- Page 1 © 2025 All rights reserved TRIO Smart Antenna Switch Controller microHAM www.microham.com microHAM s.r.o. Maticna 28 92401 Galanta Slovakia v1.1 2025...
-
Page 2: Table Of Contents
© 2025 All rights reserved TABLE OF CONTENT 1 - DEVICE DESCRIPTION ........................ 3 2 - PANEL DESCRIPTION ......................... 4 Front Panel ..............................4 Rear Panel ..............................5 3 - SETUP ............................6 Cables connection............................6 Initial menu settings............................8 4.A - FRONT PANEL USER INTERFACE..................10... -
Page 3: Device Description
RF connections from the transceivers, amplifier, and antennas. In addition to six (6) RX/TX antennas and three (3) RX antennas, TRIO supports up to four (4) optional ARXC.REL boxes connected to TRIO via RS-485 using CAT5 cable over distances up to 1500 m or up to 5000 m using optional ARXC.LoRa modules. -
Page 4: Panel Description
© 2025 All rights reserved 2 - PANEL DESCRIPTION Front Panel RADIO [4] / ENT Radio selection: Radio 1, Radio 2, Display context selection or enter in Radio 3. menu navigation. A position allows automatic radio RX ANT & EXT CONTROL selection by related PTT input. -
Page 5: Rear Panel
Radio 2 CI-V port USB A port for firmware update 6. CI-V R3 19. SWITCH Radio 3 CI-V port RJ45 connection to the TRIO SWITCH 7. ALC R1 20. ARXC ALC output to Radio 1 External relay modules connection port 8. -
Page 6: Setup
PA PTT on TRIO (16) to the KEYIN jack on your PA as well as PA ALC jack on TRIO (15) to the ALC output on your amplifier if it is required by power amplifier manufacturer. Please refer to your power amplifier manual. - Page 7 Ground the controller case using the grounding stud (24) to the central ground point in your shack. At this point, you can power the TRIO on by rear power switch. Keep transceivers and the amplifier turned off and prepare basic menu settings.
-
Page 8: Initial Menu Settings
Power amplifier communication has to be set to Icom CI-V as TRIO looks for the amplifier as an Icom transceiver. Next menu M22 allows to set CI-V address of such simulated Icom transceiver. - Page 9 © 2025 All rights reserved M23: PA PTT TAIL Sets how long will TRIO keep amplifier keyed after the PTT from the radio is released. To avoid hot switching, it is good to keep at least default 30ms delay, as some transceivers drop PTT output prematurely while RF is still present on its antenna connector.
-
Page 10: A - Front Panel User Interface
© 2025 All rights reserved 4.A - FRONT PANEL USER INTERFACE TRIO can be operated either from the front panel, or from the browser on a computer or mobile device. This chapter describes the operation from the front panel. -
Page 11: Power Amplifier
Display, four buttons below the display and RX ANT & EXT CONTROL knob serve for multiple purposes set by a rotary knob. When the knob is set to S position, TRIO and display enter into the menu system. Buttons ← and → navigates through individual menu items. ENT button moves the cursor to the bottom line and allows to edit particular menu item parameter with ←... - Page 12 ARXC3, and ARXC4 modules respectively. All ARXC modules are connected in parallel to ARXC bus on TRIO, address (1, 2, 3, or 4) is set by dip-switch on the ARXC module. If selected template contains the BCD output, menu M34: ARXC1 DIR sets azimuth of zero position BCD output.
-
Page 13: Arxc.rel Addressing And Use
ARXC wiring In order to control the ARXC module, it must be connected to the TRIO. If the control cable between the TRIO and the ARXC module, or between the different ARXC modules for any reason cannot be installed, communication can be established by the RF link using pair of ARXC LoRa modules. -
Page 14: C - Web User Interface
M82: LAN STATUS has to show assigned IP address. Then you can enter “trio.local” in your browser or type in the IP address of the TRIO shown in the menu M82. Web UI provides all buttons available on the controller front panel, including RX antennas selection and ARXC controls, all visible on the dashboard. - Page 15 DHCP range of your router or reserved IP address, and you must have enabled the forwarding feature for the port 80 used by the TRIO to its local IP address in your home Internet router. Another option is to set up your own VPN and use the same web UI access as on local computer.
-
Page 16: Settings Menu
© 2025 All rights reserved 5 - SETTINGS MENU MENU of the TRIO controller allows to set individual parameters of complete controller behavior. There are no internal switches, jumpers or trimmers, all settings can be set in menus. Settings menu is invoked by turning the RXANT rotary switch to the utmost right S position. - Page 17 © 2025 All rights reserved M23: PA PTT TAIL 0-500ms, default 30ms. Sets un-key delay for power amplifier. M24: PA INH ENABLED, DISABLED. Sets if connected power amplifier supplies inhibit (KEYOUT) signal. M25: PA INH INV NORMAL, INVERTED. Sets polarity of inhibit signal from the power amplifier.
- Page 18 Prevents any output changes while radio is in TX state. M70: LINK ID DISABLED, 1-30. Sets unique TRIO LINK address. M80: USE PASSWORD YES, NO. Enables password protected access to web UI. M81: USE DHCP YES, NO. Enables TRIO IP address assignment by the DHCP server.
- Page 19 During update display is blank, various LEDS blink or lit, just wait until update finishes and TRIO boots to its main screen, it takes a while, up to one minute.
-
Page 20: Usb Firmware Update
4. Remove the USB FLASH drive from TRIO and continue operating. If the update process fails the BUSY, SPLIT and ONAIR leds will indicate the possible cause of failure: BUSY and SPLIT leds flash – trio.upd file not found in the root directory of USB FLASH • drive. -
Page 21: Hardware Specifications
Disconnected = grounded, configurable to open on switch PCB bottom side RX ANTENNA PORTS Disconnected = open RX RADIO PORTS Disconnected = open, connected port grounded on TX CONTROL Serial, RJ45 cable to TRIO Controller DIMENSIONS W: 275mm D: 190mm H: 65mm WEIGHT 1.7kg net... - Page 22 © 2025 All rights reserved Typical parameters, VNA screenshot @ switch configuration: Isolation between radio ports R1 and R2. RL at R1 port connected to A6 port, A6 loaded by 50ohm.
-
Page 23: Package Contents
SLOVAKIA 8 - WARRANTY microHAM warrants this product for two (2) years. The product must not be modified in any way or the warranty is voided. What is covered: During the warranty, microHAM, s.r.o., will repair or replace defective product at their sole discretion. -
Page 24: Declaration Of Conformity
We, microHAM s.r.o., Matičná 28, 92401 Galanta, Slovakia, declare under our sole responsibility for the equipment name TRIO (TRIO Controller + TRIO Switch), model TRIO, serial number 0001 and higher that the equipment is in conformity with the following relevant Union harmonization legislation directives:... -
Page 25: Appendix A - Trio Connectors
© 2025 All rights reserved APPENDIX A – TRIO CONNECTORS DB9 RADIO1, RADIO2, RADIO3 NAME TYPE DESCRIPTION INHIBIT OUTPUT open collector BAND DATA 3 INPUT BAND DATA 2 INPUT BAND DATA 1 INPUT BAND DATA 0 INPUT INPUT TTL, in parallel to R1/R2/R3 PTT... -
Page 26: Appendix B - Radio Cable Diagram
© 2025 All rights reserved APPENDIX B – RADIO CABLE DIAGRAM * all connectors orientation are shown from the soldering side... - Page 27 © 2025 All rights reserved...
- Page 28 © 2025 All rights reserved...
-
Page 29: Appendix C - Power Amplifier Cable Diagram
© 2025 All rights reserved APPENDIX C – POWER AMPLIFIER CABLE DIAGRAM * all connectors orientation are shown from the soldering side... - Page 30 © 2025 All rights reserved ICOM IC-PW1, IC-PW-2 can use DB9-IC-8 cable which is compatible also with these amplifiers.
