Johnson Controls YP9C Series Installation Manual page 42

Gas Side
Gas Type
Natural Gas
LP Gas Conversion Kit Part # Used
Inlet Gas Pressure (in. w.c.")
Calculated input in btuh - clock the gas meter (Nat Gas Only)
Burner flame inspected -- flames are blue and extending directly into the primary heat exchanger cells
Air Side: System External Static Pressure (Cooling Mode)
Supply static before evaporator coil (in w.c.")
Return Static (in w.c.") before filter
Total External Static Pressure
Air Side: Heating
ATR Setting
Temperature Rise in Degrees F
Air Side: Cooling
COOL Speed Selected
ADJUST Setting (ECM Models)
DELAY Setting (ECM Models)
Air Side: Continuous Fan
Blower Speed Selected
Cycle Test
Operate the furnace through several heating cycles from the thermostat, noting and correcting any problems
Operate the furnace through continuous fan cycles from the thermostat, noting and correcting any problems
Operate the furnace through cooling cycles (as applicable), noting and correcting any problems
Clean Up
Installation debris disposed of and furnace area cleaned up?
Owner Education
Give owner the owner's manual provided
Explain operation of system to equipment owner
Explain the importance of regular filter replacement and equipment maintenance
Explain thermostat use and programming (if applicable) to owner
Additional Job Detail
