  • Page 1 AX’R CONTROL MANUAL NIRR017-S - 03-2019...

  • Page 3: Table Of Contents

    CONTENTS Supervision and control The program The HMI terminal 1.2.1 Using the HMI terminal keys The room terminal (option) 1.3.1 Controls 1.3.2 Displays 1.3.3 Room terminal information, settings and browsing 1.3.4 Electrical connections The controller Description of the air handling units Temperature regulation functional analysis Management of fire faults Frost protection...
  • Page 4 Communication menu 2.10 Alarms menu 2.11 Access level menu 2.12 Versions menu Managing a network of controllers pLAN electrical connections 3.1.1 Connecting controllers to the pLAN 3.1.2 Connecting a remote screen to the pLAN Addressing the pLAN Changing the controller address 3.3.1 Addressing the HMI terminals 3.3.2...

  • Page 5: Supervision And Control

    Supervision and control The program This air handling unit is managed by its PLC. In addition to its control functions, it also monitors and detects any faults with the air handling unit. The HMI terminal displays the following data which can be edited at any time: Values of connected sensors Unit on/off cycles Calibration of the sensors...

  • Page 6: Using The Hmi Terminal Keys

    1.2.1 Using the HMI terminal keys Description Returns to the main Menu mask when pressed in any loop. The Menu loop displays the state of the unit. Provides access to the "Menu" The red button is used to display alarms and confirm acknowledgeable faults. It lights up when an alarm is triggered.

  • Page 7: The Room Terminal (Option)

    The room terminal (option) The terminal supplied is equipped with a digital display, 4 buttons and a rotary encoder. Once installed in the premises, the device can measure the ambient temperature and enables remote control of the air handling unit. 1.3.1 Controls Button not used...

  • Page 8: Displays

    1.3.2 Displays Unit operating mode Main display area Ventilation operating mode Ventilation operating speed Temperature unit Indicates whether the value displayed in the main area is a setpoint Operating icons Secondary display area Indicates if a 2-hour time program derogation is in progress Details: Unit operating mode : Unit in heating mode...

  • Page 9: Room Terminal Information, Settings And Browsing 7 En

    1.3.3 Room terminal information, settings and browsing The diagram below shows the various browsing, information and setting options on the room terminal: Terminal energising A few seconds (2-3s) u1.3 Terminal initialising A few seconds (2-3s) Press Communication fault Unit on with the controller or Unit off (default...

  • Page 10: Electrical Connections

    1.3.4 Electrical connections Room terminal Controller The room terminal and the controller are electrically connected using an AWG20/22 shielded cable (not supplied) comprising two twisted pairs. The first and last controller must be no more than 500m apart. This network must never run parallel to power cables at a distance of less than 50 cm.

  • Page 11: Description Of The Air Handling Units

    1. power supply connector [G(+), G0(-)] 2. Yellow power LED and red alarm LED 3. additional power supply for terminal and 0-5 V ratiometric sensors 4. NTC, 0-5V, 0-10V universal analogue inputs 5. NTC passive analogue inputs 6. 0-10 V analogue outputs 7.

  • Page 12: Managing Night Cooling

    Managing night cooling Several conditions must be met to activate night cooling: Time range OR override via CMS. Cooling requirement: The return air temperature must be above the cool night temperature setpoint (screen w7). The free-cooling difference (screen p17) must be sufficient: Treturn air – Tfresh air = 3°C (factory value). The outdoor temperature must be above the "temperature low limit"...

  • Page 13: 1.13 Controller Inputs And Outputs

    Restart Automatic start-up after power loss. 1.13 Controller inputs and outputs This description concerns units in standard position. The assignment of sensors B1 to B9 depends on the type of unit (see paragraph 1.13.1, page 15) Connector J1 24Vac Shared Connector J2 Pressure sensor B1 for return air (supply) filter fouling level The pressure sensor monitors the level of blockage in the filter.
  • Page 14 Connector J5 Fire sensor If a fire fault is detected, the unit is shut off and the fault is signalled (+ LED) Supply air fan monitoring Feedback from the supply air fan alarms is used to monitor the overload protection system on the motor's electronic commutator.
  • Page 15 Connector J7 Remote control or Presence detection Enables the unit to be remotely controlled or switched off if it is in On mode on the main screen. If a presence is detected, the air handling unit will automatically switch to Comfort flow rate or to nominal Intake pressure, and Comfort temperature.
  • Page 16 Connector J17 NO12 Coil 1 pump control Shared NC12 ---------- Connector J18 NO13 Coil 2 pump control Shared NC13 ---------- Connector J19 ID15 ---------- ID16 ---------- Connector J20 Coil 2 valve control (hot water, cold water or Pre-heating triac) ---------- Return temperature sensor The temperature of the air extracted from the room can be regulated based on the setpoint (if selected) 20 seconds after the fans are turned on.

  • Page 17: Reversal Depending On The Unit Type

    Connector J23 Not used 1.13.1 Reversal depending on the unit type Rotary Plate Plate Plate Unit type Standard position Standard position Vertical position Ceiling position Supply air temp. J3-B4 J3-B4 J3-B4 J3-B5 sensor Return air temp. J20-B9 J3-B5 J3-B5 J3-B4 sensor Fresh air temp.

  • Page 18: Overview Of The Screens

    Overview of the screens Menu or Esc button "Prg" button U :01 00:00 00.0°c U:00 Indicates the unit's address Indicates the request to switch the machine on or off Indicates the presence of an hourly or annual time schedule and the request status and flashes if derogation by Th-Tune 00.0°C Indicates the regulated temperature (ambient, return or supply air)

  • Page 19: Setpoint Menu

    Level 3: Manufacturer Setpoint menu Comfort Indication of the operating mode. Level 2 access Fan flow rate Supply air 01000m3/h Comfort (or maximum) flow regulation setpoint for the supply air fan Return air 01000m3/h Comfort (or maximum) flow regulation setpoint for the return air fan Degraded 01000m3/h Fan downgraded flow control setpoint Supply air...

  • Page 20: Supply Air T° Setpoint Calculation In "Energy Optimisation" Mode

    2.2.2 Supply air T° setpoint calculation in "Energy optimisation" mode Machine parameters, screen c4 Return air or room temp. control Heating p2 differential Cooling authorised Fig. 3 authorised Deadband Return T° Ambient T° Heating Cooling Setpoint Setpoint Comfort: 23°C Comfort: 25°C Eco: 18°C Eco: 27°C Neutral zone (if neutral zone compensation = with):...
  • Page 21 Cooling: Fig. 5 Cooling requirement (%) °C Supply air temp. band neutral Cooling Cooling Air supply Comfort: 16°C Eco: 18°C Level 2 access Air quality 0800ppm Air quality regulation setpoint Maximum flow rate 1000m3/h Maximum flow rate value of supply air fan for air quality control (see Fig.
  • Page 22 Level 2 access Cool night 17.0°c Control setpoint in mode "Night cooling" mode (0 to 50.0°C) Supply air 02000m3/h Supply air fan flow regulation setpoint for night cooling Return air 02000m3/h Return air fan flow regulation setpoint for night cooling Level 3 access HEX bypass -04.0°C...

  • Page 23: Machine Parameters Menu

    Machine parameters menu This menu is Level 3 access Fault type Level 2 access. This screen is used to configure the criticality of the faults managed by the regulating controller. M=Maintenance D=Danger If a fault is shown as "Danger" the unit will be shut off. If the fault is shown as "Maintenance", only an alarm message will be given.
  • Page 24 Configuration Level 3 access Type -------- Orientation ---- Type: Classic 10 (plate heat exchanger) Classic 20 (plate heat exchanger) Classic 30 (plate heat exchanger) Classic 40 (plate heat exchanger) Classic 50 (plate heat exchanger) Classic 60 (plate heat exchanger) Classic 10 RHE (rotary heat exchanger) Classic 15 RHE (rotary heat exchanger) Classic 20 RHE (rotary heat exchanger) Classic 25R RHE (rotary heat exchanger)
  • Page 25 Configuration Level 3 access Supp. air filter coef. Return air filter coef. Supp. air filter coef.: Supply air filter coefficient as per selection table Return air filter coef.: Supply air filter coefficient as per selection table Selection table: Single filtration min.
  • Page 26 Configuration Level 3 access Coil 1 Coil 2 Electric heater Coil 1: Without: No coil Cold in duct: Cold water coil installed in Supply air duct Hot in duct: Hot water coil installed in Supply air duct Internal cold: Cold water coil built into air handling unit Internal hot: Hot water coil built into air handling unit Internal mixed: Cold or hot water coil (with Changeover thermostat) built into the air handling unit Mixed in duct: Cold or hot water coil (with Changeover thermostat) installed in the Supply air duct...
  • Page 27 Configuration Level 3 access IR detector ---- th-Tune ---- Level 2 access Control priority ,NZ compensation -- IR detector: Without, With th-Tune: Without, With Control priority: Precision or Energy optimisation mode (Only available if Regulated T° (p4) = Ambient or Return air. If Regulated T°...

  • Page 28: Adjustment Parameters Menu

    Adjustment parameters menu Level 1 access Language ------------ Controller language selection (French, English, German, Spanish, Italian, Dutch) Setting Level 1 access the clock Time -- :-- Clock time correction value Date --/--/-- Clock date correction value Supply air * Level 2 access CLG band 0005.0 Proportional band for monitored temperature regulation in cooling mode...

  • Page 29: Regulated T° Compensation Based On The Outdoor T

    Duct P sensor: 0-10V: Sensor physically wired to the controller com: Pressure value via the CMS Compensated Qv: Without, With (Fan flow rate compensation as per Fig. 7, page 28) Compensated T°: Without, With (Regulated temperature compensation as per Fig. 6, page 27) Free Cooling: Without, With Fire: Without, With Level 2 access...

  • Page 30: Fan Flow Rate Compensation Based On Outdoor T

    2.4.2 Fan flow rate compensation based on outdoor T° Values used if compensated Qv = with (menu p3) Level 2 access 030% E -20.0°c 100% F 10.0°c 030% K -20.0°c 100% L 10.0°c Comfort flow rate Fig. 7 100% Outdoor T° 2.4.3 Duct pressure compensation based on the outdoor T°...

  • Page 31: Fan Flow Rate Compensation Based On The Regulated T

    2.4.4 Fan flow rate compensation based on the regulated T° Values used if Fan management = Qv/Tregul, prop (menu p3) Level 2 access G -04.0°c H -02.0°c I 02.0°c J 04.0°c Reduced 030% M 04.0°c N 06.0°c Fig. 9 Comfort flow rate 100% Reduce Regulated T°...
  • Page 32 "Morning heating" function used in a timed program (Level 2 access) Mixing opening in "Morning heating" mode 095% Opening value of mixing damper in "Morning heating" mode "ECO recycling" function used in a timed program (Level 2 access) Mixing opening in "ECO Recirculation"...
  • Page 33 Supply air Level 3 access Duct band 0595Pa Supply air duct pressure control proportional band Duct IT 0004s Supply air duct pressure control integration time Duct DT 0001s Supply air duct pressure control derivative time Return air Cst band press. 1200m3/h Return air fan proportional band in duct pressure operation Cst pressure IT...
  • Page 34 Calibration Level 3 access Return air 00.0°c Calibration of the return air or fresh air temperature sensor Supply air 00.0°c Calibration of the supply air temperature sensor Fresh air 00.0°c Calibration of the fresh air or return air temperature sensor Air quality 0000ppm Calibration of air quality sensor Duct...

  • Page 35: Read-Only Parameters Menu

    Read-only parameters menu 2.5.1 Inputs Level 1 access Supply air --.-°c Supply air temperature value Return --.-°c Return air temperature value Fresh --.-°c Fresh air temperature value Room --.-°c Room air temperature value Outdoor --.-°c Outdoor temperature value Level 1 access Comfort flow rates Indicates flow rate type displayed (Comfort, Eco or auto) Supply air...

  • Page 36: Outputs

    2.5.2 Outputs Level 1 access Supply air fan ---% Supply air fan control value Return air fan ---% Return air fan control value Coil 1 Cooling ---% Water coil No.1 valve control value in "Cooling" mode (or Heating) Coil 2 Heating ---% Water coil No.2 valve control value in "Heating"...

  • Page 37: Setpoints

    2.5.3 Setpoints Level 1 access --.-°C Calculated regulation setpoint for the supply air temperature Calculated heat exchanger frost detector ----Pa Calculated setpoint for heat exchanger frost detection via return air pressure drop measurement Level 1 access Supply air Filter dirty ---Pa Calculated setpoint for detection of the supply air "Filter dirty"...

  • Page 38: Fault Memory Menu

    Fault memory menu H000 Level 1 access Alarm 00 :00 00/00/00 H000 Indicates the log number for the alarm 00/00/00 Indicates the date of the alarm 00:00 Indicates the time of the alarm Alarm Indicates the alarm "Prg" button Level 3 access Reset Reset Reset the alarm log...
  • Page 39 WARNING! ACTIVATION OF ALL OVERRIDES IS THE PROGRAMMER'S RESPONSIBILITY NONE OF THE SAFETY DEVICES IS OPERATIONAL The unit must be set to " ". Select the unit to be changed by pressing the button or the button. Confirm by pressing ENTER. The cursor places itself below the override authorisation (free or overridden).
  • Page 40 Fault relay Level 3 access free Danger….……………………. O Maintenance……………...….. O Bypass Level 3 access free opening.……………..……… O closing….…………..…… O State ………………….000.0% Electric heater Level 3 access free state 1…..……………..……… O state 2………………..…… O Mixing damper Level 3 access free opening.……………..……… O closing….…………..……...

  • Page 41: Time Prog Menu

    Time prog menu Level 1 access Day1 Day2 Day3 Day4 → → → Period 00:00 → 00:00 Period 00:00 → 00:00 Period 00:00 → 00:00 Period 00:00 → 00:00 State: State: State: State: --------------------- --------------------- --------------------- --------------------- Period 00:00 → 00:00 Start and end times (hour and minute) of daily time program period State: Selection of the state during this period:...
  • Page 42 Annual1 Annual2 Annual3 Annual4 → → → Period 00:00 → 00:00 Period 00:00 → 00:00 Period 00:00 → 00:00 Period 00:00 → 00:00 State: State: State: State: --------------------- --------------------- --------------------- --------------------- Date 00/00/2000 Date 00/00/2000 Date 00/00/2000 Date 00/00/2000 Period 00:00 → 00:00 Start and end times (hour and minute) of annual time program period State: Selection of the state during this period:...

  • Page 43: Communication Menu

    Communication menu SUPERVISION Level 1 access Protocol ----------- Choice of the communication protocol with the CMS (LON, MODBUS RTU, KNX, WEB, MODBUS TCP, BACNET IP) Speed ----- bds Selection of the speed of communication with the CMS (4800 mandatory for LonWorks) Address Address of the controller on the network for communication with the CMS (001 mandatory for Parity...

  • Page 44: 2.11 Access Level Menu

    2.11 Access level menu Access levels Current level: 1 Displays the current level Access level 1 -> Visible only if the current level = 2 or 3, used to access or return to level 1 Level 2 access Visible only if the current level = 1 or 3, used to access or return to level 2 Level 3 access Visible only if the current level = 1 or 2, used to access or return to level 3 Access levels...

  • Page 45: Versions Menu

    Access levels If access level 2 selected and access level = 1 LEVEL 3 ACCESS Password: 0000 Re-enter the manufacturer password The level 2 password can be reset to the factory value. To do this, go to level 2 access and press the "Prg" button for 10 seconds.

  • Page 46: Managing A Network Of Controllers

    Managing a network of controllers The pLAN network (personal Local Area Network) is the name of the physical network that links controllers to remote HMI terminals. The connection of the controllers via the pLAN network allows the datapoints of one controller to be exchanged for another, following the logic set out by the program, i.e.

  • Page 47: Addressing The Plan

    Addressing the pLAN Once the controllers are connected over the pLAN network, the controllers and the terminals must be addressed. There is a range of 32 possible addresses (binary logic). As a result, a total of 32 controllers and terminals can be connected over the pLAN network.

  • Page 48: Assigning Private And Shared Terminals

    If the "setting" field is set to '0', the terminal will use the Point-to-Point Protocol (not the pLAN) to communicate with the controller and the "I/O board address: 07" field will disappear as it will not be necessary. 3.3.2 Assigning private and shared terminals Follow the procedure below if, at this point, it is necessary to change the list of terminals associated with each controller: •...

  • Page 49: Replacing The Lithium Battery

    Replacing the lithium battery The lithium battery must be replaced by the customer when the notification alarm appears, approximately 10 years after the unit is commissioned on site. Once the replacement has been carried out, do not forget to reset the battery check (screen tp1) Supervision The controller may be connected to a local or remote supervision PC or to most types of CMS (Modbus, Lonworks, KNX).

  • Page 50: Modbus

    ModBus 5.3.1 Modbus RTU connection diagram 5.3.2 RS485 connection close-up Description RX+/TX+ RX-/TX- The components required for connection to the remote and/or local ModBus supervision system are as follows: An asynchronous half duplex RS485 serial card in RTU mode, connected to each controller. A standard RS485/USB converter for connection to a PC (not supplied by the manufacturer).

  • Page 51: Modbus Tcp Connection

    8: Read diagnostics counters 11: Read event counter 15: Write n bits 16: Write multiple registers (16 bits) NB: The JBus addresses are equal to the "Modbus address" - 1 5.3.3 Modbus TCP connection The Modbus TCP protocol connection requires a communication card to be connected and configured as shown below. PC local IP address: 172.16.0.2 Subnet mask: 255.255.0.0 pCOWeb card IP address: 172.16.0.1...

  • Page 52: Variables

    Enter the address http://172.16.0.1 in a web browser Click “Go to Administrator Area” User name: admin Password: fadmin Click Configuration then pCO Com. In Protocol: Modbus Extended OR BACNET IP Baud rate: 19200 Then the button: Submit The speed (baud rate) must be identical in the communication menu 5.3.4 Variables Table available upon request.

  • Page 53: Lon

    The communication card is supplied preloaded. The information data is retrieved via the CMS using a shunt on the Pin Service on the front panel of the expansion board. Connector for the controller Disconnectable terminal for connection of the LonWorks® network (GND, A, B) Pin service Green service LED: state of the node, lit during the pin service, flashing when the board...

  • Page 54: The Analogue Datapoints

    Type Index NV name Direction Description code type bit 3 Supply air filter dirty alarm bit 4 Heat exchanger frost alarm - Clogging detection bit 5 Heat exchanger frost alarm - Fresh air temperature check bit 6 Fire alarm bit 7 Return air motor alarm bit 8 Supply air motor alarm...

  • Page 55: Knx

    Type Index NV name Direction Description code type Value 5 switched off by CMS Value 6 post ventilation input nvi_T_regul SNVT_temp_p Regulated temperature setpoint output nvo_T_regul SNVT_temp_p Regulated temperature setpoint feedback input nvi_P_regul SNVT_press_p Supply air duct pressure via a communicating sensor output nvo_P_regul SNVT_press_p...

  • Page 56: Configuration Process

    5.5.2 Configuration process The manufacturer does not provide a system start-up, configuration, parameter setting or KNX network addressing service. The configuration of this type of network requires the creation of an ETS database. This database may only be used and managed by personnel trained in the use of KNX configuration tools and their associated specifications.
  • Page 57 KSet software To allocate the group addresses OFFline, install and open the KSet software. In the File menu, open the xml file provided, which contains the database below. Description DatapointName Supply air filter fouling level FiltreIntroduction DPT_Value_Temp 9.001 9.001 Supply air duct pressure PressionGaineIntro DPT_Value_Temp 9.001...
  • Page 58 Description DatapointName Bit 4 = Sensor B5 Bit 5 = Sensor B6 Bit 6 = IAQ sensor Bit 7 = Sensor B8 Bit 8 = Sensor B9 Bit 9 = Hydraulic coil 1 pump Bit 10 = Hydraulic coil 2 pump Unit On/Off command via CMS OnoffGTC DPT_Switch...
  • Page 59 The plugin Declaring the air handling unit controller in the ETS project requires the use of a plug-in: AHU_plugin_21 for ETS3 AHU_plugin_30 for ETS4 AHU_plugin_ETS5 for ETS5 This plugin is used to allocate the individual addresses for the controllers and to download the table created by KSet, which is the XML file.
  • Page 60 Reopen ETS5 and open the "AHU_plugin_ETS5" project. Copy and paste the plugin model for each device to be included in your project. The address of each device is automatically incremented. If necessary, you can manually change the address of a device in Properties. Assigning the physical address The physical address of the KNX board is assigned using the standard ETS procedure.
  • Page 61 Downloading the XML file You must ensure that: The Bus wire network is drawn out and connected The Bus is powered on The KNX board is connected to the network The controller is powered on On ETS5, use the mouse to select the controller which needs to be configured, select the "Parameter" tab and click "Open the dialogue box for parameters specific to the product".
  • Page 62 NOTE: This procedure is specific to the KNX board and is the only configuration operation permitted by the ETS5 program, other than allocation of the address. The KNX datapoints loaded via this plug-in do not appear in the Group Objects tab. To check and/or modify your group addresses, you need to re-open your xml file from KSet and, once the modifications are complete, upload it via the ETS plugin.

  • Page 63: Table Of Alarms

    Table of alarms All possible options are covered by this table. Alarm Source Causes Solutions Supply air filter fouling - Filter too dirty - Replace filter pressure sensor Supply air filter 0-1000 Pa clogged Supply air filter - Filter fouled - Clean or replace filter dirty Fresh air temperature...

  • Page 64: Control Curves

    Control curves Filter and heat exchanger fouling check Fig. 12 -3 Pa -3 Pa +3 Pa +3 Pa Filter dirty Filter blocked P > "Filter dirty": Clogged filter, maintenance alarm P > "Filter blocked": Filter blocked, system shut off alarm The Filter dirty and Filter blocked setpoints are calculated automatically (screen w4) by the controller according to the unit size and type, the type of filters and the instantaneous flow rates.
