DIGITAL-LOGIC MICROSPACE MSE-P5IP Technical User's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
TECHNICAL USER'S MANUAL FOR:
IPCI - EuroCard - Pentium
MSE-P5IP
#160299-1
Nordstrasse 11/F, CH-4542 Luterbach
Tel.: ++41 (0)32 681 53 33 - Fax: ++41 (0)32 681 53 31

Advertisement

loading
Need help?

Need help?

Do you have a question about the MICROSPACE MSE-P5IP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DIGITAL-LOGIC MICROSPACE MSE-P5IP

Summary of Contents for DIGITAL-LOGIC MICROSPACE MSE-P5IP

  • Page 1 TECHNICAL USER'S MANUAL FOR: IPCI - EuroCard - Pentium MSE-P5IP #160299-1 Nordstrasse 11/F, CH-4542 Luterbach Tel.: ++41 (0)32 681 53 33 - Fax: ++41 (0)32 681 53 31...

  • Page 2: Revision History

    02.99 JM BIOS history & Y2k description Product Registration: Please register your product at: http://www.digitallogic.ch -> SUPPORT -> Product Registration After registration, you will receive driver & software updates, errata information, customer information and news from DIGITAL-LOGIC AG products automatically.

  • Page 3: Table Of Contents

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 Table of Contents PREFACE .......................... 5 How to use this Manual....................5 Trademarks........................5 Disclaimer ........................5 Who should use this Product..................5 Recycling Information ....................6 Technical Support .......................6 Limited Warranty......................6 OVERVIEW ........................7 Standard features......................7 Unique features......................7 Block Diagram......................8 MSE586 Specifications....................9...
  • Page 4 DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 Memory........................29 4.7.1 System Memory Map....................29 4.7.2 System I/O map ....................... 29 4.7.3 BIOS-Variable-Segment ................... 30 VGA, LCD ........................31 4.8.1 VGA / LCD Controller 65548 ..................31 4.8.1.1 Display Interface....................31 4.8.1.2 Flatpanel Displays....................31 4.8.2...

  • Page 5: Preface

    The specifications given in this manual were correct at the time of printing; advances mean that some may have changed in the meantime. If errors are found, please notify DIGITAL-LOGIC AG at the address shown on the title page of this document, and we will correct them as soon as possible.

  • Page 6: Recycling Information

    DIGITAL-LOGIC AG, Switzerland. This warranty is limited to the original purchaser of the product and is not transferable. During the one year warranty period, DIGITAL-LOGIC AG will repair or replace, at its discretion, any defective products or parts at no additional charge, provided that the product is returned, shipping prepaid, to DIGITAL-LOGIC AG.

  • Page 7: Overview

    VGA/LCD video interface IPCI PCI-Bus PS/2 mouse Interface 2.2 Unique features The MICROSPACE MSE586 includes all standard PC/AT functions plus unique DIGITAL-LOGIC AG enhancements, such as: LCD interface up to 24Bit TFT with hardware accelerator Low power, 15 watt (100Mhz)

  • Page 8: Block Diagram

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 2.3 Block Diagram The real ALL-IN-ONE Industrial PENTIUM powered PC: Keyboard DRAM Chips Set Pentium PS/2 Mouse Green PC 100MHz 1 - 64 MBytes Triton FX 133MHz 72 pins SIMM RTC / CMOS 166MHz 200MHz...

  • Page 9: Mse586 Specifications

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 2.4 MSE586 Specifications CPU: CPU 64 Bit: INTEL Pentium P5 Mode: Real / Protected Compatibility: 8086 - 80586 Word Size: 64 Bits Physical addressing: 32 lines Virtual addressing: 16 GBytes Clock Rates: 100 / 133 / 166 / 200 MHz...
  • Page 10 DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 Mass Storage: Floppy disk interface, for max. 2 floppies, 26 and 34 pins connector E-IDE interface, for max. 2 harddisks, 44pins connector 2mm Sockets SSD: 1st socket for SSD: none Standard AT Interfaces Serial: Name...

  • Page 11: Ordering Codes

    10 G Temperature: Operating: Standard version: 0°C - 50°C Extended version: ask DIGITAL-LOGIC AG -55°C to +85 °C Storage: EMV / EMC (IEC1131-2 refer MIL 461/462): ESD Electro Static Discharge: IEC 801-2, EN55101-2, VDE 0843/0847 Part 2 metallic protection needed...

  • Page 12: This Product Is "Year 2000 Capable

    2000 CAPABLE” means only that DIGITAL-LOGIC has verified that the product as a whole meet this definition when tested as a stand-alone product in a test lab, but dies not mean that DIGITAL-LOGIC has verified that the product is “YEAR 2000 CAPABLE” as used in your particular situation or configu- ration.

  • Page 13: The At96 And Pc/104 Bus Signals

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 AT96 PC/104 B IGNALS AEN, output Address Enable is used to degate the microprocessor and other devices from the I/O channel to allow DMA transfers to take place. low = CPU Cycle , high = DMA Cycle...
  • Page 14 DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 IRQ[ 3 - 7, 9 - 12, 14, 15], input These signals are used to tell the microprocessor that an I/O device needs attention. An interrupt re- quest is generated when an IRQ line is raised from low to high. The line must be held high until the microprocessor acknowledges the interrupt request.
  • Page 15 DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 /SBHE, input/output Bus High Enable (system) indicates a transfer of data on the upper byte of the data bus, XD8 through XD15. Sixteen-Bit devices use /SBHE to condition data-bus buffers tied to XD8 through XD15.

  • Page 16: Expansion Bus

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 Expansion Bus The Bus currents are: Output-Signals: IOH: IOL: D0 - D16 24mA 24mA A0 - A23: 24mA 24mA MR, MW, IOR, IOW, RES, ALE, AEN, C14 24mA 24mA DACKx, DRQx, INTx, PSx, OPW 24mA...

  • Page 17: Ipci Bus: Pci Signals

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 3.2 IPCI Bus: PCI Signals Expansion connector 64 Bit PCI Bus not supported 1 +3,3V REQ64# ACK64# 2 AD2 3 AD6 C/BE0# 4 GND +3,3V M66EN 5 AD10 +3,3V AD11 AD12 6 AD13 AD14 AD15...

  • Page 18: Ipci Bus: Isa-Uni Bus

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 3.3 IPCI BUS: ISA-UNI Bus Expansion Connector 64 Bit PCI Bus Base Connector 32 Bit PCI Bus RSTDRV SD15 SD14 IRQ9 SD13 SD12 SD11 SD10 SBHE# IOCHRDY SMEMW# SMEMR# SA19 IOW# SA18 IOR# SA17 SA16...

  • Page 19: Detailed System Description

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 ETAILED YSTEM ESCRIPTION This systems has a system configuration based on the ISA architecture. Check the I/O and the Mem- ory map in this chapter. 4.1 Power Requirements The power is connected through the AT96 Bus connector; or the PC/104 Power connector; or the separate power connector on the board.

  • Page 20: Interface

    COM2; it is supported as the 'COM2' device. However, it is possible to disable either or both serial ports using the DIGITAL-LOGIC AG BMP utility. (Note: if you disable the primary port and enable the secondary port, then the secondary port is installed as COM1 by DOS.)

  • Page 21: Floppy Disk Interface

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 Serial Port Connectors COM1, COM2 Signal Function in/out DB25 Pin DB9 Pin Name Data Carrier Detect Data Set Ready Receive Data Request to Send Transmit Data Clear to Send Data Terminal Ready Ring Indicator Signal Ground The serial port signals are compatible with the RS232C specifications.

  • Page 22: Speaker Interface

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 Floppy Disk Interface Connector FD34: FD26: Signal Name Function in/out -RPM/-RWC Speed/Precomp (option) (Not used) (Not used) -IDX Index Pulse -MO1 Motor On 1 -DS2 Drive Select 2 -DS1 Drive Select 1 -M02 Motor On 2...

  • Page 23: Controllers

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 4.4 Controllers 4.4.1 Interrupt Controllers An 8259A compatible interrupt controller, within the CS4021 device, provides seven prioritized inter- rupt levels. Of these, several are normally associated with the board's onboard device interfaces and controllers, and several are available on the AT expansion bus.

  • Page 24: Real Time Clock (Rtc)

    800 ms. If no strobe occures within the 800 ms, the watchdog resets the system. To program the watchdog in user application DIGITAL-LOGIC AG has implemented a special BIOS extension in interrupt 60h (function: EBh).

  • Page 25: Bios

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 4.6 BIOS 4.6.1 BIOS Memory Devices 4.6.1.1 FLASH/ROM-BIOS Sockets An EPROM socket with 8 Bit wide data access normally contains the board's AT compatible ROM- BIOS. The socket takes any of a 27C010 to 27C040 EPROM (or equivalent) device. The board's wait- state control logic automatically inserts four memory wait states in all CPU accesses to this socket.

  • Page 26: Bios Cmos Setup

    On the next Setup pages (switched with PgDn and PgUp) the values for special parameters are modi- fiable. Normally the parameters are set correctly by DIGITAL-LOGIC AG. Be very careful with modify- ing any parameter since the system could crash. Some parameters are dependent on the type of CPU.

  • Page 27: Cmos Setup Harddisk

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 4.6.3 CMOS Setup Harddisk Harddisk parameter selection: Since the BIOS autodetects the harddisk type, no HD-drive parameter table is needed. Refer to the BIOS-HD-Setup and select autodetect. The parameters are read out of the harddisk and stored into the CMOS memory.

  • Page 28: Eeprom Saved Cmos Setup

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 4.6.5 EEPROM saved CMOS Setup The EEPROM has different functions, as listed below: • Backup of the CMOS-Setup values. • Storing the keymatrix definitions, if the hardware supports a keymatrix (MSM386SV, MSM386SN, MSM486SV). • Storing system informations like: version, production date, customisation of the board, CPU type.

  • Page 29: Memory

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 • 4.7 Memory 4.7.1 System Memory Map The Pentium CPU used as central processing unit on the MICROSPACE has a memory address space which is defined by 32 address bits. Therefore, it can address 1GByte of memory. The memory...

  • Page 30: Bios-Variable-Segment

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 4.7.3 BIOS-Variable-Segment Every PC contains a memory segment which is reserved for BIOS-variables. The segment starts at the address of 0040:0000h and ends at the address of 0040:0100h. In the offset of 0A1h to 0FFh is an area reserved which is used in multiple BIOS-extensions and programs.

  • Page 31: Vga, Lcd

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 4.8 VGA, LCD 4.8.1 VGA / LCD Controller 65548 The 65548A High Performance VGA Flatpanel / CRT controllers provide a powerful, yet versatile, set of optimized features for portable PC requirements. The 65548, which integrates the VGA controller, industry standard RAMDAC, and monitor sense circuitry, enables a complete VGA sub-system to be implemented with just two chips: CHIPS 65548 VGA controller and one memory device.

  • Page 32: Vga Bios Selection With The Multibios Feature

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 4.8.2 VGA BIOS Selection with the MultiBIOS Feature Multi-BIOS Panel Support The BIOS Device integrates 4 LCD-BIOS. With the jumpers, the corresponding BIOS may be selected. For jumper setting refer to JUMPER LOCATION ON THE BOARD.

  • Page 33: Supported Vga Modes

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 4.8.5 Supported VGA Modes Mode: Type: Colors: CRT: Text: Graphic: DRAM: Monitor: Refresh/HR: Text 40 x 25 320 x 200 256k 70 Hz Text 80 x 25 640 x 200 256k 70 Hz Graphic 40 x 25...

  • Page 34: Simultaneous Display

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 4.8.6.1 Simultaneous Display CRT: Flatpanel type: Needed modifications: Mono Single Drive STN LCD none Mono Dual Drive STN LCD none Mono Single Drive TFT LCD none Color Single Drive STN LCD none Color Single Drive TFT LCD none 4.8.7 VGA CRT/LCD Display Driver...

  • Page 35: Vga Driver Resolutions And File Names

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 4.8.7.1 VGA Driver Resolutions and File Names Actual driver version is: 3.2 Date: 3.96 Application: Resolution: Colors: 65535/65540: Acce.: 65545/48 Windows 3.1 640 x 480 LINEAR4.DRV VIDGX4.DRV 800 x 600 LINEAR4.DRV VIDGX4.DRV 1024 x 768 LINEAR4.DRV...

  • Page 36: Description Of The Connectors

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 ESCRIPTION OF THE ONNECTORS 44pin IDE is: IDT Terminal for Dual Row (2.00mm grid) and 1.00mm flat cable All others are: IDT Terminal for Dual Row 0.1" (2.54mm grid) and 1.27mm flat cable Power Supply Use both connectors parallel.
  • Page 37 DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 Utility connector Function: Pin 1 PS/2 Mouse Data Pin 2 PS/2 Mouse Clock Pin 3 Keyboard Data (controller side) Pin 4 Keyboard Clock (controller side) Pin 5 Keyboard Clock (connector) Pin 6 Keyboard Data (connector)
  • Page 38 DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 Floppy disk interface for 5,25" and 3,5" FD (34 pins header) Signal Signal Pin 1, = GND Pin 2 = RPM Pin 3 = GND Pin 4 = NC Pin 5 = GND Pin 6...
  • Page 39 DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 Printerport (LPT1) The printer connector provides an interface for 8 Bit centronics printers. Header onboard: D-SUB connector Signal on the cable: Pin 1 Pin 1 = Strobe Pin 3 Pin 2 = Data 0 Pin 5...
  • Page 40 DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 VGA-LCD connector Signal Function Pin 1 M-Clock Pin 2 Frame Pin 3 M-Clock2 / Display enable Pin 4 Line pulse Pin 5 Pin 6 Pin 7 ENAVDD Logic signal for a P-FET to switch 5V supply...
  • Page 41 DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 J43 / J44 PC/104 BUS Interface Connector J 16 Ground Ground IOCHCK Ground SBHE MEMCS16 RESET LA23 IOCS16 LA22 IRQ10 IRQ9 LA21 IRQ11 LA20 IRQ12 DRQ2 LA19 IRQ13 (-12V) LA18 IRQ14 LA17 DACK0 +12V MEMR...

  • Page 42: Connector Locations

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 5.1 Connector Locations...

  • Page 43: Jumper Locations

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 UMPER OCATIONS The figure shows the location of all jumper blocks on the MSE586 board. The numbers shown in this figure are silk screened on the board so that the pins can easily be located. This chapter refers to the individual pins for these jumpers.

  • Page 44: Jumper Locations Front Side

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 6.1.1 Jumper Locations front side...

  • Page 45: Jumper Locations Rear Side

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 6.1.2 Jumper Locations rear side...

  • Page 46: Cable Interface

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 ABLE NTERFACE 7.1 The Floppy Disk Cable IDT Terminal for Dual Row 0.1" (2.54 mm grid) and 1.27 mm flat cable. Use only 34pin connectors without polarisation nozzle. Floppydisk Cable 34pin MicroSpace DRIVE B: DRIVE A: max.

  • Page 47: The Harddisk Cable 44 Pins

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 7.2 The Harddisk Cable 44 pins IDT Terminal for Dual Row (2.00 mm grid) and 1.00 mm flat cable. 44 pins = 40 pins signal and 4 pins power. Use only connectors without polarisation nozzle.

  • Page 48: The Com 1/2 Serial Interface Cable

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 7.3 The COM 1/2 Serial Interface Cable DT terminal for dual row 0.1" (2.54 mm grid) and 1.27 mm flat cable. Use only connectors without po- larisation nozzle. Line of pin 1 COM1 9pin D-Sub...

  • Page 49: The Printer Interface Cable

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 7.4 The Printer Interface Cable IDT terminal for dual row 0.1" (2.54mm grid) and 1.27 mm flat cable. Use only connectors without po- larisation nozzle. This connector is shared with the utility conector J42. Use a 40pin connector at the place of a separate 26pin and a 14pin connector.

  • Page 50: The Keymatrix Cable

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 7.5 The Keymatrix Cable To support a simultaneous operating membrane keyboard, you may use the DIGITAL-LOGIC keyma- trix controller with this product. The following cables are needed to support the keymatrix option: Overview: PC-Board PS/2...

  • Page 51: The Lcd Interface Cable

    7.6 The LCD Interface Cable To support a LCD with this product, consult the LCD datasheet and the Flatpanel Support Manual from DIGITAL-LOGIC AG. This section describes only the special issue, if you are interfacing an LCD to this product.

  • Page 52: Software

    V1.x and V2.x IBM: OS/2 V2.0 Application Programs: All software DIGITAL-LOGIC AG has tested so far are compatible and run without any problem. 8.2 Software Tools and Drivers for the MICROSPACE PC The tool disk is divided into the following subdirectories: MSE586-TOOLS ROMDISK ROMDISK.EXE...

  • Page 53: Hd Harddisk Driver

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 8.3 HD Harddisk Driver This driver is installed as TSR and controls the power saving features of the harddisk. After a specified time, the driver sends an E0h command to the harddisk, to stop the spindle motor and the control electronics.

  • Page 54: Special Peripherals, Configuration,Function

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 PECIAL ERIPHERALS ONFIGURATION UNCTION 9.1 Special Peripherals 9.1.1 Multifunction Latch The multifunction latch allows control over several functions such as powerdown, contrast and watch- dog. This latch can be controlled by the application program. The multifunction latch allows control of several function as powerdown, SSD and watchdog. This latch can be controlled with the application program.

  • Page 55: The Special Function Interface (Sfi)

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 9.2 The Special Function Interface (SFI) All functions are performed by starting the SW-interrupt 15hex with the following arguments: 9.2.1 INT 15h SFI Functions Function: WRITE TO EEPROM Number: Description: Writes the Data byte into the addressed User-Memory-Cell from the serial EEPROM.
  • Page 56 DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 Function: READ SERIALNUMBER Number: Description: Reads the serialnumber from the board into the serial EEPROM. Input Values: AH = E3h Function Request Output Values: DX,CX,BX Serialnumber (Binary, not Ascii) Function: WRITE PRODUCTION DATE & RESET DLAG-COUNTERS...
  • Page 57 DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 Function: TRANSFER KEYMATRIX TO EEPROM Number: Description: Transfers the Keymatrix table from the Keyboard controller to the serial EEPROM. Input Values: AH = E7h Function Request Output Values: None, all registers are preserved. Function: WRITE INFO2 TO THE EEPROM...
  • Page 58 DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 Function: READ INFO3 FROM THE EEPROM Number: Description: Reads the information bytes out of the serial EEPROM. Input Values: AH = EAh Function Request Output Values: counter of BOOTERRORS counter of SETUP ENTRIES counter of LOW BATTERY ERROR...
  • Page 59 DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 Function: SET POWERSAVE Number: Description: Sets Powersave options. Input Values: AH = EDh Function Request AL 00 => LCD Powersave Bit 2 LCD-VDD on/off Bit 1 LCD-VEE on/off Bit 0 LCD-Backl. on/off 01 => HD0 Powersave The drive will immediately go to standby mode.
  • Page 60 DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 Function: LED SWITCH-STATUS Number: Description: Sets LED and reads Switches. Input Values: AH = EEh Function Request AL 01 Set LEDs only Reads Switches only Set LEDs and read Switches BL Only for Set LED mode used...

  • Page 61: Building A System

    Does the harddisk spindle motor start? Reset the CMOS-RAM: see A.3. C. If the error appears again: Contact your nearest DIGITAL-LOGIC AG dealer for technical support. Or contact our technical support by Fax (No. ++41 32 681 53 31). DIGITAL-LOGIC AG, Switzerland.

  • Page 62: Diagnostics

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 11 D IAGNOSTICS This is the checkpoint list o fthe AMIBIOS in order of execution. Uncompressed INIT code check-points NMI is Disabled. CPU ID saved. Init code Checksum verification starting. To do DMA init, Keyboard controller BAT test, start memory refresh and going to 4GB flat mode.
  • Page 63 DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 To prepare the descriptor tables. To enter in virtual mode for memory test. To enable interrupts for diagnostics mode. To initialize data to check memory wrap around at 0:0. Data initialized. Going to check for memory wrap around at 0:0 and finding the total system memory size.
  • Page 64 DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 APPENDIX The system BIOS gives control to the different BUSes at following check-points to do various tasks on the different BUSes. CHECK-POINT DESCRIPTION OF THE CHECKPOINT Different BUSes init (system, static, output devices) to start if present.

  • Page 65: Index

    DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 12 I NDEX battery-backed clock............24 Keyboard PS/2 or AT compatible........20 BIOS CMOS setup ............26 keymatrix interface cable..........50 BIOS ROM ..............25 BIOS-Variable-Segment..........30 Block diagram..............8 Building a system............61 latch.................54 Bus currents..............16 LCD connector..............40 LCD interface cable ............51 LCD-BIOS 548..............32...
  • Page 66 DIGITAL-LOGIC AG MSE-P5IP Manual V1.31 TOOLS................52 VGA driver resolutions...........35 VGA Modes: ..............33 VGA software drivers.............34 VGA TOOLS..............52 VGA-LCD connector............40 Utility connector............37 Watchdog................24 VGA BIOS ROM............25 Windows.................35 VGA BIOS Selection............32 VGA Controller Chips...........32...
