- Page 1 Pure & Easy ASSEMBLY INSTRUCTIONS FTPLSS-4126 FTPLSS-4127 TZAB-V1...
- Page 2 NOTICE IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY WICHTIG, FÜR SPÄTERE NACHSCHLAGE AUFBEWAHREN: SORGFÄLTIG LESEN IMPORTANTE, GUARDAR PARA REFERENCIA FUTURA: LEER ATENTAMENTE IMPORTANTE, CONSERVARE PER RIFERIMENTI FUTURI: LEGGERE ATTENTAMENTE IMPORTANT, À CONSERVER POUR RÉFÉRENCE FUTURE : LIRE ATTENTIVEMENT Assemble on a flat and solid surface.To avoid the unstable surface affecting the overall frame stability during installation.
- Page 3 It is recommended that multiple people assemble this product. Es wird empfohlen, dass mehrere Personen dieses Produkt zusammenbauen. Il est recommandé que plusieurs personnes assemblent ce produit. Si raccomanda che più persone assemblino questo prodotto. Se recomienda que varias personas ensamblen este producto. Please contact us if parts of your furniture are missing.
- Page 4 PARTS Item no. Item no. Reference Image Reference Image Qty. Qty.
- Page 5 Item no. Item no. Reference Image Reference Image Qty. Qty.
- Page 6 Item no. Item no. Reference Image Reference Image Qty. Qty. X387...
- Page 7 Item no. Item no. Reference Image Reference Image Qty. Qty. X438 M4X10mm M5X16mm X129 M4X8mm X121...
- Page 8 EXPLODED VIEW...
- Page 10 ASSEMBLY 4pcs...
- Page 11 4pcs...
- Page 12 2pcs 2pcs 2pcs 8pcs...
- Page 13 4pcs 16pcs...
- Page 14 4pcs...
- Page 15 4pcs...
- Page 16 4pcs...
- Page 17 2pcs 2pcs 2pcs 2pcs 8pcs...
- Page 18 4pcs 8pcs NOTES: When assembling the beam: 1.Make sure parts (7B,7F, 8L, 8R) have the sides with closely spaced holes facing outward, and the sides with widely spaced holes facing upward. 2.Ensure parts (6L, 6R) have the sides with rectangular latch lock slot facing downward. Part 6L should be on the left side and part 6R on the right.
- Page 19 6pcs 6pcs 80pcs 10pcs 10pcs 90pcs When fixing the screws, leave the screws on both sides of the component unfastened. Wait until the adjacent component is installed, and then once the two components are overlapped, secure the screws. The installation steps are the same on the opposite side Fasten the screws according to the numerical order.
- Page 20 2pcs 5pcs 50pcs 6pcs 6pcs 56pcs When fixing the screws, leave the screws on both sides of the component unfastened. Wait until the adjacent component is installed, and then once the two components are overlapped, secure the screws. Fasten the screws according to the numerical order.
- Page 21 2pcs 10pcs 4pcs 4pcs 12pcs...
- Page 22 2pcs 4pcs 2pcs 2pcs 6pcs...
- Page 23 30pcs 5pcs 5pcs 31pcs Fasten the screws according to the numerical order.
- Page 24 2pcs 2pcs 2pcs 16pcs...
- Page 25 2pcs 2pcs 2pcs 2pcs 6pcs 6pcs...
- Page 26 20pcs...
- Page 27 2pcs 6pcs 4pcs...
- Page 28 4pcs 4pcs 4pcs 4pcs 40pcs 40pcs Fasten the screws according to the numerical order.
- Page 29 12pcs 12pcs 12pcs...
- Page 30 12pcs 76pcs 2pcs 78pcs 21-1 Fasten the screws according to the numerical order.
- Page 31 21-2 Pay attention to the placement of the fastening screws at the overlap joints when installing corrugated roofing.
- Page 32 4pcs 36pcs 36pcs Fasten the screws according to the numerical order. Pay attention to the placement of the fastening screws at the overlap joints when installing corrugated roofing.
- Page 33 4pcs 8pcs 8pcs Pay close attention to the positioning of the fixing screws at the joint connections.
- Page 34 4pcs 2pcs 6pcs 18pcs 12pcs The installation steps are the same on the opposite side 19L 19R 20L 20R 1.Align part F10 (joint) at the center position and secure it to the top panel using part S8 (screw). 2.Insert parts 19L and 20L into part F10 on both sides of the roof panel.
- Page 35 2pcs 6pcs 6pcs...
- Page 36 44pcs After fixing the screws, there will be some exposed screw parts on the component. Please use the provided plastic protective covers to protect the exposed screw parts, to avoid scratches during use.
- Page 37 2pcs 6pcs 6pcs 4pcs 1pcs Install part 16 to the side of part M1 (front side panel) with the longer distance from the center screw hole to the edge, and part 22 to the side with the shorter distance.
- Page 38 2pcs 8pcs 8pcs...
- Page 39 10pcs 4pcs 4pcs 2pcs 2pcs 4pcs...
- Page 40 2pcs 10pcs 4pcs 4pcs Install part 16 to the side of part M1 (front side panel) with the longer distance from the center screw hole to the edge, and part 23 to the side with the shorter distance.
- Page 41 2pcs 8pcs 8pcs...
- Page 42 4pcs 4pcs 4pcs 4pcs...
- Page 43 12pcs 12pcs...
- Page 44 4pcs To improve the wind resistance, please be sure to complete this installation step. If expansion bolts or ground stakes are not installed, strong winds may cause the tool shed to collapse. Expansion bolts are crucial for the stability on concrete surfaces, and ground stakes are used for grassy areas.
- Page 45 Installation Completed Installation Abgeschlossen Installation Complétée Installazione Completata Instalación Completada...
- Page 46 HELP CENTER Inquiry Assembly issue Missing parts If you encounter any difficulties during assembly, please contact us. Wenn Sie während der Montage auf Schwierigkeiten stoßen, kontaktieren Sie uns bitte. Si vous rencontrez des difficultés lors du montage, veuillez nous contacter. Se incontri difficoltà...
