Dynex DX-UA Quick Setup Manual

FCC Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation. Your power supply is listed to UL standards
and meets all applicable FCC standards.
Warning: Changes or modifications to this unit may cause interference and void
the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
1. Re-orient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Consult Dynex customer service at www.dynexproducts.com if the problem
still exists.
Cautions:
• The charger must attach to the power supply source with a built-in over-
current protective device (Max. 15A), such as a 15A fuse and branch circuit.
• Make sure the charger is disconnected from the AC outlet and device before
adjusting the voltage setting.
• Do not use the charger to power a device that exceeds the maximum
power rating.
Note: The charger's voltage must be the same as the voltage your portable
device requires. The charger's current (mA) must be equal to or greater than the
current your portable device requires.
90-day limited warranty
For complete warranty, visit www.dynexproducts.com.
© 2009 Dynex. DYNEX and the DYNEX logo are trademarks of Best Buy Enterprise Services, Inc. Other
brands and product names are trademarks or registered trademarks of their respective holders.
Specifications and features are subject to change without notice or obligation.

Device compatibility list

Brand Model #
AGFA ePHOTO CL-30/34/50/307/780/ 780C/1280/1680
CANON A10/20/30/40, ESD-1100
SD790
A590, A1000
SX10
CASIO QV-10A/11/70/100/120/200/300/700/770/780/2000UX/2300UX
QV-2400UX/2800UX/2900UX/3000EX/3000Plus/3500EX/4000E,
QV-5000SX/5500SX/7000SX/8000SX
EPSON PC 550/600/650/700/750Z/800Z/850Z/2100Z/3000Z/3100Z
FUJIFILM Finepix 50i/1300/1400Z/2300/2400Z/2700Z/2800Z/2900/3800/4800Z,
4900Z/6800Z/6900Z/DX-10, F401/402/601, M603, MX-500/600Z/700/1200
MX-1300/1400Z/1500/1700/2700/2900Z, S1 Pro, S2 Pro, S-304/602/3100
A210/345/350/2650/S-5100
HP PhotoSmart 120, 315, 318, 320, 612, 620, 720, 850
JVC GZ-MS100, GZ-MG33, GRD-8500
KODAK DC40/50/120/200/200plus/210/210plus/215/220/240/240i/260/265/280
DC290/3200z/3400z/DC5000z
DC4800, LS443, DX7430/7440/7590/7630, M863, M1063, M1033, Z1015IS
Z-650/DX-6440/Z-740
KYOCERA Finecam S3/S3L/S4/S5
MINOLTA Dimage 5/7/7Hi/7i/3D/1500/EX1500/2300/2330z, E201.
RD3000, S304/S404
NIKON Coolpix 100/300/600/700/750/800/900/950/990/2000
CoolPix 775/880/885/995/4300/4500/5000/5700/8700
OLYMPUS C-100/120/200Z/211/300Z/320L/700UZ/720UZ/730UZ/960Z/990Z/2000Z
C-2020Z/2030/2040Z/2100Z/2500L/3000Z/3020Z/3040Z/4000Z/4040Z/5050Z
D-200L/220L/320L/340L/340R/360L/370L/400Z/450L/450Z/460Z/500L/550Z
D-600L/620L, E-10/20/20P/100 RS
C-1/1Z/2/40Z/220Z, D-40Z/100/150Z/230/395/540/580
C-50Z, Stylus 300/410
PANASONIC DMC-F7, SDR-57K
DMC-FZ1, VDR-D50, PV-GS90, DMC-LC5/LC40, PVDV - 102/203/402/53
PVL-352/452/453/672
SVAV-25/50A/50S/100, PVDV-103/953, HDC-SD9
PVGS-9/12/15
DMC-LZ3/DMC-LZ2pp
PENTAX Optio 330RS/430RS
PREMIER DC620/820/1310,/1311/1500/2000
PURE DIGITAL Flip Mino HD, Flip Mino, Flip Ultra, Flip Video
RICOH Caplio PR1/PR10/PR120, RDC-2/2E/7/300/300Z/1500/1700/4200
RDC-4300/5000/5300/6000,
SANYO VPC-MZ1/AZ1
SONY CD200/250/300/400/450/1000, F707/717, FD85/87/90/92/95/97/100
FD200, S50/70/75/85,. CCDTRV-118/128/318/460/608, DCRDVD-101/102
DCRHC-85, DCRTRV-260/460
SONY P1/2/3/5/9/20/30/31/50/51/71
Cybershot DSC P8, P10, P32, P52, P72, P92, V-1,
CCD-TRV138,CCD-TRV338, DCR-DVD Series,DCR-HC Series, DCR-IP Series,
DCR-PC Series,DCR-TRV Series, HDR-Series, HDR-CX7, HDR-UX Series,
HDR-HC Series,DCR-SR Series, HDR-SR10
ENGLISH 09-0318
TOSHIBA PDR-M1/M3/M4/M5/M11/M21/M25/M60/M61/M65/M70/M71/M81
Voltage Plug size
6.5V 4.0 x 1.7
4.2V 4.0 x 1.7
4.2V 4 x 1.75
3.3V 2.35 x .73
6.5V 2.35 x .75
DX-UA Universal Camera/Camcorder AC Charger
6.5V 4.0 x 1.7
6.5V 4.75 x 1.75
Congratulations on your purchase of the DX-UA Dynex Universal
Camera/Camcorder AC Charger. The charger can power digital
5.0V 4.0 x 1.7
3.3V 2.35 x .75
cameras, camcorders, and other portable electronic devices that
6.5V 4.0 x 1.7
require 3.3V, 4.2V, 5.0V, 6.5V, 8.4V, or 11.0V DC power. It is fully
11.0V JVC AP-V
regulated using high efficiency switching technology and features
6.5V 4.75 x 1.75
overload and short circuit protection. The charger comes with
5.0V 4.0 x 1.7
3.3V 2.35 x .75
connectors to fit different digital cameras, camcorders, and other
5.0V 4.0 x 1.7
electronic devices. Additional connectors are available from Dynex
6.5V 4.75 x 1.75
by contacting customer service.
6.5V 4.75 x 1.75
8.4V 4.75 x 1.75
6.5V 4.75 x 1.75
3.3V 4.0 x 1.7
4.2V 4.0 x 1.7
5.0V 4.0 x 1.7
8.4V 4.75 x 1.75
3.3V
4.2V
6.5V 4.0 x 1.7
5.0V
6.5V
8.4V
8.4V 4.0 x 1.7
9.5V
11V
8.4V 4.75 x 1.75
3.3V 2.35 x .75
4.2V 4.0 x 1.7
6.5V 4.75 x 1.75
5.0V USB
5.0V 4.0 x 1.7
3.3V 4.0 x 1.7
8.4V Sony L/M
4.2V Sony S/C
4.2V Sony F/C
QUICK SETUP GUIDE
8.4V Sony A/P/F
5.0V 4.0 x 1.7
