- Page 1 Agri Remote TL-ARM Instruction Manual...
-
Page 2: Specifications
INTRODUCTION The Nemtek Agri Remote can switch an energizer on and off along the electric fence by holding the remote against the fence wire. The Agri Remote also helps find faults on the fence by showing the direction and magnitude of the current flow. Note the current reading on the remote as you move along the fence. When the reading drops significantly, the fault is between the last two checkpoints. - Page 3 The arrow shows the or earth wire direction of the fence current. The display gives the voltage on the fence in Kilovolts and the current in Amperes 3. Press the function button to display the fence load resistance in Ohms. www.nemtek.com...
-
Page 4: Operation
Operation Holding the meter Grip the fence meter tightly in your hand, taking care not to grip too close to the electric fence wire, contact strip or LCD screen. For the best results and a more accurate reading use the black ground lead supplied and attach it to an earthed metal pole or earth wire. - Page 5 Mode Switching on the Remote Press the function button, and one long press of the ON/OFF buttons to send the remote commands down the fence to the energizer At power ON, the meter displays kV and A fields while it is in Voltage and Current Mode. The next mode displays fence loading in Ohms.
-
Page 6: Fault Finding
Fault Finding The resistance reading (Ohms) will be low when there is a short on the fence Following the direction of the current, take readings approximately every 50 - 100m or at junction points along your fence line. At a junction point, follow the wire with the highest resistance. Increasing proximity to a fault to earth is indicated by a decrease in resistance between adjacent checkpoints. -
Page 7: Short-Circuit Fault
Fault Finding The two most common faults in an electric fence installation are an open-circuit (wire break, poor connection etc.) fault or a short-circuit (insulator breakdown, vegetation, live and ground wire touching etc.) fault. In order to facilitate the fault-finding process, current and voltage measurements at regular points along the fence, when in a healthy condition, should be recorded for comparison when a fault occurs. - Page 8 Warnings 1. This product is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the product by a person responsible for their safety. 2.
-
Page 9: Limitation Of Warranty
WARRANTY Unless otherwise specified all Nemtek energizers have a 2 year warranty and all other fencing components have a 1 year warranty from date of sale against defects due to faulty workmanship or materials. Nemtek (Pty) Ltd will, at its discretion, either repair or replace a product that proves to be defective.
