- Page 1 INSTALLATION & MAINTENANCE MANUAL OP2 / OP21 / OP3...
-
Page 2: General Instructions
These instructions should be used to aid installation of the following product: OP2 / OP21 / OP3 SAFETY • This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671) and current Building Regulations. -
Page 3: Installation
These instructions should be used to aid installation of the following product: INSTALLATION OP2 / OP21 / OP3 SAFETY Note: the unit should be fixed to a rigid flat surface as unevenness could cause damage to •... - Page 4 • The backbox has drain hole drilling guides marked (see Fig. 2). Drilling a drain hole is advised if • The backbox has drain hole drilling guides marked (see Fig. 2). Drilling a drain hole is the unit is installed in a location subject to temperature fluctuations where a build-up of advised if the unit is installed in a location subject to temperature fluctuations where a condensation may occur.
- Page 5 Feed the mains cable into the unit and secure the base plate to the surface. The fixing holes are slotted to allow some rotational adjustment Replace the gasket onto the backbox, then wire as shown below in Fig. 3 (1-way operation) or Fig. 4 (2-way operation) ensuring that correct polarity is observed: L - Live (brown), E - Earth (1-way operation) or Fig.
- Page 6 Fig. 4 • An earth connection must be made to the earth terminal of the socket. Use green/yellow sleeving • Ensuring the gasket does not become damaged or pinched, fit the socket assembly onto on earth conductors that are not insulated. The earth terminal in the backbox is provided for the backbox, taking care not to compress, damage or trap any cables, and secure with the convenience and does not need to be connected •...
-
Page 7: Power Mode
POWER MODE POWER MODE POWER MODE Connect the supply Neutral to the terminal block (see fig.6) Connect the supply Neutral to the terminal block (see fig.6) Connect the supply Neutral to the terminal block (see fig.6) Fig. 6 Note: when the switch is wired for two-way operation, the power indicator LED, must be Fig. - Page 8 Fig. 7 Note: when the switch is wired for two-way operation, the power indicator LED must be connected to the L2 terminal instead of the L1 terminal (see Fig 10) LOCATOR MODE LOCATOR MODE Connect the supply Neutral to the terminal block; disconnect the power indicator LED from Connect the supply Neutral to the terminal block;...
- Page 9 If this product should fail within its warranty period, it should be returned to the place of purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve the right to alter product specification without prior notice.
-
Page 10: Warranty
ML Accessories does not accept responsibility for any installation costs associated with the replacement product. Your statutory rights are not affected. ML... - Page 11 SUPPLIED BY: (UK) MANUFACTURER ML ACCESSORIES LTD, UNIT E CHILTERN PARK, BOSCOMBE ROAD, DUNSTABLE LU5 4LT, WWW.MLACCESSORIES.CO.UK (EU) AUTHORISED REPRESENTATIVE SLV LIGHTING GROUP, DAIMLERSTRASSE 21-23, 52531 ÜBACH-PALENBERG, GERMANY EMAIL: EPREL@GROUP.SLV.COM MADE IN CHINA 230V 50Hz JBOCT24_V1...
