3311A (W-4) M-3311A (W-1) M-3311A Output Contacts M-3311A Input Contacts IN 1 IN 2 IN 3 (52b) Typical Typical Return Self- OUT 2 OUT 1 Typical Typical Test Other Other Inputs Inputs Self- Power Trip Test Alarm Alarm Status Alarm...
Page 187: System Setpoints
System Setup and Setpoints – 4 System Setpoints Setpoint Profiles (Setting Groups) Up to four setpoint profiles may be used. Each profile contains a function configuration and associated settings. One of the four profiles may be designated as the Active Profile which will contain the parameters that the relay will actively use.
Page 188: Special Considerations
M‑3311A Instruction Book Special Considerations Status input IN1 is pre-assigned to be the 52b breaker contact. IN5 and IN6 may be used to select setpoint profiles (with input activated profiles enabled). Outputs 1–6 and 9–23 are form "a" contacts (normally open), and outputs 7 and 8 are form "c" contacts (center tapped "a"...
Page 189: Figure 4-28 Example Of V/Hz Capability And Protection Curves
System Setup and Setpoints – 4 This function provides two Definite Operating Time setpoints, four families of Inverse Time curves widely used in the industry (see Appendix D Appendix D, Figure D-1 Figure D-4), and a linear reset rate programmable to match specific cooling characteristics of the transformer.
Page 190 M‑3311A Instruction Book Definite time setpoint #1 establishes the V/Hz level above 24DT#1 PICKUP which the protection operating time will be fixed at the definite 110% time delay #1 (See Figure 4-28). 100% is equal to nominal voltage at nominal frequency (50/60 Hz). See Section 4.2, Setup System...
Page 191: Command Buttons
System Setup and Setpoints – 4 Figure 4-29 IPScom (24) Volts/Hertz Setpoint Ranges Path Path: Relay / Setup / Relay Setpoints / 24 Volts/HZ Overexcitation Command Buttons Save Save Saves all information to the relay. Cancel Cancel Returns the user to the previous window; any changes to the displayed information are lost. 4–59...
Page 192 M‑3311A Instruction Book 27 Phase Undervoltage NOTE: NOTE: Two or four voltage inputs are available for the M-3311A. The Voltage Input can be a phase   voltage input or voltage generated from a broken delta VT connection. 81O/U, 27, and 24 Functions are only available if the voltage input is connected to the phase voltage.
Page 193: Figure 4-30 Ipscom (27) Undervoltage Setpoint Ranges (Two-/Three-Winding)
System Setup and Setpoints – 4  NOTE: NOTE: Elements #2 and #3 are not available in four-winding applications.  Figure 4-30 IPScom (27) Undervoltage Setpoint Ranges (Two- / Three-Winding) Figure 4-31 IPScom (27) Undervoltage Setpoint Ranges (Four-Winding) Path Path: Relay / Setup / Relay Setpoints / 27 Phase Undervoltage Command Buttons Save Save...
Page 194: 46 Negative Sequence Overcurrent
M‑3311A Instruction Book 46 Negative Sequence Overcurrent The 46 Negative Sequence Overcurrent function provides protection against possible damage due to unbalanced faults and open conductors. The pickup setting of this function can be set below the system load for increased sensitivity for phase-to- phase fault backup of feeder protective relays.
Page 195: Figure 4-32 Ipscom (46) Negative Sequence Overcurrent Setpoint Ranges
System Setup and Setpoints – 4 NOTE: NOTE: Winding Four is not available in Two or Three Winding applications.   Figure 4-32 IPScom (46) Negative Sequence Overcurrent Setpoint Ranges Path Path: Relay / Setup / Relay Setpoints / 46 Negative Sequence Overcurrent Command Buttons Save Save...
Page 196: 49 Winding Thermal Protection
M‑3311A Instruction Book 49 Winding Thermal Protection The thermal overload function provides protection against possible damage during overload conditions. Temperature and overload monitoring of oil-filled transformers are carried out with the use of indicating thermostats (standard). The oil thermometer, which measures the top oil temperature, cannot be relied upon to detect short-time overloads beyond permissible limits.
Page 197: Figure 4-33 49 Function Overload Curves
System Setup and Setpoints – 4 49 - Overload Curves load preload where: P = Figure 4-33 49 Function Overload Curves 4–65...
Page 198: Time Constant
M‑3311A Instruction Book τ Selects the time constant, ' 46 TIME CONSTANT 5.0 Min Selects the maximum allowed continuous overload current. 49 MAX OVERLOAD CURRENT 2.00 Amps Select the winding current to be used as the input. 49 CURRENT SELECTION sum1 sum2 w1 w2 w3 w4 NOTE: NOTE:...
Page 199: 50Bf Breaker Failure
System Setup and Setpoints – 4 50BF Breaker Failure The 50BF function is applicable when a transformer breaker is present. If enabled, the 50BF-Ph phase detector element is used for breaker failure and the 50BF-N provides breaker flashover protection (see Figure 4-35).
Page 200: Figure 4-36 Ipscom (50Bf) Breaker Failure Setpoint Ranges
M‑3311A Instruction Book Sets 50BFW1 residual current pickup. 0.5 A is a typical 50BFW1 PICKUP RESIDUAL setting. This element operates on 3I 1.00 Amps Sets 50BFW1 phase current pickup. 0.3 A is a typical setting. 50BFW1 PICKUP PHASE 1.00 Amps Designates the control/status inputs which will initiate the 50BFW1 INPUT INITIATE breaker failure timer.
Page 201: 50/50G Instantaneous Overcurrent, Phase & Ground
System Setup and Setpoints – 4 50/50G Instantaneous Overcurrent, Phase & Ground The Instantaneous phase 50 and Instantaneous Ground 50G overcurrent functions provide fast tripping for high fault currents. The settings of both functions must be set such that they will not pickup for faults or conditions outside the immediate protective zone.
Page 202: Figure 4-37 Ipscom (50) Instantaneous Phase Overcurrent Setpoint Ranges
M‑3311A Instruction Book NOTE: NOTE: Elements #7 and #8 are not available in Two or Three Winding applications.   Figure 4-37 IPScom (50) Instantaneous Phase Overcurrent Setpoint Ranges Path Path: Relay / Setup / Relay Setpoints / 50 Instantaneous Phase Overcurrent Command Buttons Save Save...
Page 203: 50N Instantaneous Residual Overcurrent
System Setup and Setpoints – 4 50N Instantaneous Residual Overcurrent The Instantaneous Residual (50N) overcurrent function provides fast tripping for high fault currents. Settings must be made in such a way as to prevent pickup for fault or conditions outside the immediate protective zone. NOTE: NOTE: Instantaneous Residual Overcurrent Elements #7 and #8 are not available in Two or...
Page 204: 51 Inverse Time Phase Overcurrent
M‑3311A Instruction Book 51 Inverse Time Phase Overcurrent The 51 Inverse Time Phase Overcurrent function, one set per winding are used to trip circuits selectively and to time coordinate with up or down stream relays. For this function, eleven complete series of inverse time tripping characteristics are included.
Page 205: 51N Inverse Time Residual Overcurrent
System Setup and Setpoints – 4 51N Inverse Time Residual Overcurrent The 51 Inverse time Residual Overcurrent provides protection against ground faults. Since normal residual current is usually much lower than the full load phase current, this function can be set more sensitively than the phase overcurrent protection.
Page 206: 51G Inverse Time Ground Overcurrent
M‑3311A Instruction Book 51G Inverse Time Ground Overcurrent The 51G Inverse Time Ground Overcurrent function is used to trip circuits selectively and to time coordinate with up or downstream relays. For this function, eleven complete series of inverse time neutral tripping characteristics are included.
Page 207: Phase Overvoltage (Two-/Three-Winding)
System Setup and Setpoints – 4 59 Phase Overvoltage (Two- / Three-Winding) The 59 Phase Overvoltage function may be used to provide overvoltage protection for the transformer. Transformers should not be exposed to long periods of overvoltage. If a transformer is operated about 110 percent rated voltage the exciting current becomes very high and can damage the windings.
Page 208: 59G Ground Overvoltage
M‑3311A Instruction Book 59G Ground Overvoltage NOTE: NOTE: Zero, two, or four voltage inputs are available for two- or three-winding M-3311A relays.   Zero or two voltage inputs are available for four-winding M-3311A relays. The voltage input can be a phase voltage input or ground voltage input. The 24, 27, 59, and 81O/U functions are only available if one or more phase voltages are wired to the phase voltage input(s).
Page 209: Ground Overvoltage (Two-/Three-Winding) Zero Sequence Voltage Selection
System Setup and Setpoints – 4 59G Ground Overvoltage Zero Sequence Voltage Selection (available on Two- or Three- Winding Relays with Four Voltage Inputs) This selection determines the operating quantity that will be used by the 59G Ground Overvoltage elements. This applies to all three 59G elements.
Page 210: 81O/U Over/Underfrequency
M‑3311A Instruction Book 81O/U Over/Underfrequency NOTE: NOTE: Two or Four voltage inputs are available for the M-3311A. The Voltage Input can be a phase   voltage input or voltage generated from a broken delta VT connection. 81O/U, 27, and 24 Functions are only available if the voltage input is connected to the phase voltage.
Page 211: Figure 4-46 Ipscom (81O/U) Over/Underfrequency Setpoint Ranges
System Setup and Setpoints – 4 Figure 4-46 IPScom (81O/U) Over/Underfrequency Setpoint Ranges Path Path: Relay / Setup / Relay Setpoints / 81 Over/Under Frequency Command Buttons Save Save Saves all information to the relay. Cancel Cancel Returns the user to the previous window; any changes to the displayed information are lost.
Page 212: 87 Phase Differential
M‑3311A Instruction Book 87 Phase Differential 87H Phase Differential Unrestrained High Set Overcurrent The 87H Phase Differential Unrestrained High Set Overcurrent function is used to detect transformer internal winding faults with high currents. Unlike the 87T function, the 87H function is not blocked by harmonic restraint.
Page 213: Figure 4-48 Ipscom (87H) Phase Differential Current Setpoint Ranges
System Setup and Setpoints – 4 Figure 4-48 IPScom (87H) Phase Differential Current Setpoint Ranges Path Path: Relay / Setup / Relay Setpoints / 87 Phase Differential Current Command Buttons Save Save Saves all information to the relay. Cancel Cancel Returns the user to the previous window;...
Page 214: 87 Phase Differential
M‑3311A Instruction Book 87 Phase Differential NOTE: NOTE: Section 4.6, Transformer Connections Transformer Connections for detailed discussion on transformer   connection applications for 87 function differential. 87T Phase Differential Restrained Overcurrent The 87T Phase Differential function is a percentage differential function with dual adjustable slope characteristics (see Figure 4-50).
Page 215: Figure 4-50 87T Programmable Dual Slope Percentage Restraint Characteristic
System Setup and Setpoints – 4 Fifth Harmonic Restraint Transformer over-excitation produces a high amount of excitation current, which will appear as a differential current to the 87T function. The Fifth Harmonic restraint function can prevent misoperation of the 87T function by shifting the minimum pickup to a higher value (typically set at 150 to 200% of 87T minimum pickup), during transformer over-excitation conditions.
Page 216: Cross Phase Averaging
M‑3311A Instruction Book Cross Phase Averaging Cross phase averaging is used to average the harmonics of all three phases to provide restraint of phases which may not have enough harmonics. Cross phase average, when enabled, provides security against misoperation during magnetizing inrush. However, it may slightly delay the relay operation for internal faults. The level of cross phase average current may be found using the following equations.
Page 217: Figure 4-51 Transformer Ct Tap Setting Example
System Setup and Setpoints – 4 Transformer Rating 392.8 MVA / 196.4 MVA / 196.4 MVA 161 kV / 17.1 kV / 17.1 kV Dac CT 2000:5 Wye CT 8000:5 Wye CT 8000:5 Figure 4-51 Transformer CT Tap Setting Example See previous pages for more information on these settings.
Page 218: 87Gd Ground Differential
M‑3311A Instruction Book 87GD Ground Differential NOTE: NOTE: This function is not provided on Winding One.   The 87GD ground differential element may provide sensitive ground fault protection on winding 2, 3 or winding 4. The relay provides a CT Ratio Correction which removes the need for auxiliary CTs when the phase, winding 2, 3 or winding 4 and their ground CT ratios are different.
Page 219: Figure 4-52 Ipscom (87Gd) Ground Differential Current Setpoint Ranges
System Setup and Setpoints – 4 NOTE: NOTE: Winding Four is not available for Two or Three Winding applications.   Figure 4-52 IPScom (87GD) Ground Differential Current Setpoint Ranges Path Path: Relay / Setup / Relay Setpoints / 87GD Ground Differential current Command Buttons Save Save...
Page 220: Tcm (Trip Circuit Monitoring) Aux Input
M‑3311A Instruction Book TCM (Trip Circuit Monitoring) Aux Input External connections for the Trip Circuit Monitoring function are shown in Figure 4-53. The default Trip Circuit Monitor input voltage is 250 Vdc. See Section 5.5, Circuit Board Switches and Jumpers, Circuit Board Switches and Jumpers, Table 5-3 other available trip circuit input voltage selections.
Page 221: Tcm (Trip Circuit Monitor) Expanded I/O
System Setup and Setpoints – 4 TCM (Trip Circuit Monitor) Expanded I/O The TCM inputs are provided for monitoring the continuity of the trip circuits (Figure 4-55). The inputs can be used for nominal trip coil voltages of 24 Vdc to 250 Vdc. Trip circuit monitoring is performed in the active breaker status only.
Page 222: Figure 4-56 Trip/Close Circuit Monitor Setpoint Ranges
M‑3311A Instruction Book Figure 4-56 Trip/Close Circuit Monitor Setpoint Ranges Path Path: Relay / Setup / Relay Setpoints / TCM/CCM Time Delay – Time Delay – A Time Delay can be applied to delay the TCM function output. Dropout Time Delay – Dropout Time Delay –...
Page 223: Ccm (Close Circuit Monitor)
System Setup and Setpoints – 4 CCM (Close Circuit Monitor) Figure 4-56 displays the settings for the CCM function. The settings for the CCM #2 Close Circuit Monitor are the same as the CCM #1. The CCM inputs are provided for monitoring the continuity of the close circuits. The inputs can be used for nominal close coil voltages of 24 Vdc to 250 Vdc.
Page 224: Figure 4-57 Recommended Close Circuit Monitoring Input Configuration
M‑3311A Instruction Book Dropout Time Delay – Dropout Time Delay – A Time Delay can be applied to delay the reset of the CCM (Close Circuit Monitor) function output. I/O Selection – I/O Selection – I/O Selection allows any input to be selected to block the CCM. The CCM #1(2) Function can also be used to activate a selected output when it times out.
Page 225: Breaker Monitoring
System Setup and Setpoints – 4 Breaker Monitoring The Breaker Monitoring feature calculates an estimate of the per-phase wear on the breaker contacts by measuring and integrating the current or current squared passing through the breaker contacts during the interruption period. The per-phase values are added to an accumulated total for each phase, and then compared to a user-programmed threshold value.
Page 226: Through Fault
M‑3311A Instruction Book Through Fault The Through Fault Monitor feature of the relay provides the user with the means to capture time-stamped Through Fault current information. A "through fault" is defined as an overcurrent event where the overcurrent passes through a transformer and supplies a connected circuit that is faulted. Power transformers may be subjected to Through Fault currents, which can cause mechanical stresses and thermal stress to winding insulation.
Page 227: Ipslogic
System Setup and Setpoints – 4 IPSlogic The relay provides six IPSlogic Functions. IPSlogic Functions can be used to allow external devices to trip through the relay, providing additional target information for the external device. More importantly, these functions can be used in conjunction with IPSlogic to expand the capability of the relay by allowing the user to define customized operating logic.
Page 228: Figure 4-61 Ipslogic Function Setup
M‑3311A Instruction Book Time Delay Time OUT6 Delay OUT4 Figure 4-61 IPSlogic Function Setup 4–96...
Page 229: Settings And Logic Applicable When Ipslogic Function(S) Programmed Using Ipscom
System Setup and Setpoints – 4 Settings and Logic Applicable when IPSlogic Function(s) programmed using IPScom There are four initiating input sources: Initiating Outputs, Initiating Function Trips (including the IPSlogic Functions themselves), Initiating Inputs, and initiation using the Communication Port. The only limitation is that an IPSlogic Function may not be used to initiate itself.
Page 230: Figure 4-63 Select Initiating Functions Screen (Two-/Three-Winding)
M‑3311A Instruction Book Figure 4-63 Select Initiating Functions Screen (Two- / Three-Winding) Figure 4-64 Select Initiating Functions Screen (Four-Winding) 4–98...
Page 231: Figure 4-65 Ipslogic Function Setup
System Setup and Setpoints – 4 Figure 4-65 IPSlogic Function Setup 4–99...
Page 232: System Applications And Logic Schemes
M‑3311A Instruction Book System Applications and Logic Schemes Bus Fault Protection Digital feeder and transformer protection logic can be combined together to provide high-speed bus fault protection. The 50W2 function will act as a delayed overcurrent detector (see Figure 4-66). A fault detected from any feeder relay will activate a programmable input on the relay.
Page 233: Backup For Digital Feeder Relay Failure
System Setup and Setpoints – 4 Backup for Digital feeder Relay Failure The M-3311A Transformer Protection Relay can provide backup for digital feeder relays (see Figure 4-67 Figure 4-68). The backup feature is initiated by the closure of a feeder relay's self-test error contact. This scheme assumes that some sort of contact multiplying is done on the self-test outputs.
Page 234: Figure 4-68 Feeder Backup Logic
M‑3311A Instruction Book Designated by Figure 4-68 Feeder Backup Logic 4–102...
Page 235: Load Shedding
System Setup and Setpoints – 4 Load Shedding Description In stations where there are two or more transformers (see Figure 4-69), usually there is a normally open tie breaker on the secondary side. If one of the transformers is removed from the system, the tie breaker closes and the remaining transformers will pick up the entire load.
Page 236: Figure 4-70 Load Shedding Logic
M‑3311A Instruction Book Figure 4-70 Load Shedding Logic 4–104...
Page 237: Ltc Blocking During Faults
System Setup and Setpoints – 4 LTC Blocking During Faults Description The relay contains logic to block load Tapchangers from operating during feeder fault conditions (see Figure 4-71). Blocking LTC operation during feeder faults can prevent excessive tap changes, reduce contact wear and provide more predictable trip coordination.
Page 238: Transformer Connections
M‑3311A Instruction Book Transformer Connections Transformer Winding Selection The M-3311A can be applied in either a two-, three- or four- winding transformer differential application. For applications where a two or three winding differential is required, the user can set the relay system configuration for Two-Winding and designate the winding current that will be disabled in the 87 Phase Differential Current function.
Page 239: Phase Angle Shift - Standard Connections
System Setup and Setpoints – 4 The compensation calculation uses a counter clockwise rotation from zero. Therefore a Delta-ab transformer (defined as 30 degree leading) has a compensation phase angle shift of 330°, (11x30°). The Delta-ac transformer (defined as 30° lagging) has a compensation phase angle shift of 30°, (1x30°). For a system with acb phase rotation, the compensation calculation uses a counterclockwise rotation.
Page 240: Table 4-5 Transformer Connections
M‑3311A Instruction Book IEC Connection Beckwith Standard Connection Beckwith Custom Description Symbol Description Symbol Input Value Symbol Dac Dac Dac Dac Y Dac Y Dac Y Dab Yd11 Y Dab Dab Y Dab Y Dac Y Dy11 Dac Y Y Inverse Y Inverse Dab Dac Inverse Y Inverse Y...
Page 241: Phase Angle Shift - Custom Connections
System Setup and Setpoints – 4 Where: ConnectXfm is the connection of any transformer winding ConnectCT is the connection of any CT If the transformer connection is a Delta-ac/Delta-ab/Inverse wye with Wye/Delta-ab/Delta-ac CT's, the resulting phase angle compensation shifts and CT magnitude compensation are: ConnectType (W1) = ConnectXfm (Delta-ac) + ConnectCT (Wye) ConnectType (W1) = 1 + 0 = 1 connect type 1 or 30°...
Page 242: Table 4-7 Custom Transformer And Ct Configuration
M‑3311A Instruction Book Transformer Phase Compensation CT Phase/Magnitude Compensation Beckwith Beckwith Compensation Compensation Incremente # Connection Incremente # Connection 1 ∠ 0° 1 ∠ 0° 1 ∠ 30° Delta-ac 1 ∠ 30° 1 ∠ 60° 1 ∠ 60° 1 ∠ 90° 1 ∠...
Page 243: Calculation Of Differential & Restraint Currents
System Setup and Setpoints – 4 Calculation of Differential & Restraint Currents The M-3311A uses the following algorithms for calculating the restraint and differential currents. I restraint: = Σ I differential: I = Σ The differential current (I ) under normal load conditions should equal zero. As indicated by the operate equation, the currents must be correctly defined as entering/exiting the relay terminals.
Page 244: Gsu Transformer Example
M‑3311A Instruction Book GSU Transformer Example The GSU transformer illustrated in the example is a Wye/Delta/Delta with a resistance grounded wye winding and Delta-ac/Wye/Wye CT's. The IEC definition of the transformer is Yd1d1. The Beckwith standard connection is a Wye/Delta-ac/Delta-ac. The application requires an 87GD (Ground Differential) function for the wye winding.
Page 245: Connection Examples
System Setup and Setpoints – 4 Connection Examples GSU Transformer Y d1 d1 Delta-ac Delta-ac Σ Transformer CT2 = CT3 Auxiliary Power Transformer Auxiliary Transformer Dy 11 y11 Delta-ac Figure 4-72 Typical Transformer Differential Application 4–113...
Page 246: Figure 4-73 Delta-Ac/Wye/Wye Ct Connection Diagram
M‑3311A Instruction Book Auxiliary Transformer Example Beckwith Delta-ac/Wye/Wye with Wye/Wye/Wye CTs Dy d M-3311A IAW2 IAW3 IBW2 IBW3 ICW2 ICW3 IGW2 IGW3 IAW1 IBW1 ICW2 Required CT Polarity M-3311A M-3311A If W1 CT Polarity is reversed, then use Inverse-wye CT connection for W1.
Page 247: Figure 4-74 Custom Settings For Delta-Ac/Wye/Wye
System Setup and Setpoints – 4 Auxiliary Transformer Example Winding Winding Type CT Type Line Current in Degrees ∠° 30° 0° 0° Phase Compensation To ref winding CCW Rotation 30° 0° 0° Relay Phase Setting CT Compensation Phase Degrees 0° 0°...
Page 248: Figure 4-75 Wye/Delta-Ac/Delta-Ac Ct Connection Diagram
M‑3311A Instruction Book GSU Transformer Example Beckwith Wye/Delta-ac/Delta-ac with Delta-ac/Wye/Wye CTs IEC Y d1 d1 M-3311A IAW2 IAW3 IBW2 IBW3 ICW2 ICW3 IGW3 IAW1 IAW4 IBW1 IBW4 ICW1 ICW4 Required CT Polarity Reversed W3 and W4 CT Connections M-3311A M-3311A If W3 and W4 CT Polarity is reversed, then use Inverse Delta-ac CT connection.
Page 249: Figure 4-76 Custom Settings For Wye/Delta-Ac/Delta-Ac
System Setup and Setpoints – 4 GSU Transformer Example Breaker and a half application Beckwith: Y/Delta-ac/Delta-ac IEC Description: Y d1 d1 Ι REF Winding Winding Winding Type CT Type Line Current in Degrees ∠° 30° 0° 0° 0° Phase Compensation To ref winding CCW Rotation 30°...
Page 250 M‑3311A Instruction Book This Page Left Intentionally Blank 4–118...
Page 251: General Information
Installation – 5 Installation General Information ................5–1 Mechanical/Physical Dimensions ............5–1 External Connections ................5–7 Pre-Commissioning Checkout ............5–35 Circuit Board Switches and Jumpers ..........5–38 IPScom Communications and Analysis Software Installation .....5–42 Activating Initial Local Communications ..........5–43 Initial Setup Procedure ...............5–44 General Information Prior to the installation of the equipment, it is essential to review the contents of this NOTE: manual to locate data which may be of importance during the installation procedures.
Page 252: Figure 5-1 M-3311A Horizontal Chassis Mounting Dimensions (H1)
M‑3311A Instruction Book 17.50 [44.45] ACTUAL 5.21 [13.23] ACTUAL 17.50 [44.45] 10.20 [25.91] 19.00 [48.26] 19.00 [48.26] 18.31 0.35 [46.51] [0.89] 0.40 [1.02] X 0.27 [0.68] Slot (4X) 2.25 [5.72] 1.48 [3.8] Standard 19" Horizontal Mount Chassis NOTE: Dimensions in brackets are in centimeters. Dimensions in brackets are in centimeters.
Page 253: Figure 5-2 M-3311A Mounting Dimensions - Horizontal Chassis With Expanded I/O
Installation – 5 M-3311A TRANSFORMER PROTECTION ® 0.35 18.31 [0.89] [46.51] NOTE: NOTE: Dimensions in brackets are in centimeters. 㽮㽮 Figure 5-2 M-3311A Mounting Dimensions – Horizontal Chassis With Expanded I/O 5–3...
Page 254: Figure 5-3 M-3311A Panel Mount Cutout Dimensions
M‑3311A Instruction Book 18.31 [46.51] 0.32 [0.81] 18.31 0.32 [46.51] [0.81] Dimensions in brackets are in centimeters. NOTE: Figure 5-3 M-3311A Panel Mount Cutout Dimensions 5–4...
Page 255: Figure 5-4 M-3311A Vertical Chassis Mounting Dimensions Without Expanded I/O (H2)
Installation – 5 5.65 [14.40] 5.59 6.19 0.03 [14.20] [15.7] [0.076] Actual 2.25 1.97 2.25 1.67 0.35 [5.72] [5.0] [5.72] [4.24] [0.89] 0.28 [0.71] Dia. (4X) TARGETS 19.00 [48.26] OUTPUTS OUT 1 OUT 3 OUT 5 OUT 7 18.30 OUT 4 OUT 6 OUT 8 OUT 2...
Page 256: Figure 5-5 Mounting Dimensions For Ge L-2 Cabinet H3 And H4
M‑3311A Instruction Book 8.84 [22.45] 2.83 2.83 [7.19] [7.19] 8.84 [22.45] Dimensions in brackets are in centimeters. NOTE: Figure 5-5 Mounting Dimensions for GE L-2 Cabinet H3 and H4 5–6...
Page 257: External Connections
Installation – 5 External Connections The protective grounding terminal must be connected to an earthed ground anytime CAUTION: ▲ external connections have been made to the unit. Only dry contacts must be connected to inputs because these contact inputs are CAUTION: ▲...
Page 258: Grounding Requirements
M‑3311A Instruction Book Grounding Requirements The M-3311A is designed to be mounted in an adequately grounded metal panel, using grounding techniques (metal-to-metal mounting) and hardware that assures a low impedance ground. Unit Isolation Sensing inputs should be equipped with test switches and shorting devices where necessary to isolate the unit from external potential or current sources.
Page 259 Installation – 5 5–9...
Page 260 M‑3311A Instruction Book 5–10...
Page 261 Installation – 5 5–11...
Page 262 M‑3311A Instruction Book 5–12...
Page 263 Installation – 5 5–13...
Page 264 M‑3311A Instruction Book 5–14...
Page 265 Installation – 5 5–15...
Page 266 M‑3311A Instruction Book 5–16...
Page 267 Installation – 5 5–17...
Page 268 M‑3311A Instruction Book 5–18...
Page 269 Installation – 5 5–19...
Page 270 M‑3311A Instruction Book 5–20...
Page 271 Installation – 5 5–21...
Page 272 M‑3311A Instruction Book 5–22...
Page 273: Figure 5-22 Two Winding - One Ground Input - Zero Voltage Inputs Vertical Chassis External Connections
Installation – 5 COM 2 IRIG- B RATED CURRENT 1A,NOM COM 2 5 A,NOM RS232 ETHERNET COM 3 RS485 IN 6 IN 5 IN 4 IN 3 IN 2 IN 1 ( 5 2 b ) WIND- ING 1 (W1) RT N SEL F- TEST...
Page 274: Figure 5-23 Two Winding - One Ground Input - Two Voltage Inputs Vertical Chassis External Connections
M‑3311A Instruction Book COM 2 IRIG- B RATED CURRENT 1A,NOM COM 2 5 A,NOM RS232 ETHERNET Ø COM 3 RS485 IN 6 IN 5 Ø IN 4 IN 3 IN 2 IN 1 ( 5 2 b ) WIND- ING 1 (W1) RT N SEL F-...
Page 275: Figure 5-24 Two Winding - One Ground Input - Four Voltage Inputs Vertical Chassis External Connections
Installation – 5 COM 2 IRIG- B RATED CURRENT 1A,NOM COM 2 5 A,NOM RS232 ETHERNET COM 3 RS485 IN 6 IN 5 IN 4 IN 3 IN 2 IN 1 ( 5 2 b ) WIND- ING 1 (W1) RT N SEL F- TEST...
Page 276: Figure 5-25 Three Winding - Two Ground Inputs - Zero Voltage Inputs Vertical Chassis External Connections
M‑3311A Instruction Book IRIG- B COM 2 RATED CURRENT 1A,NOM COM 2 5 A,NOM RS232 ETHERNET WIND- ING 1 (W1) COM 3 RS485 IN 6 IN 5 IN 4 IN 3 IN 2 IN 1 ( 5 2 b ) WIND- ING 2 (W2)
Page 277: Figure 5-26 Three Winding - Two Ground Inputs - Two Voltage Inputs Vertical Chassis External Connections
Installation – 5 COM 2 IRIG- B RATED CURRENT 1A,NOM COM 2 5 A,NOM RS232 ETHERNET WIND- ING 1 (W1) Ø COM 3 RS485 IN 6 IN 5 IN 4 Ø IN 3 IN 2 IN 1 ( 5 2 b ) WIND- ING 2 (W2)
Page 278: Figure 5-27 Three Winding - Two Ground Inputs - Four Voltage Inputs Vertical Chassis External Connections
M‑3311A Instruction Book COM 2 IRIG- B RATED CURRENT 1A,NOM COM 2 5 A,NOM RS232 ETHERNET WIND- ING 1 (W1) COM 3 RS485 IN 6 IN 5 IN 4 IN 3 IN 2 IN 1 ( 5 2 b ) WIND- ING 2 (W2)
Page 279: Figure 5-28 Four-Winding - Three Ground Inputs - Zero Or Two Voltage Inputs Vertical Chassis External Connections
Installation – 5 COM 2 IRIG- B RATED CURRENT 1A,NOM COM 2 5 A,NOM RS232 Ø ETHERNET WIND- ING 1 (W1) COM 3 RS485 IN 6 IN 5 WIND- ING 4 IN 4 (W4) IN 3 IN 2 IN 1 ( 5 2 b ) WIND- ING 2...
Page 280: Figure 5-29 Typical (Two Winding - Two Voltage Inputs) Three-Line Connection Diagram
M‑3311A Instruction Book M-3311A Output Contacts M-3311A (W-1) Self- OUT 2 OUT 1 Test Typical Typical Self- Power Trip Test Alarm Alarm Status Trip Alarm M-3311A Input Contacts IN 1 IN 2 IN 3 Winding 1 (52b) Typical Typical Return (W-1) Other Other...
Page 281: Figure 5-30 Typical (Two Winding - Four Voltage Inputs) Three-Line Connection Diagram
Installation – 5 M-3311A Output Contacts Self- OUT 2 OUT 1 Typical Typical Test M-3311A (W-1) Self- Power Trip Test Alarm Alarm Status Alarm Trip M-3311A Input Contacts IN 1 IN 2 IN 3 (52b) Typical Typical Return Other Other Inputs Inputs Winding 1...
Page 282: Figure 5-31 Typical (Three Winding - Two Voltage Inputs) Three-Line Connection Diagram
M‑3311A Instruction Book M-3311A Output Contacts Self- OUT 2 OUT 1 Typical Typical Test M-3311A (W-1) Self- Power OK Trip Test Status Alarm Alarm Alarm Trip M-3311A Input Contacts IN 1 IN 2 IN 3 (52b) Typical Typical Return Other Other Inputs Inputs...
Page 283: Figure 5-32 Typical (Three Winding - Four Voltage Inputs) Three-Line Connection Diagram
Installation – 5 M-3311A Output Contacts M-3311A (W-1) Self- OUT 2 OUT 1 Typical Typical Test Self- Power OK Trip Test Status Alarm Alarm Alarm Trip M-3311A NOTES: Broken Delta VTs Delta-Wye power transformer shown with Wye-Wye connedted CTs (Connected #4 DABY yy). Other M-3311A connections are possible.
Page 284: Figure 5-33 Typical (Four-Winding - Two Voltage Inputs) Three-Line Connection Diagram
M‑3311A Instruction Book M-3311A (W-4) M-3311A (W-1) M-3311A Output Contacts M-3311A Input Contacts IN 1 IN 2 IN 3 (52b) Typical Typical Return Self- OUT 2 OUT 1 Typical Typical Test Other Other Inputs Inputs Self- Power OK Trip Test Status Alarm Alarm...
Page 285: Pre-Commissioning Checkout
Installation – 5 Pre‑Commissioning Checkout During M-3311A Transformer Protection Relay field commissioning, check the following procedure to ensure that the CT and VT connections are correct. 1. On the keypad, press ENTER. After a short delay, the unit should display: VOLTAGE RELAY VOLT curr freq v/hz ...
Page 286 M‑3311A Instruction Book 10. Press ENTER to display line currents for Winding 4 (I ). Compare these currents with the measured values using a meter. If there is a discrepancy, check the CT connections to the rear terminal block of the unit. The unit should display: W4 PHASE CURRENT A= 5.00 B=5.00 C=5.00 11.
Page 287 Installation – 5 19. Press ENTER for the unit to display the ground differential current. The ground differential current should be I W2 GND DIFF CURRENT 0.00 Amps Press ENTER for W3 W3 GND DIFF CURRENT 0.00 Amps Press ENTER for W4 W4 GND DIFF CURRENT 0.00 Amps 20.
Page 288: Circuit Board Switches And Jumpers
M‑3311A Instruction Book Circuit Board Switches and Jumpers Dip Jumper Position Description Connects CD signal to COM 2 Pin 1* Connects +15 V to COM 2 Pin 1 Connects -15 V to COM 2 Pin 9 Disconnects COM 2 Pin 9 COM 3 Termination Resistor Inserted COM 3 Termination Resistor Not Inserted* COM 3 Shares Baud Rate with COM 1...
Page 289: Table 5-4 Close Circuit Monitor 1 Input Voltage Select Jumper Configuration
Installation – 5 Close Circuit Monitor 1 Input Voltage Select Input Voltage Jumper J4 Position Jumper J5 Position Jumper J6 Position 24 Vdc A to B A to B A to B 48 Vdc B to C A to B A to B 125 Vdc B to C...
Page 290: Figure 5-34 M-3311A Circuit Board Standard I/O
M‑3311A Instruction Book Figure 5-34 M-3311A Circuit Board Standard I/O 5–40...
Page 291: Figure 5-35 M-3311A Circuit Board Expanded I/O
Installation – 5 ® BECKWITH ELECTRIC BE# 450-00236 P-2053 REV RV28 C132 FB16 C130 R116 R114 FB13 C126 C128 RV27 R113 R111 C122 C124 RV26 FB31 R108 C118 FB30 RV25 C120 R107 R105 FB29 C114 C116 RV24 R104 R102 FB28 C110 C112 RV23...
Page 292: Ipscom Communications And Analysis Software Installation
M‑3311A Instruction Book IPScom Communications and Analysis Software Installation IPScom Installation and Setup IPScom is available on CD-ROM, or may be downloaded from our website at www.beckwithelectric.com. The S-3300 IPScom Communications Software is not copy-protected. For more information on your specific rights and responsibilities, see the licensing agreement enclosed with your software or contact Beckwith Electric.
Page 293: Activating Initial Local Communications
Installation – 5 Activating Initial Local Communications The relay and IPScom Communications Software are shipped from the factory with the same default communication parameters. Therefore, it may not be necessary to set up communication parameters. In order for IPScom to communicate with the relay using direct serial connection, a serial "null modem" cable is required, with a 9-pin connector (DB9P) for the relay, and an applicable connector for the computer (usually DB9S or DB25S).
Page 294: Initial Setup Procedure
M‑3311A Instruction Book Initial Setup Procedure The relay is shipped with the initial configuration settings as listed in Appendix A, Figure A-1 System Communication Setup, Figure A-2 Setup System (Two or Three Winding), Figure A-3 Setup System (Four Windings), Figure A-4 System Setpoints and Settings.
Page 295 Installation – 5 9. Enter the desired setpoints for the enabled functions. See Section 4.4, System Setpoints. The general information that is required to complete the input data in this section includes individual relay function: • Pickup settings (converted to relay quantities) •...
Page 296 M‑3311A Instruction Book This Page Left Intentionally Blank 5–46...
Page 297: Chapter 6 Testing
Testing – 6 Testing Equipment and Test Setup ..............6–2 Diagnostic Test Procedures ..............6–2 Automatic Calibration .................6–13 Input Configurations ................6–15 Protection Elements ................6–21 Terminal Connections .................6–23 Accuracy For Voltage Protection Functions ........6–25 Functional Test Procedures ..............6–26 Power On Self Tests................6–27 24DT Volts/Hz Overexcitation Definite Time (#1 or #2) ......6–28 24IT Volts/Hz Overexcitation Inverse Time .........6–29 27 Phase Undervoltage ..............6–30 46DT Negative Sequence Overcurrent Definite Time ......6–31...
Page 298: Equipment And Test Setup
M‑3311A Instruction Book Equipment and Test Setup No calibration is necessary, as the M-3311A Transformer Protection Relay is calibrated and fully tested at the factory. If calibration is necessary because of a component replacement, follow the Auto Calibration procedure detailed in Section 6.3.
Page 299: Output Test (Relay)
Testing – 6 4. If Level Access is not active, then the following is displayed: VOLTAGE RELAY VOLT curr freq v/hz Do not enter DIAGNOSTIC MODE when protected equipment is in service. Entering CAUTION: ▲ DIAGNOSTIC MODE when protected equipment is in service removes all protective functions of the relay.
Page 300: Relay Number
M‑3311A Instruction Book Relay/Output Number Normally Open Contact* Normally Closed Contacts* (Self-Test) (Power Supply) * "Normal" position of the contact corresponds to the OFF or de-energized state of the relay. Table 6-1 Output Contacts Following completion of testing, the output contacts, can be turned ON in the following manner: 1.
Page 301: Input Test (Status)
Testing – 6 INPUT TEST (STATUS) The INPUT TEST menu enables the user to determine the status of the individual status inputs. Each input can be selected by number using the up and down arrow buttons. The status of the input will then be displayed.
Page 302: Status Led Test
M‑3311A Instruction Book STATUS LED TEST The STATUS LED TEST STATUS LED TEST menu enables the user to check the front panel LED’s Individually. ® Figure 6-1 Status LED Panel 1. When INPUT TESTS (STATUS) INPUT TESTS (STATUS) is displayed, press the right arrow button until the following is displayed: STATUS LED TEST output input LED target ...
Page 303: Target Led Test
Testing – 6 TARGET LED TEST The TARGET LED TEST menu allows the user to check the Target Module LED’s individually. TARGETS 24 DT/IT OVEREXCITATION INV OC 51GW2 PHASE UV INV OC 51GW3 PHASE OV BREAKER FAILURE 50BF MULTIPURPOSE OV FREQUENCY 81 O/U 46 DT/IT...
Page 304: Button Test
M‑3311A Instruction Book BUTTON TEST BUTTON TEST The BUTTON TEST BUTTON TEST menu selection allows the user to check the HMI Module Keypad. As each button is pressed, its name is displayed. Figure 6-4 Human-Machine Interface Module 1. When the TARGET LED TEST TARGET LED TEST is displayed, press the right button until the following is displayed: BUTTON TEST BUTTON disp com1 com2...
Page 305: Communication Tests
Testing – 6 COMMUNICATION TESTS COM1 and COM2 Test The COM1 and COM2 LOOPBACK TESTS allow the user to test the front and rear RS-232 ports for proper operation. These tests require the use of a loop-back plug (Figure 6-5). The loopback plug consists of a DB9P connector (male) with pin 2 (RX) connected to pin 3 (TX) and pin 7 (RTS) connected to pin 8 (CTS).
Page 306: Com3 Test (2-Wire)
M‑3311A Instruction Book COM3 Test (2-Wire) This test requires a PC with an RS-485 converter and terminal emulator software installed. NOTE: The COM3 ECHO TEST 2 WIRE allows the user to test the RS-485 rear terminal connections for proper operation. 1.
Page 307: Clock Test
Testing – 6 CLOCK TEST 1. When COM3 ECHO TEST 2WIRE is displayed, press the right arrow button until the following is displayed: CLOCK TEST  com3 CLOCK led cal  Press ENTER. A display similar to the following is shown: CLOCK TEST 03-JAN-1998 09:00:00.000 Press ENTER again to toggle the clock.
Page 308: Flash Relay Ok Led
M‑3311A Instruction Book FLASH RELAY OK LED The Flash Relay OK LED function is provided to enable or disable the flashing of the Relay OK LED. This function only has effect while the relay is in normal operating mode and will not be noticed while in Diagnostic Mode.
Page 309: Automatic Calibration
Testing – 6 Automatic Calibration The M-3311A Transformer Protection Relay has been fully calibrated at the factory. There is no need to recalibrate the unit prior to installation. Further calibration is only necessary if a component was changed. WARNING: All relay functions and protection will be inoperative while the relay is in Diagnostic Mode.
Page 310: Figure 6-8 Current Calibration Configuration (Four-Winding)
M‑3311A Instruction Book Current Input Figure 6-8 Current Calibration Configuration (Four-Winding) 4. Press ENTER to start calibration. While the unit is calibrating, the display will show: AUTO CALIBRATION -WAIT- When the calibration is complete, unit will display: AUTO CALIBRATION -DONE- The calibration can be verified by reading the Status (see the Monitor Status menu, and Monitor Status/Metering in Chapter 3).
Page 311: Input Configurations
Testing – 6 Input Configurations Phase angles shown here represent leading angles as positive and lagging angles as negative. Some test equipment manufacturers use lagging angles as positive, in which case I =∠20° and I =∠240°. Other current phase angles should be adjusted in the same manner. Voltage 120 Vac Input...
Page 312: Figure 6-13 Current Inputs, Configuration C1 (Four-Winding)
M‑3311A Instruction Book Current ∠0 Input 1 Current ∠-120 Input 2 Current ∠120 Input 3 Figure 6-13 Current Inputs, Configuration C1 (Four-Winding) Current ∠0 Input 1 Current ∠-120 Input 2 Current ∠120 Input 3 Figure 6-14 Current Inputs, Configuration C2 (Four-Winding) Current ∠0 Input 1...
Page 313: Figure 6-16 Current Inputs, Configuration C4 (Four-Winding)
Testing – 6 Current ∠0 Input 1 Current ∠-120 Input 2 Current ∠120 Input 3 Figure 6-16 Current Inputs, Configuration C4 (Four-Winding) Current ∠0 Input 1 Current ∠0 Input 2 Current ∠0 Input 3 Figure 6-17 Current Inputs, Configuration C5 (Four-Winding) 6–17...
Page 314: Figure 6-18 Current Configuration C6 (Four-Winding)
M‑3311A Instruction Book Current Current ∠0 ∠0 Input 1 Input 2 ∠-120 ∠-120 ∠120 ∠120 Current Current ∠0 ∠0 Input 3 Input 4 ∠-120 ∠-120 ∠120 ∠120 Figure 6-18 Current Configuration C6 (Four-Winding) Current ∠0 Input 1 ∠-120 ∠120 Current ∠0 ∠0 Input 2...
Page 315: Figure 6-20 Current Inputs, Configuration C8 (Three-Winding)
Testing – 6 Current ∠0 Input 1 ∠-120 ∠120 Current ∠0 ∠0 Input 2 ∠-120 ∠120 Current ∠0 ∠0 Input 3 ∠-120 ∠120 Figure 6-20 Current Inputs, Configuration C8 (Three-Winding) Voltage Voltage Input Input Neutral Neutral Figure 6-21 Two Voltage Inputs, Configuration V5 (Two-Winding) 6–19...
Page 316: Figure 6-22 Two Voltage Inputs, Configuration V6 (Three-Winding)
M‑3311A Instruction Book Voltage Voltage Input Input Neutral Neutral Figure 6-22 Two Voltage Inputs, Configuration V6 (Three-Winding) Voltage Voltage Input Input Neutral Neutral Voltage Input Neutral Voltage Input Neutral Figure 6-23 Four Voltage Inputs, Configuration V7 (Two-Winding) Voltage Voltage Input Input Neutral Neutral...
Page 317: Protection Elements
Testing – 6 Protection Elements M-3311A TWO WINDING CONFIGURATION DATA PROTECTION NUMBER OF WINDINGS NOTES FUNCTION ELEMENTS Voltage Based 24DT #1, #2 24IT #1, #2, #3 Only for Four Voltage #1, #2, #3 Inputs selectable as: , or V #1, #2, #3 #1, #2, #3, #4 Current Based 46DT...
Page 318: Table 6-4 List Of Protection Elements For Three-Winding Version (Four Voltages)
M‑3311A Instruction Book M-3311A THREE WINDING CONFIGURATION DATA PROTECTION NUMBER OF WINDINGS SELECTABLE NOTES FUNCTION ELEMENTS Voltage Based 24DT #1, #2 24IT #1, #2, #3 Only for Four Voltage #1, #2, #3 Inputs selectable as: , or V #1, #2, #3 #1, #2, #3, #4 Current Based 46DT...
Page 319: Terminal Connections
Testing – 6 Terminal Connections INPUT TERMINAL INPUT TERMINAL IAW1 (+) IAW1 (+) IAW1 (-) IAW1 (-) IBW1 (+) IBW1 (+) IBW1 (-) IBW1 (-) ICW1 (+) ICW1 (+) ICW1 (-) ICW1 (-) IAW2 (+) IAW2 (+) IAW2 (-) IAW2 (-) IBW2 (+) IBW2 (+) IBW2 (-)
Page 320: Table 6-8 Terminal Connections For Two Voltage Inputs (Three-Winding)
M‑3311A Instruction Book INPUT TERMINAL VØ (+) VØ (-) VG (+) VG (-) Table 6-8 Terminal Connections for Two Voltage Inputs (Three-Winding) INPUT TERMINAL VA (+) VA (-) VB (+) VB (-) VC (+) VC (-) VG (+) VG (-) Table 6-9 Terminal Connections for Four Voltage Inputs (Two-Winding) INPUT TERMINAL...
Page 321: Accuracy For Voltage Protection Functions
Testing – 6 Accuracy For Voltage Protection Functions Two-/Three-Winding Two-/Three-Winding Four-Winding Version Two Voltage Version Two Voltage Version Four Voltage Function Voltage Inputs (V Ø, Inputs (V Inputs (V Ø, 24DT Voltage source = V Voltage source = V Voltage source = V Ø...
Page 322: Functional Test Procedures
M‑3311A Instruction Book Functional Test Procedures The functional tests procedures presented here are for the four-winding version of the relay. Use the tables and figures provided in Section 6 to test the two- and three-winding versions. Table 6-3 Table 6-4 provide a list of the protection elements for the two- and three-winding versions.
Page 323: Power On Selftests
Testing – 6 Power On Self Tests VOLTAGE INPUTS: None CURRENT INPUTS: None 1. Apply proper power to the power input terminals: 60 (hot) and 61 (neutral) 2. The unit will display: POWER ON SELFTESTS XXXXXXXXxxxxxxxxxxxxxxX All LEDs will illuminate simultaneously for approximately 1 second. The POWER and RELAY OK LEDs will remain illuminated;...
Page 324: 24Dt Volts/Hz Overexcitation Definite Time (#1 Or #2)
M‑3311A Instruction Book 24DT Volts/Hz Overexcitation Definite Time (#1 or #2) Relays with four voltage inputs use two positive-sequence voltages for 24DT#1 and #2. See Table 6-11 the accuracy when testing relays with four voltage inputs. Configuration V1 VOLTAGE INPUTS: None CURRENT INPUTS: Definite Time Pickup...
Page 325: 24It Volts/Hz Overexcitation Inverse Time
Testing – 6 24IT Volts/Hz Overexcitation Inverse Time Relays with four voltage inputs use the positive-sequence voltages for 24IT. See Table 6-11 for the accuracy when testing relays with four voltage inputs. Configuration V1 VOLTAGE INPUTS: None CURRENT INPUTS: Inverse Time Pickup (100 to 150) TEST SETTINGS: Inverse Time Curve...
Page 326: 27 Phase Undervoltage
M‑3311A Instruction Book 27 Phase Undervoltage Configuration V1 VOLTAGE INPUTS: None CURRENT INPUTS: Pickup Volts (5 to 140) TEST SETTINGS: Inhibit Setting Volts (5 to 140) Time Delay Cycles (1 to 8160) Programmed Outputs (1 to 8) Expanded I/O (9 to 16) Functions 24DT, 24IT Disable Function 81O/U...
Page 327: 46Dt Negative Sequence Overcurrent Definite Time
Testing – 6 46DT Negative Sequence Overcurrent Definite Time Configuration V1 VOLTAGE INPUTS: Configuration C2, C3 or C4 (MODIFIED) CURRENT INPUTS: Definite Time Pickup Amps (0.1 to 20) TEST SETTINGS: 1 Amp CT Rating (0.02 to 4) Time Delay Cycles (1 to 8160) Programmed Outputs (1 to 8)
Page 328: 46It Negative Sequence Overcurrent Inverse Time
M‑3311A Instruction Book 46IT Negative Sequence Overcurrent Inverse Time Configuration V1 VOLTAGE INPUTS: Configuration C2, C3 or C4 (MODIFIED) CURRENT INPUTS: Inverse Time Pickup Amps (0.50 to 5.00) TEST SETTINGS: 1 Amp CT Rating (0.10 to 1.00) Standard Inverse Time Curves: Curve (1 to 4) Time Dial...
Page 329 Testing – 6 Standard Curve Testing: The operating time will be read from Appendix D, Negative Sequence Inverse Time Curves for the applied current and appropriate Time Dial (TD) setting. The curve portions extending to lower than P current values are inactive and can be ignored. t = time in seconds TD = Time Dial setting M = current in multiples of pickup Time Test: With output contacts connected to the timer, apply currents equal to the multiple of the Inverse Time Pickup (P) and start timing.
Page 330: 49 Winding Thermal Protection
M‑3311A Instruction Book 49 Winding Thermal Protection None VOLTAGE INPUTS: Configuration C1, C2, C3 or C4 CURRENT INPUTS: Time Constant τ Minutes (1.0 to 999.9) TEST SETTINGS: Max Overload Current Amps (1.00 to 10.00) 1 Amp CT Rating (0.20 to 2.00) Current Selection (Sum1,Sum2,W1,W2,W3,W4) Programmed Outputs...
Page 331 Testing – 6 Time Test (Cold Start): Connect a timer to output contacts (Z) so that the timer stops timing when the contacts (Z) close. The 49 Thermal Overload 49 current value can be obtained utilizing either the NOTE: HMI (Status/Current Status) or IPScom Communications Software (Relay/Monitor/ Secondary Status).
Page 332: Instantaneous Phase Overcurrent 1-8
M‑3311A Instruction Book 50 Instantaneous Phase Overcurrent 1–8 None VOLTAGE INPUTS: Configurations C1, C2, C3, C4 CURRENT INPUTS: 50W1 Pickup Amps (1.0 to 100) TEST SETTINGS: 1 Amp CT Rating (0.2 to 20) Current Selection (Sum1, Sum2, W1, W2, W3, W4) Time Delay Cycles (1 to 8160)
Page 333: 50G Instantaneous Ground Overcurrent
Testing – 6 50G Instantaneous Ground Overcurrent None VOLTAGE INPUTS: Configuration C5 CURRENT INPUTS: 50GW2/W3/W4 Pickup Amps (1.0 to 100.0) TEST SETTINGS: 1 Amp CT Rating (0.2 to 20.0) Programmed Outputs (1 to 8) Expanded I/O (9 to 16) Function 51G Disable Function 87GD Disable...
Page 334: 50N Instantaneous Residual Overcurrent
M‑3311A Instruction Book 50N Instantaneous Residual Overcurrent Configuration V1 VOLTAGE INPUTS: As Described CURRENT INPUTS: Pickup Amps (1.0 to 100.0) TEST SETTINGS: 1 Amp CT Rating (0.2 to 20.0) Current Selection (Sum1, Sum2, W1, W2, W3, W4) Time Delay Cycles (1 to 8160) Programmed Outputs (1 to 8)
Page 335: 50Bf Breaker Failure
Testing – 6 50BF Breaker Failure Configuration V1 VOLTAGE INPUTS: As Described CURRENT INPUTS: 50BFW1/W2/W3/W4 Phase Pickup Amps (0.10 to 10.00) TEST SETTINGS: 1 Amp CT Rating (0.02 to 2.00) 50BFW1/W2/W3/W4 Residual Pickup Amps (0.10 to 10.0) 1 Amp CT Rating (0.02 to 2) Time Delay Cycles...
Page 336 M‑3311A Instruction Book e. Press TARGET RESET button to remove targets. When calculating values for residual current functions, the relay adds the three-phase NOTE: currents (3I ). The relay operates on I Timer Test : With output contacts (Z) connected to the timer, apply approximately 110% of above Pickup (P) Amps and start timing.
Page 337: 51 Inverse Time Phase Overcurrent
Testing – 6 51 Inverse Time Phase Overcurrent None VOLTAGE INPUTS: Configuration C1 or C2 or C3 or C4 CURRENT INPUTS: 51W1/W2/W3/W4 Pickup Amps (0.50 to 12.00) TEST SETTINGS: Current Selection (Sum1, Sum2, W1, W2, W3, W4) 1 Amp CT Rating (0.10 to 1.00) Standard Inverse Time Curves: Curve...
Page 338 M‑3311A Instruction Book Standard Inverse Very Inverse Extremely Inverse Long Time Inverse 0.14 13.5 t = TD x t = TD x t = TD x t = TD x 0.02 M - 1 M - 1 t = time in seconds TD = Time Dial setting M = current in multiples of pickup Repeat Steps 4 and 5 using Configurations C2, C3 and C4.
Page 339: 51G Inverse Time Ground Overcurrent
Testing – 6 51G Inverse Time Ground Overcurrent None VOLTAGE INPUTS: Configuration C5 CURRENT INPUTS: 51GW2/W3/W4 Pickup Amps (0.50 to 12.00) TEST SETTINGS: 1 Amp CT Rating (0.1 to 2.4) Standard Inverse Time Curves: Curve (1 to 4) Time Dial (0.5 to 11.0) IEC Inverse Time Curves: IEC Curve...
Page 340: 51N Inverse Time Residual Overcurrent
M‑3311A Instruction Book 51N Inverse Time Residual Overcurrent None VOLTAGE INPUTS: As Described CURRENT INPUTS: 51N W1/W2/W3/W4 Pickup Amps (0.5 to 6) TEST SETTINGS: 1 Amp CT Rating (0.1 to 1.2) Current Selection (Sum1, Sum2, W1, W2, W3, W4) Standard Inverse Time Curves: Curve (1 to 4) Time Dial...
Page 341 Testing – 6 Refer to Appendix D. Calculate test times for levels represented on the graphs. It is suggested that 4 or 5 test levels be chosen. Very Inverse Extremely Inverse Long Time Inverse Standard Inverse 0.14 13.5 t = TD x t = TD x t = TD x t = TD x...
Page 342: Phase Overvoltage (#1, #2 Or #3)
M‑3311A Instruction Book 59 Phase Overvoltage (#1, #2 or #3) Configuration V1 or V3 VOLTAGE INPUTS: None CURRENT INPUTS: 59 Pickup Volts (5 to 180) TEST SETTINGS: Time Delay Cycles (1 to 8160) Programmed Outputs (1 to 8) Expanded I/O (9 to 16) Function 81O/U Disable...
Page 343: Ground Overvoltage (#1 Or #2)
Testing – 6 59G Ground Overvoltage (#1 or #2) Configuration V2 VOLTAGE INPUTS: None CURRENT INPUTS: 59G Pickup Volts (5 to 180) TEST SETTINGS: Time Delay Cycles (1 to 8160) Programmed Outputs (1 to 8) Expanded I/O (9 to 16) Function 81O/U Disable Disable functions as shown.
Page 344: 81 Overfrequency/Underfrequency
M‑3311A Instruction Book 81 Overfrequency/Underfrequency Configuration V1 VOLTAGE INPUTS: None CURRENT INPUTS: Pickup (55 to 65) TEST SETTINGS: 50 Hz Relay (45 to 55) Time Delay Cycles (2 to 65,500) Programmed Outputs (1 to 8) Expanded I/O (9 to 16) Functions 24DT, 24IT Disable Function 27...
Page 345: 87H Phase Differential Overcurrent
Testing – 6 87H Phase Differential Overcurrent None VOLTAGE INPUTS: Configuration C6 CURRENT INPUTS: Pickup (5.0 to 20.0) TEST SETTINGS: Time Delay Cycles (1 to 8160) Programmed Outputs (1 to 8) Expanded I/O (9 to 16) Functions 46DT, 46IT, 49 Disable Function 50 Disable...
Page 346 M‑3311A Instruction Book Wye (Winding 1) Wye (Winding 2) Transformer c. Release the TARGET RESET button, then decrease the current. The OUTPUT LED will extinguish. d. Press TARGET RESET button to remove targets. This test may be repeated for testing the opposite winding or another phase.
Page 347 Testing – 6 87T Phase Differential Overcurrent None VOLTAGE INPUTS: Configuration C6 CURRENT INPUTS: Pickup (0.10 to 1.00) TEST SETTINGS: Percent Slope #1 (5 to 100) Percent Slope #2 (5 to 200) Slope Break Point (1.0 to 4.0) Even Harmonics Restraint E,D,A ENABLE/DISABLE/ and 4...
Page 348 M‑3311A Instruction Book Delta (Winding 1) Wye (Winding 2) Transformer Press and hold the TARGET RESET button in, then slowly increase I (Input 2) until the PHASE DIFFERENTIAL 87T/H LED illuminates or the pickup indicator operates on the computer target screen.
Page 349 Testing – 6 Slope 2 Test: a. Define any number of testing points desirable to verify the trip I (Input 2) current curve. b. Choose any values for I (Input 2) and calculate the expected I (Input 1) according to the following: (1 + S2 ) + BP (S1-S2) (1 -...
Page 350: 87Gd Ground Differential (#1, #2)
M‑3311A Instruction Book 87GD Ground Differential (#1, #2) None VOLTAGE INPUTS: As Described Below CURRENT INPUTS: 87GD Pickup Amps (0.20 to 10.00) TEST SETTINGS: 1 Amp CT Rating (0.04 to 2.00) Time Delay Cycles (1 to 8160) CT Ratio Correction (0.10 to 7.99) Programmed Outputs (1 to 8)
Page 351: Bm Breaker Monitoring
Testing – 6 BM Breaker Monitoring None VOLTAGE INPUTS: As Described Below CURRENT INPUTS: Pickup kAmps (kA2)* (0 to 50,000) TEST SETTINGS: Delay Cycles (0.1 to 4095.9) Timing Method T or Preset Accumulators Phase A, B, or C kAmp (kA ) Cycles* (0 to 50,000) Programmed Outputs...
Page 352: Trip/Close Circuit Monitoring
M‑3311A Instruction Book Trip/Close Circuit Monitoring As Described VOLTAGE INPUTS: None CURRENT INPUTS: Delay Cycles (1 to 8160) TEST SETTINGS: Dropout Time Delay Cycles (1 to 8160) Programmed Outputs (1 to 8) Expanded I/O (9 to 16) Test Setup: Determine the Trip/Close Circuit Monitoring function settings to be tested. Disable all other functions prior to testing.
Page 353: Through Fault
Testing – 6 Through Fault As Described VOLTAGE INPUTS: None CURRENT INPUTS: Through Fault Current Threshold 5 Amps (1.0-100.0) TEST SETTINGS: 1 Amp (0.2-20.0) Pickup Operation Limit (1-65535) Cumulative I^2T 100k A^2 Cycles (10-1000000) Time Delay 1 Cycles (1-8160) Current Selection (Sum1, Sum2, W1, W2, W3, W4) Threshold and Cumulative I^2 T Limit Tests: Utilize the IPSCom Metering II screen to monitor the counters.
Page 354: Ipslogic (#1-6)
M‑3311A Instruction Book IPSlogic (#1–6) As required VOLTAGE INPUTS: As required CURRENT INPUTS: Time Delay Cycles (1 to 65500) TEST SETTINGS: Reset/Dropout Delay Cycles (0 to 65500) Programmed Outputs (1 to 8) Expanded I/O (9 to 16) Blocking Inputs (1 to 6) Expanded I/O (7 to 8) Output Initiate...
Page 355: Appendix A Configuration Record Forms
Appendix – A Configuration Record Forms This Appendix contains forms for photocopying, and recording the configuration and setting of the M-3311A Transformer Protection Relay, and to file the data for future reference. Examples of the suggested use of these forms are illustrated in Chapter 4, System Setup and Setpoints and Chapter 2, Operation. Page A-2 contains a copy of the Relay Configuration Table and is herein provided to define and record the blocking inputs and output configuration for the relay.
Page 356 M‑3311A Instruction Book OUTPUTS BLOCKING INPUTS Function D 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 24 Def Time 24 Inv Time 46 Def Time W2...
Page 357 Appendix – A OUTPUTS BLOCKING INPUTS Function D 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 51G W2 51G W3 51G W4**...
Page 358: Figure A-1 System Communication Setup
M‑3311A Instruction Book System Communication Setup Communication Setup COM 1 Baud Rate: o 300 o 600 o 1200 o 2400 o 4800 o [9600] COM 2 Baud Rate: o 300 o 600 o 1200 o 2400 o 4800 o [9600] Dead Sync Time: _____ 2 msec –...
Page 359 Appendix – A Setup System – Two or Three Windings Nominal Voltage: _____ 60 V – 140 V [120] Nominal Current: _____ 0.50 A – 15.00 A [5.00] o ACB o [ABC] Phase Rotation o [15 Minutes] o 30 Minutes o 60 Minutes Demand Timing Method o W1 o W2 o W3 Current Summing 1...
Page 360 M‑3311A Instruction Book Setup System – Two or Three Windings (Cont.) Custom Selections: Transformer W1 Transformer W2 Transformer W3 o 0 Y o 0 Y o 0 Y o 1 Dac o 1 Dac o 1 Dac o 5 Inverse Dab o 5 Inverse Dab o 5 Inverse Dab o 6 Inverse Y...
Page 361 Appendix – A Setup System – Two or Three Windings (Cont.) Setup System – Two or Three Windings (Cont.) VT a Ratio: ________:1 1.0 – 6550.0 [1.0] VT Vx Ratio: ________:1 1.0 – 6550.0 [1.0] CT W1 Phase Ratio: ________:1 1 –...
Page 362 M‑3311A Instruction Book Setup System – Four Windings Nominal Voltage: _____ 60 V – 140 V [120] o [ACB] o ABC Phase Rotation Demand Timing Method o [15 Minutes] o 30 Minutes o 60 Minutes o [VAB] o VBC o VCA o VA o VB o VC VT Config.
Page 363 Appendix – A Setup System – Four Windings (Cont.) Custom Selections: Transformer W1 Transformer W2 Transformer W3 Transformer W4 o 0 (Y) o 0 Y o 0 Y o 0 Y o 1 Dac o 1 Dac o 1 Dac o 1 Dac o 5 (Inverse Dab) o 5 Inverse Dab...
Page 364: Figure A-3 Setup System (Four Windings
M‑3311A Instruction Book Setup System – Four Windings (Cont.) VT and CT Ratio VT Ratio: ________:1 1.0 – 6550.0 [1.0] VT Ground Ratio: ________:1 1.0 – 6550.0 [1.0] CT W1 Phase Ratio: ________:1 1 – 65500.0 [1.0] CT W2 Phase Ratio: ________:1 1 –...
Page 365 Appendix – A System Setpoints and Settings 24 – Volts/Hz Overexcitation o Disable o Enable Definite Time #1 Pickup: _____ 100 – 200 (%) Time Delay: _____ 30 – 8160 (Cycles) I/O Selection: Outputs o #1 o #2 o #3 o #4 o #5 o #6...
Page 366 M‑3311A Instruction Book System Setpoints and Settings (Cont.) 27 – Phase Undervoltage 27 #1 o Disable o Enable Pickup: _____ 5 – 140 (V) Time Delay: _____ 1 – 8160 (Cycles) Inhibit: _____ 5 – 140 (V) o Disable o Enable I/O Selection: Outputs o #1...
Page 367 Appendix – A System Setpoints and Settings (Cont.) 46 – Negative Sequence Overcurrent 46-W2 Definite Time o Disable o Enable Pickup: _____ 0.10 – 20.00 (A) Time Delay: _____ 1 – 8160 (Cycles) I/O Selection: Outputs o #1 o #2 o #3 o #4 o #5...
Page 368 M‑3311A Instruction Book System Setpoints and Settings (Cont.) 46 – Negative Sequence Overcurrent (Cont.) 46-W3 (Cont.) o Disable o Enable Inverse Time Pickup: _____ 0.50 – 5.00 (A) Time Dial: _____ 0.5 – 11.0 Inverse Time Curves: o BECO Definite Time o BECO Inverse o BECO Very Inverse o BECO Extremely Inverse...
Page 369 Appendix – A System Setpoints and Settings (Cont.) 46 – Negative Sequence Overcurrent (Cont.) 46-W4 (Cont.) (Not available in Two or Three Winding applications) Inverse Time Curves: o BECO Definite Time o BECO Inverse o BECO Very Inverse o BECO Extremely Inverse o IEC Inverse o IEC Very Inverse o IEC Extremely Inverse...
Page 370 M‑3311A Instruction Book System Setpoints and Settings (Cont.) 50 – Instantaneous Phase Overcurrent 50 – #1 o Disable o Enable Pickup: _____ 1.0 – 100.0 (A) Time Delay: _____ 1 – 8160 (Cycles) Current Selection: o Summing 1 o Summing 2 o Winding 1 o Winding 2 o Winding 3...
Page 371 Appendix – A System Setpoints and Settings (Cont.) 50 – Instantaneous Phase Overcurrent (Cont.) 50 – #4 o Disable o Enable Pickup: _____ 1.0 – 100.0 (A) Time Delay: _____ 1 – 8160 (Cycles) Current Selection: o Summing 1 o Summing 2 o Winding 1 o Winding 2 o Winding 3...
Page 372 M‑3311A Instruction Book System Setpoints and Settings (Cont.) 50 – Instantaneous Phase Overcurrent (Cont.) 50 – #7 o Disable o Enable (Not available in Two or Three Winding applications) Pickup: _____ 1.0 – 100.0 (A) Time Delay: _____ 1 – 8160 (Cycles) Current Selection: o Summing 1 o Summing 2...
Page 373 Appendix – A System Setpoints and Settings (Cont.) 50N – Instantaneous Residual Overcurrent 50N – #1 o Disable o Enable Pickup: _____ 1.0 – 100.0 (A) Time Delay: _____ 1 – 8160 (Cycles) Current Selection: o Summing 1 o Summing 2 o Winding 1 o Winding 2 o Winding 3...
Page 374 M‑3311A Instruction Book System Setpoints and Settings (Cont.) 50N – Instantaneous Residual Overcurrent (Cont.) 50N – #4 o Disable o Enable Pickup: _____ 1.0 – 100.0 (A) Time Delay: _____ 1 – 8160 (Cycles) Current Selection: o Summing 1 o Summing 2 o Winding 1 o Winding 2 o Winding 3...
Page 375 Appendix – A System Setpoints and Settings (Cont.) 50N – Instantaneous Residual Overcurrent (Cont.) 50N – #7 o Disable o Enable (Not available in Two or Three Winding applications) Pickup: _____ 1.0 – 100.0 (A) Time Delay: _____ 1 – 8160 (Cycles) Current Selection: o Summing 1 o Summing 2...
Page 376 M‑3311A Instruction Book System Setpoints and Settings (Cont.) 50G – Instantaneous Ground Overcurrent 50G-W2-#1 o Disable o Enable Pickup: _____ 1.0 – 100.0 (A) Time Delay: _____ 1 – 8160 (Cycles) I/O Selection: Outputs o #1 o #2 o #3 o #4 o #5 o #6...
Page 377 Appendix – A System Setpoints and Settings (Cont.) 50G – Instantaneous Ground Overcurrent (Cont.) 50G-W3-#2 o Disable o Enable Pickup: _____ 1.0 – 100.0 (A) Time Delay: _____ 1 – 8160 (Cycles) I/O Selection: Outputs o #1 o #2 o #3 o #4 o #5 o #6...
Page 378 M‑3311A Instruction Book System Setpoints and Settings (Cont.) 50BF – Breaker Failure 50BF-W1 o Disable o Enable Phase Pickup: _____ 0.10 – 10.00 (A) Residual Pickup: _____ 0.10 – 10.00 (A) Time Delay: _____ 1 – 8160 (Cycles) I/O Selection: Output Initiate o #1 o #2...
Page 379 Appendix – A System Setpoints and Settings (Cont.) 50BF-W3 o Disable o Enable Phase Pickup: _____ 0.10 – 10.00 (A) Residual Pickup: _____ 0.10 – 10.00 (A) Time Delay: _____ 1 – 8160 (Cycles) I/O Selection: Output Initiate o #1 o #2 o #3 o #4...
Page 380 M‑3311A Instruction Book System Setpoints and Settings (Cont.) 51 – Inverse Time Phase Overcurrent 51 – #1 o Disable o Enable Pickup: _____ 0.50 – 12.00 (A) Time Dial: _____ 0.5 – 11.0 Current Selection: o Summing 1 o Summing 2 o Winding 1 o Winding 2 o Winding 3...
Page 381 Appendix – A System Setpoints and Settings (Cont.) 51 – Inverse Time Phase Overcurrent (Cont.) 51 – #3 o Disable o Enable Pickup: _____ 0.50 – 12.00 (A) Time Dial: _____ 0.5 – 11.0 Current Selection: o Summing 1 o Summing 2 o Winding 1 o Winding 2 o Winding 3...
Page 382 M‑3311A Instruction Book System Setpoints and Settings (Cont.) 51N – Inverse Time Residual Overcurrent 51N – #1 o Disable o Enable Pickup: _____ 0.50 – 6.00 (A) Time Dial: _____ 0.5 – 11.0 Current Selection: o Summing 1 o Summing 2 o Winding 1 o Winding 2 o Winding 3...
Page 383 Appendix – A System Setpoints and Settings (Cont.) 51N – Inverse Time Residual Overcurrent (Cont.) 51N – #3 o Disable o Enable Pickup: _____ 0.50 – 6.00 (A) Time Dial: _____ 0.5 – 11.0 Current Selection: o Summing 1 o Summing 2 o Winding 1 o Winding 2 o Winding 3...
Page 384 M‑3311A Instruction Book System Setpoints and Settings (Cont.) 51G – Inverse Time Ground Overcurrent 51G – W2 o Disable o Enable Pickup: _____ 0.50 – 12.00 (A) Time Dial: _____ 0.5 – 11.0 Inverse Time Curves: o BECO Definite Time o BECO Inverse o BECO Very Inverse o BECO Extremely Inverse...
Page 385 Appendix – A System Setpoints and Settings (Cont.) 51G – Inverse Time Ground Overcurrent (Cont.) 51G – W4 o Disable o Enable (Not available in Two or Three Winding applications) Pickup: _____ 0.50 – 12.00 (A) Time Dial: _____ 0.5 – 11.0 Inverse Time Curves: o BECO Definite Time o BECO Inverse...
Page 386 M‑3311A Instruction Book System Setpoints and Settings (Cont.) 59 – Phase Overvoltage (Only available in Two or Three Winding applications) 59 – #1 o Disable o Enable Pickup: _____ 5 – 180 (V) Time Delay: _____ 1 – 8160 (Cycles) Input Voltage Select o Phase o Positive Sequence...
Page 387 Appendix – A System Setpoints and Settings (Cont.) 59G – Ground Overvoltage (Only available in four-winding applications) 59G – #1 o Disable o Enable Pickup: _____ 5 – 180 (V) Time Delay: _____ 1 – 8160 (Cycles) I/O Selection: Outputs o #1 o #2 o #3...
Page 388 M‑3311A Instruction Book System Setpoints and Settings (Cont.) 59G – Ground Overvoltage (Only available in Two or Three Winding applications) 59G – #1 o Disable o Enable Pickup: _____ 5 – 180 (V) Time Delay: _____ 1 – 8160 (Cycles) I/O Selection: Outputs o #1...
Page 389 Appendix – A System Setpoints and Settings (Cont.) 81 – Over/Under Frequency 81 – #1 o Disable o Enable Pickup: _____ 55.00 – 65.00 (Hz) Time Delay: _____ 2 – 65500 (Cycles) I/O Selection: Outputs o #1 o #2 o #3 o #4 o #5 o #6...
Page 390 M‑3311A Instruction Book System Setpoints and Settings (Cont.) 87 – Phase Differential Current 87T o Disable o Enable Pickup: _____ 0.10 – 1.00 (PU) Percent Slope #1: _____ 5 – 100 (%) Percent Slope #2: _____ 5 – 200 (%) Slope Break Point: _____ 1.0 –...
Page 391 Appendix – A System Setpoints and Settings (Cont.) 87GD – Ground Differential 87GD-W2-#1 o Disable o Enable Pickup: _____ 0.20 – 10.0 (A) Time Delay: _____ 1 – 8160 (Cycles) I/O Selection: Outputs o #1 o #2 o #3 o #4 o #5 o #6 o #7...
Page 392 M‑3311A Instruction Book System Setpoints and Settings (Cont.) 87GD – Ground Differential (Cont.) 87GD-W3-#1 o Disable o Enable Pickup: _____ 0.20 – 10.0 (A) Time Delay: _____ 1 – 8160 (Cycles) I/O Selection: Outputs o #1 o #2 o #3 o #4 o #5 o #6...
Page 393 Appendix – A System Setpoints and Settings (Cont.) 87GD – Ground Differential (Cont.) 87GD-W4-#1 o Disable o Enable (Not available in Two or Three Winding applications) Pickup: _____ 0.20 – 10.0 (A) Time Delay: _____ 1 – 8160 (Cycles) I/O Selection: Outputs o #1 o #2...
Page 394 M‑3311A Instruction Book System Setpoints and Settings (Cont.) IPSlogic #1 o Disable o Enable Initiating Outputs: o #1 o #2 o #3 o #4 o #5 o #6 o #7 o #8 o #9 o #10 o #11 o #12 o #13 o #14 o #15 o #16 Initiating Outputs Logic Gate:...
Page 395 Appendix – A System Setpoints and Settings (Cont.) IPSlogic #2 o Disable o Enable Initiating Outputs: o #1 o #2 o #3 o #4 o #5 o #6 o #7 o #8 o #9 o #10 o #11 o #12 o #13 o #14 o #15 o #16 Initiating Outputs Logic Gate:...
Page 396 M‑3311A Instruction Book System Setpoints and Settings (Cont.) IPSlogic #3 o Disable o Enable Initiating Outputs: o #1 o #2 o #3 o #4 o #5 o #6 o #7 o #8 o #9 o #10 o #11 o #12 o #13 o #14 o #15 o #16 Initiating Outputs Logic Gate:...
Page 397 Appendix – A System Setpoints and Settings (Cont.) IPSlogic #4 o Disable o Enable Initiating Outputs: o #1 o #2 o #3 o #4 o #5 o #6 o #7 o #8 o #9 o #10 o #11 o #12 o #13 o #14 o #15 o #16 Initiating Outputs Logic Gate:...
Page 398 M‑3311A Instruction Book System Setpoints and Settings (Cont.) IPSlogic #5 o Disable o Enable Initiating Outputs: o #1 o #2 o #3 o #4 o #5 o #6 o #7 o #8 o #9 o #10 o #11 o #12 o #13 o #14 o #15 o #16 Initiating Outputs Logic Gate:...
Page 399 Appendix – A System Setpoints and Settings (Cont.) IPSlogic #6 o Disable o Enable Initiating Outputs: o #1 o #2 o #3 o #4 o #5 o #6 o #7 o #8 o #9 o #10 o #11 o #12 o #13 o #14 o #15 o #16 Initiating Outputs Logic Gate:...
Page 400 M‑3311A Instruction Book System Setpoints and Settings (Cont.) BM – Breaker Monitor BM–W1 o Disable o Enable Pickup: _____ 1 – 50000 (kA Cycles) Time Delay: _____ 0.1 – 4095.9 (Cycles) Timing Method Selection o IT o I^2T Preset Accumulator Phase A: _____ 0 – 50000 (kA Cycles) Preset Accumulator Phase B: _____ 0 –...
Page 401 Appendix – A System Setpoints and Settings (Cont.) BM – Breaker Monitor (Cont.) BM–W3 o Disable o Enable Pickup: _____ 1 – 50000 (kA Cycles) Time Delay: _____ 0.1 – 4095.9 (Cycles) Timing Method Selection o IT o I^2T Preset Accumulator Phase A: _____ 0 – 50000 (kA Cycles) Preset Accumulator Phase B: _____ 0 –...
Page 402 M‑3311A Instruction Book System Setpoints and Settings (Cont.) TCM #1 – Trip Circuit Monitor o Disable o Enable Delay: _____ 1 – 8160 (Cycles) Dropout Time Delay: _____ 1 – 8160 (Cycles) I/O Selection: Outputs o #1 o #2 o #3 o #4 o #5 o #6...
Page 403: Figure A-4 System Setpoints And Settings
Appendix – A System Setpoints and Settings (Cont.) TF – Through Fault o Disable o Enable Through Fault Current Threshold: _____ 1.0 – 100.0 (A) Through Fault Current Time Delay: _____ 1 – 8160 (Cycles) Pickup Operation limit: _____ 1 – 65535 Cumulative I^2T Limit: _____ 1 –...
Page 404 M‑3311A Instruction Book This Page Left Intentionally Blank A–50...
Page 405: Appendix B Communications
Appendix – B Communications The M-3311A Transformer Protection Relay incorporates three serial ports for intelligent, digital communication with external devices. Equipment such as RTUs, data concentrators, modem, or computers can be interfaced for direct, on-line real time data acquisition and control. Generally, all data available to the operator through the front panel of the relay with the HMI is also accessible remotely through the BECO 2200 data exchange protocol.
Page 406: M-3311 Slave Address
M‑3311A Instruction Book M-3311 Slave Address DNP3 Slave IED address range is from 0 to 65519. Address 65535 (hex FFFF) is used to broadcast messages to all devices. The communication address can be set through the HMI (front panel; optional). The DNP3 device profile document, including the point list, is available from the factory or our website, www.beckwithelectric.com.
Page 407: Figure B-1 Null Modem Cable For M-3311A
Appendix – B Circuit Signal COM 1 COM 2 Receive Data Pin 2 Pin 2 Transmit Data Pin 3 Pin 3 Request to Send Pin 7 Pin 7 Clear to Send Pin 8 Data Terminal Ready Pin 4 Pin 4 Data Carrier Detect Pin 1 Signal Ground...
Page 408: Figure B-2 Rs-232 Fiber Optic Network
M‑3311A Instruction Book PC Master IPScom running in “Echo Cancel” mode 25 pin or 9-25 pin Straight-through Cable DYMEC Fiber Optic Link/Repeater D C E D T E Fiber Optic Cable Slave #1 Slave #2 Slave #3 Address 1 Address 2 Address 3 RS-232 RS-232...
Page 409: Figure B-3 Rs-485 Network
Appendix – B RS‑485 2‑Wire Network Slave #1 Slave #2 Slave #3 Address 1 Address 6 Address 8 ‑ + ‑ + PC Master 200 Ω* B(‑) A(+) Twisted RS‑232 to RS‑485 2‑wire converter or RS‑485 PC Card Due to the possibility of ground potential difference between units, all units should CAUTION: ▲...
Page 410 M‑3311A Instruction Book This Page Left Intentionally Blank B–6...
Page 411: Self-Test Error Codes
Appendix – C Self-Test Error Codes Self-Test Error Codes and Corrective Actions When power is initially applied, the relay performs a number of self-tests to ensure proper operation. If any test should fail, the error code will be displayed on the HMI. Some self-test errors may be "HALT" errors, which will will not allow operation to proceed and the protective function of the relay is disabled.
Page 412 M‑3311A Instruction Book ERROR HALT? Error Code Name and Description Type CODE EEPROM write setpoint checksum fail loss of power – Non Volatile settings storage error EEPROM write setpoint checksum fail loss of battery backed RAM – Non Volatile settings storage error DMA checksum/physical block fail –...
Page 413 Appendix – C ERROR HALT? Error Code Name and Description Type CODE Supply/mux PGA running test fail – Possible noisy Data Acquisition circuitry External DSP RAM test fail – Possible Memory error Unrecognized INT1 code – Possible internal Communication if count ≥ 4 error between two processors Values update watchdog fail –...
Page 414 M‑3311A Instruction Book ERROR HALT? Error Code Name and Description Type CODE Unable to calibrate input (phase) – If this error is obtained during calibration procedures, check relay connections with signal generating equipment and signals amplitude and phase magnitudes and repeat calibration procedures after reboot. If this error is obtained without calibration procedures being performed, contact Beckwith Electric without rebooting the relay if possible.
Page 415: Inverse Time Curves
Appendix – D Inverse Time Curves This Appendix contains three sets of Inverse Time Curve Families. The first set is used for Volts per Hertz functions (Figure D-1 through Figure D-4), the second set is for the M-3311A functions which utilize the IEC time over current curves (Figure D-5 through...
Page 416: Figure D-1 Volts/Hz (24It) Inverse Time Curve Family #1 (Inverse Square
M‑3311A Instruction Book Figure D-1 Volts/Hz (24IT) Inverse Time Curve Family #1 (Inverse Square) D–2...
Page 417: Figure D-2 Volts/Hz (24It) Inverse Time Curve Family #2
Appendix – D Figure D-2 Volts/Hz (24IT) Inverse Time Curve Family #2 D–3...
Page 418: Figure D-3 Volts/Hz (24It) Inverse Time Curve Family #3
M‑3311A Instruction Book Figure D-3 Volts/Hz (24IT) Inverse Time Curve Family #3 D–4...
Page 419: Figure D-4 Volts/Hz (24It) Inverse Time Curve Family #4
Appendix – D Figure D-4 Volts/Hz (24IT) Inverse Time Curve Family #4 D–5...
Page 420 M‑3311A Instruction Book Multiple of Tap Setting Definite Time Inverse Time Very Inverse Time Extremely Inverse Time 1.50 0.69899 4.53954 3.46578 4.83520 1.55 0.64862 4.15533 3.11203 4.28747 1.60 0.60539 3.81903 2.81228 3.83562 1.65 0.56803 3.52265 2.55654 3.45706 1.70 0.53558 3.25987 2.33607 3.13573 1.75...
Page 421 Appendix – D Multiple of Tap Setting Definite Time Inverse Time Very Inverse Time Extremely Inverse Time 5.20 0.23029 0.39078 0.23269 0.24343 5.40 0.22834 0.37495 0.22254 0.22660 5.60 0.22684 0.36102 0.21394 0.21151 5.80 0.22583 0.34884 0.20673 0.19793 6.00 0.22534 0.33828 0.20081 0.18567 6.20...
Page 422: Figure D-5 Definite Time Overcurrent Curve
M‑3311A Instruction Book Figure D-5 Definite Time Overcurrent Curve D–8...
Page 423: Figure D-6 Inverse Time Overcurrent Curve
Appendix – D Figure D-6 Inverse Time Overcurrent Curve D–9...
Page 424: Figure D-7 Very Inverse Time Overcurrent Curve
M‑3311A Instruction Book Figure D-7 Very Inverse Time Overcurrent Curve D–10...
Page 425: Figure D-8 Extremely Inverse Time Overcurrent Curve
Appendix – D Figure D-8 Extremely Inverse Time Overcurrent Curve D–11...
Page 426: Figure D-9 Iec Curve #1 Inverse
M‑3311A Instruction Book 0.01 10 11 12 13 14 15 16 17 18 19 20 IEC Class B Multiple of Pickup IEC Class A Very Inverse Standard Inverse 0.14 13.5 t=TD x t=TD x 0.02 M - 1 Curve 5 Curve 6 Figure D-9 IEC Curve #1 Inverse D–12...
Page 427: Figure D-10 Iec Curve #2 Very Inverse
Appendix – D 0.01 10 11 12 13 14 15 16 17 18 19 20 IEC Class B IEC Class C IEC Class A Multiple of Pickup Very Inverse Extremely Inverse Standard Inverse 0.14 13.5 t=TD x t=TD x t=TD x 0.02 M - 1 Curve 5...
Page 428: Figure D-11 Iec Curve #3 Extremely Inverse
M‑3311A Instruction Book 0.01 11 12 13 14 15 16 17 18 19 IEC Class B IEC Class C IEC Class D Multiple of Pickup Very Inverse Extremely Inverse Long Time Inverse 13.5 t=TD x t=TD x t=TD x M - 1 M - 1 Curve 7 Curve 6...
Page 429: Figure D-12 Iec Curve #4 Long-Time Inverse
Appendix – D 1000 IEC Class C IEC Class D Extremely Inverse Long Time Inverse Multiple of Pickup t=TD x t=TD x M - 1 Curve 7 Curve 8 Figure D-12 IEC Curve #4 Long-Time Inverse D–15...
Page 430: Figure D-13 Ieee (Moderately) Inverse Time Overcurrent Curves
M‑3311A Instruction Book 0.01 Current in Multiples of Pickup Figure D-13 IEEE (Moderately) Inverse Time Overcurrent Curves D–16...
Page 431: Figure D-14 Ieee Very Inverse Time Overcurrent Curves
Appendix – D 0.01 Current in Multiples of Pickup Figure D-14 IEEE Very Inverse Time Overcurrent Curves D–17...
Page 432: Figure D-15 Ieee Extremely Inverse Time Overcurrent Curves
M‑3311A Instruction Book 0.01 Multiple of Pickup Figure D-15 IEEE Extremely Inverse Time Overcurrent Curves D–18...
Page 433: Appendix E Layup And Storage
Appendix – E Layup and Storage Appendix E includes the recommended storage parameters, periodic surveillance activities and layup configuration for the M-3311A Transformer Protection Relay Storage Requirements (Environment) The recommended storage environment parameters for the M-3311A are: • The ambient temperature where the M-3311A is stored is within a range of 5° C to 40° C •...
Page 434 M‑3311A Instruction Book 9. Press ENTER. Unit will now reset and DIAGNOSTIC MODE will be temporarily displayed, followed by OUTPUT TEST (RELAY). This is the beginning of the diagnostic menu. 10. Press the right arrow pushbutton until the following is displayed: CLOCK TEST ...
Page 435: Appendix F Hmi Menu Flow
Appendix – F HMI Menu Flow HMI Menu Overview ....................F–2 Figure F-1 Human-Machine Interface Module ............ F–2 Figure F-2 HMI Menu Flow Overview ..............F–3 HMI Menu Flow ......................F–4 Figure F-3 Voltage Relay Menu Flow ..............F–4 Figure F-4 Current Relay Menu Flow ..............F–5 Figure F-5 Frequency Relay, Volts Per Hertz Relay and IPS Logic Menu Flow ..
Page 436: Hmi Menu Overview
M‑3311A Instruction Book HMI Menu Overview Appendix F illustrates the Human Machine Interface (HMI) menu flow that is presented on the Human‑Machine interface module. Key to Input Data 1. All heavily bordered screens are either MENU screens which have horizontal choices (made with right ‑...
Page 437: Figure F-2 Hmi Menu Flow Overview
Appendix – F Figure F-2 HMI Menu Flow Overview F–3...
Page 438: Hmi Menu Flow
M‑3311A Instruction Book HMI Menu Flow Figure F-3 Voltage Relay Menu Flow F–4...
Page 439: Figure F-4 Current Relay Menu Flow
Appendix – F Figure F-4 Current Relay Menu Flow (1 of 2) F–5...
Page 440 M‑3311A Instruction Book Figure F-4 Current Relay Menu Flow (2 of 2) F–6...
Page 441: Figure F-5 Frequency Relay, Volts Per Hertz Relay And Ips Logic Menu Flow
Appendix – F Figure F-5 Frequency Relay, Volts Per Hertz Relay and IPS Logic Menu Flow F–7...
Page 442: Figure F-6 Breaker Monitoring, Through Fault Monitoring And Trip Circuit Monitoring Menu Flow
M‑3311A Instruction Book Figure F-6 Breaker Monitoring, Through Fault Monitoring and Trip Circuit Monitoring Menu Flow F–8...
Page 443: Figure F-7 Configure Relay/Voltage Relay Menu Flow
Appendix – F Figure F-7 Configure Relay/Voltage Relay Menu Flow (1 of 3) F–9...
Page 444 M‑3311A Instruction Book Figure F-7 Configure Relay/Voltage Relay Menu Flow (2 of 3) F–10...
Page 445 Appendix – F Figure F‑7 Configure Relay/Voltage Relay Menu Flow (3 of 3) F–11...
Page 446: Figure F-8 Two-/Three-Winding Setup System Menu Flow
M‑3311A Instruction Book Figure F-8 Two-/Three-Winding Setup System Menu Flow (1 of 3) F–12...
Page 447 Appendix – F Figure F-8 Two-/Three-Winding Setup System Menu Flow (2 of 3) F–13...
Page 448 M‑3311A Instruction Book Figure F-8 Two-/Three-Winding Setup System Menu Flow (3 of 3) F–14...
Page 449: Figure F-9 Four-Winding Setup System Menu Flow
Appendix – F Figure F-9 Four-Winding Setup System Menu Flow (1 of 3) F–15...
Page 450 M‑3311A Instruction Book Figure F-9 Four-Winding Setup System Menu Flow (2 of 3) F–16...
Page 451 Appendix – F Figure F-9 Four-Winding Setup System Menu Flow (3 of 3) F–17...
Page 452: Figure F-10 Relay Status Menu Flow
M‑3311A Instruction Book Figure F-10 Relay Status Menu Flow (1 of 2) F–18...
Page 453 Appendix – F Figure F-10 Relay Status Menu Flow (2 of 2) F–19...
Page 454: Figure F-11 Relay Demand Menu Flow
M‑3311A Instruction Book Figure F-11 Relay Demand Menu Flow F–20...
Page 455: Figure F-12 View Target History And Oscillograph Recorder Menu Flow
Appendix – F Figure F-12 View Target History and Oscillograph Recorder Menu Flow F–21...
Page 456: Figure F-13 Relay Communication Menu Flow
M‑3311A Instruction Book Figure F-13 Relay Communication Menu Flow (1 of 2) F–22...
Page 457 Appendix – F Figure F-13 Relay Communication Menu Flow (2 of 2) F–23...
Page 458: Figure F-14 Relay Setup Menu Flow
M‑3311A Instruction Book Figure F-14 Relay Setup Menu Flow (1 of 4) F–24...
Page 459 Appendix – F Figure F-14 Relay Setup Menu Flow (2 of 4) F–25...
Page 460 M‑3311A Instruction Book Figure F-14 Relay Setup Menu Flow (3 of 4) F–26...
Page 461 Appendix – F Figure F-14 Relay Setup Menu Flow (4 of 4) F–27...
Page 462 M‑3311A Instruction Book This Page Left Intentionally Blank F–28...
Page 463: Appendix H Declaration Of Conformity
Appendix – H Declaration of Conformity DECLARATION OF CONFORMITY (In accordance to BS EN ISO/IEC 17050-1:2010) Manufacturer’s Name: Beckwith Electric No. M-3311A 6190 118th Avenue North Manufacturer’s Address: Largo, FL 33773-3724 The manufacturer hereby declares under our sole responsibility that the M-3311A relay product conforms to the following EMC product standard as of September 9 , 2014 in accordance to Directive 2014/30/EU for equipment incorporated into stationary fixed installations:...
Page 464 M‑3311A Instruction Book Short duration AC/DC Voltage interruptions 0% residual (AC) 5 cycles, (DC) 30ms 40% residual (AC) 5 cycles, (DC) 30ms 70% residual (AC) 30 cycles, (DC) 30ms IEC 61000-4-11:2010 Environmental: IEC 60255-27:2013 Pollution Degree 2 IEC 60068-2-1:2007 Cold, -20°C IEC 60068-2-2:2007 Dry Heat, +70°C IEC 60068-2-78:2012 Damp Heat, +40°C @ 95%rh IEC 60068-2-30:2005 Damp Heat condensing cycle +25°C, +55°C @ 95%rh...
Page 465 Appendix – G Index NUMERICAL 24 Volts/Hz Overexcitation, SP-1, 4-56, 4-59, A-11 Alarm Counters, 2-30:2-32, 3-37 27 Phase Undervoltage, SP-1, 4-56, 4-60:4-61, Alphanumeric Display, 1-2, 2-2:2-3, 2-16, 6-8 6-1, 6-30, A-12 Alter Access Codes, 2-6, 2-27:2-28, 4-5:4-6 46 Negative Sequence Overcurrent, 4-62:4-63, Alter User Access Codes, 2-28 A-13:A-15 Arrow Pushbuttons, 2-2, 2-28, 4-3, 4-5, 4-7:4-10,...
Page 466 M‑3311A Instruction Book Clear, 2-13:2-15, 2-17:2-19, 2-22:2-23, 2-25, CT Configuration, 4-36, 4-42, 4-106, 4-109:4-112 2-30:2-36, 3-28:3-30, 3-32, 3-37, 4-28, CT Tap Setting Calculation Example, 4-84 4-31:4-32, 6-57, B-2 CT Tap Settings, 4-84, 6-49, 6-51 Clear Alarm Counters, 2-31 CT Tap Settings For W1, 4-84 Clear Error Codes, 2-32:2-33, 4-32 Custom Connections, 4-109 Clear Output Counters, 2-30...
Page 467 Appendix – G HMI User Access Codes Setup, 4-5 HMI User Control Number Setup, 4-8 F87T, 3-15 HMI User Logo Line Setup, 4-7 Factory Use Only, 6-12 Hz Overexcitation, SP-1, 4-56, 4-59, 6-1, File, SP-10, 2-19, 2-23:2-25, 2-34:2-35, 3-1, 6-28:6-29, A-11 3-3:3-4, 3-18, 3-28, 3-30, 3-32, 3-34, 3-40, 4-24, 4-27, 4-29, 4-90, 4-92, 5-42, A-1 File Menu, 3-3...
Page 468 M‑3311A Instruction Book IPSplot, SP-2, SP-10, SP-13, 1-3:1-4, 2-19, 3-32, 4-24 Open Command, 3-3 IPSplot Plus Oscillograph Analysis Software, SP-2, SP-10, SP-13, 1-3:1-4, 3-32 Open Terminal Window, 3-7 IRIG-B, SP-2, SP-12:SP-14, 1-3, 3-23, 4-13, 4-17 Optional Features, SP-2 Optional Voltage Protection Package, SP-2, SP-10, 4-56 OSC, SP-12, 2-7, 2-9, 2-17:2-19, 2-22, 2-25, 3-8, Key, 2-2, 2-15, 2-31:2-33, 4-10, 6-3, 6-8, 6-10,...
Page 469 Appendix – G Serial Number, SP-11, 1-2, 2-26:2-27, 3-29, 4-29, 5-44, 6-27 Read Data From Relay, 3-18, 3-34 Serial Port, SP-2, 2-4, 3-1, 3-5, 4-13, 4-17, 4-21, 4-23, 5-43, B-1 Recommended Storage Parameters, SP-16, 1-2, Set Date, 3-18, 3-23, 4-11 Recycling, SP-16 Setpoint Profiles, SP-10, 4-55:4-56, 5-44 Redundant High Voltage Power Supply, 1-4...
Page 470 M‑3311A Instruction Book Underfrequency, SP-2, 4-60, 4-78:4-79, 6-1, 6-48 Target, SP-11:SP-13, 1-3:1-4, 2-3:2-4, 2-6, 2-16:2-19, 2-28:2-29, 2-33:2-35, 3-5, 3-28, Unit Isolation, 5-8 3-35, 4-2, 4-4, 4-6, 4-10:4-11, 4-14, 4-18, 4-27, User Control Number, 3-36, 4-1, 4-6, 4-8:4-9 4-29:4-30, 4-35, 4-41, 4-89:4-92, 4-95, 5-43, 6-3, User Information, 3-36, 4-6 6-5:6-8, 6-28:6-31, 6-34, 6-36:6-43, 6-45:6-55, User Logo Line, 3-36, 4-6:4-8...
Page 471 The Seller shall not be liable for any property The units described in this manual are covered by damages whatsoever or for any loss or damage U.S. Patents, with other patents pending. arising out of, connected with, or resulting from this Buyer shall hold harmless and indemnify the Seller, contract, or from the performance or breach thereof, its directors, officers, agents, and employees from...
Page 472 This Page Left Intentionally Blank...
Page 474 6190 118th Avenue North • Largo, Florida 33773-3724 U.S.A. 6190 118th Avenue North • Largo, Florida 33773-3724 U.S.A. PHONE (727) 544-2326 PHONE (727) 544-2326 beckwithelectricsupport beckwithelectricsupport hubbell.com hubbell.com www.beckwithelectric.com www.beckwithelectric.com ISO 9001:2015 ISO 9001:2015 © 2007 Beckwith Electric. All Rights Reserved.

Hubbell BECKWITH ELECTRIC M-3311A Instruction Book

Quick Links

Need help?

Questions and answers

Related Manuals for Hubbell BECKWITH ELECTRIC M-3311A

Summary of Contents for Hubbell BECKWITH ELECTRIC M-3311A
