Summary of Contents for Stealth Products IC24PS-QL
- Page 1 Alternative Drive Controls ICPS-RN ICPS-QL ICPS-MK6i ICPS Power Source Owner’s Manual - Maintenance Guide ICPS 12V/24V Power Source...
-
Page 2: Table Of Contents
Table of Contents Customer Satisfaction ..............i Important Information............... ii-iii Warranty .......................ii Supplier Reference..................ii Warning Labels..................iii Limited Liability..................iii Testing ......................iii Design & Function ................1 Intended Use....................1 Installation Instructions .............. 2-4 ICPS-QL Power Source ................2 ICPS-RN Power Source................3 ICPS-MK6i Power Source .............. -
Page 3: Customer Satisfaction
For further assistance, or more advanced applications, please contact your supplier or Stealth Products at (512) 715-9995 or toll free at (800) 965-9229. Always keep the operating instructions in a safe place so they may be referenced as necessary. -
Page 4: Important Information
Warranty Our products are designed, manufactured, and produced to the highest of standards. If any defect in material or workmanship is found, Stealth Products will repair or replace the product at our discretion. Any implied warranty, including the implied warranties of merchantability and fitness for a particular purpose, shall not extend beyond the duration of this warranty. -
Page 5: Warning Labels
Stealth Products does not hold responsibility for final integration of final assembly of product to end user. Stealth Products is not liable for user death or injury. Testing Initial setup and driving should be done in an open area free of obstacles until the... -
Page 6: Design & Function
Design & Function Intended Use i-Connect provides the capability to use fiber optic or proximity sensors to perform mechanical switch functions for clients that have difficulty maintaining pressure or position on mechanical switches. Fiber Optic or Capacitive Proximity Sensors do not require physical contact to activate the switch circuit, and the sensitivity of each can be adjusted to fit the needs of the user. -
Page 7: Installation Instructions
Neatly route the 1/8" mono plug(s) to the input jack(s), and secure the cable(s) to the chair. Avoid loops that could snag the user or environment. Plug the 2-pin flat power connector of the IC24PS-QL Power Source cable into the 2- pin flat power connector on the Power Cable of the i-Connect Control Unit. Neatly route and secure the cable. -
Page 8: Icps-Rn Power Source
Installation Instructions IC24PS-RN Power Source Securely install the Control Unit in a location that is unlikely to sustain damage from impact during normal use. Install the sensor(s) in the desired location(s), neatly routing the cable(s) to the Control Unit. Avoid loops that could snag the user or environment. Neatly route the 1/8"... -
Page 9: Icps-Mk6I Power Source
Installation Instructions IC24PS-MK6i Power Source Securely install the Control Unit in a location that is unlikely to sustain damage from impact during normal use. Install the sensor(s) in the desired location(s), neatly routing the cable(s) to the Control Unit. Avoid loops that could become entangled with the user or environment. Neatly route the 1/8"... -
Page 10: Ic12A-B 12V Battery
Installation Instructions IC12A-B 12V Battery Securely install the Control Unit in a location that is unlikely to sustain damage from impact during normal use. Install the sensor(s) in the desired location(s), neatly routing the cable(s) to the Control Unit. Avoid loops that could snag the user or environment. Neatly route the 1/8"... -
Page 11: Ic12A-Bc Battery And Charger
Adjustment Instructions IC12A-BC 12V Battery & Charger Charge Level LEDs Charger On/Off Power/ Port Switch Charging Port The IC12A-B Battery has a combination power/charging port, a USB port, and an on/off switch. The Power/Charging port is used to power wheelchair devices that require 12V and to recharge the battery using the included battery charger. - Page 12 © 2024, Stealth Products, LLC Warranty Information Home Page Online User Manual Stealth Products, LLC · info@stealthproducts.com · www.stealthproducts.com (800) 965-9229 | (512) 715-9995 | 104 John Kelly Drive, Burnet, TX 78611 P91D21R4 ICPS Power Source.afpub Aug 24, 2020...
