KL-0880-20
Infrared Thermometer
GEDORE Automotive GmbH
Breslauer Straße 41
78166 - Donaueschingen
Postfach 1329
78154 Donaueschingen - GERMANY
+49 (0) 771 / 8 32 23-0
+49 (0) 771 / 8 32 23-90
info.gam@gedore.com
Worldwide GEDORE service centers and offices are listed on the Internet at: www.gedore.com
www.gedore-automotive.com
www.gedore-automotive.com
Operating instructions
EN
04/2024
KL-0880-20 (EN240209).indd
Advertisement
Table of Contents
Summary of Contents for Gedore KL-0880-20
- Page 1 78166 - Donaueschingen Postfach 1329 78154 Donaueschingen - GERMANY +49 (0) 771 / 8 32 23-0 www.gedore-automotive.com www.gedore-automotive.com 04/2024 +49 (0) 771 / 8 32 23-90 info.gam@gedore.com KL-0880-20 (EN240209).indd Worldwide GEDORE service centers and offices are listed on the Internet at: www.gedore.com...
-
Page 2: Address Of The Manufacturer
Instructions for use and safety are not binding. They never substitute for any legal or trade association regulations. We do not accept any liability for printing errors. Any reproduction, in whole or in part, requires the prior written consent of GEDORE Automotive GmbH. All rights reserved worldwide. -
Page 3: Table Of Contents
1.12 Duty to provide information pursuant to the Battery Act (BattG) ..................6 2. PRODUCT DESCRIPTION ....................................2.1 KL-0880-20 - Infrared thermometer ............................7 2.2 Scope of delivery .................................... 7 2.3 Specifications ....................................7 3. OPERATION - AND FUNCTION OVERVIEW ............................ -
Page 4: Read And Understand For Your Safety
GEDORE Automotive genuine spare parts and accessories! may only be used in the way described in these operating instructions! Any other use may result in SEVERE INJURY ! 1.4 Reasonably foreseeable misuse... -
Page 5: Labelling Of The Warnings
Always work with the infrared thermometer in accordance with the basic regulations on work safety, accident prevention and environmental protection! Always use the infrared thermometer as intended. GEDORE Automotive does not accept any liability or warranty or guarantee claims for injuries and damage resulting from improper use or disregard of the safety regulations. -
Page 6: Care / Storage
Batteries may contain harmful substances that can damage the environment or health if not stored or disposed of properly. Used batteries can be returned to established collection points, e.g. municipal collection points, retailers or to us at GEDORE Automotive GmbH. Used batteries may only be returned to collection points when discharged and with the battery terminals... -
Page 7: Product Description
Automatic switch-off: ....................................... 30 seconds Time to measurement result: ..................................0.5 seconds Power supply: ..............................2x 1.5V AAA batteries (not included) Weight: ......................................100g (without batteries) Dimensions (LxWxH): ....................................145x95x45 mm © Copyright by GEDORE Automotive GmbH, Germany KL-0880-20 (EN240209).indd... -
Page 8: Operation And Function Overview
Two 1.5V AAA batteries required, these are not included in the scope of delivery! Function buttons Further information see chapter 3.2 Automatic switch-off The infrared thermometer switches off automatically after 30 seconds when not in use. © Copyright by GEDORE Automotive GmbH, Germany KL-0880-20 (EN240209).indd... -
Page 9: Overview Of Display And Button Functions
• Low: For setting the lower temperature limit for the temperature warning light. ε =: For setting the material emissivity. Various setting values, see chapter 3.3. • • °C / °F: For changing the temperature unit to °Celsius or °Fahrenheit. © Copyright by GEDORE Automotive GmbH, Germany KL-0880-20 (EN240209).indd... -
Page 10: Overview Of Key Functions
Own values... Material Emissivity ε Lead, oxidised at 25°C Lead, oxidised, heated to 200°C Nickel... Material Emissivity ε Nickel, pure Nickel sheet, oxidised 0.4 – 0.5 Nichrome Nichrome, oxidised 0.95 10 - © Copyright by GEDORE Automotive GmbH, Germany KL-0880-20 (EN240209).indd... -
Page 11: Typical Application
Laser radiation can cause damage to the eyes. Therefore, never look directly into the laser beam of the infrared thermometer or point it at people or animals! Never point the laser beam at reflective surfaces as it may be reflected into the eyes! - 11 © Copyright by GEDORE Automotive GmbH, Germany KL-0880-20 (EN240209).indd... -
Page 12: Ec Declaration Of Conformity
EN IEC/IEEE 82079-1:2020 - Preparation of information for use (instructions for use) of products - Part 1: Principles and general requirements Authorised representative for compiling the technical documents: GEDORE Torque Ltd. / Tannery Ln, Gosden Common / Guildford GU5 0AJ, United Kingdom Donaueschingen, 11 April 2024 Patrick Mau, Managing Director of GEDORE Automotive GmbH 12 - ©...
